Acura RDX 2009 Owner's Manual

µµ
µ
When you press the UNLOCK
button, the ceiling lights (if the f ront
and rear ceiling light switches are in
the door activated position) will
come on. If you do not open any door,
the lights stay on for about 30
seconds, then f ade out. If you relock
the doors with the remote
transmitter before 30 seconds have
elapsed, the lights go of f
immediately.
Press this button once to
lock all doors and the tailgate. Some
exterior lights will f lash. When you
push LOCK twice within 5 seconds,
you will hear a beep to verify that the
doors and tailgate are locked and the
security system has set. This button
does not work if any door or tailgate
is not f ully closed.
To change the ‘‘KEYLESS LOCK
ACKNOWLEDGEMENT’’ setting,
see page . Press this button once
to unlock the driver’s door. Push it
twice to unlock the other doors.
Some exterior lights will f lash twice
when you push the button. If you do
not open any door or the tailgate
within 30 seconds, they will
automatically relock.
To change the ‘‘DOOR LOCK
MODE’’ setting, see page .
To change the ‘‘SECURITY
RELOCK TIMER’’ setting, see page . To change the ‘‘INTERIOR LIGHT
DIMMING TIME’’ setting, see page
.
Pressthisbuttonfor
about 1 second to attract attention;
the horn will sound, and the exterior
lights will f lash f or about 30 seconds.
To cancel panic mode, press any
button on the remote transmitter, or
turn the ignition switch to the ON
(II) position.
105 103
10796
LOCK UNL OCK
PA NIC
Remote Transmitter
Inst rument s and Cont rols
127
UNLOCK
BUTTONLOCK
BUTTON
PANIC
BUTTON
\f—\f—

y


y
() \fy\f
y
2009 RDX

To replace the battery:Remove the screw at the base of
the transmitter with a small
Phillips-head screwdriver.
Separate the keypad from the
transmitter by pushing any button
f rom outside.
If it takes several pushes on the
button to lock or unlock the doors
and the tailgate, replace the battery
as soon as possible.
Battery type: CR1616
Avoid dropping or throwing the
transmitter.
Protect the transmitter from
extreme temperature.
Do not immerse the transmitter in
any liquid.
If you lose a transmitter, the
replacement needs to be
reprogrammed by your dealer.
1.
2.
Remote Transmitter
Replacing the Transmitter
Battery
Remote Transmitter Care
128
SCREW KEYPAD
\f—\f—

y

y
() \fy\f
y
2009 RDX

µ
As required by the FCC:This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.Remove the old battery and note
the polarity. Make sure the
polarity of the new battery is the
same ( side f acing up), then
insert it in the keypad.
An improperly disposed of battery
can hurt the environment.
Always conf irm local regulations
for battery disposal.
Snap the two halves of the keypad,
then install the parts in reverse
order.
Place a cloth on the edge of the
keypad, and remove the upper half
by caref ully prying on the edge
with a small f lat-tip screwdriver. 4.
5.
3.
Remote Transmitter
Inst rument s and Cont rols
129
BATTERY
\f—\f—

y


y
() \fy\f
y
2009 RDX

Here are the settings activated with
the remote;
When you unlock the driver’s door
with your remote, each remote
activates the keyless memory
settings related to that remote. The
driver’s ID (MEMORY 1 or
MEMORY 2) is shown on the back
of each remote. To turn of f this f eature, press and
hold the LOCK and UNLOCK
buttonsatthesametime.TheLED
in the remote will blink twice. Then
release the buttons. Doing this
cancels the keyless memory settings
f or that remote.
Driving position memory
(see page ).
To turn the keyless memory settings
back on, repeat this procedure. The
LED will blink once to indicate the
f eature has been turned on.
When you unlock and open the
driver’s door with the remote
transmitter, the driver’s seat (except
the power lumbar feature) and
outside mirrors start to move to the
positions stored in memory. The
indicator in the related memory
button to the remote comes on. 145
K eyless Memory Settings
Remote Transmitter
130
TM
\f—\f—

y

y
() \fy\f
y
2009 RDX

µ
See pagesf or important saf ety
inf ormation and warnings about how toproperly position the seats and seat-backs. 1213
The controls f or the power
adjustable front seats are on the
outside edge of each seat bottom.
You can adjust the seats with the
ignition switch in any position. Make
all seat adjustments bef ore you start
driving.
The passenger seat has the same
adjustments as the driver’s seat but
without any height and lumbar
adjustments. Moves the seat forward
and backward.
Moves the f ront of the seat
up or down. (Driver’s seat
only)
Raises or lowers the seat.
(Driver’s seat only)Moves the whole seat up
and f orward, or down and
backward. The f ront of the
seat also tilts up or down at
thesametime.(Driver’s
seat only)
Adjusts the seat-back angle
forward or backward.
Increases or decreases the
lumbar support. (Driver’s
seat only)
Seats
Front Seat Power A djustments
Inst rument s and Cont rols
131
DRIVER’S SEAT PASSENGER’S SEAT
\f—\f—

y

\fy
() \fy\f
y
2009 RDX

See pagef or important saf etyinf ormation and a warning aboutimproperly positioning head restraints. 14
Your vehicle is equipped with head
restraints in all seating positions to
help protect you and your
passengers f rom whiplash and other
injuries.
The f ront and rear head restraints
adjust f or height. You need both
hands to adjust the restraint. Do not
attempt to adjust it while driving. To
raise it, pull upward. To lower the
restraint, push the release button
and push the restraint down.
They are most ef f ective when you
adjust them so the center of the back
of the occupant’s head rests against
the center of the restraint.
Head Restraints
A djust ing t he Head Rest raint
Seats
132
RELEASE BUTTON
Front
CUSHION
LEG
SEAT-BACK
\f—\f—

y

y
() \fy\f
y
2009 RDX

To remove a head restraint f or
cleaning or repair, pull it up as f ar as
it will go. Push the release button,
then pull the restraint out of the seat-
back.When reinstalling a head restraint,
put the legs back in place. Then
adjust it to the appropriate height
while pressing the release button.
Make sure the removed head
restraints are securely stored.
CONT INUED
Removing t he Head Rest raint
Seats
Inst rument s and Cont rols
133
Rear
CUSHION
LEGS RELEASE BUTTON
SEAT-BACK
Failure to reinstall the head
restraints can result in severe
injury during a crash.
Always replace the head
restraints before driving.
\f—\f—

y
\f\fy
() \fy\f
y
2009 RDX

The driver’s and f ront passenger’s
seats have active head restraints. If
the vehicle is struck severely f rom
the rear, the occupant properly
secured with the seat belt will be
pushed against the seat-back and the
head restraint will automatically
move forward.For a head restraint system to work
properly:
Do not hang any items on the head
restraints, or f rom the restraint
legs.
Do not place any object between
an occupant and the seat-back.
Install each restraint in its proper
location.
If the restraints do not return to their
normal position, or in the event of a
severe collision, have the vehicle
inspected by an Acura dealer.
Af ter a collision, the activated
restraint should return to its normal
position.
This reduces the distance between
the restraint and the occupant’s head.
It also helps protect the occupants
against whiplash and injuries to the
neck and upper spine.
Only use genuine Acura
replacement head restraints.
A ct ive Head Rest raint s
Seats
134
\f—\f—

y
\f
y
() \fy\f
y
2009 RDX

The rear seat armrest is in the
center of the rear seat. Pivot it down
to use it.Remove any items from the seat
before folding down the seat-back.
Make sure there are no items on the
f loor bef ore f olding down the seats.
The lid of the console compartment
canbeusedasanarmrest. The rear seat-backs can be f olded
down to give more cargo room. Each
side f olds down separately. So you
can still carry a passenger in the rear
seat.
A beverage holder is located in the
armrest.
CONT INUED
Folding the Rear Seats Down
Armrests
Seats
Inst rument s and Cont rols
135
Front Rear
\f—\f—

y
\f
y
() \fy\f
\fy
2009 RDX

Move the front seats as far
f orward as possible. Make sure
the front seat-backs are in the
upright positions.
Store the center seat belt buckle
into the pocket in the rear seat-
back.
Lower the head restraints to their
lowest positions.Pull up the release lever on the
outside of the seat-back.
Push the armrest back in place.
Fold the seat-back forward.
Lif t the f ront edge of the rear seat
cushion, then pull up on the rear
of the seat cushion, then f old the
cushion f orward. Move the front seats backward to
the desired position.
1.
2.
3. 4.
5.
6.
7.
Seats
136
RELEASE LEVER
BUCKLE
\f—\f—

y
\f
y
() \fy\f

y
