Acura RDX 2009 Owner's Manual

Do not put any heavy items on the
seat-back when it is folded down.
Make sure all items in the cargo area
are secured. Loose items can f ly
f orward and cause injury if you have
to brake hard (See
on page ).
Make sure that the f olded down rear
seat does not interf ere with the f ront
passenger’s seat-back. This will
cause the f ront passenger’s weight
sensors and the f ront passenger’s
seat belt reminder indicator to work
improperly (see pages and ).
Also check the passenger airbag of f
indicator to assure proper operation
of the passenger’s front airbag.After returning the seat-back to the
upright position, tug on the seat-back
to make sure it is latched. If the seat-
back is not latched f ully, the seat belt
will not work properly and you will
seetheredindicatorbehindthe
release lever as shown.To return the seat cushion to its
original position, lif t up the seat
cushion, then place the rear of the
seat cushion at the base of the seat-
back. Use the seat buckles as guides.
Lower the f ront of the seat cushion
until it locks into place.
Make sure the seat-back and seat
cushion are locked securely and all
rear shoulder belts are positioned in
front of the rear seat-backs.
283
2032
Carrying Cargo
Seats
Inst rument s and Cont rols
137
RELEASE
LEVER
INDICATOR
\f—\f—

y
\fy
() \fy\f
y
2009 RDX

Follow these precautions whenever
you use the seat heaters:Use the HI setting only to heat the
seats quickly, because it draws
large amounts of current f rom the
battery.
If the engine is lef t idling f or an
extended period, do not use the
seat heaters, even on the LO
setting. It can weaken the battery,
causing hard starting.
In the LO setting, the heater runs
continuously. It does not cycle with
temperature changes.
In the HI setting, the heater turns off
when the seat gets warm, and turns
back on after the seat’s temperature
drops.
Both f ront seats are equipped with
seat heaters. The passenger seat is
only heated in the seat bottom
because of the side airbag cutof f
system. The ignition switch must be in the
ON (II) position to use seat heaters.
Push the top of the switch, HI, to
rapidly heat up the seat. Af ter the
seat reaches a comfortable
temperature, select LO by pushing
the bottom of the switch. This will
keep the seat warm.
Seat Heaters
138
SEAT HEATER SWITCHES
Passenger’s Seat
Driver’s Seat
HEATERS
\f—\f—

y
\fy
() \fy\f
y
2009 RDX

Turn the ignition switch to the ON
(II) position to raise or lower any
window. To open the window, push
the switch down and hold it. Release
the switch when you want to stop the
window. To close the window, pull
back on the switch and hold it.When you push the MAIN switch in,
the switch is off, and the passenger
windows cannot be raised or lowered.
To cancel this f eature, push on the
switch again to get it to pop out.
Keep the MAIN switch of f when you
have children in the vehicle so they
do not injure themselves by
operating the windows
unintentionally.
The windows will operate f or up to
10 minutes af ter you turn of f the
ignition switch. Opening either f ront
door cancels this f unction.
CONT INUED
Power Windows
Inst rument s and Cont rols
139
DRIVER’S WINDOW
SWITCH
MAIN SWITCH
Closing a power window on
someone’s hands or fingers can
cause serious injury.
Make sure your passengers are
away from the windows before
closing them.
\f—\f—

y
\fy
() \fy\f
y
2009 RDX

µ
µ
Auto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it.If either f ront
window senses any obstacle while it
is closing automatically, it will
reverse direction and then stop. To
close the window, remove the
obstacle, then use the window switch
again.
To open or close either
f ront window f ully, push or pull the
window switch firmly down or up to
the second detent, and release it.
The window will automatically go up
or down all the way. To stop the
window, pull or push the window
switch brief ly.
To open or close either f ront window
partially, push down or pull back on
the window switch lightly to the first
detent and hold it. The window will
stop when you release the switch. AUTO REVERSE
AUTO
Power Windows
140
\f—\f—

y
\fy
() \fy\f
y
2009 RDX

Turn the ignition switch to the ON
(II) position bef ore operating the
moonroof switch on the ceiling
console.
To open the moonroof f ully, pull
back the moonroof switch f irmly.
The moonroof opens all the way. To
stop the moonroof f rom opening
f ully, brief ly move the switch in
either direction.
To tilt the moonroof , push the center
of the moonroof switch straight up.
To stop the moonroof f rom tilting
f ully open, push the moonroof switch
forward.To open or close the moonroof
partially, pull or push the moonroof
switch lightly to the f irst detent and
hold it. The moonroof will stop when
you release the switch.To close the moonroof f ully, push
the moonroof switch f orward to the
second detent, then release it. The
moonroof closes all the way. To stop
the moonroof f rom closing all the
way,brieflymovetheswitchin
either direction.
CONT INUED
Moonroof
Inst rument s and Cont rols
141
MOONROOF SWITCH
Tilt
Open
Close
\f—\f—

y

\fy
() \fy\f
y
2009 RDX

The moonroof has a key-of f delay.
You can open and close the
moonroof f or up to 10 minutes af ter
you turn of f the ignition switch. The
key-of f delay cancels as soon as you
open either f ront door. You must
then turn the ignition switch to the
ON (II) position f or the moonroof to
operate.If the moonroof runs into any
obstacle while it is closing
automatically, it will reverse
direction, and then stop. To close the
moonroof , remove the obstacle, then
use the moonroof switch again.
Auto reverse stops sensing when the
moonroof is almost closed. You
should always check that all
passengers and objects are away
f rom the moonroof bef ore closing it.
Auto Reverse
Moonroof
142
Opening or closing the
moonroof on someone’s hands
or fingers can cause serious
injury.
Make sure all hands and fingers
are clear of the moonroof
before opening or closing it.
If you try to open the moonroof in
below-f reezing temperatures, or when
it is covered with snow or ice, you can
damage the moonroof panel or motor.
\f—\f—

y


\fy
() \fy\f
y
2009 RDX

Turn the ignition switch to the ON
(II) position.
Move the selector switch to L
(driver’s side) or R (passenger’s
side).
Keeptheinsideandoutsidemirrors
clean and adjusted f or best visibility.
Be sure to adjust the mirrors bef ore
you start driving. The inside mirror can automatically
darken to reduce glare. To turn on
this feature, press the button on the
bottom of the mirror. The AUTO
indicator comes on as a reminder.
When it is on, the mirror darkens
when it senses the headlights of a
vehicle behind you, then returns to
normal visibility when the lights are
gone. Press the button again to turn
of f this f eature.
1.
2.
CONT INUED
Adjusting the Power Mirrors
Mirrors
Inst rument s and Cont rols
143
SELECTOR SWITCH
INDICATOR
AUTO BUTTON SENSOR
There is also a sensor on the back of
the mirror. Items hung on the mirror
may block this sensor and af f ect its
perf ormance.
\f—\f—

y


y
() \fy\f
y
2009 RDX

Push the appropriate edge of the
adjustment switch to move the
mirrorright,left,up,ordown.
When you f inish, move the
selector switch to the center (off)
position. This turns the
adjustment switch of f to keep your
setting.The outside mirrors are heated to
remove fog and frost. With the
ignition switch in the ON (II)
position, turn on the heaters by
pressing the button. The indicator in
the button comes on as a reminder.
Press the button again to turn the
heaters off. Pressing this button also
turns the rear window def ogger on
and off.
Outside mirror positions can be
stored in the driving position
memory system (see page ).
The passenger’s outside mirror has a
reverse tilt f eature. When in reverse,
the mirror will tilt down slightly to
improve your view as you parallel
park. Shif ting out of reverse will
return the mirror to its original
position.
To turn the feature off, place the
switch in the center or lef t position.
To tilt the passenger mirror, place
the selector switch in the right
position.
3.
4. 145
Heated Mirrors
Reverse Tilt Door Mirror
Mirrors
144
ADJUSTMENT SWITCH HEATED MIRROR BUTTON
\f—\f—

y

y
() \fy\f
y
2009 RDX

Adjust the seat to a comfortable
position (see page ).
Store a driving position only when
the vehicle is parked.
Turn the ignition switch to the ON
(II) position. You cannot add a
new driving position to the
memory unless the ignition switch
is in the ON (II) position. You can
recall a memorized position with
the ignition switch in any position.
Your vehicle has a memory feature
f or the driver’s seat and outside
mirror positions.
Adjust the outside mirrors f or best
visibility (see page ).Press and release the SET button
on the control panel. You will hear
a beep. Immediately press and
hold one of the memory buttons (1
or 2) until you hear two beeps.
The indicator in the memory
button will come on. The current
positions of the driver’s seat and
outside mirrors are now stored.
Seat, except f or power lumbar, and
outside mirror positions, can be
stored in separate memories. You
select a memorized position by
pushing the appropriate button or
using the appropriate remote
transmitter (Memory 1 or
Memory 2).
3.
1.
2.
131
143
CONT INUED
Storing a Driving Position in
Memory
Driving Position Memory System
Inst rument s and Cont rols
145
MEMORY BUTTONS SET BUTTON
\f—\f—

y

y
() \fy\f
\fy
2009 RDX

Not press a memory button within
5 seconds.
Readjust the seat position.
Readjusting the outside mirror
position.
Each memory button stores only one
driving position. Storing a new
position erases the previous setting
stored in that button’s memory. If
you want to add a new position while
retaining the current one, use the
other memory button. To select a memorized position, do
this:
To stop the system’s automatic
adjustment, do any of these actions:
Push any of the adjustment
switches f or the seat.
Shif t out of Park.
Adjust the outside mirrors.
Make sure the vehicle is parked.
Press the desired memory button
(1 or 2) until you hear a beep, then
release the button.
Doing any of the f ollowing af ter
pressing the SET button will cancel
the storing procedure.
The system will move the seat and
outside mirrors to the memorized
positions. The indicator in the
selected memory button will f lash
during movement. When the
adjustments are complete, you will
hear two beeps, and the indicator will
remain on. Press any button on the control
panel: SET, 1, or 2.
If desired, you can use the
adjustment switches to change the
positions of the seat or outside
mirrors af ter they are in their
memorized positions. If you change
the memorized position, the
indicator in the memory button will
go out. To keep this driving position
f or later use, you must store it in the
driving position memory.
1.
2.
Selecting a Memorized Position
Driving Position Memory System
146
\f—\f—

y

y
() \fy\f

y
2009 RDX
