Page 71 of 433
Itcomesonasareminderthatyou
have turned off the vehicle
stability assist (VSA) system.
This indicator has three f unctions: This indicator comes on when you
turn on the cruise control system by
pressing the CRUISE button (see
page ).
This indicator comes on when you
set the cruise control. See pagef or inf ormation on operating the
cruise control.
This indicator comes on with the
high beam headlights. For more
inf ormation, see page .
This indicator also comes on with
reduced brightness when the
daytime running lights (DRL) are on
(see page ).
It comes on along with the VSA
system indicator if there is a
problem with the VSA system.
It flashes when VSA is active (see
page ).
You will also see a ‘‘CHECK VSA
SYSTEM’’ message on the multi-
inf ormation display (see page
).
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. For more inf ormation, see
page . The lef t or right turn signal indicator
blinks when you signal a lane change
or turn. If an indicator does not blink
or blinks rapidly, it usually means
one of the turn signal bulbs is
burned out (see pages and ).
Replace the bulb as soon as possible,
since other drivers cannot see that
you are signaling.
When you press the hazard warning
button, both turn signal indicators
and all turn signals on the outside of
the vehicle f lash.
1.
2.
3.
312
78 312 234
234
115
116 348350
VSA A ctivation Indicator
Cruise Control Indicator
Cruise Main Indicator
High Beam Indicator Turn Signal and
Hazard Warning
Indicators
Instrument Panel Indicators
Inst rument s and Cont rols
67
\f—\f—
y
y
() \fy\f\fy
2009 RDX
Page 351 of 433
Theheadlightswereproperlyaimed
when your vehicle was new. If you
regularly carry heavy items in the
cargo area or pull a trailer,
readjustment may be required.
Adjustmentsshouldbedonebyyour
dealer or another qualif ied
technician.Your vehicle has halogen headlight
bulbs. When replacing a bulb, handle
it by its base, and protect the glass
f rom contact with your skin or hard
objects. If you touch the glass, clean
it with denatured alcohol and a clean
cloth.
Insert the new bulb into the hole,
and turn it one-quarter turn
clockwise to lock it in place.
Push the electrical connector onto
the new bulb.
Turn on the headlights to test the
new bulb.
Remove the bulb by turning it
about one-quarter turn
counterclockwise.
Remove the electrical connector
f rom the bulb by pushing on the
tab and pulling the connector
down.
Open the hood.
The low beam headlight bulbs are a
type of high voltage discharge tube.
High voltage can remain in the
circuit even with the light switch of f
and the key removed. Because of
this, you should not attempt to
examine or change a low beam
headlight bulb yourself . If a low
beam headlight bulb fails, take the
vehicle to your dealer to have it
replaced. 1.
2.3.
4.
5.
Headlight A iming Replacing a High Beam Headlight
Bulb
L ow Beam Headlight Bulb
Replacement
Lights
Maint enance
347
BULB CONNECTORHalogen headlight bulbs get very hot
when lit. Oil, perspiration, or a scratch
on the glass can cause the bulb to
overheat and shatter.
\f—\f—
y
y
() \fy\fy
2009 RDX
Page 352 of 433
Test the lights to make sure the
new bulb is working.
Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Install the new bulb in the socket.
Turn it clockwise to lock it in place.
Remove the bulb f rom the socket
by pushing the bulb in and turning
it counterclockwise until it unlocks.
Open the hood. Remove the
socket f rom the headlight
assembly by turning it one-quarter
turn counterclockwise. Open the hood. Remove the
socket f rom the headlight
assembly by turning it one-quarter
turn counterclockwise.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
1.
2.
3. 1.
2.
4.
5.
Lights
Replacing a Front T urn Signal/
Parking L ight Bulb
Replacing a Front Side Marker
Light Bulb
348
BULB
SOCKET SOCKET BULB
\f—\f—
y
\fy
() \fy\fy
2009 RDX
Page 353 of 433
Remove the socket by turning it
one-quarter turn counterclockwise.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Open the tailgate. Place a cloth on
the edge of the light assembly
cover. Remove the cover by
caref ully prying in the notch on its
middle edge with a f lat-tip
screwdriver.
Determine which of the two bulbs
is burned out: taillight or back-up
light.
Install the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
1.
2. 3.
4.
3.
4.
CONT INUED
Lights
Replacing Rear Bulbs
(in Tailgate)
Maint enance
349
COVER
NOTCH SOCKETS
BULBS
\f—\f—
y
y
() \fy\fy
2009 RDX
Page 354 of 433
Determine which of the three
bulbs is burned out: brake/
taillight, turn signal or rear side
marker.
Remove the socket by turning it
one-quarter turn counterclockwise.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Open the tailgate.
Remove the two bolt covers on the
rear pillar by prying on the bottom
edge with a flat-tip screwdriver.
Remove the bolts with a Phillips-
head screwdriver, and remove the
light assembly f rom the rear pillar.
Turn on the lights to make sure
the new bulb is working.
Reinstall the light assembly cover.
Reinstall the socket into the light
assembly by turning it clockwise
until it locks.
2. 4.
5.
3.
1.
5.
6.
7.
Lights
Replacing Rear Bulbs
(in Rear Pillar)
350
COVERS
BULB SOCKET
BOLTS
\f—\f—
y
y
() \fy\fy
2009 RDX
Page 355 of 433
CONT INUED
Use a Phillips-head screwdriver to
remove the screw and use a flat-
tipped screwdriver to remove the
holding clip located under the
f ront bumper.
Push up the undercover.
Your vehicle uses halogen light
bulbs. When replacing a bulb, handle
it by its plastic case, and protect the
glass from contact with your skin or
hard objects. If you touch the glass,
clean it with denatured alcohol and a
clean cloth.
Turn on the lights to make sure
the new bulb is working.
Put the socket back into the light
assembly, and turn it clockwise to
lock it in place.
Install the rear light assembly in
the rear pillar. Tighten the two
bolts. Snap the bolt covers into
position.
1.
2.
6.
7.
8.
Lights
Replacing a Front Fog L ight Bulb
Maint enance
351
HOLDING CLIP
SCREWHalogen bulbs get very hot when lit.
Oil, perspiration, or a scratch on the
glass can cause the bulb to overheat
and shatter.
\f—\f—
y
y
() \fy\fy
2009 RDX
Page 356 of 433
Remove the two screw covers on
the light assembly by prying on
the side edge with a flat-tip
screwdriver.
Remove the screws with a Phillips-
head screwdriver, then remove
the light assembly f rom the
tailgate.
Install the new bulb into the hole
and turn it one-quarter turn
clockwise to lock it in place.
Push the electrical connector back
onto the bulb. Make sure it is on
all the way.
Turn on the f og lights to test the
new bulb.
Put the undercover in place.
Reinstall the clip, and tighten the
screw securely.
Remove the electrical connector
f rom the bulb by pushing on the
tab and pulling the connector
down.
Remove the bulb f rom the f og
light assembly by turning it one-
quarter turn counterclockwise. 5.
6.
7.
8.
1.
2.
3.
4.
Lights
Replacing a High-mount Brake
Light Bulb
352
COVERS
SCREWS
CONNECTOR
BULB
\f—\f—
y
y
() \fy\fy
2009 RDX
Page 357 of 433
Each outside mirror has side turn
signal lights. The lights should be
replaced by your dealer.
The license plate has two lights
above it. The bulbs should be
replaced by your dealer.
Press the brake pedal to make
sure the new bulb is working.
Put the socket back into the light
assembly, and turn it clockwise to
lock it in place.
Reinstall the high-mount brake
light assembly into the tailgate.
Tighten the two screws and
reinstall the covers.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Remove the socket f rom the light
assembly by turning it one-quarter
turn counterclockwise. 6.
5.
7.
3.
4.
Lights
Side T urn Signal L ights
Replacing a Rear License Plate
Light Bulb
Maint enance
353
SOCKET
BULB
\f—\f—
y
y
() \fy\fy
2009 RDX
Page 401 of 433
µµµ
µ
µ
Î µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
Î
Specif ications
Technical Inf ormation
397
Air Conditioning
Battery Fuses
Alignment
Tires
Lights
HFC-134a (R-134a)
15.8 17.6 oz (450 500 g) SP-10
Refrigerant type
Charge quantity
Lubricant type
12 V 60 W
12 V 35 W
12 V 24/2.2 CP
12 V
12 V
12 V
12 V
12 V
12 V
12 V
12 V
12 V
Capacity 12 V
12 V65 AH/20 HR
52 AH/5 HR
12 V
12 V
5W
4CP
8W
16 W
3CP
2CP
21 W
3CP
21/5 W
21 W
3CP
55 W
12 V
12 V 2 CP Interior
Under-hood
Toe-in
Camber
Caster
0.0in(0mm)
0.10 in (2.5 mm) 0°10’1°
2°57’
Size
Pressure P235/55R18 99V
T165/80D17 104M
32 psi (220 kPa , 2.2 kgf/cm
)
60 psi (420 kPa , 4.2 kgf/cm)
Headlights
Front turn signal/parking
lights
Front fog lights
Front side marker lights
Rear turn signal lights
Brake/Taillights (in fenders)
Taillights (in tailgate)
Back-up lights
Rear side marker lights
License plate lights
High-mount brake light
Rear ceiling light
Front ceiling lights/Spotlights
Door courtesy lights
Cargo area light See page389or the fuse label
attached to the dashboard.
See page390or the fuse box
covers.
The low beam headlight bulbs are high voltage discharge bulbs.
Replacement of a low beam headlight bulb should be performed by
your dealer. Front
Rear
Front
Rear
Front
Front/Rear
Spare
Front/Rear
Spare
: (HB3)
(D2S)
High
Low
(Amber)
(H11)
\f—\f—
y
y
() \fy\f\fy
2009 RDX
Page 419 of 433
CONT INUED
....................................
Accessories .281
ACCESSORY (Ignition Key
.....................................
Position) .122
............
Accessory Power Sockets .154
................
Active Head Restraints .134
......................................
AcuraLink .237
....................
Additives, Engine Oil .337
.......................
Additives, Gasoline .272
.............
Adjusting the Sound .186,217
.....
Adjusting the Steering Wheel .119
........
Adjust Outside Temperature .74
......
Adjust Outside Temp. Display .89
...........................
Advanced Airbags .27
...............................
Airbag (SRS) .9,23
..............
Air Conditioning System .160
.........................................
Usage .161
.......................
Air Pressure, Tires .361
......................................
Antif reeze .340
Anti-lock Brakes (ABS)
...............................
Indicator .64,305
...................................
Operation .305
..............
Anti-thef t, Audio System .232
Anti-thef t Steering Column
............................................
Lock .122 ........................................
Armrests .135
..............................
Audio Antenna .355
................................
Audio System .168
............................
Auto Door Lock .101
.........................
Auto Door Unlock .109
.
Automatic Lighting Off Feature .115
...
Automatic Seat Belt Tensioners .21
..............
Automatic Transmission .293
..........................
Capacity, Fluid .396
...............
Checking Fluid Level .343
Driving with the Paddle
...................................
Shif ters .297
.......................................
Shif ting .293
Shif t Lever Position
...............................
Indicators .293
................
Shif t Lever Positions .294
....................
Shif t Lock Release .296
......................
Auxiliary Input Jack .220
Battery
Charging System ...........................
Indicator .63,381
............................
Jump Starting .377
..............................
Maintenance .366 ............................
Specif ications .397
..............................
Bef ore Driving .271
....................................
Belts,Seat.8,19
.........................
Beverage Holders .153
.......
Bluetooth
HandsFreeLink.250
..................................
Booster Seats .53
Brakes
...........
Anti-lock System (ABS) .305
.............
Break-in, New Linings .272
....................
Bulb Replacement .350
...........................................
Fluid .345
.......................................
Parking .147
......
System Indicator (Red) .65,383
System Indicator
...........................
(Amber) .65,384
..........................
System Design .304
........................
Wear Indicators .304
.............................
Braking System .304
.................
Break-in, New Vehicle .272
Brightness Control,
...............................
Instruments .117
Index
A
B
INDEX
I
\f—\f—
y
y
() \fy\f\fy
2009 RDX
