service indicator Acura RDX 2011 User Guide

Your tires have wear indicators
molded into the tread. When the
tread wears down, you will see a 1/2
inch (12.7 mm) wide band across the
tread. This shows there is less than
1/16 inch (1.6 mm) of tread left on
the tire.
A tire this worn gives very little
traction on wet roads. You should
replace the tire if you can see three
or more tread wear indicators.Tire Service Life
The service life of your tires is
dependent on many factors,
including, but not limited to, driving
habits, road conditions, vehicle
loading, inflation pressure,
maintenance history, speed, and
environmental conditions (even
when the tires are not in use).
In addition to your regular
inspections and inflation pressure
maintenance, it is recommended that
you have annual inspections
performed once the tires reach five
years old. It is also recommended
that all tires, including the spare, be
removed from service after 10 years
from the date of manufacture,
regardless of their condition or state
of wear.
The last four digits of the TIN (tire
identification number) are found on
the sidewall of the tire and indicate
the date of manufacture (See
Tire
Labeling on page 484). Tire Maintenance
In addition to proper inflation, correct
wheel alignment helps to decrease
tire wear. If you find a tire is worn
unevenly, have your dealer check the
wheel alignment.
Have your dealer check the tires if
you feel a consistent vibration while
driving. A tire should always be
rebalanced if it is removed from the
wheel. When you have new tires
installed, make sure they are
balanced. This increases riding
comfort and tire life. For best results,
have the installer perform a dynamic
balance.
Improper wheel weights can damage
your vehicle's aluminum wheels. Use
only Acura wheel weights for
balancing.
INDICATOR LOCATION MARKS
TREAD WEAR INDICATORS
Tires44610/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

Low Oil Pressure Indicator
This indicator should never
come on when the engine is
running. If it starts flashing or stays
on, the oil pressure has dropped very
low or lost pressure. Serious engine
damage is possible, and you should
take immediate action.
You will also see an ‘‘OIL PRESSURE
LOW ’’message on the multi-
information display (see page 79).
Running the engine with low oil
pressure can cause serious mechanical
damage almost immediately. Turn off
the engine as soon as you can safely get
the vehicle stopped. 1. Safely pull off the road, and shut
off the engine. Turn on the hazard
warning lights.
2. Let the vehicle sit for a minute. Open the hood, and check the oil
level (see page 356). An engine
very low on oil can lose pressure
during cornering and other driving
maneuvers.
3. If necessary, add oil to bring the level back to the full mark on the
dipstick (see page 420).
4. Start the engine, and watch the oil pressure indicator. If it does not go
out within 10 seconds, turn off the
engine. There is a mechanical
problem that needs to be repaired
before you can continue driving
(see Emergency Towing on page
475). Charging System Indicator
If the charging system
indicator comes on brightly
when the engine is running, the
battery is not being charged.
You will also see a ‘‘CHECK
CHARGING SYSTEM ’’message on
the multi-information display (see
page 79).
Immediately turn off all electrical
accessories. Try not to use other
electrically operated controls such as
the power windows. Keep the engine
running; starting the engine will
discharge the battery rapidly.
Go to a service station or garage
where you can get technical
assistance.
Low Oil Pressure Indicator, Charging System Indicator
465
Taking Care of the Unexpected
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

Brake System Indicator
(Red)U.S. CanadaThe brake system indicator (red)
normally comes on when you turn
the ignition switch to the ON (II)
position, and as a reminder to check
the parking brake. It will stay on if
you do not fully release the parking
brake.
If the brake system indicator (red)
comes on while driving, the brake
fluid level is probably low. Press
lightly on the brake pedal to see if it
feels normal. If it does, check the
brake fluid level the next time you
stop at a service station (see page
429).
You will also see a‘‘BRAKE FLUID
LOW ’’message on the multi-
information display (see page 79). If the fluid level is low, take your
vehicle to a dealer, and have the
brake system inspected for leaks or
worn brake pads.
However, if the brake pedal does not
feel normal, you should take
immediate action. A problem in one
part of the system's dual circuit
design will still give you braking at
two wheels. You will feel the brake
pedal go down much farther before
the vehicle begins to slow down, and
you will have to press harder on the
pedal.
You will also see a
‘‘CHECK BRAKE
SYSTEM ’’message on the multi-
information display (see page 79). Slow down by shifting to a lower
gear, and pull to the side of the road
when it is safe. Because of the long
distance needed to stop, it is
hazardous to drive the vehicle. You
should have it towed, and repaired as
soon as possible (see
Emergency
Towing on page 475).
If you must drive the vehicle a short
distance in this condition, drive
slowly and carefully.
If the ABS indicator and the VSA
system indicator come on with the
brake system indicator, have your
vehicle inspected by your dealer
immediately.
Brake System Indicator
467
Taking Care of the Unexpected
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

Bulb ReplacementBack-up Lights
........................
433
Brake Lights
...........................
433
Fog Lights
...............................
435
Front Parking Lights
...............
432
Front Side Marker Lights
........
432
Headlights
..............................
431
High-mount Brake Light
.........
436
Rear Bulbs
......................
433, 434
Rear License Plate Lights........
437
Specifications
..........................
481
Taillights
.........................
433, 434
Turn Signal Lights
..........
432, 433
Bulbs, Halogen
..........................
431
C
Capacities Chart
.........................
480
Carbon Monoxide Hazard
............
57
Cargo
.........................................
364
Cargo Area Cover
.......................
160
Cargo Area Light
........................
153
Cargo, How to Carry
..................
364
Carrying Cargo
..........................
364
CAUTION, Explanation of
............
iii CD Care
.....................................
257
Ceiling Lights
.............................
151
Certification Label
......................
478
Chains, Tires
..............................
449
Changing a Flat Tire
..................
455
Changing Oil How to
....................................
422
When to
..................................
411
Charging System Indicator
...........................
65, 465
Checklist, Before Driving
...........
373
Childproof Door Locks
...............
127
Child Safety
..................................
36
Booster Seats
...........................
54
Child Seats
....................
41, 42, 44
Important Safety Reminders
.....
40
Infants
......................................
41
Larger Children
.......................
53
LATCH
.....................................
46
Risks with Airbags
...................
37
Small Children
.........................
42
Tethers
....................................
51
Warning Labels
........................
38
Where Should a Child Sit?
........
37
Child Seats
...................................
44
LATCH Anchorage Points
........
46 Tether Anchorage Points
.........
51
Cleaning the Seat Belts
..............
438
Client Service Information
..........
494
Climate Control Sensors
............
171
Climate Control System
.............
164
Clock
..........................................
293
Coat Hook
..................................
161
Code, Audio System
...................
292
CO in the Exhaust
................
57, 487
Cold Weather, Starting in
...........
374
Compact Spare Tire
....................
454
Compass Operation
..................
295
Console Compartment
...............
158
Consumer Information
...............
494
Controls, Instruments and
............
61
Coolant Adding
....................................
424
Checking
................................
357
Proper Solution
.......................
424
Courtesy Lights
..........................
153
Crankcase Emissions Control
System
...................................
487
Cruise Control Indicator
...............
69
Cruise Control Operation
...........
300
Cruise Main Indicator
..................
69
Cup Holders
...............................
156
IndexII10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

System Components
................
20
Use During Pregnancy
.............
18
Wearing a Lap/Shoulder Belt
..................................
15, 21
Seats
..........................................
134
Armrest
...................................
138
Head Restraints
.......................
135
Heaters
...................................
141
Position Memory
....................
148
Seats, Adjusting the
...................
134
Security System
.........................
294
Security System Indicator
............
70
Sensors Driver's Seat Position Sensor
...
28
Front Passenger's Weight Sensors
................................
28
Impact Sensors
........................
24
Serial Number
............................
478
Service Intervals
.........................
411
Service Manual (U.S. only)
........
497
Service Station Procedures
........
353
Setting the Clock
........................
293
SH-AWD
®...................................
384
Indicator
...................................
70
Torque Distribution Monitor
...
384 Shifting the Automatic
Transmission
..........................
376
Shift Lever Position Indicators
...
376
Shift Lock Release
......................
379
Side Airbags
.................................
30
How the Side Airbag Off Indicator Works
...................
32
How Your Side Airbags Work..30
Side Curtain Airbags
....................
31
How Your Side Curtain Airbags Work
....................................
31
Side Marker Lights, Bulb
Replacement in
.......................
432
Signaling Turns
............................
69
Snow Tires
.................................
448
Sound System
.....................
172, 216
Spare Tire
..................................
454
Inflating
...........................
444, 454
Specifications
..........................
481
Spark Plugs
................................
480
Specifications
.............................
480
Speed Control
............................
300
Speed Limiter
.............................
378
Speedometer
................................
73
SRS, Additional Information
.........
24
Additional Safety Precautions
...
35 Airbag Service
..........................
34
Airbag System Components
.....
24
How the Side Airbag Off Indicator Works
...................
32
How the SRS Indicator Works..32
How Your Front Airbags Work
....................................
26
How Your Side Airbags Work..30
How Your Side Curtain Airbags Work
....................................
31
SRS Indicator
.........................
32, 65
START (Ignition Key
Position)
.................................
125
Starting the Engine
....................
374
Auto Control Mode
.................
375
In Cold Weather at High Altitude
................................
374
With a Dead Battery
................
461
State Emissions Testing
.............
490
Steam Coming from Engine
.......
463
Steering Wheel
Adjustments
............................
122
Anti-theft Column Lock
...........
125
Buttons
...........................
289, 300
Stereo Sound System
..........
172, 216
CONTINUED
Index
IX
