sensor Acura RDX 2011 Owner's Guide

Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes significantly low, the sensor
in that tire immediately sends a
signal that causes the low tire
pressure/TPMS indicator in the
instrument panel to come on. If this
happens, you will see which tire is
losing pressure on the multi-
information display along with a
‘‘CHECK TIRE PRESSURE ’’
message.
Low Tire Pressure/TPMS
Indicator
When the low tire pressure/TPMS
indicator is on, one or more of your
tires is significantly underinflated.
You should stop and check your tires
as soon as possible, and inflate them
to the proper pressure as indicated
on the vehicle's tire information
placard.
It is possible that the pressures
shown on the multi-information
display and the pressures you
manually measure are slightly
different.
If the difference is significant or you
cannot make the low tire pressure/
TPMS indicator and message on the
multi-information display go out after
inflating the tires to the specified
values, have your dealer check the
system as soon as possible. If you think you can safely drive a
short distance to a service station,
proceed slowly to the station, then
inflate the tire to the recommended
pressure.
If the tire is flat, or if the tire pressure
is too low to continue driving, replace
the tire with the compact spare tire
(see page 454).
Driving on a significantly under-
inflated tire causes the tire to
overheat and can lead to tire failure.
Under-inflation also reduces fuel
efficiency and tire tread life, and may
affect the vehicle's handling and
stopping ability.
Because tire pressure varies by
temperature and other conditions,
the low tire pressure/TPMS
indicator may come on unexpectedly.
Tire Pressure Monitoring System (TPMS)39010/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

To see the inflation pressures of all
four tires, press the SEL/RESET
button. The display changes as
shown above.
Each tire pressure is shown in PSI
(U.S. models) or in kPa (Canadian
models).
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes significantly low, the sensor
in that tire immediately sends a
signal that causes the low tire
pressure/TPMS indicator in the
instrument panel to come on. If this
happens, you will see which tire is
losing pressure on the multi-
information display along with a
‘‘CHECK TIRE PRESSURE ’’
message.
When any of the tires have low
pressure, the tire pressure monitor
shows a ‘‘TIRE PRESS. ERROR
SYSTEM FUNC NORMAL ’’
message.
When you continue driving after
installing the spare tire, you will also
see this message on the multi-
information display.
U.S.
Canada SEL/RESET BUTTON
This shows that front left tire is
losing pressure.
Tire Pressure Monitoring System (TPMS)39210/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

Changing a Tire with TPMS
If you have a flat tire, the low tire
pressure/TPMS and tire monitor
indicators will come on. Replace the
indicated flat tire with the compact
spare tire (see page 454).
After the flat tire is replaced with the
spare tire, the low tire pressure/
TPMS indicator stays on while
driving. After several miles
(kilometers) driving, this indicator
begins to flash, then stays on again.
You will also see a‘‘CHECK TPMS
SYSTEM ’’message on the multi-
information display. This is normal;
the system cannot monitor the spare
tire pressure. Manually check the
spare tire pressure to be sure it is
correct. This indicator and the warning
message on the multi-information
display will go off, after several miles
(kilometers) driving, when the spare
tire is replaced with the specified
regular tire equipped with the tire
pressure monitor sensor.
Each wheel is equipped with a tire
pressure sensor. You must use
TPMS specific wheels. It is
recommended that you always have
your tires serviced by your dealer or
a qualified technician.
Never use a puncture-repairing agent
in a flat tire. If used, you will have to
replace the tire pressure sensor.
Have the flat tire repaired by your
dealer as soon as possible.
As required by the FCC:
This device complies with Part 15 of theFCC rules. Operation is subject to the
following two conditions: (1) This devicemay not cause harmful interference, and(2) this device must accept any
interference received, includinginterference that may cause undesiredoperation.
Changes or modifications not expresslyapproved by the party responsible for
compliance could void the user'sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.
Operation is subject to the following twoconditions: (1) this device may not causeinterference, and (2) this device must
accept any interference that may causeundesired operation of the device.
Tire Pressure Monitoring System (TPMS)39410/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

Cleaning the Seat BeltsIf your seat belts get dirty, use a soft
brush with a mixture of mild soap
and warm water to clean them. Do
not use bleach, dye, or cleaning
solvents. Let the belts air-dry before
you use the vehicle.
Dirt build-up the openings of the seat
belt anchors can cause the belts to
retract slowly. Wipe the openings
with a clean cloth dampened in mild
soap and warm water or isopropyl
alcohol.Floor Mats
The driver's and front passenger's
floor mats that came with your
vehicle hook over the floor mat
anchors. To lock each anchor, turn
the knob clockwise. This keeps the
floor mats from sliding forward
(possibly interfering with the
pedals), or backwards (making the
front passenger's weight sensors
ineffective). If you remove a floor
mat, make sure to re-anchor it when
you put it back in your vehicle.If you use a non-Acura floor mat,
make sure it fits properly and that it
can be used with the floormat
anchors. Do not put additional floor
mats on top of the anchored mats.
OPENING
FLOOR MAT ANCHORS
KNOB
Unlock
Lock
Cleaning the Seat Belts, Floor Mats43810/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

13. Tighten the wheel nuts securely inthe same crisscross pattern. Have
the wheel nut torque checked at
the nearest automotive service
facility.
Tighten the wheel nuts to:
80 lbf·ft (108 N·m, 11 kgf·m)
14. Store the jack in its holder. Turn the jack's end bracket to lock it in
place. Store the tools.
15. Remove the center cap from theflat tire, and store it in the cargo
area.
16. Place the flat tire face up in the cargo area.
17. Secure the flat tire by screwing the wing bolt back into its hole.
Loose items can fly around the
interior in a crash and could
seriously injure the occupants.
Store the wheel, jack, and tools
securely before driving.
18. Reinstall the cargo area floor, and close the tailgate.
19. Your vehicle's original tire has a tire pressure monitoring system
sensor. To replace a tire, refer to
Changing a Tire with TPMS (see
page 394).
For spare
tire For normal
tire
Changing a Flat Tire45810/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

Onboard Refueling Vapor
Recovery
The onboard refueling vapor
recovery (ORVR) system captures
the fuel vapors during refueling. The
vapors are adsorbed in a canister
filled with activated carbon. While
driving, the fuel vapors are drawn
into the engine and burned off.
Exhaust Emissions Controls
The exhaust emissions controls
include three systems: PGM-FI,
ignition timing control, and three
way catalytic converter. These three
systems work together to control the
engine's combustion and minimize
the amount of HC, CO, and NOx that
come out the tailpipe. The exhaust
emissions control systems are
separate from the crankcase and
evaporative emissions control
systems.
PGM-FI SystemThe PGM-FI system uses sequential
multiport fuel injection.
It has three subsystems: air intake,
engine control, and fuel control. The
powertrain control module (PCM)
uses various sensors to determine
how much air is going into the
engine. It then controls how much
fuel to inject under all operating
conditions.Ignition Timing Control SystemThis system constantly adjusts the
ignition timing, reducing the amount
of HC, CO, and NOx produced.Three Way Catalytic ConverterThe three way catalytic converter is
in the exhaust system. Through
chemical reactions, it converts HC,
CO, and NOx in the engine's exhaust
to carbon dioxide (CO
2), nitrogen
(N
2), and water vapor. Replacement Parts
The emissions control systems are
designed and certified to work
together in reducing emissions to
levels that comply with the Clean Air
Act. To make sure the emissions
remain low, you should use only new
Acura replacement parts or their
equivalent for repairs. Using lower
quality parts may increase the
emissions from your vehicle.
The emissions control systems are
covered by warranties separate from
the rest of your vehicle. Read your
warranty manual for more
information.
Emissions Controls48810/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

Bulb ReplacementBack-up Lights
........................
433
Brake Lights
...........................
433
Fog Lights
...............................
435
Front Parking Lights
...............
432
Front Side Marker Lights
........
432
Headlights
..............................
431
High-mount Brake Light
.........
436
Rear Bulbs
......................
433, 434
Rear License Plate Lights........
437
Specifications
..........................
481
Taillights
.........................
433, 434
Turn Signal Lights
..........
432, 433
Bulbs, Halogen
..........................
431
C
Capacities Chart
.........................
480
Carbon Monoxide Hazard
............
57
Cargo
.........................................
364
Cargo Area Cover
.......................
160
Cargo Area Light
........................
153
Cargo, How to Carry
..................
364
Carrying Cargo
..........................
364
CAUTION, Explanation of
............
iii CD Care
.....................................
257
Ceiling Lights
.............................
151
Certification Label
......................
478
Chains, Tires
..............................
449
Changing a Flat Tire
..................
455
Changing Oil How to
....................................
422
When to
..................................
411
Charging System Indicator
...........................
65, 465
Checklist, Before Driving
...........
373
Childproof Door Locks
...............
127
Child Safety
..................................
36
Booster Seats
...........................
54
Child Seats
....................
41, 42, 44
Important Safety Reminders
.....
40
Infants
......................................
41
Larger Children
.......................
53
LATCH
.....................................
46
Risks with Airbags
...................
37
Small Children
.........................
42
Tethers
....................................
51
Warning Labels
........................
38
Where Should a Child Sit?
........
37
Child Seats
...................................
44
LATCH Anchorage Points
........
46 Tether Anchorage Points
.........
51
Cleaning the Seat Belts
..............
438
Client Service Information
..........
494
Climate Control Sensors
............
171
Climate Control System
.............
164
Clock
..........................................
293
Coat Hook
..................................
161
Code, Audio System
...................
292
CO in the Exhaust
................
57, 487
Cold Weather, Starting in
...........
374
Compact Spare Tire
....................
454
Compass Operation
..................
295
Console Compartment
...............
158
Consumer Information
...............
494
Controls, Instruments and
............
61
Coolant Adding
....................................
424
Checking
................................
357
Proper Solution
.......................
424
Courtesy Lights
..........................
153
Crankcase Emissions Control
System
...................................
487
Cruise Control Indicator
...............
69
Cruise Control Operation
...........
300
Cruise Main Indicator
..................
69
Cup Holders
...............................
156
IndexII10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

System Components
................
20
Use During Pregnancy
.............
18
Wearing a Lap/Shoulder Belt
..................................
15, 21
Seats
..........................................
134
Armrest
...................................
138
Head Restraints
.......................
135
Heaters
...................................
141
Position Memory
....................
148
Seats, Adjusting the
...................
134
Security System
.........................
294
Security System Indicator
............
70
Sensors Driver's Seat Position Sensor
...
28
Front Passenger's Weight Sensors
................................
28
Impact Sensors
........................
24
Serial Number
............................
478
Service Intervals
.........................
411
Service Manual (U.S. only)
........
497
Service Station Procedures
........
353
Setting the Clock
........................
293
SH-AWD
®...................................
384
Indicator
...................................
70
Torque Distribution Monitor
...
384 Shifting the Automatic
Transmission
..........................
376
Shift Lever Position Indicators
...
376
Shift Lock Release
......................
379
Side Airbags
.................................
30
How the Side Airbag Off Indicator Works
...................
32
How Your Side Airbags Work..30
Side Curtain Airbags
....................
31
How Your Side Curtain Airbags Work
....................................
31
Side Marker Lights, Bulb
Replacement in
.......................
432
Signaling Turns
............................
69
Snow Tires
.................................
448
Sound System
.....................
172, 216
Spare Tire
..................................
454
Inflating
...........................
444, 454
Specifications
..........................
481
Spark Plugs
................................
480
Specifications
.............................
480
Speed Control
............................
300
Speed Limiter
.............................
378
Speedometer
................................
73
SRS, Additional Information
.........
24
Additional Safety Precautions
...
35 Airbag Service
..........................
34
Airbag System Components
.....
24
How the Side Airbag Off Indicator Works
...................
32
How the SRS Indicator Works..32
How Your Front Airbags Work
....................................
26
How Your Side Airbags Work..30
How Your Side Curtain Airbags Work
....................................
31
SRS Indicator
.........................
32, 65
START (Ignition Key
Position)
.................................
125
Starting the Engine
....................
374
Auto Control Mode
.................
375
In Cold Weather at High Altitude
................................
374
With a Dead Battery
................
461
State Emissions Testing
.............
490
Steam Coming from Engine
.......
463
Steering Wheel
Adjustments
............................
122
Anti-theft Column Lock
...........
125
Buttons
...........................
289, 300
Stereo Sound System
..........
172, 216
CONTINUED
Index
IX
INDEX
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu
