remote start ACURA RDX 2022 Owner's Manual

uuWhen Driving uStarting the Engine
446
Driving
■To stop the engine
Press and hold the button
for one second.
Go within the range,
and try again.
Amber LED: Blinks when any
button is pressed. Red LED:
●Comes on for one second to let you
know that the engine has stopped.
●Blinks when the remote is out of
the keyless access system range.
The engine will not stop.
1
Remote Engine Start*
The engine may not start by the remote engine start
if:
•You have disabled a remo te engine start setting
using the audio/information screen. 2Customized Features P. 359
•The power mode is not in VEHICLE OFF (LOCK).
•The transmission is in a position other than (P.
•The hood is open, or any door or the tailgate is
unlocked.
•The 12-volt battery temp is too low or the 12-volt
battery charge is too low.
•You have already used the remote twice to start
the engine.
•Another registered keyless remote is in the vehicle.
•There is any antenna failure.•The door is unlocked with the built-in key.
•The engine oil pressure is low.
•The engine coolant temper ature is extremely high.•The telematics unit malfunctions.
•The security system alarm is not set.
Before starting the engine, make sure to check the
door lock status using the remote. When you press
the button, wait for the green LED to blink. If
the red LED turns on, the doors and tailgate did not
lock, and the engine does not start.
* Not available on all models
22 ACURA RDX-31TJB6300.book 446 ページ ２０２１年８月２日　月曜日　午前１１時０分

Continued447
uuWhen Driving uStarting the Engine
Driving
1Remote Engine Start*
While the engine is running, the vehicle will
automatically preconditi on inside the vehicle.
When it is warm outside:
•The climate control system is activated in
recirculation mode.
•The seat ventilator* is activated.
When it is cold outside:
•The defroster is activated at a moderately warm
temperature.
•The rear defogger and door mirror heaters are
activated.
•The front seat heaters a nd heated steering wheel
are activated. 2Heated Steering Wheel
* P. 244
2 Front Seat Heaters/Ventilators* P. 245
* Not available on all models
22 ACURA RDX-31TJB6300.book 447 ページ ２０２１年８月２日　月曜日　午前１１時０分

uuWhen Driving uStarting the Engine
448
Driving
1. Depress and hold the brake pedal, then press the ENGINE START/STOP button.
2. Keeping your right foot on the brake pedal, put the transmission into
(D. Select
(R when reversing.
3. With the parking brake applied, release the brake pedal and gently depress the
accelerator pedal.
u Make sure the Parking Brake and Brake System indicator (red) goes off.
2Parking Brake P. 545
■Hill start assist system
Hill start assist keeps the brake engaged br iefly to help prevent the vehicle from
rolling on inclines as you move your fo ot from the brake pedal to the accelerator.
Put the transmission into
(D or (S when facing uphill, or (R when facing downhill,
then release the brake pedal.
You can turn the engine off when the vehicle is completely stopped.
1. Put the transmission into
(P.
2. Press the ENGINE START/STOP button.
■Starting to Drive
■Stopping the Engine
1Starting to Drive
You can also release the parking brake by pulling the
electric parking brake sw itch while depressing the
brake pedal. When facing downhill, you can start
your vehicle more smoothly by manually releasing it
with the electric parki ng brake switch than by
releasing it with th e accelerator pedal.
The engine stops when th e transmission is taken out
of
( P before the ENGINE START/STOP button is
pressed. Follow step 1 when starting to drive.
When the engine was started using the keyless remote*
When the engine was started using the keyless remote*
When the engine was started in any case
1Hill start assist system
Hill start assist may not prevent the vehicle from
rolling downhill on a very steep or slippe ry slope, and
will not operate on small inclines.
Hill start assist will operate even when VSA ® is
switched off.
Hill start assist is not a replacement for the parking
brake.
* Not available on all models
22 ACURA RDX-31TJB6300.book 448 ページ ２０２１年８月２日　月曜日　午前１１時０分

462
uuWhen Driving uAcura Integrated Dynamics System
Driving
■Next start-up mode
The mode for the next start-up is saved according to the following chart. Each keyless remote has its own mode saved.
*1:Interior accent light only available if equipped. Interior accent light changes with Dynamic Mode only when Accent Light Theme is
set to Dynamic Mode .
2Customized Features P. 359
2 Lighting area of the accent light P. 463
Last Dynamic ModeNext Dynamic ModeWelcome Accent Light Color*1
SNOWNORMALWhite
COMFORTCOMFORTBlue
NORMAL or SPORTNORMALWhite
22 ACURA RDX-31TJB6300.book 462 ページ ２０２１年８月２日　月曜日　午前１１時０分

635
Handling the Unexpected
This chapter explains how to handle unexpected troubles.
Tools.................................................. 636
If a Tire Goes Flat
Changing a Flat Tire ......................... 637
Temporarily Repairi ng a Flat Tire....... 645
Handling of the Jack ......................... 659
Engine Does Not Start Checking the Engine ........................ 660
If the Keyless Remote Battery is Weak ...661
Emergency Engine Stop ................... 662
Vehicles with a compact spare tire
Vehicles with temporary tire repair kit
Models with temporary tire repair kit
If the Battery Is DeadJump Starting Procedure .................. 663
Overheating ...................................... 665
Indicator, Coming On/Blinking
If the Engine Oil Pressure Low Warning
Appears ............................................. 667
If the Charging System Indicator Comes On .. 668If the Malfunction Indicator Lamp Comes On or Blinks ................................... 668
If the Brake System Indicator (Red) Comes On or Blinks ....................................... 669
If the Electric Power Steering (EPS) System
Indicator Comes On ........................... 670
If the Brake System Indicator (Red) Comes On or Blinks at the Same Time When the Brake
System Indicator (Amber) Comes On .....671
If the Low Tire Pressure/TPMS Indicator Comes On or Blinks ....................... 672
If the Transmission System Indicator Blinks along with the Warning Message .... 673
Fuses .................................................. 674
Emergency Towing ........................... 681
If You Cannot Unlock the Fuel Fill Door.. 682If You Cannot Open the Tailgate .... 683
Refueling ........................................... 684
22 ACURA RDX-31TJB6300.book 635 ページ ２０２１年８月２日　月曜日　午前１１時０分

660
Handling the Unexpected
Engine Does Not Start
Checking the Engine
If the engine does not start, check the starter.
Starter conditionChecklist
Starter doesn’t turn or turns
over slowly.
The battery may be dead. Check
each of the items on the right and
respond accordingly.Check for a message on the multi-information display.
●If the To Start, Hold Remote Near Start Button message appears
2If the Keyless Remote Battery is Weak P. 661
uMake sure the keyless remote is in its operating range.
2ENGINE START/STOP Button P. 193
The starter turns over normally
but the engine doesn’t start.
There may be a problem with a
fuse. Check each of the items on
the right and respond accordingly. Review the engine start procedure.
Follow its instructions, and try to start the engine again.
2
Starting the Engine P. 443
Check the immobilizer system indicator.
When the immobilizer system indicator is blinking, the engine cannot be started.
2Immobilizer System P. 183
Check the fuel level.
There should be enough fuel in the tank.
2 Fuel Gauge P. 136
Check the fuses.
Check all fuses, or have the vehicle checked by a dealer.
2Inspecting and Changing Fuses P. 680
If the problem continues:
2Emergency Towing P. 681
1Checking the Engine
If you must start the vehi cle immediately, use an
assisting vehicle or booster battery to jump start it.
2 If the Battery Is Dead P. 663
22 ACURA RDX-31TJB6300.book 660 ページ ２０２１年８月２日　月曜日　午前１１時０分

661
uuEngine Does Not Start uIf the Keyless Remote Battery is Weak
Handling the Unexpected
If the Keyless Remo te Battery is Weak
If the beeper sounds, the To Start, Hold Remote Near Start Button message
appears on the multi-information display, the ENGINE START/STOP button flashes,
and the engine won’t start, start the engine as follows:
1.Touch the center of the ENGINE START/
STOP button with the A logo on the keyless
remote while the ENGINE START/STOP
button is flashing. The buttons on the
keyless remote should be facing you.
u The ENGINE START/STOP button
flashes for about 30 seconds.
2. Depress the brake pedal and press the
ENGINE START/STOP button within 10
seconds after the beeper sounds and the
ENGINE START/STOP button changes
from flashing to on.
u If you don’t depress the pedal, the mode
will change to ACCESSORY.
22 ACURA RDX-31TJB6300.book 661 ページ ２０２１年８月２日　月曜日　午前１１時０分

700
Index
Cup Holders............................................... 235
Customized Features ................................ 359
D
Daytime Running Lights ........................... 200
Dead Battery ............................................. 663
Defaulting All the Settings ...................... 385
Defrosting the Windshield and Windows .................................................. 249
Devices that Emit Radio Waves ................ 689
Dimming Headlights ............................................... 197
Rearview Mirror ....................................... 213
Dipstick (Engine Oil) ................................. 594
Directional Signals (Turn Signal) .............. 196
Door Mirrors ............................................. 214
Doors ......................................................... 156
Auto Door Locking .................................. 172
Auto Door Unlocking ............................... 172
Keys ........................................................ 156
Locking/Unlocking the Doors from the Inside ..................................................... 169
Locking/Unlocking the Doors from the
Outside .................................................. 160
Lockout Prevention System ...................... 167
DOT Tire Quality Grading ........................ 615
Driving ....................................................... 429
Automatic Transmission ........................... 450
Braking .................................................... 545
Off-Highway Driving Guidelines ............... 441 Shifting Gear ........................................... 451
Starting the Engine.................................. 443
Driving Position Memory System ............ 210
Dust and Pollen Filter ............................... 626
Dynamic Mode Switch ............................. 460
E
Electric Parking Brake
Switch ..................................................... 545
Electric Power Steering (EPS) System Indicator............................................ 95, 670
Electronic Stability Control (ESC) ............. 471
Emergency ................................................ 681
Emissions Testing (Readiness Codes) ....... 691
Engine ....................................................... 688
Coolant ................................................... 598
If the Battery Is Dead ............................... 663
Oil ........................................................... 593
Remote Engine Start................................ 445
Starting ................................................... 443
Engine Compartment Cover .................... 592
Engine Coolant ......................................... 598
Adding to the Radiator ............................ 599
Adding to the Reserve Tank..................... 598
Overheating ............................................ 665
Temperature Gauge ................................ 136
Engine Oil ................................................. 593
Adding .................................................... 595
Checking................................................. 594
Displaying Oil Life .................................... 584 Engine Oil Pressure Low Warning ............ 667
Recommended Engine Oil ....................... 593
ENGINE START/STOP Button .................... 193
EPS (Electric Power Steering) System ...... 670
Exhaust Gas Hazard (Carbon Monoxide) .. 77
Exterior Care (Cleaning) .......................... 629
Exterior Mirrors ........................................ 214F
Features.................................................... 253
Filters Dust and Pollen....................................... 626
Oil .......................................................... 596
Flat Tire ............................................. 637, 645
Floor Mats ................................................ 628
Fluids Automatic Transmission .......................... 600
Brake ...................................................... 601
Engine Coolant ....................................... 598
Windshield Washer ................................. 602
FM/AM Radio ........................................... 293
Fog Lights Indicator ................................................... 98
Folding Down the Rear Seats .................. 222
Foot Brake ................................................ 549
Front Airbags (SRS) .................................... 49
Front Seats ................................................ 216
Adjusting ................................................ 216
Front Sensor Camera ............................... 541
22 ACURA RDX-31TJB6300.book 700 ページ ２０２１年８月２日　月曜日　午前１１時０分

702
Index
Indicators..................................................... 80
Adaptive Cruise Control (ACC) with Low
Speed Follow (Amber) ............................ 102
Adaptive Cruise Control (ACC) with Low Speed Follow (White/Green) ... 102, 503
Anti-lock Brake System (ABS) ..................... 94
Auto High-Beam ........................................ 98
Auto Idle Stop (Green) ............................... 90
Auto Idle Stop OFF..................................... 90
Auto Idle Stop Suspend ................. 90, 91, 92
Auto Idle Stop System (Amber) .................. 90
Automatic Brake Hold........................ 85, 550
Automatic Brake Hold System ............ 85, 550
Charging System ............................... 87, 668
Cruise Mode (White/Green) ..................... 101
Electric Power Steering (EPS) System .. 95, 670
Engine Oil Pressure Low Warning............. 667
Fog Light ................................................... 98
Gear Position ............................................. 87
High Beam................................................. 98
Immobilizer System .................................... 99
Lane Keeping Assist System (LKAS) (Amber) ................................................. 102
Lane Keeping Assist System (LKAS) (White/Green) ........................................ 102
Lights On ................................................... 98
Low Fuel (Amber) ...................................... 94
Low Tire Pressure/TPMS ..................... 97, 672
M (sequential mode ) Indicator/Gear
Selection Indicator ................................... 87
Maintenance Minder ............................... 101 Malfunction Indicator Lamp............... 86, 668
Parking Brake a
nd Brake System
(Amber) ........................................... 83, 671
Parking Brake and Brake System (Red)...................... 81, 82, 669, 671
Safety Support (Amber) ........... 103, 104, 105
Safety Support (Green/Gray) .................... 106
Seat Belt Reminder .............................. 39, 93
Security System Alarm ............................... 99
Super Handling-All Wheel Drive
TM
(SH-AWD ®) ............................................ 101
Supplemental Restraint System ............ 60, 95
System Message ...................................... 100
Transmission System.......................... 88, 673
Turn Signal and Hazard Warning ............... 98
Vehicle Stability Assist
TM (VSA ®) OFF .......... 96
Vehicle Stability AssistTM (VSA ®)
System ............................................ 96, 471
VSA ® OFF ................................................ 472
Information .............................................. 685
Instant Fuel Economy ............................... 141
Instrument Panel ........................................ 79
Brightness Control................................... 208
Interior Lights ........................................... 230
Interior Rearview Mirror .......................... 213
iPad ........................................................... 337
iPhone ....................................................... 337
iPod ................................................... 310, 337
J
Jack (Wheel Nut Wrench) ........................ 641
Jump Starting ........................................... 663
K
Key Number Tag ...................................... 158
Keyless Access System .............................. 160
Keyless Lockout Prevention ..................... 167
Keys ........................................................... 156
Lockout Prevention ................................. 167
Number Tag............................................ 158
Rear Door Won’t Open ........................... 171
Remote Transmitter ................................ 165
Two-way Keyless Remote ........................ 168
Types and Functions................................ 156
Kickdown (Automatic Transmission) ...... 450
Knee Airbags .............................................. 54
L
Lane Keeping Assist System (LKAS) ........ 522
LATCH (Child Seats) ............................. 69, 73
Legal Information .................................... 351
License Information ................................. 354
Lights ................................................ 197, 603
Automatic............................................... 198
Bulb Replacement ................................... 603
Daytime Running Lights .......................... 200
Fog Lights ............................................... 200
High Beam Indicator ................................. 98
22 ACURA RDX-31TJB6300.book 702 ページ ２０２１年８月２日　月曜日　午前１１時０分

704
Index
Parking Brake and Brake System Indicator (Red) ............................ 81, 82, 671
Parking Sensor System .............................. 556
Passenger Airbag Off Indicator ................. 61
Passing Indicators ..................................... 197
Playing Bluetooth ® Audio ........................ 316
Power Tailgate .......................................... 175
Power Windows ........................................ 186
Precautions While Driving ........................ 449
Driving Guidelines for Your Utility Vehicle................................................... 449
Rain ......................................................... 450
Pregnant Women ....................................... 44
Puncture (Tire) .................................. 637, 645
R
Radar Sensor............................................. 543
Radiator ..................................................... 599
Radio (AM/FM) .......................................... 293
Radio (SiriusXM ®)...................................... 297
Range ........................................................ 141
Readiness Codes (Emissions Testing) ....... 691
Rear Defogger/Heated Door Mirror
Button ...................................................... 207
Rear Seat Reminder .................................. 224
Rear Seats (Folding Down) ....................... 222
Rear Temperature Control Dial ............... 251
Rearview Mirror ........................................ 213
Refueling ........................................... 574, 684
Fuel Gauge .............................................. 136 Gasoline .......................................... 574, 686
Low Fuel Indicator ..................................... 94
Regulations ............................... 477, 615, 689
Remote Engine Start ................................ 445
Remote Transmitter ................................. 165
Replacement Battery ............................................ 623, 624
Bulbs ....................................................... 603
Fuses ....................................... 674, 677, 678
Rear Wiper Blade Rubber......................... 610
Tires ........................................................ 618
Wiper Blade Rubber ................................ 607
Reporting Safety Defects ......................... 690
Resetting a Trip Meter ............................. 140
Reverse Tilt Door Mirror .......................... 214
Road Departure Mitigation (RDM) ......... 530
On and Off.............................................. 532
S
Safe Driving ................................................ 31
Safety Check ............................................... 36
Safety Labels ............................................... 78
Safety Message ............................................. 3
Safety Support .......................................... 146
Seat Belts .................................................... 37
Adjusting the Shoulder Anchor.................. 43
Automatic Seat Belt Tensioners ................. 41
Checking................................................... 45
Fastening .................................................. 42 Installing a Child Seat
with a Lap/Shoulder
Seat Belt ................................................. 71
Pregnant Women...................................... 44
Reminder .................................................. 39
Warning Indicator ............................... 39, 93
Seat Heaters ............................................. 245
Seat Ventilators ........................................ 245
Seats .......................................................... 216
Adjusting ................................................ 216
Front Seats.............................................. 216
Lumbar Support ...................................... 216
Rear Seats ............................................... 222
Seat Control Interface ............................. 218
Seat Heaters ................................... 245, 246
Ventilators .............................................. 245
Security System ........................................ 183
Immobilizer System Indicator ..................... 99
Security System Alarm Indicator ................ 99
Selecting a Child Seat ................................ 68
Sequential Mode ...................................... 457
Setting the Clock ...................................... 154
SH-AWD ® (Super Handling-All Wheel
Drive
TM) ................................................... 474
Shift Button ........................................ 21, 451
Operation ......................................... 21, 453
Shifting (Transmission) ...................... 21, 451
Shoulder Anchor ........................................ 43
Side Airbags ............................................... 57
Side Curtain Airbags .................................. 59
SiriusXM ® Radio ....................................... 297
Smart Shortcuts ........................................ 278
22 ACURA RDX-31TJB6300.book 704 ページ ２０２１年８月２日　月曜日　午前１１時０分
