wiper blades ACURA RDX 2022 Owners Manual

Contents
This owner’s manual should be considered a permanent part of the
vehicle and should remain with the vehicle when it is sold.
The Navigation Manual is available online at owners.acura.com
(U.S.) or acura.ca (Canada). If you are the firs t registered owner
of your vehicle, you may request a complimentary printed
copy of the Navigation Manual within the first six months of
vehicle purchase. To request a copy, visit owners.acura.com. In
Canada, please request a copy from your Acura dealer.
This owner’s manual covers all models of your vehicle. You may find
descriptions of equipment and features that are not on your
particular model.
Images throughout this owner’s manu al (including the front cover)
represent features and equipment that are available on some, but
not all, models. Your particular mo del may not have some of these
features.
This owner’s manual is for vehicles sold in the United States and
Canada.
The information and specifications in cluded in this publication were
in effect at the time of approval for printing. Honda Motor Co., Ltd.
reserves the right, however, to discontinue or change specifications
or design at any time without notice and without incurring any
obligation.2 Safe Driving P. 31
For Safe Driving P. 32 Seat Belts P. 37 Airbags P. 46
2Instrument Panel P. 79
Indicators P. 80 Gauges and Displays P. 136
2Controls P. 153
Clock P. 154 Locking and Unlocking the Doors P. 156
Panoramic Roof P. 189
Seats P. 216
2 Features P. 253
Audio System P. 254 Audio System Basic Operation P. 260
Customized Features P. 359 HomeLink® Universal Transceiver P. 386
2 Driving P. 429
Before Driving P. 430 Towing a Trailer P. 435
Braking P. 545Parking Your Vehicle P. 554
Fuel Economy and CO2 Emissions P. 577 Turbo Engine Vehicle P. 578
2 Maintenance P. 579
Before Performing Maintenance P. 580 Maintenance MinderTM P. 583
Checking and Maintaining Wiper Blades P. 607
Climate Control System Main tenance P. 625 Cleaning P. 627
2Handling the Unexpected P. 635
Tools P. 636 If a Tire Goes Flat P. 637
Overheating P. 665 Indicator, Coming On/Blinking P. 667
If You Cannot Unlock the Fuel Fill Door P. 682
2 Information P. 685
Specifications P. 686 Identification Numbers P. 688
Warranty Coverages P. 693 Authorized Manuals P. 696
22 ACURA RDX-31TJB6300.book 4 ページ ２０２１年８月２日　月曜日　午前１１時０分

26
Quick Reference Guide
Maintenance (P 579)
Under the Hood (P 590)
●Check engine oil, engine coolant, and windshield washer
fluid. Add when necessary.
●Check brake fluid.●Check the battery condition monthly.
aPull the hood release handle under the corner of the
dashboard.
bLocate the hood latch lever, push it to the side, and then
raise the hood. Once you have raised the hood slightly, you
can release the lever.
cWhen finished, close the hood and make sure it is firmly
locked in place.
Lights (P 603)
●Inspect all lights regularly.
Wiper Blades (P 607)
●Replace blades if they leave streaks
across the windshield or become
noisy.
Tires (P 612)
●Inspect tires and wheels regularly.●Check tire pressures regularly.●Install snow tires for winter
driving.
22 ACURA RDX-31TJB6300.book 26 ページ ２０２１年８月２日　月曜日　午前１１時０分

204
uuOperating the Switches Around the Steering Wheel uWipers and Washers
Controls
Wipers and Washers
The windshield wipers and washers can be
used when the power mode is in ON.
■MIST
The wipers run at high speed until you release
the lever.
■Wiper switch (OFF, INT*1/AUTO*2, LO, HI)
Move the lever up or down to change the
wiper settings.
■Adjusting wiper operation*
Turn the adjustment ring to adjust the wiper
operation.
■Washer
Sprays while you pull the lever toward you.
When you release the lever for more than one
second, the spray stops, the wipers sweep two
or three more times to clear the windshield,
then stop.
*1 : Models with manual intermittent operation
*2 : Models with automatic intermittent operation
■Windshield Wipers/Washers1 Wipers and Washers
NOTICE
Do not use the wipers when the windshield is dry.
The windshield will get sc ratched, or the rubber
blades will get damaged.
NOTICE
Turn the washers off if no washer fluid comes out.
The pump may get damaged.
The wiper motor may stop motor operation
temporarily to prevent an overload. Wiper operation
will return to normal within a few minutes.
If the vehicle speeds up while the wipers are
operating intermittently, the length of the wipe
interval shortens.
When the vehicle speeds up, the wiper operation’s
shortest delay setting ( ) and the LO setting become
the same.
NOTICE
In cold weather, the blades may freeze to the
windshield.
Operating the wipers in th is condition may damage
the wipers. Use the defogge r or heated windshield
*
to warm the windshield, then turn the wipers on.
Models without automatic intermittent wipers
Intermittent Time
Adjustment Ring*
MIST
INT*1/AUTO*2OFF
LO: Low speed wipe
HI: High speed wipe Pull to
use
washer.
Lower speed, fewer sweeps
Higher speed, more sweeps
* Not available on all models
22 ACURA RDX-31TJB6300.book 204 ページ ２０２１年８月２日　月曜日　午前１１時０分

579
Maintenance
This chapter discusses basic maintenance.
Before Performing MaintenanceInspection and Maintenance ............ 580
Safety When Performing Maintenance ..581
Parts and Fluids Used in Maintenance Service ........................................... 582
Maintenance Minder
TM..................... 583
Maintenance Under the Hood Maintenance Items Under the Hood .. 590
Opening the Hood ........................... 591
Engine Compartment Cover ............. 592
Recommended Engine Oil ................ 593
Oil Check ......................................... 594
Adding Engine Oil ............................ 595 Changing the Engine Oi
l and Oil Filter .. 596
Engine Coolant ................................ 598
Transmission Fluid ............................ 600
Brake Fluid ....................................... 601
Refilling Window Washer Fluid......... 602
Replacing Light Bulbs ....................... 603Checking and Maintaining Wiper
Blades .......................................... 607
Checking and Maintaining Tires
Checking Tires ................................. 612
Tire and Loading Information Label .. 613
Tire Labeling .................................... 613
DOT Tire Quality Grading (U.S. Vehicles).. 615
Wear Indicators ............................... 617
Tire Service Life ................................ 617
Tire and Wheel Replacement ........... 618
Tire Rotation .................................... 619
Winter Tires ..................................... 620
Battery ............................................... 621
Remote Transmitter Care Replacing the Remote Battery .......... 623
Climate Control System Maintenance.. 625Cleaning
Interior Care .................................... 627
Exterior Care.................................... 629
Accessories and Modifications ........ 633
22 ACURA RDX-31TJB6300.book 579 ページ ２０２１年８月２日　月曜日　午前１１時０分

580
Maintenance
Before Performing Maintenance
Inspection and Maintenance
For your safety, perform all listed inspections and maintenance to keep your vehicle
in good condition. If you become aware of an y abnormality (noise, smell, insufficient
brake fluid, oil residue on the ground, etc.), have your vehicle inspected by a dealer.
(Note, however, that service at a dealer is not mandatory to keep your warranties in
effect.) Refer to the separate maintena nce booklet for detailed maintenance and
inspection information.
■Routine inspections
Perform inspections before long distance trips, when washing the vehicle, or when
refueling.
2 Maintenance P. 26
■Periodic inspections
• Check the brake fluid level monthly.
2 Checking the Brake Fluid P. 601
•Check the tire pressure monthly. Examin e the tread for wear and foreign objects.
2Checking and Maintaining Tires P. 612
•Check the operation of the exterior lights monthly.
2 Replacing Light Bulbs P. 603
•Check the condition of the wiper bl ades at least every six months.
2Checking and Maintaining Wiper Blades P. 607
■Types of Inspection and Maintenance
1Inspection and Maintenance
Maintenance, replacement, or repair of
emissions control devices and systems may be
done by any automotive repair establishment or
individuals using parts that are “certified” to
EPA standards.
According to state and fede ral regulations, failure to
perform maintenance on the maintenance main
items marked with # will not void your emissions
warranties. However, all ma intenance services should
be performed in accordan ce with the intervals
indicated by the mult i-information display.
2 Maintenance Service Items P. 587
If you want to perform complex maintenance tasks
that require more skills a nd tools, you can purchase a
subscription to the Service Express website at
www.techinfo.acura.com .
2 Authorized Manuals P. 696
If you want to perform ma intenance yourself, make
sure that you have the necessary tools and skills first.
After performing maintenanc e, update the records in
the separate maintenance booklet.
U.S. models
22 ACURA RDX-31TJB6300.book 580 ページ ２０２１年８月２日　月曜日　午前１１時０分

607Continued
Maintenance
Checking and Maintaining Wiper Blades
Checking Wiper Blades
If the wiper blade rubber has deteriorated, it will leave streaks, become noisy, and
the hard surfaces of the blade may scratch the window glass.
Changing the Front Wiper Blade Rubber
1.Set the power mode to VEHICLE OFF.
2. While holding the wiper switch in the MIST
position, set the power mode to ON, then
to VEHICLE OFF.
u Both wiper arms are set to the
maintenance position as shown in the
image.
3. Lift both wiper arms.
1Changing the Front Wiper Blade Rubber
NOTICE
Avoid dropping the wiper arm onto the windshield, it
may damage the wiper arm and/or the windshield.
22 ACURA RDX-31TJB6300.book 607 ページ ２０２１年８月２日　月曜日　午前１１時０分

608
uuChecking and Maintaining Wiper Blades uChanging the Front Wiper Blade Rubber
Maintenance
4. Press up on and hold the tab, then slide
the holder off the wiper arm.
5. Pull the end of the wiper blade in the
direction of the arrow in the image until it
is out of the holder’s end cap.
6. Pull the wiper blade in the opposite
direction to slide it out of the holder.
Tab
Holder
Wiper Arm
Wiper
Blade
End cap at
the bottom
Wiper Blade
Holder
22 ACURA RDX-31TJB6300.book 608 ページ ２０２１年８月２日　月曜日　午前１１時０分

609
uuChecking and Maintaining Wiper Blades uChanging the Front Wiper Blade Rubber
Maintenance
7. Insert the flat side of the new wiper blade
onto the bottom part of the holder. Insert
the blade all the way.
8. Install the end of the wiper blade into the
cap.
9. Slide the holder onto the wiper arm until it
locks.
10. Lower both wiper arms.
11. Set the power mode to ON and hold the
wiper switch in the MIST position until
both wiper arms return to the standard
position.
Holder Wiper
Blade
Cap
22 ACURA RDX-31TJB6300.book 609 ページ ２０２１年８月２日　月曜日　午前１１時０分

610
uuChecking and Maintaining Wiper Blades uChanging the Rear Wiper Blade Rubber
Maintenance
Changing the Rear Wiper Blade Rubber
1. Raise the wiper arm off.
2. Slide the wiper blade out from the end with
the indent.
3. Remove the retainers from wiper blade and
mount to a new rubber blade.1Changing the Rear Wiper Blade Rubber
NOTICE
Avoid dropping the wiper ar m, it may damage the
rear window.
Blade
Retainer
Rubber
22 ACURA RDX-31TJB6300.book 610 ページ ２０２１年８月２日　月曜日　午前１１時０分

611
uuChecking and Maintaining Wiper Blades uChanging the Rear Wiper Blade Rubber
Maintenance
4. Slide the new wiper bl ade onto the holder.
u Make sure it is engaged correctly, then
install the wiper blade assembly onto the
wiper arm.
22 ACURA RDX-31TJB6300.book 611 ページ ２０２１年８月２日　月曜日　午前１１時０分
