window Acura RL 2001 3.5 User Guide

Power Windows, Moonroof

The master control panel also con- tains these extra features:
AUTO — To open the driver's window fully, push the windowswitch firmly down and release it.
The window automatically goes all the way down. To stop the window
from going all the way down, pull back on the window switch briefly.
To open the driver's window only partially, push the window switchdown lightly and hold it. The window
will stop as soon as you release the
switch.

The AUTO function only works to lower the driver's window. To raise
the window, you must pull back on
the window switch and hold it until the window reaches the desired

position.
The MAIN switch controls power to
the passengers'windows. With thisswitch off, the passengers'windows
cannot be raised or lowered. The
MAIN switch does not affect the driv-
er's window. Keep the MAIN switch
off when you have children in the car
so they do not injure themselves by
operating the windows unintentional-
ly. The lights inside the switches
come on when you turn the parking
lights or headlights on.
The power window system has a key- off delay function. The windows willstill operate for up to ten minutes
after you turn off the ignition.
Opening either front door cancels
the delay function. You must turn
the ignition switch ON (II) again
before you can raise or lower the
windows. Moonroof
There are two switches on the ceiling near the front ceiling light.
The ignition switch must be ON (II).
To open the moonroof, pull the OPEN/CLOSE switch backward and
hold it until the moonroof reaches
the desired position.

CONTINUED

Instruments and Controls
OPEN/CLOSE
SWITCH

Sun Visor, Vanity Mirror

Sun Visor
To use the sun visor, pull it down. You can also use the sun visor at the side window. Remove the support
rod from the clip and swing the sun
visor toward the side window. In this
position, the sun visor can be extended by sliding out the

extension.
Make sure you put the sun visor

back in place when you are getting

into or out of the car. Do not use the
sun visor extension over the rear

view mirror.
Vanity Mirror

To use a vanity mirror on the back of the sun visor, pull up the cover.
The light beside the mirror comes on when you pull up the cover.
Instruments and Controls EXTENSION

Climate Control System

The button directs the main
air flow to the windshield for fasterdefrosting. It also overrides any
MODE selection you may have made. When you select the A/C
turns on automatically and thesystem selects Fresh Air mode. For
faster defrosting, manually set the
fan speed to high. You can also increase air flow to the windshield by
closing the side vents in the
dashboard. When you turn off by
pressing the button again, thesystem returns to its former settings.
Rear Window Defogger Button
This button turns the rear window defogger on and off (see page 71).
REAR WINDOW DEFOGGER BUTTONComfort and Convenience Features

Preparing to Drive

You should do the following checks and adjustments every day before
you drive your car.
1. Make sure all windows, mirrors, and outside lights are clean and
unobstructed. Remove frost, snow,or ice.
2. Check that the hood and trunk are
fully closed.

3. Visually check the tires. If a tire

looks low, use a gauge to check its
pressure.

4. Check that any items you may be

carrying with you inside are stored
properly or fastened down
securely.

5. Check the adjustment of the seat (see page 94 ).
6. Check the adjustment of the

inside and outside mirrors (see
page 99 ).

7. Check the adjustment of the

steering wheel (see page 7 1 ).

8. Make sure the doors are securely

closed and locked.

9. Fasten your seat belt. Check that

your passengers have fastened
their seat belts (see page 15 ).

10.Turn the ignition switch ON (II).

Check the indicator lights in the
instrument panel.

11.Start the engine (see page 181).
12.Check the gauges and indicator

lights in the instrument panel (see
page 53).

Driving

Parking

Always use the parking brake when
you park your car. The indicator on the instrument panel shows that the
parking brake is not fully released; itdoes not indicate that the parking
brake is firmly set. Make sure the
parking brake is set firmly or your car may roll if it is parked on an

incline.

Set the parking brake before you put
the transmission in Park. This keeps
the car from moving and putting pressure on the parking mechanism
in the transmission — making it
easier to move the shift lever out of
Park when you want to drive away. If the car is facing uphill, turn the
front wheels away from the curb.
If the car is facing downhill, turn the
front wheels toward the curb.
Make sure the parking brake is fully
released before driving away.
Driving with the parking brake
partially set can overheat or damage the rear brakes. Parking Tips Make sure the moonroof and the
windows are closed.
Turn off the lights.Place any packages, valuables, etc.,
in the trunk or take them with you.
Lock the doors with the key or the
remote transmitter. Check the
indicator on the driver's door to
verify that the security system is set.
Never park over dry leaves, tall
grass, or other flammable
materials. The three way catalytic converter gets very hot, and could
cause these materials to catch on

fire.

Driving

Driving in Bad Weather

Visibility — Being able to see clearly in all directions and being
visible to other drivers are important in all weather conditions. This is
more difficult in bad weather. To be seen more clearly during daylight
hours, turn on your headlights.
Inspect your windshield wipers and
washers frequently. Keep the wind- shield washer reservoir full of the
proper fluid. Have the windshield
wiper blades replaced if they start to streak the windshield or leave parts
unwiped. Use the defroster and air conditioning to keep the windows
from fogging up on the inside (see
pages 128 and 133). Traction — Check your tires
frequently for wear and properpressure. Both are important in
preventing "hydroplaning" (loss of
traction on a wet surface). In the
winter, mount snow tires on all four
wheels for the best handling.
Watch road conditions carefully, they can change from moment tomoment. Wet leaves can be as slip-
pery as ice. "Clear" roads can have
patches of ice. Driving conditionscan be very hazardous when the
outside temperature is near freezing.
The road surface can become covered with areas of water puddles
mixed with areas of ice, so your
traction can change without warning.
Be careful when downshifting. If
traction is low, you can lock up the drive wheels for a moment and cause
a skid. Be very cautious when passing, or
being passed by other vehicles. The spray from large vehicles reduces
your visibility, and the wind buffeting can cause you to lose control.
Driving

Spark Plugs, Battery

Specifications:
NGK:

DENSO:
PFR5L-11

PK16PR-L11

Spark Plug Gap:
0.043 in (1.1 mm )
Battery
Check the condition of your car's
battery monthly. You should check
the color of the test indicator window, and for corrosion on the terminals.
Check the battery condition bylooking at the test indicator window on the battery.
The label on the battery explains the test indicator's colors.
Maintenance TEST INDICATOR WINDOW

Storing Your Car

If you need to park your car for an extended period (more than one
month), there are several things you should do to prepare it for storage.
Proper preparation helps prevent deterioration and makes it easier to
get your car back on the road. If
possible, store your car indoors. Fill the fuel tank.
Change the engine oil and filter
(see page 219).
Wash and dry the exterior
completely.
Clean the interior. Make sure the
carpeting, floor mats, etc. are
completely dry.
Leave the parking brake off. Put
the transmission in Park. Block the rear wheels.
If the car is to be stored for a
longer period, it should be supported on jackstands so the
tires are off the ground.
Leave one window open slightly (if
the car is being stored indoors).
Disconnect the battery.
Support the front wiper blade
arms with a folded towel or rag so
they do not touch the windshield. To minimize sticking, apply a
silicone spray lubricant to all door
and trunk seals. Also, apply a vehicle body wax to the painted
surfaces that mate with the door
and trunk seals. Cover the car with a "breathable"
cover, one made from a porous
material such as cotton. Nonporous materials, such as
plastic sheeting, trap moisture,
which can damage the paint. If possible, run the engine for a
while periodically (preferably once
a month).
If you store your car for 12 months or longer, have your Acura dealer
perform the inspections called for in
the 24 months/30,000 miles (48,000
km) maintenance schedule (Normal Conditions) as soon as you take it
out of storage (see page 208). The
replacements called for in the
maintenance schedule are not
needed unless the car has actually
reached that time or mileage.

Maintenance

Appearance Care

Regular cleaning and polishing of
your Acura helps to keep it "new" looking. This section gives you hintson how to clean your car and
preserve its appearance: the paint,
brightwork, wheels and interior. Also included are several things you cando to help prevent corrosion. Exterior Care.................................. 264
Washing...................................... 264

Waxing........................................265

Aluminum Wheels..................... 265Paint Touch-up........................... 265
Interior Care................................... 266 Carpeting.................................... 266
Floor Mats.................................. 266

Fabric.......................................... 267

Vinyl............................................ 267
Leather........................................ 267

Seat Belts.................................... 267

Wood Trim................................. 268

Windows..................................... 268
Air Fresheners........................... 268
Corrosion Protection..................... 269
Body Repairs.................................. 270

Appearance Care

Interior Care
Dirt build-up in the loops of the seat
belt anchors can cause the belts to
retract slowly. Wipe the insides of
the loops with a clean cloth dampened in mild soap and warm
water or isopropyl alcohol.

Wood Trim
Clean the wood trim with a soft cloth
dipped in clear water and wipe it dry
with another soft cloth. Soap may leave a film that dulls the finish. Windows
Clean the windows, inside and out,
with a commercially-available glass cleaner. You can also use a mixtureof one part white vinegar to ten parts
water. This will remove the haze that builds up on the inside of the
windows. Use a soft cloth or paper
towels to clean all glass and clearplastic surfaces.

The rear window defogger and antenna wires are bonded to the inside

of the glass. Wiping vigorously up-and-

down can dislodge and break these

wires. When cleaning the rear window,

use gentle pressure and wipe side-to-
side.
Air Fresheners
If you want to use an air freshener/
deodorizer in the interior of your car,
it is best to use a solid type. Some
liquid air fresheners contain chemi- cals that may cause parts of the
interior trim and fabric to crack or discolor.
If you use a liquid air freshener,
make sure you fasten it securely so it does not spill as you drive.

Appearance Care
NOTICE
