Acura RL 2001 3.5 Owner's Manual

Malfunction Indicator Lamp

Readiness Codes
Your car has certain "readiness codes" that are part of the on-boarddiagnostics for the emissions
systems. In some states, part of the
emissions testing is to make sure
these codes are set. If they are not set, the test cannot be completed.
If your car's battery has been
disconnected or gone dead, these
codes are erased. It takes several
days of driving under various
conditions to set the codes again. If possible, do not take your car for a
state emissions test until the
readiness codes are set. See State
Emissions Testing on pages 311 and 312.

Taking Care of the Unexpected

Brake System Indicator

The Brake System Indicator normally comes on when you turn
the ignition switch ON (II). It is a
reminder to check the parking brake.It comes on and stays lit if you do not
fully release the parking brake. If it comes on at any other time, it
indicates a problem with the car's
brake system. In most cases, the
problem is a low fluid level in the
brake fluid reservoir. Press lightly on
the brake pedal to see if it feels
normal. If it does, check the brake
fluid level the next time you stop at a service station (see page 230 ). If the
fluid level is low, take the car to your dealer and have the brake system
inspected for leaks or worn brake

pads.

However, if the brake pedal does not
feel normal, you should take immediate action. Because of the
brake system's dual-circuit design, a
problem in one part of the system
will still give you braking at two
wheels. You will feel the brake pedal
go down much farther before the car
begins to slow down, and you will
have to press harder on the pedal.
The distance needed to stop will be much longer. Slow down by shifting to a lower
gear, and pull to the side of the road
when it is safe. Because of the
longer distance needed to stop, it is
hazardous to drive the car. You should have it towed, and repaired as
soon as possible. (See Emergency
Towing on page 296 .)
If you must drive the car a shortdistance in this condition, drive
slowly and cautiously.
If the ABS indicator and the VSA system indicator come on with this
indicator, have the car inspected by
your dealer immediately.
Taking Care of the Unexpected

BRAKE SYSTEM INDICATOR*

"U.S. indicator shown

Closing the Moonroof

If the electric motor will not close
the moonroof, do the following:
1. Check the fuse for the moonroof motor (see page 292). If the fuse
is blown, replace it with one of the
same or lower rating.
2. Try closing the moonroof. If the new fuse blows immediately or the
moonroof motor still does not
operate, you can close the
moonroof manually.
3. Get the moonroof wrench out of the tool kit in the trunk.
4. Remove the lens from the rear ceiling light (see page 259). 5. Remove the plug in the center of
the rear ceiling light. 6. Insert the moonroof wrench into
the socket behind this plug. Turn
the wrench until the moonroof is
fully closed.
7. Remove the wrench. Replace the
plug and lens.

Taking Care of the Unexpected
PLUG
SOCKET

Fuses

All the electrical circuits in your car have fuses to protect them from ashort circuit or overload. These
fuses are located in two fuse boxes.
The interior fuse box is underneaththe dashboard on the driver's side.
To open it, turn the knob as shown. The under-hood fuse box is located
in the engine compartment next to
the battery. To open it, push the tab
as shown.

Taking Care of the Unexpected

INTERIOR
KNOB
UNDER-HOOD

TAB

Fuses
Checking and Replacing Fuses

If something electrical in your car
stops working, the first thing you
should check for is a blown fuse.
Determine from the chart on pages 294 and 295 , or the diagram on the
fuse box lid, which fuse or fuses control that component. Check those
fuses first, but check all the fuses
before deciding that a blown fuse is not the cause. Replace any blown
fuses and check the component's
operation.

1. Turn the ignition switch to LOCK (0). Make sure the headlights and
all other accessories are off.
2. Remove the cover from the fuse box. FUSE

3. Check each of the large fuses in
the under-hood fuse box by

looking through the top at the wire

inside. Removing these fuses

requires a Phillips-head screw-

driver.
4. Check the smaller fuses in the
under-hood fuse box and all the
fuses in the interior fuse box by pulling out each fuse with the fuse
puller provided in the door of theinterior fuse box.
Taking Care of the Unexpected BLOWN
FUSE

PULLER

Fuses

5. Look for a burned wire inside the fuse. If it is burned, replace it with
one of the spare fuses of the same
rating or lower. If you cannot drive the car without
fixing the problem, and you do not
have a spare fuse, take a fuse of the same rating or a lower rating from
one of the other circuits. Make sure
you can do without that circuit
temporarily (such as the cigarette
lighter or radio).
If you replace the blown fuse with aspare fuse that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
fuse with one of the correct rating as soon as you can.
Replacing a fuse with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a replace-
ment fuse with the proper rating for the circuit, install one with a lower rating.
6. If the replacement fuse of the
same rating blows in a short time,

there is probably a serious electrical problem in your car.
Leave the blown fuse in that
circuit and have your car checked
by a qualified mechanic.
If the radio fuse is removed, the audio system will disable itself. The
next time you turn on the radio you
will see "Code" in the frequency display. Use the Preset buttons to
enter the five-digit code (see page
164).
Taking Care of the Unexpected
CONTINUED

BLOWN

NOTICE

Fuses

UNDER-HOOD FUSE BOX

Taking Care of the Unexpected

Fuses

INTERIOR FUSE BOX
* 1 : On Canadian models
Taking Care of the Unexpected

Emergency Towing

If your car needs to be towed, call a
professional towing service or, if you
belong to one, an organization that
provides roadside assistance. Never tow your car behind another vehicle
with just a rope or chain. It is very
dangerous.

There are three popular types of professional towing equipment.

Flat-bed Equipment — The operator

loads your car on the back of a truck.
This is the best way to transport
your Acura.

Wheel-lift Equipment — The tow

truck uses two pivoting arms that go
under the tires (front or rear) and lift
them off the ground. The other two
tires remain on the ground. This is

an acceptable way to tow your

Acura.
Sling-type Equipment — The tow

truck uses metal cables with hooks on the ends. These hooks go around
parts of the frame or suspension and the cables lift that end of the car off
the ground. Your car's suspensionand body can be seriously damaged.
This method of towing is
unacceptable.

If your Acura cannot be transported
by flat-bed, it should be towed by
wheel-lift equipment with the front
wheels off the ground. If, due to damage, your car must be towed
with the front wheels on the ground, do the following.
Release the parking brake. Shift the transmission to Neutral.
Improper towing preparation will

damage the transmission. Follow the

above procedure exactly. If you cannot

shift the transmission or start the
engine, your car must be transported
with the front wheels off the ground.

With the front wheels on the ground, it is best to tow the car no farther
than 50 miles (80 km), and keep the speed below 35 mph (55 km/h).
Taking Care of the Unexpected
NOTICE

Emergency Towing
If you decide to tow your car with all
four wheels on the ground, make sure you use a properly-designed and
attached tow bar. Prepare the car for
towing as described above, and leave
the ignition switch in Accessory (I) so the steering wheel does not lock.
Make sure the radio and any items
plugged into the accessory power socket are turned off so they do not
run down the battery.

The steering system can be damaged if
the steering wheel is locked. Leave the
ignition switch in Accessory (I), and
make sure the steering wheel turns
freely before you begin towing. Trying to lift or tow your car by the
bumpers will cause serious damage. The bumpers are not designed to

support the car's weight.

Taking Care of the Unexpected

NOTICE
NOTICE
