Important Safety Precautions
You'll find many safely recommendations throughout this
section, and throughout this manual.
The recommendations on this page are the ones we consider to be the
most important.
Always Wear Your Seat Belt A seat belt is your best protection in all types of collisions. Airbags
supplement seat belts, but airbags
are designed to inflate only in a
moderate to severe frontal collision.
So even though your car is equipped
with airbags, make sure you and
your passengers always wear your seat belts, and wear them properly. (See page 15.)
Restrain All Children Children are safest when they are
properly restrained in the back seat,
not the front seat. A child who is too small for a seat belt must be properly
restrained in a child safety seat. (See
page 20.) Be Aware of Airbag Hazards
While airbags can save lives, they can cause serious or fatal injuries to
occupants who sit too close to them,
or are not properly restrained.
Infants, young children, and short
adults are at the greatest risk. Besure to follow all instructions and
warnings in this manual. (See page 9.)

Don't Drink and Drive

Alcohol and driving don't mix. Even one drink can reduce your ability to
respond to changing conditions, and
your reaction time gets worse with every additional drink. So don't drink
and drive, and don't let your friends
drink and drive, either. Control Your Speed
Excessive speed is a major factor in
crash injuries and deaths. Generally,
the higher the speed the greater the risk, but serious accidents can alsooccur at lower speeds. Never drive
faster than is safe for current conditions, regardless of the
maximum speed posted.
Keep Your Car in Safe Condition
Having a tire blowout or amechanical failure can be extremely
hazardous. To reduce the possibility of such problems, check your tire
pressures and condition frequently,and perform all regularly scheduled
maintenance. (See page 206.)

Driver and Passenger Safety

Fuel Economy

The condition of your car and your driving habits are the two most
important things that affect the fuel
mileage you get.
Car Condition
Always maintain your car according to the maintenance schedule. This
will keep it in top operating condition.
An important part of that mainte- nance is the Owner Maintenance
Checks (see page 215 ). For
example, an underinflated tire
causes more "rolling resistance,"
which uses fuel. It also wears out
faster, so check the tire pressure at least monthly.
In winter, the build-up of snow on
your car's underside adds weight and
rolling resistance. Frequent cleaning
helps your fuel mileage and reduces
the chance of corrosion. Driving Habits
You can improve fuel economy by driving moderately. Rapid acceler-
ation, abrupt cornering, and hard
braking use more fuel.
Always drive in the highest gear that allows the engine to run and acceler-
ate smoothly.
Depending on traffic conditions, try
to maintain a constant speed. Every
time you slow down and speed up,
your car uses extra fuel. Use the cruise control, when appropriate, to
increase fuel economy. A cold engine uses more fuel than a
warm engine. It is not necessary to"warm-up" a cold engine by letting it
idle for a long time. You can drive
away in about a minute, no matter
how cold it is outside. The engine
will warm up faster, and you get
better fuel economy. To cut down on the number of "cold starts," try to
combine several short trips into one.
The air conditioning puts an extra load on the engine which makes it
use more fuel. Turn off the A/C orset the climate control to a higher
temperature to cut down on air
conditioning use. Use the flow-
through ventilation when the outside air temperature is moderate.

Before Driving

Accessories and Modifications

Modifications Do not remove any original
equipment or modify your car in any
way that would alter its design or operation. This could make your car
unsafe and illegal to drive.
For example, do not make any
modifications that would change the
ride height of your car, or install
wheels and tires with a different overall diameter.
Such modifications can adversely
affect handling, and interfere with
the operation of the car's anti-lock
brakes and other systems.
In addition, any modifications that
decrease ground clearance increase
the chance of undercarriage parts striking a curb, speed bump, or other
raised object, which could cause
your airbags to deploy. Do not modify your steering wheel
or any other part of your
Supplemental Restraint System.
Modifications could make the
system ineffective.
Additional Safety Precautions
Do not attach or place objects on

the front airbag covers. Any object

attached to or placed on the covers
marked "SRS AIRBAG," in the
center of the steering wheel and
on top of the dashboard, could
interfere with the proper operation of the airbags. Or, if the airbags
inflate, the objects could be
propelled inside the car and hurt
someone.
Do not attach hard objects on or

near a front door. If a side airbag
inflates, a cup holder or other hard
object attached on or near the door could be propelled inside the
car and hurt someone.
Do not place any objects over theoutside edge of a front seat-back.
Covering the outside edge of a
front seat-back, with a non-Acura seat cover for example, could
prevent the airbag from inflating
properly.

Before Driving

Towing a Trailer

Additional Trailer Equipment
Many states and Canadian provinces
require special outside mirrors when
towing a trailer. Even if they don't,
you should install special mirrors if
you cannot clearly see behind you, or if the trailer creates a blind spot.
Ask your trailer sales or rental agency if any other items are
recommended or required for your

towing situation.
Pre-Tow Checklist
When preparing to tow, and before driving away, be sure to check the
following:
The vehicle has been properlyserviced, and the tires, brakes,
suspension, and cooling system
are in good operating condition.
All weights and loads are within limits (see pages 196 and 197 ). The hitch, safety chains, and any
other attachments are secure. All items on and in the trailer are
properly secured and cannot shift
while you drive. The lights and brakes on your
vehicle and the trailer are workingproperly. Your vehicle tires and spare are
properly inflated (see page 244 ),and the trailer tires and spare are
inflated as recommended by thetrailer maker.

Driving

Maintenance

This section explains why it is important to keep your car well
maintained and to follow basic
maintenance safety precautions.
This section also includes Maintenance Schedules for normal
driving and severe driving conditions,
a Maintenance Record, and instruc-
tions for simple maintenance tasks
you may want to take care of
yourself.
If you have the skills and tools to per-
form more complex maintenance
tasks on your Acura, you may want
to purchase the Service Manual. See
page 319 for information on how to obtain a copy, or see your Acura

dealer.
Maintenance Safety....................... 204
Important Safety Precautions.. 205
Maintenance Schedule.................. 206
Required Maintenance Record.... 213 Owner Maintenance Checks........ 215
Fluid Locations............................... 216

Engine Oil...................................... 217
Adding Oil................................... 217
Recommended Oil.................... 217
Synthetic Oil.............................. 218

Additives.................................... 218

Changing the Oil and Filter...... 219
Cooling System.............................. 221 Adding Engine Coolant............. 221Replacing Engine Coolant........ 223
Windshield Washers..................... 227
Automatic Transmission Fluid..... 228 Differential Oil.............................. 229

Brake Fluid.................................... 230
Brake System............................. 230
Power Steering............................... 230

Hood Latch.................................... 231

Air Cleaner Element...................... 231 Spark Plugs..................................... 233

Replacement.............................. 233
Specifications............................ 236
Battery............................................ 236
Wiper Blades.................................. 239
Air Conditioning System............... 241
Air Conditioning Filter.................. 242
Drive Belts...................................... 242
Timing Belt..................................... 243
Tires................................................ 243
Inflation..................................... 243

Inspection................................... 245
Maintenance............................... 246
Tire Rotation.............................. 246
Replacing Tires and Wheels .... 247
Wheels and Tires....................... 248
Winter Driving........................... 248
Snow Tires............................ 249

Tire Chains.............................
249
Lights.............................................. 250 Replacing Bulbs......................... 252
Storing Your Car............................

261

Maintenance

Timing Belt, Tires

Timing Belt
The timing belt and balancer belt should normally be replaced at the
intervals shown in the maintenance
schedule.

Replace these belts at 60,000 miles (U.S.) or 100,000 km (Canada) if you
regularly drive your car in one or
more of these conditions:
In very high temperatures
(over 110°F, 43°C).
In very low temperatures

(under — 20°F, — 29°C).

Tires
To safely operate your car, your tiresmust be the proper type and size, in
good condition with adequate tread, and correctly inflated. The following
pages give more detailed information on how and when to check air
pressure, how to inspect your tires
for damage and wear, and what to do
when your tires need to be replaced.
Inflation

Keeping the tires properly inflated
provides the best combination of
handling, tread life and riding comfort. Underinflated tires wear
unevenly, adversely affect handling
and fuel economy, and are more
likely to fail from being overheated. Overinflated tires can make your car
ride more harshly, are more prone to damage from road hazards, and wear

unevenly.

We recommend that you visually check your tires every day. If you
think a tire might be low, check it immediately with a tire gauge.

CONTINUED

Maintenance

Using tires that are excessively
worn or improperly inflated can
cause a crash in which you canbe seriously hurt or killed.
Follow all instructions in this

owner's manual regarding tire
inflation and maintenance.

Tires

Use a gauge to measure the air
pressure at least once a month. Even
tires that are in good condition may
lose one to two psi (10 to 20 kPa, 0.1 to 0.2 kgf/cm2) per month.
Remember to check the spare tire at
the same time you check all the other tires.
Check the pressure in the tires when
they are cold. This means the car has been parked for at least three
hours. If you have to drive the car
before checking the tire pressure,
the tires can still be considered "cold" if you drive less than 1 mile
(1.6 km).
If you check the pressure when the
tires are hot (the car has been driven several miles), you will see readings

4 to 6 psi
(30
to
40 kPa,
0.3 to 0.4

kgf/cm2) higher than the cold reading. This is normal. Do not let
air out to match the specified cold
pressure. The tire will be
underinflated.

You should get your own tire pressure gauge and use it whenever
you check your tire pressures. This
will make it easier for you to tell if a pressure loss is due to a tire problem
and not due to a variation between

gauges.
Recommended Tire Pressures for
Normal Driving

The following chart shows the recommended cold tire pressures formost normal driving conditions andspeeds. Tire pressures for high
speed driving are the same as for
normal driving.
The compact spare tire pressure is:60 psi (420 kPa , 4.2 kgf/cm2)
These pressures are also given on the tire information label on thedriver's doorjamb.

Maintenance

Tires

Tubeless tires have some ability to self-seal if they are punctured.
However, because leakage is often
very slow, you should look closely for punctures if a tire starts losing

pressure.
Inspection
Every time you check inflation, you
should also examine the tires for
damage, foreign objects, and wear.
You should look for:
Bumps or bulges in the tread orside of the tire. Replace the tire if
you find either of these conditions. Cuts, splits, or cracks in the side
of the tire. Replace the tire if you
can see fabric or cord.
Excessive tread wear. Your car's tires have wear indicators
molded into the tread. When thetread wears down to that point, you
will see a 1/2 inch (12.7 mm) wide band running across the tread. This shows there is less than 1/16 inch (1.6 mm) of tread left on the tire. A
tire that is this worn gives very little
traction on wet roads. You should
replace the tire if you can see the
tread wear indicator in three or more
places around the tire.

Maintenance

INDICATOR LOCATION MARKS
TREAD WEAR INDICATORS

Tires

Maintenance

In addition to proper inflation,
correct wheel alignment helps todecrease tire wear. If you find a tire
is worn unevenly, have your dealer
check the wheel alignment.
The tires were properly balanced by the factory. They may need to be
rebalanced at some time before theyare worn out. Have your dealer
check the tires if you feel a consis-
tent vibration while driving. A tire should always be rebalanced if it is
removed from the wheel for repair. Make sure the installer balances the
wheels when you have new tires installed. This increases riding
comfort and tire life. Your car'soriginal tires were dynamic or "spin"
balanced at the factory. For best
results, have the installer perform a dynamic balance.

Improper wheel weights can damageyour vehicle 's aluminum wheels. Use
only Genuine Acura wheel weights for
balancing.
Tire Rotation
To help increase tire life and distribute wear more evenly, youshould have the tires rotated every
7,500 miles (12,000 km). Move the
tires to the positions shown in the chart each time they are rotated.

Maintenance
Front

NOTICE
(For Non-directional

Tires and Wheels)
(For Directional

Tires and Wheels)
Front

Taking Care of the Unexpected

This section covers the more- common problems that motorists
experience with their vehicles. It
gives you information about how to safely evaluate the problem and what
to do to correct it. If the problem has stranded you on the side of the road,
you may be able to get going again. If not, you will also find instructions
on getting your car towed. Compact Spare Tire....................... 272
Changing a Flat Tire ..................... 273
If Your Engine Won't Start........... 278 Nothing Happens or the Starter Motor OperatesVery Slowly......................... 278
The Starter Operates Normally.................................
279

Jump
Starting................................. 280
If Your Engine Overheats............. 283
Low Oil Pressure Indicator.......... 285 Charging System Indicator........... 286
Malfunction Indicator Lamp ........ 287
Brake System Indicator................ 289
Closing the Moonroof................... 290

Fuses............................................... 291
Checking and Replacing........... 292

Emergency Towing....................... 296

Taking Care of the Unexpected
