Your Car at a Glance
WINDSHIELD WIPERS/WASHERS
(P.
68, 70) HAZARD WARNING LIGHTS
(P. 70)
VEHICLE STABILITY
ASSIST SYSTEM OFF SWITCH
(P. 192)
CRUISE CONTROL
(P. 73)
INSTRUMENT PANEL BRIGHTNESS
(P. 66)
STEERING WHEEL
ADJUSTMENTS
(P. 71)
HEADLIGHTS/TURN SIGNALS
(P.
63, 66) FOG LIGHTS
(P.
67)REAR WINDOW DEFOGGER
(P. 71)
Page 54 of 333
Instruments and Controls
This section gives information about the controls and displays thatcontribute to the daily operation of
your Acura. All the essential controls are within easy reach.
Control Locations............................ 52
Indicator Lights................................ 53 Gauges.............................................. 58 Speedometer................................ 58
Tachometer.................................. 58
Odometer...................................... 59
Trip Meter/Outside Temperature Indicator............ 59
Temperature Gauge.................... 60 Fuel Gauge................................... 60
Maintenance Required Indicator.................................... 61
Controls Near the Steering Wheel........ 62
Headlights.................................... 63
Automatic Lighting..................... 64 Daytime Running Lights............. 65
Instrument Panel Brightness..... 66
Turn Signals................................. 66
Fog Lights.................................... 67
Windshield Wipers...................... 68 Windshield Washers................... 70
Hazard Warning........................... 70
Rear Window Defogger.............. 71
Steering Wheel Adjustments..... 71
Steering Wheel Controls ................ 73
Cruise Control.............................. 73
Remote Audio Controls .............. 76
Keys and Locks................................ 77
Keys...............................................77
Immobilizer System..................... 78
Ignition Switch............................. 80
Power Door Locks....................... 81
Remote Transmitter.................... 82
Childproof Door Locks............... 85
Trunk............................................ 86
Emergency Trunk Opener......... 87Glove Box..................................... 88
HomeLink Universal Transmitter......... 89
Customer Assistance.................. 89
Important Safety Precautions.... 89
Training the Transmitter............ 90
Training With a Rolling Code
System.......................................92
Erasing Codes.............................. 93
Seat Adjustments............................. 94 Driver's Seat Adjustments.......... 94
Driver's Lumbar Support............ 96
Front Passenger's SeatAdjustments............................. 96
Head Restraints........................... 96
Armrest............................................. 97
Mirrors.............................................. 99
Adjusting the Power Mirrors..... 99
Driving Position Memory
System......................................... 101
Seat Heaters................................... 103
Ski Sleeve........................................ 104
Power Windows............................. 106
Moonroof........................................ 107
Parking Brake................................ 109
Digital Clock................................... 109Sunglasses Holder......................... 111
Beverage Holder............................ 112Console Compartment.................. 113
Coin Box......................................... 113
Sun Visor......................................... 114
Vanity Mirror................................. 114
Accessory Power Socket.............. 115 Cigarette Lighter........................... 116
Ashtrays.......................................... 117 Ceiling Lights................................. 118
Courtesy Lights............................. 119
Instruments and Controls
Page 65 of 333
Controls Near the Steering Wheel
The two levers on the steering column contain controls for driving
features you use most often. The left
lever controls the turn signals, headlights, and high beams. The
right lever controls the windshield
washers and wipers.
The switch for the hazard warning lights is on the dashboard to the
right of the steering column.
The controls under the left air vent are for the cruise control, instrument
panel brightness and the VSA
System.
The switches for the rear window defogger and fog lights are under
the audio system.
The steering wheel adjustment switch on the side of the steering
column allows you to tilt and
telescope the steering wheel.
Instruments and Controls
VEHICLE
STABILITY
ASSIST SYSTEM
OFF SWITCH
HEADLIGHTS/
TURN SIGNALS HAZARD WARNING
LIGHTS WINDSHIELD
WIPERS/WASHERS
REAR WINDOW
DEFOGGER
HORN
FOG
LIGHTS
INSTRUMENT
PANEL
BRIGHTNESS
STEERING WHEEL
ADJUSTMENTS
CRUISE
CONTROL
Page 71 of 333
Controls Near the Steering Wheel
Windshield Wipers
The right lever controls the wind- shield wipers and washers. The
rotary switch at the end of the lever
has three positions: INT: intermittent
: low speed
: high speed
In intermittent, the wipers operate
every few seconds. The sweep
interval will change slightly with
speed; getting shorter as you drive
faster. In low speed and high speed,
the wipers run continuously.
You can vary how often the wipers
sweep the windshield by turning the
INT TIME ring next to the rotary
switch.
If you turn the INT TIME ring to the shortest delay, the wipers will
change from intermittent to low speed operation when vehicle speed
exceeds 12 mph (20 km/h).
Instruments and Controls
Page 72 of 333
Controls Near the Steering Wheel
To operate the wipers in mist mode, push the control lever down. The
wipers run at high speed until you release the lever. This gives you a
quick way to clear the windshield.
Wiper Arms Winter Position
The windshield wiper arms have two
parked positions: Winter and
Summer. In the winter position, thearms sit slightly above the edge of
the hood. This reduces the possibili-
ty of damage to the wiper arms or
windshield wiper motor by a build-up of snow and ice.
Adjust the wiper arms to the winter position by grasping either arm near
the pivot. Pull on the arm, parallel to
the windshield, until it locks in the
higher position. Push the arm in theother direction to return the wipers
to the summer position. A heavy build-up of snow or ice on
the wiper arms will cause them toautomatically park in the winter
position.
Instruments and Controls
WIPER ARMS
Page 73 of 333
Controls Near the Steering Wheel
Windshield Washers
To clean the windshield, pull back on the wiper control lever. The washersspray until you release the lever. The
wipers run at low speed while you're pulling the lever, then complete one
more sweep of the windshield after
you release it. Hazard Warning
Push the red button to the left of the
clock to turn on the hazard warning
lights (four-way flashers). This causes all four outside turn signals
and both indicators in the instrument
panel to flash. Use the hazard
warning lights if you need to park in a dangerous area near heavy traffic,
or if your car is disabled.
Instruments and Controls
Cars with navigation system
Page 198 of 333
Driving in Bad Weather
Visibility — Being able to see clearly in all directions and being
visible to other drivers are important in all weather conditions. This is
more difficult in bad weather. To be seen more clearly during daylight
hours, turn on your headlights.
Inspect your windshield wipers and
washers frequently. Keep the wind- shield washer reservoir full of the
proper fluid. Have the windshield
wiper blades replaced if they start to streak the windshield or leave parts
unwiped. Use the defroster and air conditioning to keep the windows
from fogging up on the inside (see
pages 128 and 133). Traction — Check your tires
frequently for wear and properpressure. Both are important in
preventing "hydroplaning" (loss of
traction on a wet surface). In the
winter, mount snow tires on all four
wheels for the best handling.
Watch road conditions carefully, they can change from moment tomoment. Wet leaves can be as slip-
pery as ice. "Clear" roads can have
patches of ice. Driving conditionscan be very hazardous when the
outside temperature is near freezing.
The road surface can become covered with areas of water puddles
mixed with areas of ice, so your
traction can change without warning.
Be careful when downshifting. If
traction is low, you can lock up the drive wheels for a moment and cause
a skid. Be very cautious when passing, or
being passed by other vehicles. The spray from large vehicles reduces
your visibility, and the wind buffeting can cause you to lose control.
Driving
Page 243 of 333
Wiper Blades
3. Remove the blade from its holder
by grasping the tabbed end of theblade. Pull firmly until the tabscome out of the holder.
4. Examine the new wiper blades. If
they have no plastic or metal rein-forcement along the back edge,
remove the metal reinforcement strips from the old wiper blade and
install them in the slots along the
edge of the new blade.
5. Slide the new wiper blade into the
holder until the tabs lock.
6. Slide the wiper blade assembly
onto the wiper arm. Make sure it
locks in place.
7. Turn the ignition switch ON (II)
and return the windshield wipers
to their park position.
Maintenance
BLADE
BLADE
REINFORCEMENT
Page 332 of 333
Index
Fluid Selection............................ 228
Identification Number............... 301
Shifting the Automatic.............. 182
Treadwear...................................... 304
Trip Meter........................................ 59
Trunk................................................. 86
Emergency Trunk Opener......... 87
Opening the.................................. 86
Open Monitor Light.................... 57
Turn Signals..................................... 66
Underside. Cleaning...................... 269
Unexpected, Taking Care
of the........................................... 271
Uniform Tire Quality Grading..... 304
Unleaded Gasoline......................... 168
Upholstery Cleaning...................... 267
Used Oil, How to Dispose of........ 220
Vanity Mirror................................. 114
Vehicle Capacity Load .................. 177
Vehicle Dimensions....................... 302
Vehicle Identification Number..... 300
Vehicle Stability Assist (VSA)
System..................................... 191
VSA System Indicator........ 56, 192
VSA
Activation Indicator.... 56, 191
VSA Off Switch.......................... 192
Vehicle Storage.............................. 261
Ventilation...................................... 122
VIN.................................................. 300
Vinyl Cleaning................................ 267
Viscosity, Oil................................... 218
WARNING, Explanation of.............. ii
Warning Labels, Location of.......... 50
Warranty Coverages*................... 316
Washer, Windshield Checking the Fluid Level......... 227
Operation...................................... 70
Washing.......................................... 264
Waxing and Polishing................... 265
Wheels Adjusting the Steering................ 71
Alignment and Balance............. 246
Cleaning Aluminum Alloys....... 265
Compact Spare........................... 272
Wrench....................................... 274
Windows
Cleaning...................................... 267
Operating the Power................. 106
Rear, Defogger............................ 71
Windshield Cleaning........................................ 68
Defroster............................ 128,
133
Washers........................................
70
Wipers, Windshield
Changing Blades........................ 239
Operation...................................... 68
Wood Trim..................................... 267
Worn Tires..................................... 245
Wrecker, Emergency Towing...... 296
* U.S. and Canada only
