When you f inish a command
sequence, the HFL goes back to
its main menu. For example, when
you store the name, ‘‘Eric,’’ the
HFL response is, ‘‘Eric has been
stored.’’ The next time you press
the Talk button, you will be at the
main menu.
If nothing is said while the HFL is
listening f or a command, the HFL
will time out and stop its voice
recognition. The next time you
press the Talk button, the HFL
begins listening f rom the point at
which it timed out. To go back one step in a command
process, say, ‘‘Go back,’’ or press
the Back button.
To end a command sequence at
any time, press and hold the Back
button, or press and release the
Talk button, wait f or the beep, and
say, ‘‘Cancel.’’ The next time you
press the Talk button, the HFL
begins f rom its main menu.
Many commands can be spoken
together. For example, you can
say, ‘‘Dial 123-456-7891.’’ To hear a list of available options
at any time, press the Talk button,
wait f or the beep, and say, ‘‘Hands
f ree link help.’’
To enter a string of numbers in a
Call or Dial command, you can say
them all at once, or you can
separate them in blocks of 3, 4, 7,
10, or 11.
To skip a voice prompt, press the
Talk button while the HFL is
speaking. The HFL will then begin
listening f or your next command.
HandsFreeL ink
310
TM
——
y

y
(y
y

The HFL system response
continues ‘‘A security option is
available to lock the hands f ree
system. Each time the vehicle is
turned on, a password would be
required to use this system. Would
you like this security option turned
on?’’
Press and release the Talk button.
If you say ‘‘No’’ af ter the beep, the
HFL system response is, ‘‘Security
willnotbeused.Thesystemsetup
is complete.’’
If you say ‘‘Yes,’’ you can set your
password. Ref er to the setting
procedure in the next column.
Press and release the Talk button.
If you say ‘‘Yes’’ af ter the beep, the
HFL system response is, ‘‘Would
you like the notification to be a
ring tone or a prompt?’’ If you say
‘‘No’’ af ter the beep, the HFL
system returns to its main menu.
Saying ‘‘No’’ will result in no ring
tone or prompt playback during an
incoming call. The audio system
will be mute, and a message will
be displayed.
Press and release the Talk button.
Af ter the beep, say ‘‘Ring tone’’ or
‘‘Prompt.’’ The HFL system
response is ‘‘A ring tone will be
used.’’ or ‘‘An incoming call
prompt will be used.’’
If you choose ‘‘Ring tone,’’ you will
hear a ring tone through the audio
speakers to announce an incoming
call. If you choose ‘‘Prompt,’’ you
will hear this message to
announce an incoming call: ‘‘You
have an incoming call.’’
Thevoiceof theHFLcanbesetto
male or f emale (U.S. models only).
Also, the incoming notif ication can
be set to a ring tone, a prompt, or no
notification.
Press and release the Talk button.
Af ter the beep, say ‘‘System.’’ The
HFL response is, ‘‘System options
are setup and clear.’’
Press and release the Talk button.
Af ter the beep, say ‘‘Setup.’’ The
HFL response is ‘‘Would you like
male or f emale prompts?’’
Press and release the Talk button.
Af ter the beep, say ‘‘Male’’ or
‘‘Female,’’ depending on the
system voice you want. The HFL
response is, ‘‘Male (Female)
prompts have been selected.
Would you like an audible
notif ication of an incoming call?’’ 4.
5.
6.
7.
1.
2.
3.
To set up the system, do this:
HandsFreeL ink
Setting Up the System
Features
311
TM
——
y
y
(y
y

The HFL system will accept a
numeric, f our-digit password that
you can use f or security purposes.Follow the system setup
procedure f rom the step 1 through
the step 5 as described previously.
Press and release the Talk button.
Af ter the beep, say ‘‘Yes.’’
The HFL system response is
‘‘What is the f our digit number
you would like to set as your
password?’’ Press and release the Talk button.
Af ter the beep, say ‘‘Yes.’’ The
HFL system response is ‘‘The
system is now locked. Each time
the vehicle is turned on, the
password will be required to use
the system. The system setup is
complete. Returning to the main
menu.’’
Once a password is set, you can lock
the HFL system so it only operates
af ter the password is entered.
Press and release the Talk button.
Af ter the beep, say the f our-digit
password you want to use. For
example,say‘‘1,2,3,4.’’TheHFL
systemresponseis‘‘1,2,3,4.Is
this correct?’’ The HFL system will prompt you
foryourpasswordeachtimethe
ignition switch is turned to the ON
(II) position and you press the
Talk button. You will only be
asked for the password once per
ignition cycle. If the password is
set, the response is ‘‘The system is
locked. What is the f our-digit
password?’’Press and release the Talk button.
Af ter the beep, say your f our-digit
password. For example, say ‘‘1, 2,
3, 4.’’
If the password is correct, the
HFL system response is ‘‘Main
menu.’’
If the password is not correct, the
HFLsystemresponseis‘‘1,2,3,4is
incorrect. Please try again.’’ Go back
to the step 2.
If you f orget your password and you
cannot activate the HFL system,
consult your dealer to cancel the
password.
5.
1.
2.
3.
4. 1.2.
3.
To set your password, do this:
To enter your password, do this:
HandsFreeL ink
Setting Your Password
312
TM
——
y
y
(y
y

CONT INUED
Your Bluetoothcompatible phone
with HandsFree Prof ile must be
paired to the HFL before you can
make and receive hands-free calls. HFL does not allow you to pair
your phone if the vehicle is
moving.
For pairing, your phone must be in
its Discovery mode.
Up to six phones can be paired to
the HFL.
The f ollowing procedure works f or
most phones. If you cannot pair
your phone to the HFL with this
procedure, ref er to your phone’s
operating manual, talk to your
phone retailer, or call the
HandsFreeLink customer support
at (888) 528-7876.
During the pairing process, turn
of f any previously paired phones
bef ore pairing a new phone.With your phone on and the
ignition in the ACCESSORY (I) or
ON (II) position, press and release
the Talk button. After the beep,
say ‘‘Phone setup.’’ The HFL
response is ‘‘Phone setup options
are status, pair, edit, delete, and
list.’’
Press and release the Talk button.
Af ter the beep, say ‘‘Pair.’’ The
HFL response is ‘‘The pairing
process requires operation of your
mobile phone. For saf ety, only
perf orm this f unction while the
vehicle is stopped. State a f our-
digit code f or pairing. Note this
code. It will be requested by the
phone.’’
1.
2.
HandsFreeL ink
Pairing Your Phone
Features
313
NOTE:
TM
——
y

y
(y
y

Press and release the Talk button.
After the beep, say the name you
want to use. For example, say
‘‘Eric’s phone.’’ The HFL response
is ‘‘Eric’s phone has been
successf ully paired. Returning to
the main menu.’’
If you want to pair another phone,
repeat steps 1 through 7.
Press and release the Talk button.
Af ter the beep, say the f our-digit
code you want to use. For example,
say‘‘1,2,3,4.’’TheHFLresponse
is,‘‘1,2,3,4.Isthiscorrect?’’
Press and release the Talk button.
Af ter the beep, say ‘‘Yes.’’ The
HFL system response is
‘‘Searching f or a Bluetooth phone.
Make sure the phone you are
trying to pair is in discovery mode.’’ Steps 5 and 6 show a
common way to get your phone into
its Discovery mode. If these steps do
not work on your phone, ref er to the
phone’s operating manual.
Follow the prompts on your phone
togetitintoitsDiscoverymode.
The phone will search f or the HFL.
When it comes up, select
HandsFreeLink f rom the list of
options displayed on your phone.
When asked by the phone, enter
the four-digit code from step 3 into
your phone. The HFL response is
‘‘A new phone has been f ound.
What would you like to name this
phone?’’ Once the pairing process is
completed, AcuraLink may display a
connection conf irmation screen. This
screen is used to create a data
connection between your cellphone
and the AcuraLink system. You can
choose to set up the data connection
now, or do it later. If you want to do
it now, exit the HFL menu by
pressing the HFL Back button one
or more times.
4.
5.
6.7.
3.
8.
On vehicles with navigation system
HandsFreeL ink
314
NOTE:
TM
——
y

y
(y
y

To rename a paired phone, do this: To delete a paired phone, do this:
Press and release the Talk button.
Af ter the beep, say ‘‘Phone setup.’’
The HFL response is ‘‘Phone
setup options are status, pair, edit,
delete, and list.’’
Press and release the Talk button.
Af ter the beep, say ‘‘Edit.’’ The
HFL response is ‘‘Which phone
would you like to edit?’’
Press and release the Talk button.
After the beep, say the name of
the phone you want to rename.
For example, say ‘‘Eric’s phone.’’
The HFL response is ‘‘What is the
new name f or Eric’s phone?’’
Press and release the Talk button.
Af ter the beep, say the new name
of the phone. For example, say
‘‘Lisa’s phone.’’ The HFL response
is, ‘‘The name has been changed.
Returning to the main menu.’’Press and release the Talk button.
Af ter the beep, say ‘‘Phone setup.’’
The HFL response is, ‘‘Phone
setup options are status, pair, edit,
delete, and list.’’
Press and release the Talk button.
Af ter the beep, say ‘‘Delete.’’ The
HFL response is, ‘‘Which phone
would you like to delete?’’
Press and release the Talk button.
After the beep, say the name of
the phone you want to delete. For
example say ‘‘Eric’s phone.’’ The
HFL response is ‘‘Would you like
to delete Eric’s phone?’’
Press and release the Talk button.
Af ter the beep, say ‘‘Yes.’’ The
HFL response is ‘‘Preparing to
delete Eric’s phone.’’ Say ‘‘OK’’ to
continue. Otherwise, say ‘‘Go back,’’
or ‘‘Cancel.’’
Press and release the Talk button.
If you say ‘‘OK’’ af ter the beep, the
HFL response is ‘‘The phone has
been deleted. Returning to the
main menu.’’ If you say ‘‘Go back,’’
or ‘‘Cancel,’’ the phone will not be
deleted.
2.
3. 4.
1. 1.
2. 3.
4. 5.
CONT INUED
HandsFreeL ink
Features
315
TM
——
y

y
(yy

To list all paired phones, do this:To f ind out the status of the phone being
used, do this: To change f rom the currently linked
phone to another paired phone, do this:
Press and release the Talk button.
Af ter the beep, say ‘‘Phone setup.’’
The HFL response is ‘‘Phone
setup options are status, pair, edit,
delete, and list.’’ Press and release the Talk button.
Af ter the beep, say ‘‘Phone setup.’’
The HFL response is ‘‘Phone
setup options are status, pair, edit,
delete, and list.’’Press and release the Talk button.
Af ter the beep, say ‘‘Next phone.’’
The HFL response is ‘‘Searching
f or the next phone.’’ The HFL
then disconnects the linked phone
and searches for another paired
phone. If no other phones are
f ound, the f irst phone remains
linked.
Press and release the Talk button.
Af ter the beep, say ‘‘List.’’ The
HFL responds by listing the name
of each paired phone. When all
phones paired to the system have
been read, the HFL response is
‘‘The entire list has been read.
Returning to the main menu.’’ Press and release the Talk button.
After the beep, say ‘‘Status.’’ An
example of the HFL response is,
‘‘Eric’s phone is linked. Battery
strength is three bars. Signal
strength is f ive bars, and the
phone is roaming. Returning to the
main menu.’’
2.
1.
1.
2. 1.
HandsFreeL ink
316
TM
——
y
y
(y
y

Press and release the Talk button.
Af ter the beep, say ‘‘Call’’ or ‘‘Dial.’’
The HFL response is ‘‘Calling’’ or
‘‘Dialing.’’ Once connected, you
will hear the person you called
through the audio speakers. To
change the volume, use the audio
system volume knob.
You can make calls using any phone
number, or by using a name in the
HFL phonebook. You can also redial
the last number called. During a call,
theHFLallowsyoutotalkupto30
minutes af ter you remove the key
from the ignition switch.
With your phone on and the
ignition in the ACCESSORY (I) or
ON (II) position, press and release
the Talk button. After the beep,
say ‘‘Call’’ or ‘‘Dial.’’ The HFL
response is, ‘‘What name or
number would you like to call/
dial?’’
Press and release the Talk button.
Af ter the beep, say the number
you want to call. For example, say
‘‘123 456 7891.’’ The HFL response
is ‘‘123 456 7891. Say call, dial, or
continue to add numbers.’’ To end the call, press the Back
button.
With your phone on and the
ignition in the ACCESSORY (I) or
ON (II) position, press and release
the Talk button. After the beep,
say ‘‘Call’’ or ‘‘Dial.’’ The HFL
response is ‘‘What name or
number would you like to call/
dial?’’
Press and release the Talk button.
After the beep, say the name you
want to call. For example, say‘‘Eric.’’ The HFL response is
‘‘Would you like to call Eric?’’
Press and release the Talk button.
Af ter the beep, say ‘‘Yes.’’ The
HFL response is ‘‘Calling’’ or
‘‘Dialing.’’ Once connected, you
will hear the person you called
through the audio speakers. To
change the volume, use the audio
system volume knob.
To end the call, press the Back
button.
To redial the last number called by
the phone, press and release the
Talk button. After the beep, say
‘‘Redial.’’ The HFL response is,
‘‘Redialing.’’ Once connected, you
will hear the person you called
through the audio speakers. To
change the volume, use the audio
system volume knob.
1. 3.
3.
1.
2. 2. 4.4.
To make a call using a phone number,do this:
To make a call using a name in the HFLphonebook, do this:
Making a Call
HandsFreeL ink
Features
317
TM
——
y
y
(yy

If you receive a call when you are not
on the phone, the HFL interrupts the
audio system (if it is on), and plays
the incoming call notif ication, if
activated. To answer the call, press
the Talk button and begin speaking.
If you don’t want to answer the call,
press the Back button.
The HFL allows you to send
numbers or names during a call. This
is usef ul when you call a menu-
driven phone system. You can also
program account numbers into the
HFL phonebook for easy retrieval
during menu-driven calls.
Press and release the Talk button.
Af ter the beep, say ‘‘Send.’’ The
HFL response is, ‘‘What name or
number would you like to send?’’
Press and release the Talk button.
Af ter the beep, say the number
you want to send. For example,
say‘‘1,2,3.’’TheHFLresponseis
‘‘1, 2, 3. Say send, or continue to
add numbers.’’ Press and release the Talk button.
Af ter the beep, say ‘‘Send.’’ The
dial tones will be sent, and the call
will continue.
Press and release the Talk button.
Af ter the beep, say ‘‘Send.’’ The
HFL response is ‘‘What name or
number would you like to send?’’
Press and release the Talk button.
After the beep, say the name you
want to send. For example, say
‘‘Account number.’’ The HFL
response is ‘‘Would you like to
send account number?’’
Press and release the Talk button.
Af ter the beep, say ‘‘Send.’’ The
dial tones will be sent, and the call
will continue.
If your phone has Call Waiting, and
you receive a call when you are on
the phone, press and release the
Talk button to answer it. When you
do this, the original call is placed on
hold. To return to the original call,
press the Talk button again. If you
don’t want to answer the new call,
disregard it, and continue with your
original call. If you want to hang up
the original call and answer the new
call, press the Back button.
1.
2.
1.
2. 3.
3.
To send a number during a call, do this:
To send a name during a call, do this:
Receiving a Call
Sending Numbers or Names
During a Call
HandsFreeL ink
318
TM
——
y
y
(yy

During a call, you can transfer it
f rom the HFL to your phone, or f rom
your phone to the HFL.Press and release the Talk button.
Af ter the beep, say ‘‘Transf er.’’
The audio switches f rom the HFL
to the phone.
Press and release the Talk button.
Af ter the beep, say ‘‘Transf er.’’
The audio switches f rom your
phone to the HFL.
During a call, you can mute or
unmute your voice to the person you
are talking to. Press and release the Talk button.
Af ter the beep, say ‘‘Mute.’’ The
HFL response is, ‘‘Mute is active.’’
Press and release the Talk button.
Af ter the beep, say ‘‘Mute.’’ The
HFL response is, ‘‘Mute is
canceled.’’
The HFL phonebook can store up
to 50 names with their associated
numbers. These can be any types
of numbers. For example, you can
store a phone number and use it to
make a call, or you can store an
account number and use it during
a call to a menu-driven phone
system.
Press and release the Talk button.
Af ter the beep, say ‘‘Phonebook.’’
The HFL response is ‘‘Phonebook
options are store, edit, delete,
receive contact, and list.’’
Press and release the Talk button.
After the beep, say ‘‘Store.’’ The
HFL response is, ‘‘What name
would you like to store?’’
Press and release the Talk button.
After the beep, say the name you
would like to store. For example,
say ‘‘Eric’’ or say ‘‘account number.’’
The HFL response is ‘‘What is the
number f or Eric,’’ or ‘‘What is the
number f or account number?’’
Press and release the Talk button.
After the beep, say the number.
For example, say ‘‘123 456 7891.’’
The HFL response is ‘‘123 456
7891.’’
2.
3.
1. 1.
2.
4.
2. 1.
To transfer a call from the HFL to your
phone, do this:
To transfer a call from your phone to theHFL, do this: To mute your voice, do this:
To unmute your voice, do this: To add a name, do this:
CONT INUED
Transf erring a Call
Muting a CallSetting up the Phonebook
HandsFreeL ink
Features
319
TM
——
y


y
(yy
