window Acura RL 2007 Owner's Guide

Air conditioning, as it cools, removes
moisture from the air. When used in
combination with the heater, it
makes the interior warm and dry.
This setting is suitable f or all driving
conditions whenever the outside
temperature is above 32°F (0°C).To remove f og f rom the inside of the
windows:
Select . The system
automatically switches to fresh air
mode and turns on the A/C.
Select .
Set the f an and temperature
controls to maximum level.
For your saf ety, make sure you have
a clear view through all the windows
bef ore driving.
Set the f an to the desired speed, or
high f or f aster def rosting.
Select . The system
automatically switches to f resh air
mode and turns on the A/C.
Adjust the temperature so the
airflow feels warm.
Select to help clear the
rear window.
To increase airf low to the
windshield, close the corner vents.
When you switch to another mode
from , the A/C setting
returns to the previous setting (on or
of f ). Select A/C, then press ENTER
on the interface selector to turn the
A/C of f if it is on.
Switch the f an on.
Turn on the air conditioning.
Select and fresh air mode.
Adjust the temperature to your
pref erence.
To clear the windshield f aster, you
can close the dashboard corner vents
by rotating the wheel next to it. This
sends more warm air to the
windshield def roster vents. Once the
windshield is clear, select the f resh
air mode to avoid fogging the
windows.
1.
2.
3.
4.
1.
2.
3.
1.
2.
3.
4.
5.
Dehumidif y the Interior
T o Def og and Def rostT o Remove Exterior Frost or Ice
From the Windows
Climate Control System
204
——
y
y
(yy

The automatic climate control
system adjusts the f an speed and
airflow levels to maintain the interior
temperature you select.
In AUTO mode, the vehicle’s interior
temperature is independently
regulated f or the driver and
passenger. If the driver’s side of the
vehicle is getting too much sun, the
system will adjust to a lower
temperature.Press the AUTO button.
Set the desired temperature with
the temperature control bars.
You will see AUTO in the display
if theclimatemodeisselected. The system automatically selects the
proper mix of conditioned and/or
heated air that will, as quickly as
possible, raise or lower the interior
temperature to your pref erence.
When you set the temperature to its
lower or its upper limit, the system
runs at f ull cooling or heating only. It
does not regulate the interior
temperature.
When you change the f an speed, the
f an is taken out of AUTO mode and
starts to run at the selected speed.
You can manually select various
f unctions of the climate control
system when it is in f ully automatic
mode. All other f eatures remain
automatically controlled. Making any
manual selection causes the word
AUTO in the display to go out.
Press the OFF button. However, a
lack of airf low can cause the
windowstofogup.Youshouldkeep
the fan on at all times so stale air and
moisture do not build up in the
interior and cause f ogging.
1.
2. Automatic Climate Control
Semi-automatic Operation
To Turn Everything Off
Climate Control System
Features
205
——
y
y
(y
y

To achieve optimum voice
recognition, the following guidelines
should be followed:
Make sure the correct screen
is displayed for the voice command
th at you are using. See Voice
Command Index on page . Close the windows and the
moonroof .
The f an speed will be
automatically adjusted to low.
If the system cannot recognize
your command because of
background noise, speak louder.
If the microphone picks up voices
other than yours, the system may
not interpret your voice
commands correctly.
If you speak a command with
something in your mouth, or your
voice is either too high or too
husky, the system may
misinterpret your voice commands.
If you are still having trouble with
the voice control system, ref er to
on the
main menu screen.
Make sure the airf low f rom the
A/C vents does not interf ere with
the system microphone in the
ceiling console. Place your hand
over the microphone; if you f eel
any airf low, adjust the vents.
After pressing the button,
wait f or the beep, then give a voice
command.
Give a voice command in a clear,
natural speaking voice without
pausing between words.
266
Improving Voice Recognition
Voice Command Help
Talk
Compass System (U.S. model without navigation system)
Features
265
NOTE:
——
y
y
(yy

When properly installed, cellular
phones, alarms, two-way radios, and
low-powered audio systems should
not interfere with your vehicle’s
computer controlled systems, such
as your airbags and anti-lock brakes. Before
installing any accessory:
Make sure the accessory does not
obscure any lights, or interfere
with proper vehicle operation or
performance.
Modifying
your vehicle, or installing
some non-Acura accessories, can
make your vehicle unsafe. Before
you make any modifi cations or add
anyaccessories,besuretoreadthe
following information.
Your dealer has Acura accessories
that allow you to personalize your
vehicle. These accessories have
been designed and approved for your
vehicle, and are covered by warranty.
Before installing any electronic
accessory, have the installer
contact your dealer. If possible,
have your dealer inspect the final
installation. Be sure electronic accessories do
not overload electrical circuits
(see page ) or interf ere with
the proper operation of your
vehicle.
Do not install accessories on the
side pillars or across the rear
windows. In these areas,
accessories may interf ere with
proper operation of the side
curtain airbags.
Although non-Acura accessories may
f it on your vehicle, they may not
meet f actory specif ications, and
could adversely af f ect your vehicle’s
handling and stability.
447
A ccessories
A ccessories and Modif ications
Bef ore Driving
333
Improper accessories or
modifications can affect your
vehicle’s handling, stability, and
performance, and cause a
crash in which you can be hurt
or killed.
Follow all instructions in this
owner’s manual regarding
accessories and modifications.
——
y
y
(yy

Make sure all windows, mirrors,
and outside lights are clean and
unobstructed. Remove frost, snow,
or ice.
Check that the hood is fully closed.
Check that any items you may be
carrying are stored properly or
fastened down securely. Check
the seat adjustment (see
page ).
Check the steering wheel
adjustment (see page ).
Make sure the doors and the
trunk are securely closed and
locked.
Fasten your seat belt. Check that
your passengers have fastened
their seat belts (see page ).
Youshoulddothefollowingchecks
and
adjustmen ts before you drive
your vehicle.
When you start the engine, check
the gauges and indicato rs in the
instrument panel, and the
messages on the multi-inform ation
display (see pages , and ).
Visually
check the tires. If a tire
looks low, use a gauge to check its
pressure (see page ). Check
the adjustment of the
inside and outside mirrors (see
page ).
1.
2.
3.
4. 5.
6.
7.
8.
9.
10. 17
78 155
158 147
415
61 70
Preparing to Drive
340
——
y
y
(yy

If the SH-AWD indicator on the
instrument panel stays on, and the
multi-inf ormation display shows an
SH-AWD message, there is a
problem with the system. Your
vehicle still has normal f ront-wheel
drive with vehicle stability assist
(VSA), but does not have the
advantages of SH-AWD. Have your
vehicle checked by a dealer as soon
as possible.Check the indicator on the
instrument panel to verif y that the
security system is set. If the vehicle is f acing downhill,
turn the front wheels toward the
curb. If the vehicle is f acing uphill, turn
the front wheels away from the
curb. Never park over dry leaves, tall
grass, or other f lammable
materials. The hot three way
catalytic converter could cause
these materials to catch on fire.
Make sure the parking brake is
f ully released bef ore driving away.
Driving with the parking brake
partially set can overheat or
damage the rear brakes.
Always use the parking brake when
you park your vehicle. Make sure
the parking brake is set f irmly, or
your vehicle may roll if it is parked
on an incline.
Set the parking brake bef ore you put
the transmission in Park. This keeps
the vehicle from moving and putting
pressure on the parking mechanism
in the transmission.
Make sure the moonroof and the
windows are closed.
Turn of f the lights.
Place any packages, valuables, etc.,
in the trunk or take them with you.
Lock the doors.
SH-A WD System, Parking
Parking
Parking T ips
Driving
351
——
y
y
(yy

µ
Check the condition of the battery
monthlybylookingatthetest
indicator window. The label on the
battery explains the test indicator’s
colors. Battery
posts,
terminals, and related accessories
contain lead and lead compounds.
Check
the terminals for corrosion (a
white or yellowish powder). To
remove it, cover the terminals with a
solution of baking soda and water. It
will bubble up and turn brown. When
this stops, wash it off with plain
water. Dry off the battery with a
cloth or paper towel. Coat the
terminals with grease to help prevent
future corrosion.
If additional battery maintenance is
needed, see your dealer or a
qualified technician. If
you need to connect the battery to
a charger, disconnect both cables to
prevent damaging your vehicle’s
electrical system. Always disconnect
the negative ( ) cable first, and
reconnect it last.
To see the label, remove the battery
cover (see page ). 424
CONT INUED
WARNING:
Wash your hands af ter handling.
Checking the Battery
Maint enance
423
TEST INDICATOR WINDOW
The battery gives off explosive
hydrogen gas during normal
operation.
A spark or flame can cause the
battery to explode with enough
force to kill or seriously hurt you.
Wear protective clothing and a
face shield, or have a skilled
technician do the battery
maintenance.
——
y

y
(yy

Block the rear wheels.
If the vehicle is to be stored f or a
longer period, it should be
supported on jackstands so the
tires are of f the ground.
Leave one window open slightly (if
the vehicle is being stored
indoors).
Disconnect the battery.
Support the f ront wiper blade
arms with a f olded towel or rag so
they do not touch the windshield.
To minimize sticking, apply a
silicone spray lubricant to all door
and trunk seals. Also, apply a
vehiclebodywaxtothepainted
surfaces that mate with the door
and trunk seals.
If you need to park your vehicle f or
an extended period (more than 1
month), there are several things you
should do to prepare it f or storage.
Proper preparation helps prevent
deterioration and makes it easier to
get your vehicle back on the road. If
possible, store your vehicle indoors.
Fill the f uel tank.
Change the engine oil and f ilter.
Wash and dry the exterior
completely.
Cleantheinterior.Makesurethe
carpeting, floor mats, etc., are
completely dry.
Leave the parking brake off. Put
the transmission in Park.
Push the tabs and remove the
cover by pulling it up caref ully.
To reinstall the cover, put the tabs
of the cover back to the original
position properly.
Turn the knob of the cover to
LOCK position as shown in the
illustration.
2.
3.
4.
Vehicle Storage
Maint enance
425
——
y

y
(yy

Let the vehicle sit for a minute.
Op en the hood, and check the oil
level (see page ). An engine
very low on oil can lose pressure
during cornering and other driving
maneuvers.
If necessary, add oil to bring the
level back to the full mark on the
dipstick (see page ).
Start the engine, and watch the oil
pressure indicator. If it does not go
out within 10 seconds, turn off the
engine. There is a mechanical
problem that needs to be repaired
befo re you can continue driving
(see on page
).
This indicator should never
come on when the engine is
running. If it starts f lashing or stays
on, or if you see a ‘‘CHECK ENGINE
OIL LEVEL’’ message on the multi-
inf ormation display, the oil pressure
has dropped very low or lost
pressure. Serious engine damage is
possible, and you should take
immediate action. If the charging system
indicator comes on brightly
when the engine is running, or if you
see a ‘‘CHECK CHARGING
SYSTEM’’ message on the multi-
inf ormation display, the battery is
not being charged.
Immediately turn of f all electrical
accessories. Try not to use other
electrically operated controls such as
the power windows. Keep the engine
running; starting the engine will
discharge the battery rapidly.
Go to a dealer or a service station
where you can get technical
assistance.
Saf ely pull of f the road and shut
of f the engine. Turn on the hazard
warning lights.
1.
2.
3.
4. 331
395
455
L ow Oil Pressure Indicator
Emergency T owingCharging System Indicator
L ow Oil Pressure Indicator, Charging System Indicator
T aking Care of t he Unexpect ed
443
Running the engine with low oil
pressure can cause serious mechanical
damage almost immediately. Turn of f
the engine as soon as you can saf ely get
the vehicle stopped.
——
y


y
(yy

Î
Î
No. Amps.
No. Amps.No.
Circuits Protected Circuits Protected Amps. Circuits Protected
1
2
3
4
5
6
7
8
9
10
11
12
13
14 15 A
30 A
10 A
15 A
10 A
15 A
7.5 A 15 A
30 A
30 A
20 A
7.5 A 15 A
40 A
150A 15
16
17
18
19
20
21
22
23
Radiator fan Left headlight low beam
Rear defroster coil
Left headlight high beam
Small light
Right headlight high beam
Right headlight low beam
Back-up
FI ECU
Wiper
Headlight washer
Fog lights
MG clutch
Horn, Stop
Rear defroster 40 A
15 A
30 A
40 A
40 A
(40 A) 40 A
70 A
120 A 50 A
50 A Back-up, ACC
Hazard
ABS/VSA motor
ABS/VSA
Drive by wire, LAF heater
Option
Heater motor
Passenger’s f use box
Battery
IG main
Power window
: On Canadian models
Fuse Locations
452
PRIMARY UNDER-HOOD FUSE BOX
SECONDARY UNDER-HOOD FUSE BOX
——
y


y
(yy
