Always use saf ety chains when you
tow a trailer. Make sure the chains
are secured to the trailer and hitch,
and that they cross under the tongue
and can catch the trailer if it
becomes unhitched. Leave enough
slack to allow the trailer to turn
corners easily, but do not let the
chains drag on the ground.Acura recommends that any trailer
having a total weight of 1,000 lbs
(450 kg) or more be equipped with
its own electric or surge-type brakes.
If you choose electric brakes, be
sure they are electronically actuated.
Do not attempt to tap into your
vehicle’s hydraulic system. No
matter how successf ul it may seem,
any attempt to attach trailer brakes
to your vehicle’s hydraulic system
will lower braking ef f ectiveness and
create a potential hazard.Trailer lights and equipment must
comply with federal, state, and local
regulations. Check with your local
trailerdealerorrentalagencyforthe
requirements in your area, and use
only equipment designed f or your
vehicle.
Since lighting and wiring vary by
trailer type and brand, you should
have a qualified technician install a
suitable connector between the
vehicle and the trailer. Improper
equipment or installation can cause
damage to your vehicle’s electrical
system and af f ect your vehicle
warranty.
Seeyourtrailerdealerorrental
agency f or more inf ormation on
installing electric brakes.
CONT INUED
Saf et y Chains
T railer L ight s
Trailer Brakes
Towing a Trailer
Driving
375
——
y

y
(yy

Many states and Canadian provinces
require special outside mirrors when
towing a trailer. Even if they don’t,
you should install special mirrors if
you cannot clearly see behind you, or
if the trailer creates a blind spot.
Askyourtrailersalesorrental
agency if any other items are
recommended or required f or your
towing situation.When preparing to tow, and bef ore
driving away, be sure to check the
f ollowing:
The vehicle has been properly
serviced, and the tires, brakes,
suspension, cooling system, and
lights are in good operating
condition.
All items in or on the trailer are
properly secured and cannot shif t
while you drive. Thehitch,safetychains,andany
other attachments are secure. All weights and loads are within
limits. The trailer has been properly
serviced and is in good condition,
and the lights and brakes on the
trailer are working properly. Your vehicle tires and spare are
properly inf lated, and the trailer
tires and spare are inflated as
recommended by the trailer
maker.
Pre-T ow Checklist
Towing a Trailer
A ddit ional T owing Equipment
376
——
y
y
(y
y

The component parts in the engine
compartment are protected by
several covers. You may need to
remove the covers when you
perform some simple maintenan ce
work.
All of the covers are secured by
holding clips.
To remove the front bulkhead cover,
remove the holding clips with a flat-
tip screwdriver.
To remove the left or right engine
compartment cover, remove the
holding clips by loosening the pins in
the center of the fastener.
To remove the battery cover, turn
the knob of the f astener (see page ).
424
Engine Compartment Covers
394
FRONT BULKHEAD COVER
RIGHT COMPARTMENT COVER LEFT COMPARTMENT COVER
BATTERY COVER
——
y

y
(yy

Install the engine oil f ill cap, and
tighten it securely. Wait a f ew
minutes, and recheck the oil level.
Do not f ill above the upper mark; you
could damage the engine. Unscrew and remove the engine oil
fill cap on top of the valve cover.
Pour in the oil slowly and caref ully so
you do not spill any. Clean up any
spills immediately. Spilled oil could
damage components in the engine
compartment.Honda Motor Oil is the pref erred
5W-20 lubricant f or your vehicle. It is
highly recommended that you use
Honda Motor Oil in your vehicle f or
optimum engine protection. Make
sure the API Certif ication Seal says
‘‘For Gasoline Engines.’’
The oil viscosity or weight is
provided on the container’s label.
5W-20 oil is f ormulated f or year-
round protection of your vehicle to
improve cold weather starting and
f uel economy.
Oil is a major contributor to your
engine’s perf ormance and longevity.
Always use a premium-grade 5W-20
detergent oil displaying the API
Certif ication Seal. This seal indicates
the oil is energy conserving, and that
it meets the American Petroleum
Institute’s latest requirements.
CONT INUED
Recommended Engine Oil
A dding Engine Oil
Maint enance
395
API CERTIFICATION SEAL
ENGINE OIL FILL CAP
Ambient Temperature
——
y

y
(yy

Insert the dipstick all the way back
into the transmission securely as
shown in the illustration.
The transmission should be drained
andrefilledwithnewfluidwhenthis
service is shown on a maintenance
message in the multi-inf ormation
display.
If youarenotsurehowtoaddfluid,
contact your dealer.
Insert the dipstick all the way into
the transmission as shown.
Remove the dipstick and check
the f luid level. It should be
between the upper and lower
marks. Pour the f luid slowly and caref ully
so you do not spill any. Clean up
any spill immediately; it could
damage components in the engine
compartment. If the level is below the lower
mark, add f luid into the dipstick
hole to bring it to the level
between the upper and lower
marks.
Always use Honda ATF-Z1
(automatic transmission f luid). If
it’s not available, you may use a
DEXRON
III automatic
transmission f luid as a temporary
replacement. However, continued
use can affect the shift quality.
Have the transmission f lushed and
ref illed with Honda ATF-Z1 as
soon as it is convenient.
5.
6.
3.
4.
Automatic Transmission Fluid
Maint enance
401
LOWER MARK
UPPER MARK
——
y


y
(yy

Insert the new bulb into the hole,
and turn it one-quarter turn
clockwise to lock it in place.
Push the electrical connector back
onto the bulb. Make sure it is on
all the way.
Turn on the f og lights to test the
new bulb.
Reinstall the two mounting bolts
onthesideundercoverand
tighten them securely. Put the
holding clip back on the side
under cover and push on the
center until it locks (the center is
flushwiththehead).
Remove the electrical connector
f rom the bulb by pushing on the
tab and pulling the connector
down.
Remove the bulb by turning it one-
quarter turn counterclockwise.
Caref ully push up the side under
cover into the bumper. Use a Phillips-head screwdriver to
remove the two mounting bolts,
and remove the holding clip with a
f lat-tipped screwdriver. 3.
4. 5.
6.
8. 7.
1.
2.
Lights
Maint enance
409
CLIP CONNECTORBULB
BOLTS
——
y

y
(y
y

Install the new bulb in the socket
by pushing it straight in the socket
until it bottoms.
Reinstall the socket into the light
assembly. Turn it clockwise to
lock it in place.
Testthelightstomakesurethe
new bulb is working.
Tighten the mounting nut securely,
and reinstall the maintenance lid. When reinstalling the taillight
assembly, align and pop the snap
f asteners in place. Tighten the two
mounting bolts and reinstall the
trim in place.If your seat belts get dirty, use a sof t
brush with a mixture of mild soap
and warm water to clean them. Do
not use bleach, dye, or cleaning
solvents. Let the belts air-dry bef ore
you use the vehicle.
Dirt build-up in the loops of the seat
belt anchors can cause the belts to
retract slowly. Wipe the insides of
the loops with a clean cloth
dampened in mild soap and warm
water or isopropyl alcohol.
This f ilter removes the dust and
pollenthatisbroughtinfromthe
outside through the climate control
system.
Have your dealer replace the filter
when this service is indicated by a
maintenance message in the multi-
inf ormation display. It should be
replaced every 15,000 miles (24,000
km) if you drive primarily in urban
areas that have high concentrations
of soot in the air, or if the f low f rom
theclimatecontrolsystembecomes
less than usual.
9.
10.
11.
12.
13. Cleaning the Seat Belts
Dust and Pollen Filter
Lights, Dust and Pollen Filter, Cleaning the Seat Belts
Maint enance
411
LOOP
——
y

y
(y
y

Remove the blade f rom its holder
by grasping the tabbed end of the
blade. Pull f irmly until the tabs
come out of the holder.Examine the new wiper blades. If
they have no plastic or metal
reinf orcement along the back
edge, remove the metal
reinf orcement strips f rom the old
wiper blade, and install them in
the slots along the edge of the new
blade.Slide the new wiper blade into the
holder until the tabs lock.
Reinstall the blade assembly to the
wiper arm and tighten the two
screws securely. Reinstall the
cover by pushing it in.
Set the wiper arms back on the
windshield. Adjust the windshield
wipers to their previously parked
position.
4. 5. 6.
7.
8.
Wiper Blades
414
BLADE
BLADE
REINFORCEMENT
——
y

y
(y
y

´
Tires marked ‘‘M S’’ or ‘‘All
Season’’ on the sidewall have an all-
weather tread design suitable for
most winter driving conditions.
For the best performance in snowy
or icy conditions, you should install
snow tires or tire chains. They may
be required by local laws under
certain conditions. Mount
tire chains on your tires when
required by driving conditions or
local laws. Install them only on the
front tires.
If
you mount snow tires on your
vehicle, make sure they are radial
tires of the same size and load range
as the original tires. Mount snow
tires on all four wheels. The traction
provided by snow tires on dry roads
maybelowerthanyouroriginaltires.
Check with the tire dealer for
maximum speed recommendations. Because
your vehicle has limited tire
cl earance, Acura strongly
recommends using the chain listed
below, made by Security Chain
Company (SCC).
Tire chains cannot be used with a
flat front tire. If a front tire goes flat
when a tire chain is installed on it,
remove the chain, and f ollow the
precautions described under
Michelin PAX System (see page ).
Cable-type: SCC Radial Chain
CH2612T
422
Winter Driving
T ire Chains
Snow T ires
Tires
420
——
y

y
(yy

If your vehicle’s battery is
disconnected or goes dead, all stored
driving positions will be lost. To
store the driving positions again, see
the sto ring procedure on p age .
The navigation system will also
disableitself.Thenexttimeyouturn
on the ignition switch, the system
will require you to enter a PIN
before it can be used. Refer to the
navigation system manual. Turn the knob of the battery cover
toUNLOCKasshowninthe
illustration.
If your ve
hicle’s battery is
disconnected or goes dead, the audio
system will disable itself. The next
timeyouturnontheradioyouwill
see ‘‘ ’’ in the frequency
display. Use the preset buttons to
enter the fi ve-digit code (see page
).
If your ve hicle’s battery is
disconnected or goes dead, the
power tilt and telescopic steering
wheel system will be disabled. The
system needs to be reset after
reconnecting the battery (see page ).
The c ompass System will also
disableitself.Thenexttimeyouturn
on the ignition switch, the system
will require you to enter a PIN
before it can be used. Enter the four-
digit anti-theft security code (see
page ). You will also need reset
the c lock according to the
instru ction of setting the clock (see
page ). 1.
160
239
147
272
257
On vehicles with navigation system
On vehicles without navigation system
Checking the Battery
Removing the Battery Cover
424
KNOB TABLOCK
UNLOCK
——
y

y
(yy
