Acura RL 2009 Owner's Manual

Thebatteriesintheremotenormally
last about 2 years. To ensure
maximum battery lif e, do not store
the remote close to electrical devices
such as computers or TVs. When the
multi-inf ormation display shows
‘‘KEYLESS REMOTE LOW
BATTERY,’’ replace the batteries as
soon as possible (see page ).
The engine does not restart if you
turn the ignition switch to the LOCK
(0) position when the remote is
outside the vehicle. Check where the
remote is. Make sure that you carry
the remote or built-in key with you
when you operate the ignition switch.
When the ignition switch is in the
ON (II) position, the multi-
inf ormation display shows
‘‘KEYLESS REMOTE NOT
DETECTED,’’ and the inside and
outside beepers sound.
The multi-inf ormation display
message goes away when you
bring the remote back inside the
vehicle, and close the door or
apply the parking brake.
The outside beeper sounds when
the ignition switch is in the
ACCESSORY (I) or the ON (II)
position.
If the engine is running and you
removetheremotefromthe
vehicle, it will continue to run.
Once turned to the LOCK (0)
position, the engine will not restart
until a remote is brought back into
the vehicle. If you pass the remote through an
open window, the system does not
respond.Also,evenwhentheremote
is inside the vehicle, the beeper may
sound when the location of the
remote is not detected due to
surrounding conditions. It is not a
f ailure. Make sure that you carry the
remote with you.
174
K eyless Remot e L ow Bat t ery
K eyless A ccess System
178
2009 RL

The keyless access system
indicator comes on and stays on
while you are driving.
The indicator comes on f or several
seconds when you turn the ignition
switch to the ON (II) position. Have
your vehicle checked by your dealer
if : In this case, use the built-in key to
lock/unlock the doors and start the
engine.The multi-inf ormation display
shows ‘‘CHECK KEYLESS
ACCESS SYSTEM.’’
The indicator comes on with the
ignition switch in the ON (II)
position.Check K eyless A ccess Syst em
K eyless A ccess System
Inst rument s and Cont rols
179
KEYLESS ACCESS SYSTEM
INDICATOR
2009 RL

To remove the built-in key, pull it out
while pressing the release button. To
reinstall the built-in key, push the
key into the remote until it clicks.The trunk and glove box cannot be
opened when you turn the trunk
main switch of f and lock the glove
box and trunk pass-through cover
with the built-in key. Also, the trunk
cannot be opened by using the
remote.
The keyless access system uses an
electric f ield to identif y the remote.
To avoid damaging the remote and
the built-in key, never pull on the
built-in key unless you are pressing
the release button. If you use medical equipment such
as a cardiac pacemaker, ask your
doctor if the radio waves used by the
remote will af f ect it.
Valet Function
Built-in key and Remote
K eyless A ccess System
180
RELEASE BUTTON BUILT-IN KEY
2009 RL

In the LO setting, the heater runs
continuously. It does not cycle with
temperature changes.
Follow these precautions whenever
you use the seat heaters:Use the HI setting only to heat the
seats quickly, because it draws
large amounts of current f rom the
battery.
If the engine is lef t idling f or an
extended period, do not use the
seat heaters, even on the LO
setting. It can weaken the battery,
causing hard starting.
The ignition switch must be in the
ON (II) position to use the heaters.
Push the top of the switch, HI, to
rapidly heat up the seat. Af ter the
seat reaches a comfortable
temperature, select LO by pushing
the bottom of the switch. This will
keep the seat warm.
In the HI setting, the heater turns off
when the seat gets warm, and turns
back on after the seat’s temperature
drops.
Both f ront seats are equipped with
seat heaters. The passenger seat
only has heaters in the seat bottom
because of the side airbag cutof f
system.
RL models
FrontSeatHeaters
Inst rument s and Cont rols
181
Passenger’s
seat
Driver’s
seat
HEATERS FRONT SEAT HEATER SWITCHESHI
LOW
2009 RL

Û
Ý Ý
µ µ
µ µ Û
Ý
Û
When you press the button once,
the heater is set to HI. Af ter the seat
reaches a comf ortable temperature,
select MID or LOW by pressing the
button. This will keep the seat
warm. To shut down the heater,
press the button until the
indicators go of f .
In HI, when the seat gets warm, the
heater will change to MID after
about 5 minutes.
In MID, the heater will change to
LOW af ter about 60 minutes.
In LOW, the heater runs
continuously.
The ignition switch must be in the
ON (II) position to use the heaters
and the air ventilation system.
HI Three indicators on.
MID Two indicators on.
LO One indicator on.
OFF All indicators of f .
To use the heaters, press the
button. The indicator (red) next to
the button will come on. There are
four settings in the heaters:
Both f ront seats are equipped with
seat heaters and an air ventilation
system. The passenger seat only has
heaters in the seat bottom because
of thesideairbagsystem.
If equipped
Front Seat Heaters and Seat Ventilation
182
BUTTON
INDICATORS
passenger’s
seat
Driver’s
seat
HEATERS FRONT SEAT HEATER AND
SEAT VENTILATION
SWITCHES
BUTTON
2009 RL

ÝÛ
Û
µ
µ
µ µ Ý
Follow these precautions whenever
you use the seat heaters and the seat
ventilation:
Use the HI setting only to heat or
to ventilate the seats quickly,
because it draws large amounts of
current from the battery.
If the engine is lef t idling f or an
extended period, do not use the
seat heaters or the seat ventilation,
even on the LO setting. It can
weaken the battery, causing hard
starting.
When you press the button once,
the system is set to HI. To change to
the lower mode, press the button.
To turn the air ventilation off, press
the button until the indicators go
off.
HI Three indicators on.
MID Two indicators on.
LO One indicator on.
OFF All indicators of f .
To ventilate the seat, press the
button. The indicator (blue) next to
the button will come on. The air
ventilation system has four settings:
Front Seat Heaters and Seat Ventilation
Inst rument s and Cont rols
183
2009 RL

The outer rear seat cushions and
seat-backs are equipped with seat
heaters.The rear seat heater switches are
located under the rear vents. The
lef t (right) switch controls the seat
heaters on lef t (right) outer seating
position.
If the engine is lef t idling f or an
extended period, do not use the
seat heaters even on the LO
setting. It can weaken the battery,
causing hard starting.
Use the HI setting only to heat the
seats quickly, because it draws
large amounts of current f rom the
battery.
Follow these precautions whenever
you use the seat heaters:
In the LO setting, the heater runs
continuously. It does not cycle with
temperature changes.
In the HI setting, the heater turns off
when the seat gets warm, and turns
back on after the seat’s temperature
drops.
The ignition switch must be in the
ON (II) position to use seat heaters.
Push the right side of the switch, HI,
to rapidly heat up the seat. Af ter the
seat reaches a comfortable
temperature, select LO by pushing
the lef t side of the switch. This will keep the seat warm.
Rear Seat Heaters (Canadian models)
184
HEATERS
For right outer
seating position
HEATERS
For left outer
seating position LOW
HI
REAR SEAT HEATER SWITCHES
2009 RL

If the MAIN switch is pushed down
(OFF), the passenger windows
cannot be raised or lowered. Keep
the MAIN switch off when you have
children in the vehicle so they do not
injure themselves by operating the
windows unintentionally.
Turn the ignition switch to the ON
(II) position bef ore operating any of
the window switches. To open a
window, push the switch down and
hold it. To close the window, pull the
switchupandholdit.Releasethe
switch to stop the window.
CONT INUED
Power Windows
Inst rument s and Cont rols
185
DRIVER’S WINDOW SWITCH
MAIN SWITCH
Closing a power window on
someone’s hands or fingers can
cause serious injury.
Make sure your passengers are
away from the windows before
closing them.
2009 RL

µAuto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it.
To open the window f ully,
push the window switch firmly down
to the second detent, then release it.
The window automatically goes
down all the way. To stop the
window f rom going all the way down,
pull back on the window switch
brief ly.
To close the window f ully, pull back
the window switch firmly to the
second detent, then release it. The
window automatically goes all the
way up. To stop the window f rom
going all the way up, push down on
the window switch briefly. To open or close the window
partially, push down or pull back on
the window switch lightly to the first
detent, and hold it. The window will
stop when you release the switch.
All window switches also have the
AUTO feature.
If the window runs into any obstacle
while it is closing automatically, it
will reverse direction, and then stop.
To close the window, remove the
obstacle, then use the window switch
again.The indicators in the switches come
on when you turn the ignition switch
to the ON (II) position.
The power windows have a key-of f
delay. You can still open and close
the windows f or up to 10 minutes
after you turn off the ignition switch.
The key-of f delay cancels as soon as
you open either f ront door. You must
then turn the ignition switch to the
ON (II) position f or the power
windows to operate.
Auto Reverse
AUTO
Power Windows
186
2009 RL

You can open all of the windows and
the moonroof f rom outside with the
remote.Press the UNLOCK button once
to unlock the driver’s door.
To open the windows and
moonroof f urther, press the
button again and hold it. If the
windows and the moonroof stop
bef ore the desired position, repeat
steps 1 and 2.
You cannot close the windows or the
moonroof with the remote. You can open and close the windows
and moonroof with the built-in key in
the driver’s door lock.
Insert the built-in key in the driver’s
door lock.
To open: Turn the key clockwise, then
release it.
Turn the built-in key clockwise
again, and hold it. All four
windows and the moonroof start to
open. To stop the windows and
moonroof , release the built-in key.
Press the UNLOCK button a
second time, and hold it. All the
doors unlock, and all f our windows
and moonroof start to open. To
stop the windows and moonroof ,
release the button. When the windows or moonroof
stops bef ore opening f ully, to open
the windows and moonroof f urther,
turnandholdthekeyagain
(within 10 seconds).
1.
2.
3.
1.2.
3.
4.
CONT INUED
Opening the Windows and
Moonroof with the Remote
Opening/Closing the Windows
and Moonroof with the Built-in
Key
Power Windows
Inst rument s and Cont rols
187
Open
Close
UNLOCK BUTTON
2009 RL
