When is selected, you can
increase or decrease the
temperature of airf low f rom the
dashboard vent f or the driver’s side
and the passenger’s side without
changing the temperature of airf low
f rom the f loor vent.
Push the interf ace selector right or
left,thenturntheinterfaceknobto
select the desired temperature.
Air flows from the center
and corner vents in the dashboard.
Airf low is divided between
the vents in the dashboard and the
f loor vents.
Air f lows f rom the f loor
vents.
Airf low is divided between
the floor vents and defroster vents at
the base of the windshield.
Use the mode control button to
select the vents the air flows from.
Some air will flow from the
dashboard vents in all modes.
Press the A/C button to view the
climate control display, then push
the interf ace selector down. Select
any of the modes by turning the
interf ace knob.
Using the Mode Control Button
Using the Interf ace Dial
Climate Control System
208
2009 RL

The heater uses engine coolant to
warm the air. If the engine is cold, it
will be several minutes bef ore you
f eel warm air coming f rom the
system.Select and fresh air mode.
Set the f an to the desired speed.
Adjust the warmth of the air with
the temperature control bar.
you can
cool it down more rapidly by partially
opening the windows, turning on the
air conditioning, and setting the fan
to maximum speed in f resh air mode.
Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page ). If it moves near the red zone,
turn of f the A/C until the gauge
reading returns to normal.
The f low-through ventilation system
draws in outside air, circulates it
through the interior, then releases it
through vents near the rear window.
Set the temperature to the lower
limit.
Make sure the A/C is of f .
Select and fresh air mode.
Set the f an to the desired speed.
1.
2.
3.
4.
1.
2.
3.
70
If the interior is very warm,
CONT INUED
Climate Control System
Using the Heater
Using the A/C
Ventilation
Features
209
2009 RL

To remove f og f rom the inside of the
windows:Set the f an to the desired speed, or
high f or f aster def rosting.
Select . The system
automatically switches to fresh air
mode and turns on the A/C.
Adjust the temperature so the
airflow feels warm.
Select to help clear the
rear window.
To increase airf low to the
windshield, close the corner vents.
When you switch to another mode
from , the A/C setting
returns to the previous setting (on or
of f ). Select A/C, then press ENTER
on the interface selector to turn the
A/C of f if it is on.
Air conditioning, as it cools, removes
moisture from the air. When used in
combination with the heater, it
makes the interior warm and dry.
Switch the f an on.
Turn on the air conditioning.
Select and fresh air mode.
Adjust the temperature to your
pref erence.
This setting is suitable f or all driving
conditions whenever the outside
temperature is above 32°F (0°C).
Press the A/C button to view the
climate control display.
Turn on the A/C by pushing
ENTER on the interf ace selector.
You will see A/C ON in the display.
Make sure the temperature is set
to maximum cool.
Select .
If the outside air is humid, select
recirculation mode. If the outside
air is dry, select f resh air mode.
Set the f an to the desired speed by
turning the interf ace knob.
1.
2.
3.
4.
1.
2.
3.
4.
5.
1.
2.
3.
4.
5.
6.
Climate Control System
To Def og and Def rost
Dehumidif y the Interior
210
2009 RL

The system automatically selects the
proper mix of conditioned and/or
heated air that will, as quickly as
possible, raise or lower the interior
temperature to your pref erence.
When you set the temperature to its
lower or its upper limit, the system
runs at f ull cooling or heating only. It
does not regulate the interior
temperature.
When you change the f an speed, the
f an is taken out of AUTO mode and
starts to run at the selected speed.
The automatic climate control
system adjusts the f an speed and
airflow levels to maintain the interior
temperature you select.
In AUTO mode, the vehicle’s interior
temperature is independently
regulated f or the driver and
passenger. If the driver’s side of the
vehicle is getting too much sun, the
system will adjust to a lower
temperature.
Press the AUTO button.
Set the desired temperature with
the temperature control bars.
You will see AUTO in the display
if theclimatemodeisselected.
Select . The system
automatically switches to f resh air
mode and turns on the A/C.
Select .
Set the f an and temperature
controls to maximum level.
To clear the windshield f aster, you
can close the dashboard corner vents
by rotating the wheel next to it. This
sends more warm air to the
windshield def roster vents. Once the
windshield is clear, select the f resh
air mode to avoid fogging the
windows.
For your saf ety, make sure you have
a clear view through all the windows
bef ore driving. 1.
2.
1.
2.
3.
Climate Control System
Automatic Climate Control
T o Remove Exterior Frost or
Ice From the Windows
Features
211
2009 RL

Theclimatecontrolsystemhastwo
sensors: a sunlight sensor on top of
the dashboard, and a temperature
and humidity sensor next to the
steering column. Do not cover the
sensors or spill any liquid on them.
You can manually select various
f unctions of the climate control
system when it is in f ully automatic
mode. All other f eatures remain
automatically controlled. Making any
manual selection causes the word
AUTO in the display to go out.
Press the OFF button. However, a
lack of airf low can cause the
windowstofogup.Youshouldkeep
the fan on at all times so stale air and
moisture do not build up in the
interior and cause f ogging.
Climat e Cont rol Sensors
Sunlight and T emperature
Sensors
To Turn Everything Off
Semi-automatic Operation
212
SUNLIGHT SENSOR TEMPERATURE SENSOR
2009 RL

Most audio system f unctions can still
be controlled by standard buttons,
dials, and knobs, but some f unctions
can only be accessed using the
interf ace dial. The interf ace dial has
two parts, a knob and a selector.The selector can be pushed lef t,
right, up, down, and in. Use the
selector to scroll through lists, to
select menus, and to highlight menu
items. When you make a selection,
push the center of the selector
(ENTER)togotothatselection.
The knob turns lef t and right. Use it
to make selections or adjustments to
a list or menu on the screen.
When you unlock the doors with
your remote and turn the audio
system on, the driver’s ID (Driver 1
or Driver 2) is detected, and the
radio preset memory (see page ),
the auto select preset memory (see
page ), and the volume and
sound level settings (see page )
are turned to the respective
memorized mode automatically.
The audio system can also be
operated by voice control.
SeetheNavisectioninyourQuick
Start Guide f or an overview of this
system, and the Navigation System
manual f or complete details.
Ref er to Voice Control Basics f or
complete details (see page ).216
226
217
304
On models without navigation system
On models with navigation system
Interf ace Dial Personalization Setting
Voice Control System
Audio System
Features
213
KNOBENTER
SELECTOR
2009 RL

Audio System
Playing the AM/FM Radio
214
PRESET BUTTONSAM/FM
BUTTON
AM BUTTON
FM BUTTON
PRESET BUTTONS
UPPER DISPLAY
SCAN
BUTTON
INTERFACE DIAL INTERFACE DIAL
POWER/
VOLUME
KNOB
POWER/
VOLUME
KNOB
SCAN
BUTTON TUNE BAR
SEEK BAR
AUDIO
DISPLAY
BUTTON SEEK BAR
TUNE BAR
AUDIO
DISPLAY
BUTTON Hawaiian models
A.SEL
BUTTON
U.S. models (Technology package
model is shown) and Canadian models
2009 RL

µ
You can use any of f ive methods to
f ind radio stations on the selected
band: the
preset buttons, and .
The ignition switch must be in the
ACCESSORY (I) or the ON (II)
position. Press the AUDIO button to
view the audio control display. Turn
the system on by pressing the
power/volume knob or the AM/FM
button (AM or FM button on
Canadian and Hawaiian models).
Adjust the volume by turning the
power/volume knob. The band and f requency that the
radio was last tuned to are shown on
the display. To change bands, press
the AM/FM button (AM or FM
buttonHawaiianmodels).Youcan
also change bands between FM1 and
FM2 by pushing the interf ace
selector up. Each time you push it up,
the band will change to FM1 or FM2.
On the FM bands, STEREO will be
shown on the navigation screen and
ST on the upper display, if the
stationisbroadcastinginstereo.
Stereo reproduction on AM is not
available.
Use the TUNE bar to tune
the radio to a desired f requency.
Press the right side of the bar to
tune to a higher f requency, or the
lef t side to tune to a lower f requency.
To tune with the interf ace dial, push
the selector down, and turn the knob
to TUNE icon. Then press ENTER
on the selector, and turn the knob to
the desired f requency. To exit the
TUNE mode, press ENTER on the
selector, then push the selector up.
CONT INUED
To Select a Station
TUNE,SEEK,SCAN, AUTO SELECT TUNE
Audio System
Features
215
TUNE ICON
BAND
STEREO ICON
2009 RL

µ
µµ Each preset button or
preset icon can store one f requency
on AM and two f requencies on FM.
Usethetune,seek,orscan
function to tune the radio to a
desired station.
Select the desired band, AM or
FM. FM1 and FM2 let you store
twosetsof FMfrequencieswith
the preset buttons (on-screen
icons).
Repeat steps 1 through 3 to store a
total of six stations on AM and
twelve stations on FM.
Press the preset button, and hold
it until you hear a beep. You can
also store f requencies with the
interf ace dial. Select the preset
icon you want to store the
f requency on, then press ENTER
on the interf ace selector, and hold
it f or more than 2 seconds.
The skip (seek)
f unction searches up and down f rom
the current f requency to f ind a
station with a strong signal. To
activate it, press either side ( or ) of the SKIP bar, then release
it. You can also activate the skip
f unction (SEEK is displayed on the
screen) by pushing the interf ace
selector to the right or lef t. The SCAN f unction
samples all stations with strong
signals on the selected band. To
activate it, press the SCAN button,
then release it.
To scan with the interf ace dial, push
the selector down, and then push it
to the right. You will see SCAN
f lashing on the screen and the upper
display.
The system will scan f or a station
with a strong signal. When it f inds
one, it will stop and play that station
f or about 10 seconds. If you do
nothing, the system will then scan
f or the next strong station and play it
f or 10 seconds. When it plays a
station that you want to listen to,
press the scan button again, or push
the interface selector to the right
again.
4.
1.
2.
3.
To store a preset memory location:
Preset
SK IP (SEEK ) SCA N
Audio System
216
SCAN ICON
2009 RL

µIf you are
traveling far from home and can no
longer receive your preset stations,
you can use the auto select feature to
find stations in the local area. You will see ‘‘0’’ displayed if auto
select cannot f ind a strong station f or
every preset button.
If you do not like the stations auto
select has stored, you can store
other f requencies on the preset
buttons (icons) as previously
described.
To turn of f auto select, press
ENTER on the interf ace selector
(press the A.SEL button) again. This
restores the presets you originally
set.
Push the interf ace selector down to
scroll down the screen, highlight
A.SEL, then press ENTER on the
interf ace selector. You will see
A.SEL on the upper display and
A.SEL on the screen, and the system
goes into scan mode f or several
seconds.
Press the A.SEL button. You will see
A.SEL on the upper display A.SEL on
the screen, and the system goes into
scan mode f or several seconds. The
system stores the f requencies of six
AM and twelve FM stations in the
preset buttons.
U.S. models (except Hawaiian) and
Canadian models
Hawaiian models
AUTO SELECT
Audio System
Features
217
A.SEL ICON
2009 RL
