One of the most convenient and
important f eatures of the multi-
inf ormation display on your vehicle
is the maintenance minder.
Based on engine operating
conditions and accumulated engine
revolutions, the onboard computer in
your vehicle calculates the remaining
engine oil lif e.
The system also displays the code
f or other scheduled maintenance
items needing service.
To see the remaining engine oil lif e
displayed on the lower right corner
on the multi-information display as a
percentage, turn the ignition switch
to the ON (II) position, and press the
SEL/RESET button on the steering
wheel repeatedly until the engine oil
lifeappears(seepage ).The remaining engine oil lif e is
displayed according to the table
shown below.
Calculated Engine Oil Lif e (%)
100% 91% 90% 81%
80% 71%
70% 61%
60% 51%
50% 41%
40% 31%
30% 21%
20% 16%
15% 11%
10% 6% 5% 1% 0% Displayed
Engine Oil Lif e (%)
100% 90%
80%
70%
60%
50%
40%
30%
20%
15%
10%
5%
0%
73
CONT INUED
Maintenance Minder
Engine Oil L if e Display
Maint enance
445
REMAINING ENGINE OIL LIFE
2009 RL

ÝÛÝÛ
The message will be canceled if the
or buttononthesteeringwheel
is pressed. Press the or button
to see the message again.
When the remaining engine oil lif e is
15 to 6 percent, the multi-inf ormation
display shows a ‘‘SERVICE DUE
SOON’’ message along with the
maintenance schedule code
indicating the main and sub items
required at the time of the oil change.
Refer to page and for a
complete list of the maintenance
main items and sub items. Press the SEL/RESET button on the
steering wheel repeatedly to select
the engine oil lif e. The message
‘‘OIL LIFE’’ along with the
percentage of oil lif e remaining and
the maintenance item code(s),
appear on the lower part of the multi-
inf ormation display.
453 454
Maintenance Minder
446
MESSAGE
MAINTENANCE
MAIN ITEM REMAINING
ENGINE OIL LIFE
MAINTENANCE
SUB ITEM(S) MAINTENANCE
ITEM CODE(S)
2009 RL

ÝÛÝÛ
The message will be canceled if the
or buttononthesteeringwheel
is pressed. Press the or button
to see the message again.
When the remaining engine oil lif e is
1 to 5 percent, the multi-information
display shows a ‘‘SERVICE DUE
NOW’’ message with the
maintenance items. When you see
this message have the indicated
maintenance perf ormed as soon as
possible. Press the SEL/RESET button on the
steering wheel repeatedly to select
the engine oil lif e. The message
‘‘SERVICE OIL LIFE’’, along with
‘‘5%’’, and the maintenance item
code(s) are displayed on the lower
part of the multi-inf ormation display
when the calculated engine oil lif e is
1 to 5 percent (see page ).
445
CONT INUED
Maintenance Minder
Maint enance
447
2009 RL

ÝÛÛÝ
Press and hold the SEL/RESET
button on the steering wheel f or
more than 10 seconds. The
remaining engine oil lif e reset
mode will be shown on the multi-
inf ormation display.
To reset the engine oil lif e, press
the or button on the steering
wheel to select RESET on the
display, and press the SEL/
RESET button. To cancel resetting the oil life,
press the or button on the
steering wheel to select CANCEL
on the display, and press the SEL/
RESET button.
If you do not complete the reset
procedure within 30 seconds af ter
selecting the reset mode, the mode
will be canceled automatically.
Your dealer will reset the display
af ter completing the required
maintenance service. You will see
‘‘OIL LIFE 100%’’ on the display the
next time you turn the ignition
switch to the ON (II) position.
If maintenance service is done by
someone other than your dealer,
reset the maintenance minder as
f ollows:
If the oil lif e minder is not
displayed, press the SEL/RESET
buttononthesteeringwheel
repeatedly until it is.
Turn the ignition switch to the ON
(II) position.
The maintenance item code or codes
indicate the main and sub items
required at the time of the oil change
(see page ).
1.
2.
3.
453
Maintenance Minder
448
U.S.
CANADA
2009 RL

ÝÛÝÛ
Immediately have the service
perf ormed, and make sure to reset
the oil lif e minder as previously
described.
The message will be canceled if the
or buttononthesteeringwheel
is pressed. Press the or button
to see the message again.
If the indicated maintenance service
is not done and the remaining engine
oil lif e reaches 0%, the multi-
inf ormation display will show the
message ‘‘SERVICE PAST DUE’’
and the maintenance item code(s).
This message is displayed when the
total mileage is less than 10 miles
(f or U.S. models) or 10 km (f or
Canadian models) af ter the engine
oillifebecame0%. Press the SEL/RESET button on the
steering wheel repeatedly to select
the engine oil lif e minder. The
message ‘‘SERVICE OIL LIFE’’,
along with ‘‘0%’’, and the
maintenance item code are displayed
on the lower part of the multi-
inf ormation display when the
calculated engine oil lif e is 0 percent.
CONT INUED
Maintenance Minder
Maint enance
449
2009 RL

ÝÛÝÛ
Also, the percentage ‘‘0’’ keeps
blinking on the display.
If the indicated required service is
not done and the remaining engine
oil lif e becomes 0%, the multi-
inf ormation display will show a
‘‘SERVICE PAST DUE’’ message,
thetotalmileageaftertheremaining
oillifebecame0%,andthe
maintenance item code(s).This message is displayed when you
drive over 10 miles (f or U.S. models)
or 10 km (f or Canadian models)
af ter seeing the 0% message.
Immediately have the service
perf ormed, and make sure to reset
the display as previously described.
The message will be canceled if the
or buttononthesteeringwheel
is pressed. Press the or button
to see the message again.
This particular message is displayed
whenthemileageaftertheengineoil
lif e became 0% reaches 10 miles (f or
U.S. models)/10 km (f or Canadian
models).
The maximum total mileage shown
with this message is ‘‘9999 mile’’ (f or
U.S. models) or ‘‘9999 km’’ (f or
Canadian models).
Maintenance Minder
450
U.S.
CANADATOTAL PAST DUE MILEAGE
MAINTENANCE ITEM CODE(S)
2009 RL

µ
µ
This particular message is displayed
when you drive over 10 miles (f or
U.S. models) or 10 km (f or Canadian
models) af ter seeing 0%.
When you press the SEL/RESET
button to select the engine oil lif e
minder, the message ‘‘SERVICE’’,
along with the maintenance item
code and the total negative mileage
aftertheoillifebecame0percent,
will be displayed on the lower part of
the multi-information display. The maximum total negative mileage
is ‘‘ 9999 mile’’ (f or U.S. models) or
‘‘ 9999 km’’ (f or Canadian models).
If you have the required service
perf ormed but do not reset the
display, or reset the display without
perf orming the service, the system
will not show the proper
maintenance intervals. This can lead
to serious mechanical problems
because you will no longer have an
accurate record of when
maintenance is needed.
CONT INUED
Maintenance Minder
Important Maintenance
Precautions
Maint enance
451
U.S.
CANADA
TOTAL PAST DUE MILEAGE
2009 RL

µµµ
µ
µ
µ
Ì Engine oil level Check every
time you f ill the f uel tank. See
page .
Engine coolant level Check the
radiator reserve tank every time
you f ill the f uel tank. See page .
Automatic transmission Check
the f luid level monthly. See page
.
Lights Check the operation of
the headlights, parking lights,
taillights, high-mount brake light,
and license plate lights monthly.
See page .
Tires Check the tire pressure
monthly. Examine the tread f or
wear and foreign objects. See page .
Brakes Check the f luid level
monthly. See page .
U.S. Vehicles:
According to state and federal
regulations, f ailure to perf orm
maintenance on the items marked
with will not void your emissions
warranties. However, Acura
recommends that all maintenance
services be perf ormed in accordance
with the intervals indicated by the
multi-inf ormation display.
Youshouldcheckthefollowing
items at the specif ied intervals. If
you are unsure of how to perf orm
any check, turn to the appropriate
page listed.
We recommend using Acura parts
and fluids whenever you have
maintenance done. These are
manuf actured to the same high
quality standards as the original
components, so you can be conf ident
of their perf ormance and durability.
Your authorized dealer knows your
vehicle best and can provide
competent, ef f icient service.
However, service at a dealer is not
mandatory to keep your warranties
in effect. Maintenance may be done
by any qualif ied service f acility or
person who is skilled in this type of
automotive service. Keep all receipts
as proof of completion, and have the
person who does the work f ill out
your Maintenance Journal or
Canadian Maintenance Log. Check
your warranty booklet f or more
inf ormation. 389
389
464 466
480
468
Maintenance Minder
Maintenance, replacement, or
repair of emissions control
devices and systems may be done
by any automotive repair
establishment or individual using
parts that are ‘‘certif ied’’ to EPA
standards.
Owner’s Maintenance Checks
452
2009 RL

Î
Ì Ì
Ì Î
CONT INUED
Maintenance Minder
453
:
If the message ‘‘SERVICE DUE NOW’’ does not appear more than 12 months
after the display is reset, change the engine oil every year.
See information on maintenance and emissions warranty on page .
Inspect idle speed every 160,000 miles (256,000 km).
Adjust the valves during services A, B, 1, 2, or 3 only if they are noisy. Independent of the maintenance messages in the multi-information
display, replace the brake fluid every 3 years.
NOTE:
Maintenance Main Items
Replace engine oil
Replace engine oil and oil filter
Inspect front and rear brakes
Check parking brake adjustment
Inspect these items: Tie rod ends, steering gear box, and boots
Suspension components
Driveshaft boots
Brake hoses and line (including ABS)
All fluid levels and condition of fluids
Exhaust system
Fuel lines and connections
A
B
Symbol
: 452
Maintenance Minder
2009 RL

Install the engine oil f ill cap, and
tighten it securely. Wait a f ew
minutes, and recheck the oil level.
Do not f ill above the upper mark; you
could damage the engine.
Unscrew and remove the engine oil
fill cap on top of the valve cover.
Pour in the oil slowly and caref ully so
you do not spill any. Clean up any
spills immediately. Spilled oil could
damage components in the engine
compartment.Oil is a major contributor to your
engine’s perf ormance and longevity.
Always use a premium-grade 5W-20
detergent oil displaying the API
Certif ication Seal. This seal indicates
the oil is energy conserving, and that
it meets the American Petroleum
Institute’s latest requirements.
Acura Motor Oil is the pref erred
5W-20 lubricant f or your vehicle. It is
highly recommended that you use
Acura Motor Oil in your vehicle f or
optimum engine protection. Make
sure the API Certif ication Seal says
‘‘For Gasoline Engines.’’
The oil viscosity or weight is
provided on the container’s label.
5W-20 oil is f ormulated f or year-
round protection of your vehicle to
improve cold weather starting and
f uel economy.
Recommended Engine Oil
A dding Engine Oil
458
API CERTIFICATION SEAL
ENGINE OIL FILL CAP
Ambient Temperature
2009 RL
