This indicator comes on when the
security system is set. For more
inf ormation, see page . This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
Itcomesonasareminderthatyou
have turned off the adaptive front
lighting system (AFS).
This indicator blinks when there is a
problem with the AFS system; you
will also see a ‘‘CHECK ADAPTIVE
FRONT LIGHTING SYSTEM’’
message on the multi-inf ormation
display (see page ). If this
happens, stop the vehicle in a saf e
place, turn the ignition switch to the
ACCESSORY (I) or the LOCK (0)
position, and restart the engine. If
the indicator does not go of f or
blinks again, take your vehicle to a
dealer to have it checked. For more
inf ormation, see page .The CMBS indicator also comes on
if dirt or other debris blocks the
radar sensor in the f ront grille. You
will also see a ‘‘CHECK CMBS
RADAR SENSOR’’ message on the
multi-inf ormation display. When you
clean the radar sensor, the indicator
should go of f the next time you turn
the ignition switch to the ON (II)
position.
If the indicator comes on at any
other time, there is a problem with
the CMBS. You will also see a
‘‘CHECK CMBS SYSTEM’’ message
on the multi-information display. If
this happens, take your vehicle to a
dealer, and have it checked. For
more inf ormation, see page .
When this indicator is on, the CMBS
is not working. This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. It also comes on as areminder that you have turned of f
the collision mitigation braking
system (CMBS ).
144315
144
424
If equipped
If equipped
A daptive Front L ighting
System (A FS) IndicatorSecurity System Indicator
Collision Mitigation
Braking System
(CMBS ) Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
69
SECURITY SYSTEM INDICATOR
TM
TMTM TM
11/07/20 18:08:59 31SJA670_074
ProCarManuals.com

This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise
from the bottom white mark to about
the middle of the gauge. In severe
driving conditions, such as very hot
weather or a long period of uphill
driving, the pointer may rise to theupper end of the white section of the
gauge. If it reaches the red (hot)
mark, pull saf ely to the side of the
road. For more inf ormation, see page
.This shows how much f uel you
have. It may show slightly more
or less than the actual amount.
The needle returns to the
bottom after you turn off the
ignition.
505
Gauges
Temperature GaugeFuel Gauge
70
U.S. model is shown.TACHOMETER TEMPERATURE GAUGESPEEDOMETER
FUEL GAUGE
Avoid driving with an extremely low
f uel level. Running out of f uel could
cause the engine to misf ire, damaging
the catalytic converter.
11/07/20 18:09:06 31SJA670_075
ProCarManuals.com

This shows the outside Fahrenheit
temperature in U.S. models, and
Celsius temperature in Canadian
models.The temperature sensor is in the
f ront bumper. The temperature
reading can be affected by heat
ref lection f rom the road surf ace,
engine heat, and the exhaust f rom
surrounding traf f ic. This can cause
an incorrect temperature reading
when your vehicle speed is under
19 mph (30 km/h). When you start
your trip, the sensor is not f ully
acclimatized, theref ore it may take
several minutes until the proper
temperature is displayed.
This shows the remaining lif e of the
engine oil. It shows 100% af ter the
engine oil is replaced and the display
is reset. The engine oil lif e is
calculated based on engine operating
conditions and accumulated engine
revolutions. For more inf ormation,
see page . You can adjust the outside
temperature display (see page ).
In certain weather conditions,
temperature readings near f reezing
(32°F, 0°C) could mean that ice is
f orming on the road surf ace.97
445 Outside Temperature Engine Oil Lif e
Multi-Inf ormation Display
Inst rument s and Cont rols
73
OUTSIDE TEMPERATURE
U.S.
ENGINE OIL LIFE Canada
11/07/20 18:09:29 31SJA670_078
ProCarManuals.com

When you turn of f the engine, INST.
MPG or INST. L/100 km is also
reset. This shows your instant f uel
economy. Along with the trip meter, the trip
computer calculates these values:
Instantaneous Fuel Economy
Range
Elapsed Time
Average Fuel Economy Average Vehicle Speed
This shows the estimated distance
you can travel on the fuel remaining
in the f uel tank. This distance is
estimated f rom the f uel economy
you received over the last several
miles (U.S.) or kilometers (Canada),so it will vary with changes in speed,
traf f ic, etc.
When the battery is disconnected, or
you ref uel, RANGE is also reset.
This shows the accumulated
traveling time since you last reset it.
When you turn the ignition switch to
the ON (II) position, ELAPSED
TIME is reset.
You can customize the ELAPSED
TIME reset conditions on the multi-
inf ormation display (see page ).
This shows the average speed you
are traveling in miles per hour (mph)
f or U.S. models or kilometers per
hour (km/h) f or Canadian models.
When you reset Trip A, average
speed is also reset.You can customize the average
speed reset condition on the multi-
inf ormation display (see page ).
This shows your vehicle’s average
f uel economy in mpg (U.S. models)
or liter/100 km (Canadian models)
since you last reset Trip A or Trip B.
The average f uel economy will be
reset when you reset the trip meter,
or if the vehicle’s battery goes dead
or is disconnected.
You can customize the average fuel
A reset condition on the multi-
inf ormation display (see page ). 10199
99
Multi-Inf ormation Display
INST.MPG(U.S.models)/INST.
L /100km (Canadian models) Trip Computer
RANGEEL A PSED T IME
A VERA GE SPEEDAVERAGE FUEL A/B
Inst rument s and Cont rols
75
11/07/20 18:09:50 31SJA670_080
ProCarManuals.com

When the engine oil lif e reaches 15%,
the display shows ‘‘SERVICE DUE
SOON’’ and the code f or the
maintenance items to be perf ormed.Have your dealer do the indicated
maintenance as soon as you see this
message, and have them reset the
display af ter completing the service.
If you do not perf orm the indicated
maintenance or do not reset the
display, the message changes to
‘‘SERVICE PAST DUE’’ when the
engine oil lif e becomes 0%.
These messages appear on the multi-
inf ormation display each time you
turn the ignition switch to the ON
(II) position.
For details on engine oil lif e and
maintenance messages, ref er to page
.
Also ref er to page f or important
maintenance saf ety precautions. When the engine oil lif e reaches 5%,
the display shows ‘‘SERVICE DUE
NOW’’ along with the same
maintenance items. To use the system, your cell phone
and the HFL system must be linked.
Not all cell phones are compatible
with this system. Ref er to page
for instructions on how to link
your cell phone to HFL and how to
receive or make phone calls, or visit
the acura.com/handsf reelink
website. In Canada, visit
, or call 1-888-9-ACURA-9. 354
445
444
www.acura.
ca
Maintenance Messages
Multi-Inf ormation Display
Inst rument s and Cont rols
77
11/07/20 18:10:06 31SJA670_082
ProCarManuals.com

µ
The automatic lighting f eature is
controlledbyasensorlocatedontop
of the dashboard. Do not cover this
sensor or spill liquids on it. Even with the automatic lighting
f eature turned on, we recommend
thatyouturnonthelightsmanually
when driving at night or in a dense
f og, or when you enter dark areas
such as long tunnels or parking
f acilities. To turn on automatic lighting, turn
the light switch to AUTO. The lights
will come on automatically when the
outside light level becomes low (at
dusk, f or example). The lights on
indicator comes on as a reminder.
The lights and indicator will turn of f
automatically when the system
senses high ambient light.To change the ‘‘AUTO LIGHT
SENSITIVITY’’ setting, see page
. The automatic lighting
f eature turns on the headlights, all
other exterior lights, and the
instrument panel lights when it
senses low ambient light.
The lights will remain on when you
turn of f the ignition switch. They will
turn of f automatically when you open
and close the driver’s door. To turn
them on again, either turn the
ignition switch to the ON (II)
position or turn the light switch to
the position.Do not leave the light switch in
AUTO if you will not be driving the
vehicle f or an extended period (a
weekormore).Youshouldalsoturn
of f the lights if you plan to leave the
engine idling or of f f or a long time.120 AUTO
Turn Signals and Headlights
Inst rument s and Cont rols
141
LIGHT SENSOR
11/07/20 18:17:33 31SJA670_146
ProCarManuals.com

If the AFS indicator comes on and
starts blinking while driving, pull to
the side of the road when it is saf e,
andturnoff theengine.If theAFS
indicator keeps blinking, or starts
blinking again while driving af ter
turning the ignition switch to the ON
(II) position, the AFS is not working
properly (see page ). Have the
AFS inspected by your dealer.
When the AFS indicator comes on,
you will also see a ‘‘CHECK
ADAPTIVE FRONT LIGHTING
SYSTEM’’ message on the multi-
inf ormation display (see page ). Without AFS, your vehicle still has
normal lighting ability to continue
driving. The adaptive f ront lighting system
(AFS) helps to improve visibility
during nighttime driving. The AFS
controls the aiming direction and
lighting distribution of the low
beams according to the amount of
turn applied to the steering wheel
during cornering or turning. Press
the AFS OFF switch to turn the AFS
on and off when the ignition switch
is in the ON (II) position and the
headlights are turned on.69
69
If equippedAFS Indicator
A dapt ive Front L ight ing Syst em (A FS)
144
11/07/20 18:17:55 31SJA670_149
ProCarManuals.com

These keys contain electronic
circuits that are activated by the
immobilizer system. They will not
work to start the engine if the
circuits are damaged.
Protect the keys f rom direct
sunlight, high temperature, and
high humidity.
Donotdropthekeysorsetheavy
objects on them.
Keep the keys away f rom liquids.
If they get wet, dry them
immediately with a sof t cloth.
The keys do not contain batteries.
Do not try to take them apart. The built-in key (see page ) f its
all the locks on your vehicle.
Youshouldhavereceivedakey
number tag with your keys. You will
need this key number if you ever
have to get a lost key replaced. Use
only Acura-approved key blanks.The immobilizer system protects
your vehicle f rom thef t. If an
improperly-coded key (or other
device) is used, the engine will not
start.
When you turn the ignition switch to
the ON (II) position, the immobilizer
system indicator should come on
briefly, then go out. If the indicator
starts to blink, it means the system
does not recognize the coding of the
Honda smart key or built-in key.
Turn the ignition switch to the
LOCK (0) position, release the
ignition switch and push it, or
remove the built-in key, and reinsert
it.ThenturntheswitchtotheON
(II) position again. 181
Keys and Locks, Immobilizer System
Keys and Locks Immobilizer System
150
KEY NUMBER TAG BUILT-IN KEYS
11/07/20 18:18:38 31SJA670_155
ProCarManuals.com

The system may not recognize your
key’s coding if another immobilizer
key or other metal object (i.e. key
chain) is near the ignition switch
when you turn the ignition switch to
the ON (II) position.
If the system repeatedly does not
recognize the coding of your remote
or built-in key, contact your dealer.
Do not attempt to alter this system
or add other devices to it. Electrical
problems could result that may make
your vehicle inoperable.
If you have lost your remote or
built-in key and cannot start the
engine, contact your dealer.The ignition switch has f our
positions: LOCK (0), ACCESSORY
(I), ON (II), and START (III).
To use the built-in key, you have to
remove the cover (see page ).178As required by the FCC:
This device complies with Part 15 of the
FCC rules. Operation is subject to the
f ollowing two conditions: (1) This device
may not cause harmf ul interf erence, and
(2) this device must accept any
interf erence received, including
interf erence that may cause undesired
operation.
Changes or modif ications not expressly
approved by the party responsible f or
compliance could void the user’s
authority to operate the equipment.
This device complies with Industry
Canada Standard RSS-210.
Operation is subject to the f ollowing two
conditions: (1) this device may not cause
interf erence, and (2) this device must
accept any interf erence that may cause
undesired operation of the device.
CONT INUED
Ignition Switch
Immobilizer System, Ignition Switch
Inst rument s and Cont rols
151
IGNITION SWITCHBUILT-IN KEY
COVER
Always take the keyless access remote
and built-in key with you whenever you
leave the vehicle alone.
11/07/20 18:18:47 31SJA670_156
ProCarManuals.com

µ
µµ
µ You can insert or
remove the built-in key only in this
position. To turn the ignition switch
to the LOCK (0) position, the shift
lever must be in Park, and you must
push the knob or built-in key in
slightly.
If the f ront wheels are turned, the
anti-theft lock may make it difficult
to turn the ignition switch. Firmly
turn the steering wheel to the left or
right as you turn the ignition switch.
You can
operate the audio system and the
accessory power sockets in this
position.When you turn the ignition switch to
the ACCESSORY (I) position, an
‘‘ACCESSORY (I) POSITION’’
message is shown on the multi-
inf ormation display.
This is the normal
ignition switch position when driving.
Several of the indicators on the
instrument panel come on as a test
when you turn the ignition switch
f rom the ACCESSORY (I) to the ON
(II) position.
Use this position
only to start the engine. The switch
returns to the ON (II) position when
you let go of the ignition switch.If you open the driver’s door and
leave the ignition switch in the
ACCESSORY (I) or LOCK (0)
position, you will hear a reminder
beeper, and a message appears on
the multi-information display
according to the ignition switch
position. When the ignition switch is
in the ACCESSORY (I) position, a
‘‘RETURNIGNITIONSWITCHTO
LOCK (0) POSITION’’ message is
shown on the multi-inf ormation
display. When the ignition switch is
in the LOCK (0) position, a
‘‘REMOVE KEY’’ message is shown
on the multi-information display.
TheshiftlevermustbeinPark
bef ore you turn the ignition switch
knob to the LOCK (0) position or
remove the built-in key from the
ignition switch.
Ignition Switch
LOCK (0)
A CCESSORY (I)ON (II)
ST A RT (III)
152
11/07/20 18:18:55 31SJA670_157
ProCarManuals.com
