keyless ACURA RL 2012 User Guide

ÛÝ To exit KEYLESS ACCESS LIGHT
FLASH without changing the
current setting, select EXIT by
pressing the INFO ( / ) button,
then press the SEL/RESET button.
The screen goes back to
CUSTOMIZE MENU. When your choice is set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE ENTRY.If your choice is not set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE SETUP. If this
happens, you need to repeat the
keyless access light f lash setup.
Multi-Inf ormation Display
112
11/07/20 18:14:15 31SJA670_117
ProCarManuals.com

ÛÝÛÝ When KEYLESS ACCESS BEEP is
set to ON, the beeper sounds twice
when you unlock the doors by
grabbing the drivers door handle
while carrying the remote.
When you lock the doors by
touching the door lock sensor while
carrying the remote, the beeper
sounds once.
While the multi-information display
is in the KEYLESS ACCESS SETUP
screen of the CUSTOMIZE GROUP,
press the SEL/RESET button. The
screen changes to CUSTOMIZE
MENU. Press the INFO ( / )
button until you see the above
display.Press the SEL/RESET button. The
screen changes as shown above.
Select ON or OFF by pressing the
INFO ( / ) button, then press the
SEL/RESET button to enter your
selection.
CONT INUED
K eyless A ccess Beep
Multi-Inf ormation Display
Inst rument s and Cont rols
113
11/07/20 18:14:22 31SJA670_118
ProCarManuals.com

ÛÝ To exit KEYLESS ACCESS BEEP
without changing the current setting,
select EXIT by pressing the INFO
( / ) button, then press the SEL/
RESET button. The screen goes
back to CUSTOMIZE MENU. When your choice is set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE ENTRY.If your choice is not set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE SETUP. If this
happens, you need to repeat the
keyless access beep setup.
Multi-Inf ormation Display
114
11/07/20 18:14:27 31SJA670_119
ProCarManuals.com

Û
Ý
Û
Ý
ÛÝ
ÛÝ
AUTO DOOR LOCK
AUTO DOOR UNLOCK There are five settings to choose
f rom in the door/window setup:
While CUSTOMIZE GROUP is
shown on the multi-inf ormation
display, select DOOR/WINDOW
SETUP by pressing the INFO ( /
) button, and then press the SEL/
RESET button.
Each time you press the INFO ( /
) button, the screen changes as
shown in the illustration. Press the
INFO ( / ) button, until you see
the setting you want to customize,
then press the SEL/RESET button
to enter your selection.SECURITY RELOCK TIMER DOOR LOCK MODE
KEYLESS LOCK
ACKNOWLEDGMENT Door/Window Setup
Multi-Inf ormation Display
122
seepage123
seepage125
seepage127
seepage129
see page 131
Press the or button.
Press the SEL/RESET button.
11/07/20 18:15:24 31SJA670_127
ProCarManuals.com

ÛÝ When your choice is set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE ENTRY.If your choice is not set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE SETUP. If this
happens, you need to repeat the
keyless lock acknowledgment setup.To exit KEYLESS LOCK
ACKNOWLEDGMENT without
changing the current setting, select
EXIT by pressing the INFO ( / )
button, then press the SEL/RESET
button. The screen goes back to
CUSTOMIZE MENU.
Multi-Inf ormation Display
130
11/07/20 18:16:14 31SJA670_135
ProCarManuals.com

The system may not recognize your
key’s coding if another immobilizer
key or other metal object (i.e. key
chain) is near the ignition switch
when you turn the ignition switch to
the ON (II) position.
If the system repeatedly does not
recognize the coding of your remote
or built-in key, contact your dealer.
Do not attempt to alter this system
or add other devices to it. Electrical
problems could result that may make
your vehicle inoperable.
If you have lost your remote or
built-in key and cannot start the
engine, contact your dealer.The ignition switch has f our
positions: LOCK (0), ACCESSORY
(I), ON (II), and START (III).
To use the built-in key, you have to
remove the cover (see page ).178As required by the FCC:
This device complies with Part 15 of the
FCC rules. Operation is subject to the
f ollowing two conditions: (1) This device
may not cause harmf ul interf erence, and
(2) this device must accept any
interf erence received, including
interf erence that may cause undesired
operation.
Changes or modif ications not expressly
approved by the party responsible f or
compliance could void the user’s
authority to operate the equipment.
This device complies with Industry
Canada Standard RSS-210.
Operation is subject to the f ollowing two
conditions: (1) this device may not cause
interf erence, and (2) this device must
accept any interf erence that may cause
undesired operation of the device.
CONT INUED
Ignition Switch
Immobilizer System, Ignition Switch
Inst rument s and Cont rols
151
IGNITION SWITCHBUILT-IN KEY
COVER
Always take the keyless access remote
and built-in key with you whenever you
leave the vehicle alone.
11/07/20 18:18:47 31SJA670_156
ProCarManuals.com

If your vehicle’s battery goes dead or
is disconnected, you can open the
trunk f rom the rear seat by pulling
the trunk release handle. Reach the
handle through the trunk pass-
through.
Keep the trunk lid closed at all times
while driving to avoid damaging the
lid, and to prevent exhaust gas f rom
getting into the interior. See
on page . Youcanopenthetrunkinanyof
f our ways:If the doors are locked, press the
trunk release switch on the trunk
lid with the remote in keyless
access operating range.
To close the trunk, press down on
the trunk lid.
Press the trunk release button on
the driver’s door.
Press and hold the trunk release
button on the remote.
If the doors are unlocked, press
thetrunkreleaseswitchonthe
trunk lid.56Carbon
Monoxide Hazard
Trunk
154
TRUNK RELEASE BUTTONTRUNK RELEASE HANDLE
11/07/20 18:19:12 31SJA670_159
ProCarManuals.com

Your vehicle has a keyless access
system. When you carry the remote
with you, you can lock/unlock the
door(s), unlock the trunk, and start
the engine without using the built-in
key.
The system may not work if:
Thebatteryof theremoteisweak.
You carry a cell phone, a laptop
computer, or other electrical
device near the remote. There is strong electrical current
nearby.
The remote is covered by metal.
A vehicle is being operated with a
transmitter nearby.
When the remote battery is dead.Protect the remote and the built-in
key f rom direct sunlight, high
temperature, and high humidity.
When the vehicle battery is dead.
Make sure the driver always carries
the remote/built-in key set.Do not drop the remote or the
built-in key, and do not set heavy
objects on them.
The built-in keys do not contain
batteries. Keep the remote and the built-in key
away f rom liquids. If they get wet,
dry them immediately with a sof t
cloth.
Always keep the remote and the
built-in key away from any magnetic
material.
Youshouldhavereceivedakey
number tag with your built-in key.
You will need this key number if you
ever have to get a lost key replaced.
UseonlyAcura-approvedkeyblanks.This key is used to lock/unlock the
doors, glove box, trunk pass-through
cover, and to start the engine (af ter
you remove the ignition switch cover,
see page ). The f ollowing keys come with your
vehicle. Refer to page for how to
separate the keys.
178181
CONT INUED
K eyless A ccess System
Built -in K ey
Keys
Inst rument s and Cont rols
167
BUILT-IN KEYS KEYLESS ACCESS
REMOTES
KEY NUMBER TAG
11/07/20 18:21:10 31SJA670_172
ProCarManuals.com

The handle of each f ront door has a
sensor. That sensor works with the
remote so you can automatically
unlock/lock the door(s).
By def ault, only the driver’s door
unlocks when you grab its handle.If a remote is within operating range
while you wash your vehicle or when
it is raining heavily, the door sensors
may respond by unlocking the doors.
The unlock sensors do not operate
when:
Theremoteisnotwithinthe
operating range.
The remote is too close to the
vehicle.
When the doors are unlocked.
Theremotebatteryisdead.
The vehicle battery is dead.
If you do not open any of the doors
within 30 seconds, they will
automatically relock. If you wear a glove while grabbing a
f ront door handle, the door sensor
maybeslowtorespondormaynot
respond by unlocking the doors. To change the ‘‘KEYLESS ACCESS
BEEP’’ setting, see page . To change the ‘‘KEYLESS ACCESS
LIGHT FLASH’’ setting, see page
. When you unlock the door(s), some
exterior lights blink twice and the
system beeps twice. All the doors unlock when you grab
the handle of the f ront passenger’s
door. To change the ‘‘DOOR UNLOCK
MODE’’ setting, see page .
To unlock the remaining doors and
the trunk, press the UNLOCK
button on the remote or the rear of
the master door lock switch on the
driver’s door.109
111
113 Unlocking the Door(s)
K eyless A ccess System
Inst rument s and Cont rols
169
11/07/20 18:21:30 31SJA670_174
ProCarManuals.com

Each f ront door has a LOCK/
UNLOCK f eature.
When you touch the door lock
sensor of the f ront door by hand, all
the doors and the trunk will lock.The lock sensors do not operate if :
When you lock the doors, some
exterior lights blink once and thesystem beeps once. When you
cannot set the security system
because the trunk or hood is open,
no exterior light blinks and/or no
beeper sounds.
Bef ore locking the doors, make sure
theremoteisnotinsidethevehicle.If a remote is within operating range
while you wash your vehicle or when
it is raining heavily, the door sensors
may respond by locking the doors. Within 2 seconds of touching the
handle to lock the doors or locking
the doors with remote, pull the
handletomakesurethedoorsare
actually locked. The door unlock
sensors do not operate f or about 2
seconds af ter the doors are locked. To change the ‘‘KEYLESS ACCESS
BEEP’’ setting, see page . To change the ‘‘KEYLESS ACCESS
LIGHT FLASH’’ setting, see page
.If you touch the door lock sensor of
the f ront door with your hand
wearing a glove, the door sensor may
delay to respond or not respond by
locking the doors.
Theremoteisnotwithinthe
operating range.
The doors are open.
The ignition switch is not in the
LOCK (0) position.
The built-in key is in the ignition
switch.
The remote is too close to the
vehicle.
Theremotebatteryisdead.
The vehicle battery is dead. 111
113 L ocking the Doors
K eyless A ccess System
170
DOOR LOCK SENSOR
11/07/20 18:21:43 31SJA670_175
ProCarManuals.com
