ACURA RL 2012 Workshop Manual

CONT INUED
If it is necessary to put a f orward-
f acing child seat in the f ront, move
the vehicle seat as far to the rear as
possible, and be sure the child seat is
f irmly secured to the vehicle and the
child is properly strapped in the seat.Most child seats are LATCH-
compatible (Lower Anchors and
Tethers f or CHildren). Some have a
rigid-type connector, while others
have a f lexible-type connector. Both
are equally easy to use. Some
existing and previously owned child
seats can only be installed using the
seat belt. Whichever type you
choose, f ollow the child seat
manuf acturer’s use and care
instructions as well as the
instructions in this manual. Proper
installation is key to maximizing your
child’s saf ety.In seating positions and vehicles not
equipped with LATCH, a LATCH-
compatible child seat can be installed
using the seat belt and a top tether
f or added security. This is because
all child seats are required to be
designed so that they can be secured
with a lap belt or the lap part of a
lap/shoulder belt.
In addition, the child seat
manufacturer may advise that a seat
belt be used to attach a LATCH-
compatible seat once a child reaches
a specif ied weight. Please read the
child seat owner’s manual f or proper
installation instructions.
Protecting Inf ants and Small Children, Selecting a Child Seat
Selecting a Child Seat
Driver and Passenger Saf ety
45
Placing a forward-facing child
seat in the front seat can result
in serious injury or death if the
front airbag inflates.
Ifyoumustplaceaforward-
facing child seat in front, move
the vehicle seat as far back as
possible, and properly restrain
the child.
11/07/20 18:05:24 31SJA670_050
ProCarManuals.com

Af ter selecting a proper child seat
and a good place to install the seat,
there are three main steps in
installing the seat:
All child seats must be
secured to the vehicle with the lap
part of a lap/shoulder belt or with
the LATCH (Lower Anchors and
Tethers f or CHildren) system. A
child whose seat is not properly
secured to the vehicle can be
endangered in a crash.
Af ter installing a child
seat, push and pull the seat
f orward and f rom side-to-side to
verif y that it is secure.
A child seat secured with a seat belt
should be installed as f irmly as
possible. However, it does not need
to be ‘‘rock solid.’’ Some side-to-sidemovement can be expected and
should not reduce the child seat’s
ef f ectiveness.
If the child seat is not secure, try
installing it in a dif f erent seating
position, or use a dif f erent style of
child seat that can be f irmly secured.
Make sure the child is properly
strappedinthechildseat
according to the child seat maker’s
instructions. A child who is not
properly secured in a child seat
canbeseriouslyinjuredinacrash.
The f ollowing pages provide
guidelines on how to properly install
a child seat. A f orward-f acing child
seat is used in all examples, but the
instructions are the same f or rear-
f acing child seats. Make sure the child seat meets the
f ollowing three requirements:
The child seat is the correct type
and size f or the child.
The child seat is the correct type
f or the seating position.
The child seat is compliant with
Federal Motor Vehicle Saf ety
Standard 213 or Canadian Motor
Vehicle Saf ety Standard 213.
Selecting a Child Seat, Installing a Child Seat
Installing a Child Seat Important considerations when
selecting a child seat
Properly secure t he child seat t o
the vehicle.
Make sure t he child seat is f irmly
secured.Secure the child in the child seat. 1.
2.3.
46
11/07/20 18:05:34 31SJA670_051
ProCarManuals.com

CONT INUED
To install a LATCH-compatible child
seat:
Move the seat belt buckle or
tongue away f rom the lower
anchors. Your vehicle is equipped with
LATCH (Lower Anchors and
Tethers for CHildren) at the outer
rear seats.
Make sure there are no objects
near the anchors that could
prevent a secure connection
between the child seat and the
anchors. The lower anchors are located
between the seat-back and seat
bottom, and are to be used only with
a child seat designed f or use with
LATCH.
The location of each lower anchor is
indicated by a small button above the
anchor point.Turn the ignition switch to the ON
(II) position, then push the rear
head restraint tilt button on the
ceiling console to pivot the head
restraints down. 1.
2.3.
Installing a Child Seat
Installing a Child Seat with
LATCH
Driver and Passenger Saf ety
47
REAR HEAD RESTRAINT TILT BUTTON LOWER ANCHORSBUTTON
11/07/20 18:05:44 31SJA670_052
ProCarManuals.com

Place the child seat on the vehicle
seat, then attach the seat to the
lower anchors according to the
child seat maker’s instructions.
Some LATCH-compatible seats
have a rigid-type connector as
shown above.Other LATCH-compatible seats
have a f lexible-type connector as
shown above.
Whatever type you have, f ollow
the child seat maker’s instructions
f or adjusting or tightening the f it.Route the tether strap over the
head restraint, then attach the
tether strap hook to the anchor,
making sure the strap is not
twisted.
Tighten the strap according to the
seat maker’s instructions.
Pushandpullthechildseat
f orward and f rom side-to-side to
verif y that it is secure. Open the anchor cover. 4.
5.7.
8.
6.
9.
Installing a Child Seat
48
RIGID TYPE FLEXIBLE TYPEANCHORCOVER TETHER STRAP HOOK
11/07/20 18:05:53 31SJA670_053
ProCarManuals.com

CONT INUED
When not using the LATCH system,
all child seats must be secured to the
vehicle with the lap part of a lap/
shoulder belt.
With the child seat in the desired
seating position, route the belt
through the child seat according
to the seat maker’s instructions,
then insert the latch plate into the
buckle and remove any slack f rom
the lap portion of the belt.To activate the lockable retractor,
slowly pull the shoulder part of the
belt all the way out until it stops,
then let the belt feed back into the
retractor.
Af ter the belt has retracted, tug on
it. If the belt is locked, you will not
be able to pull it out. If you can pull
thebeltout,itisnotlocked,and
you will need to repeat these steps. In addition, the lap/shoulder belts in
all seating positions except the
driver’s have a lockable retractor
that must be activated to secure a
child seat.
1. 2.
3.
Installing a Child Seat
Installing a Child Seat with a L ap/
Shoulder Belt
Driver and Passenger Saf ety
49
11/07/20 18:06:00 31SJA670_054
ProCarManuals.com

To deactivate the lockable retractor
andremoveachildseat,unlatchthe
buckle, unroute the seat belt, and let
the belt fully retract.
Push and pull the child seat
f orward and f rom side-to-side to
verif y that it is secure enough to
stay upright during normal driving
maneuvers. If the child seat is not
secure, unlatch the belt, allow it to
retract f ully, then repeat these
steps. Af ter conf irming that the belt is
locked, grab the shoulder part of
the belt near the buckle, and pull
up to remove any slack from the
lap part of the belt. Remember, if
the lap part of the belt is not tight,
the child seat will not be secure.
To remove slack, it may help to
putweightonthechildseat,or
push on the back of the seat while
pulling up on the belt.5. 4.
Installing a Child Seat
50
11/07/20 18:06:06 31SJA670_055
ProCarManuals.com

A child seat with a tether can be
installed in any seating position in
the back seat, using one of the
anchorage points shown above.
Since a tether can provide additional
security to the lap/shoulder belt
installation, we recommend using a
tether whenever one is required or
available.Lift the anchor cover, then attach
the tether strap hook to the
anchor, making sure the strap is
not twisted.
Tighten the strap according to the
seat maker’s instructions.
Af ter properly securing the child
seat with the lap/shoulder belt
(see page ), pivot the head
restraint down (see page ) and
route the tether strap over the
head restraint. 1.2.
3.
22
157
Installing a Child Seat
Installing a Child Seat with a
Tether
Driver and Passenger Saf ety
51
TETHER STRAP HOOK
ANCHOR COVERTETHER ANCHORAGE POINTS
ANCHOR
11/07/20 18:06:14 31SJA670_056
ProCarManuals.com

To determine if a lap/shoulder belt
properly f its a child, have the child
put on the seat belt, then ask
yourself :
Does the child sit all the way back
against the seat?
Do the child’s knees bend
comf ortably over the edge of the
seat? When a child reaches the
recommended weight or height limit
for a forward-facing child seat, the
child should sit in a back seat on a
booster seat and wear the lap/
shoulder belt.
The f ollowing pages give
instructions on how to check proper
seat belt f it, what kind of booster
seat to use if one is needed, and
important precautions f or a child
who must sit in f ront.
1.
2. Checking Seat Belt Fit
Protecting L arger Children
52
Allowing a child age 12 or under
to sit in front can result in injury
or death if the passenger’s front
airbag inflates.
If a child must ride in front,
move the vehicle seat as far
back as possible, use a booster
seat if needed, have the child
sit up properly and wear the
seat belt properly.
11/07/20 18:06:21 31SJA670_057
ProCarManuals.com

Does the shoulder belt cross
between the child’s neck and arm?
Is the lap part of the belt as low as
possible, touching the child’s
thighs?
Will the child be able to stay
seated like this f or the whole trip?
If you answer yes to all these
questions, the child is ready to wear
the lap/shoulder belt correctly. If
you answer no to any question, the
child needs to ride on a booster seat. A child who has outgrown a f orward-
f acing child seat should ride in a
back seat and use a booster seat
until the lap/shoulder belt f its them
properly without the booster.If a child who uses a booster seat
must ride in f ront, move the vehicle
seat as far back as possible and be
sure the child is wearing the seat
belt properly.
A child may continue using a booster
seat until the tops of their ears are
even with the top of the vehicle’s or
booster’s seat-back. A child of this
height should be tall enough to use
the lap/shoulder belt without a
booster seat. Some states, Canadian provinces and
territories also require children to
use a booster seat until they reach a
given age or weight (e.g., 6 years or
60lbs).Besuretocheckcurrent
laws in the states, provinces andterritories where you intend to drive.
Booster seats can be high-back or
low-back. Whichever style you select,
make sure the booster seat meets
f ederal saf ety standards (see page
) and that you f ollow the booster
seat maker’s instructions. 3.
4.
5.46 Using a Booster Seat
Protecting L arger Children
Driver and Passenger Saf ety
53
11/07/20 18:06:30 31SJA670_058
ProCarManuals.com

If you decide that a child can saf ely
ride up f ront, be sure to:
Caref ully read the owner’s manual,
and make sure you understand all
seat belt instructions and all saf ety
inf ormation.
Move the vehicle seat to the rear-
most position.
Have the child sit up straight, back
against the seat, and feet on or
near the f loor.
Check that the child’s seat belt is
properly and securely positioned.
Supervise the child. Even mature
children sometimes need to be
reminded to f asten the seat belts
or sit properly. Of course, children vary widely. And
while age may be one indicator of
when a child can saf ely ride in f ront,
there are other important f actors you
should consider.
If the passenger’s f ront airbag
inf lates in a moderate to severe
f rontal collision, the airbag can cause
serious injuries to a child who is
unrestrained, improperly restrained,
sitting too close to the airbag, or out
of position.
A side airbag also poses risks. If any
part of a larger child’s body is in the
path of a deploying side airbag, the
child could receive possibly serious
injuries. The National Highway Traffic Safety
Administration and Transport
Canada recommend that all children
age 12 and under be properly
restrained in a back seat.
Physically, a child must be large
enough f or the lap/shoulder belt to
properly f it (see pages and ). If
the seat belt does not f it properly,
with or without the child sitting on a
booster seat, the child should not sit
in f ront.
To saf ely ride in f ront, a child must
be able to f ollow the rules, including
sitting properly, and wearing the seat
belt properly throughout a ride.52 17
Protecting L arger Children
Physical Size
Maturity
When Can a L arger Child Sit in
Front
54
11/07/20 18:06:41 31SJA670_059
ProCarManuals.com
