The fuses are located in five fuse
boxes. The interior f use boxes are
located under the dashboard on the
driver’s and passenger’s side.
To remove the f use box lid, put your
f inger in the notch on the lid, pull it
toward you, and take it out of its
hinges.To open the secondary f use box lid,
push the tab in the direction as
shown in the illustration.
Fuses
512
NOTCHNOTCH INTERIOR FUSE BOX
Driver’s sideINTERIOR FUSE BOX
Passenger’s sideSECONDARY INTERIOR FUSE BOX
Driver’s side
FUSE BOX
11/07/20 19:07:28 31SJA670_517
ProCarManuals.com

The primary under-hood f use box is
in the engine compartment on the
driver’s side. To open it, push the
tabs as shown.The secondary under-hood f use box
is on the battery. To open it, push
thetabsasshown.
To check the f use box, remove the
battery cover f irst (see page ).492
Fuses
T aking Care of t he Unexpect ed
513
PRIMARY UNDER-HOOD FUSE BOX SECONDARY UNDER-HOOD FUSE BOX
TABTAB
11/07/20 19:07:34 31SJA670_518
ProCarManuals.com

Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are of f . If something electrical in your
vehicle stops working, the first thing
youshouldcheckforisablownfuse.
Determine f rom the chart on pages
, , and , or the diagram
on the f use box lid, which f use or
f uses control that device. Check
those fuses first, but check all the
f uses bef ore deciding that a blown
f use is the cause. Replace any blown
f uses, and check if the device works.
Check each of the large f uses in
the under-hood f use box by
looking through the top at the wire
inside. Removing these f uses
requires a Phillips-head
screwdriver. Remove the cover f rom the f use
box.3. 1.
2.518 519 520 Checking and Replacing Fuses
Fuses
514
FUSE
BLOWN
BLOWN
11/07/20 19:07:42 31SJA670_519
ProCarManuals.com

CONT INUED
Check the smaller f uses in the
under-hood f use box and all the
fuses in the interior fuse boxes by
pulling out each f use with the f use
puller. The f use puller is inside the
primary under-hood f use box.Look f or a blown wire inside the
fuse.If itisblown,replaceitwith
one of the spare f uses of the same
rating or lower. 4. 5.
Fuses
T aking Care of t he Unexpect ed
515
FUSE
FUSE PULLERBLOWN
BLOWN
11/07/20 19:07:48 31SJA670_520
ProCarManuals.com

If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem with your
vehicle. Leave the blown fuse in
that circuit, and have your vehicle
checked by a qualif ied technician. If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accessory
power socket).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate that anything is wrong.
Replace the f use with one of the
correct rating as soon as you can.6.
Fuses
516
SPARE FUSES
FUSE PULLER
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper rating
f or the circuit, install one with a lower
rating.
11/07/20 19:07:54 31SJA670_521
ProCarManuals.com

If thefuseforthedrivingposition
memory system is removed, all
stored driving positions will be lost.
To store the driving positions again,
see page .If the navigation system f use is
removed, the navigation system will
disableitself.Thenexttimeyouturn
on the ignition switch, the system
will require you to enter a PIN
bef ore it can be used. Ref er to the
navigation system manual. If thefuseforthepowertilt
telescopic steering is removed, the
system will be disabled. The system
needs to be reset af ter reinstalling
thefuse(seepage ). If thecompasssystemfuseis
removed, the compass system will
disableitself.Thenexttimeyouturn
on the ignition switch, the system
will require you to enter a PIN
bef ore it can be used. Enter the f our-
digit anti-thef t security code (see
page ). You will also need to
reset the clock according to the
setting the clock instructions (see
page ). 149
298
313 164On vehicles with navigation system
On vehicles without navigation system
Fuses
T aking Care of t he Unexpect ed
517
11/07/20 19:08:00 31SJA670_522
ProCarManuals.com

Î
Î
No.
No. Amps.No.
Circuits Protected Circuits Protected Amps. Circuits ProtectedAmps.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
150A15
16
17
18
19
20
21
22
23
Radiator fan Left headlight low beam
Rear defroster coil
Lef t headlight high beam
Small light
Right headlight high beam
Right headlight low beam
Back-up
FI ECU
Wiper
Headlight washer
Fog lights
MG clutch
Horn, Stop
Rear defroster 15 A
30 A
10 A
15 A
10 A
15 A
7.5 A
15 A
30 A
30 A
10 A
7.5 A
15 A
40 ABack-up, ACC
Hazard
ABS/VSA motor
ABS/VSA
Option
Option
Heater motor
Passenger’s f use box
Battery
IG main
Power window 40 A
15 A
30 A
40 A
40 A
40 A
40 A
70 A
120 A
50 A
50 A
: On Canadian models
Fuse Locations
518
PRIMARY UNDER-HOOD FUSE BOX
SECONDARY UNDER-HOOD FUSE BOX
11/07/20 19:08:09 31SJA670_523
ProCarManuals.com

µ
No. Circuits ProtectedAmps. No. No.Amps. Circuits Protected Circuits ProtectedAmps.
1
2Starter diag.
Starter signal 7.5 A
7.5 A 1
2
3
4
5
6
7
8
9
10
11
12
13
14
1516
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33 15 A
15 A
10 A
15 A
7.5 A
7.5 A
10 A
20 A
20 A
7.5 A
15 A
15 A
20 A
20 A
7.5 ADrivebyWire
Ignition coil
Daytime running light
LAF heater
Radio
Interior light
Back-up
Door lock
Accessory socket
Occupant position detection
system (OPDS)
Wiper
Rear heated seat
Driver’s power seat sliding
Tire pressure monitoring
system (T PMS)Driver’s power seat reclining
Passenger’s power seat sliding
ACG
Fuel Pump
IGN SOL
Meter
SRS
IGP (PGM-FI ECU)
Left rear power window
ETS (telescopic)
ETS (tilt)
Driver’s power window
Moonroof
Adaptive Front Lighting
System
Air Conditioner
e-pretensioner
ACC
Not Used 20 A
20 A
15 A
20 A
15 A
10 A
10 A
7.5 A
20 A
20 A
20 A
30 A
20 A
7.5 A
7.5 A
7.5 A
10 A
Passenger’s power seat reclining
Fuse Locations
T aking Care of t he Unexpect ed
519
INTERIOR FUSE BOX
Driver’s side
SECONDARY INTERIOR FUSE BOX
Driver’s side
11/07/20 19:08:18 31SJA670_524
ProCarManuals.com

No. Amps. No. Amps.Circuits Protected Circuits Protected
1
2
3
4
530 A
30 A
30 A
30 A
20 A6
7
8
920 A
7.5 A
30 A
7.5 A SH-AWD
Premium amplif ier
Passenger’s power window
Driver’s automatic seat belt
tensioner/e-pretensioner
Right rear power windowHeated seats
Illumination lights
Passenger’s automatic seat
belt tensioner/
e-pretensioner
Air conditioner
Fuse Locations
520
INTERIOR FUSE BOX
Passenger’s side
11/07/20 19:08:24 31SJA670_525
