Acura RLX 2014 Owner's Manual

490Handling the Unexpected
Emergency TowingCall a professional towing service if you need to tow your vehicle.■Flat bed equipment
The operator loads your vehicle on the back of a truck.
This is the only way you can safely transport your vehicle.
Any other towing method will damage the vehicle’s drive system.
1Emergency TowingNOTICETrying to lift or tow your vehicle by the bumpers will
cause serious damage. The bumpers are not designed
to support the vehicle's weight.NOTICEImproper towing such as towing behind a
motorhome or other motor vehicle can damage the
transmission.
Never tow your vehicle with just a rope or chain.
It is very dangerous, since ropes or chains may shift
from side to side or break.

491Handling the Unexpected
When You Cannot Unlock the Fuel Fill DoorIf you cannot unlock the fuel fill door, use the following procedure.
1.Open the trunk and remove the cover.
2.Pull the release lever toward you.
uThe release lever unlocks the fuel fill door
when it is pulled.
1When You Cannot Unlock the Fuel Fill Door
After taking these steps, contact a dealer to have the
vehicle checked.
Cover
Release Lever

492Handling the Unexpected
When You Cannot Open the TrunkIf you cannot open the trunk, use the following procedure.
1.Open the trunk pass-through cover.
2Trunk Pass-through Cover P. 170
2.Pull the trunk release handle down.
1When You Cannot Open the Trunk
What to do-Following up
After taking these steps, contact a dealer to have the
vehicle checked.
Trunk Pass-through Cover
Trunk Release Handle

493Handling the Unexpected
RefuelingRefueling From a Portable Fuel ContainerIf you have run out of fuel and need to refuel your vehicle from a portable fuel
container, use the funnel provided with your vehicle.
1.Turn off the engine.
2.Press the fuel fill door release button.
uThe fuel fill door opens.
3.Take the funnel out of the tool case in the
trunk.
2Types of Tools P. 454
4.Remove the funnel from the case.
5.Place the end of the funnel on the lower
part of filler opening, then insert it slowly
and fully.
uMake sure that the end of the funnel
goes down along with the filler pipe.
6.Fill the tank with fuel from the portable fuel
container.
uPour fuel carefully so you do not spill any.
7.Remove the funnel from the filler neck.
uWipe up any fuel from the funnel before
storing it.
8.Shut the fuel fill door by hand.
1Refueling From a Portable Fuel ContainerNOTICEDo not insert the nozzle of a portable fuel container
or any funnel other than the one provided with your
vehicle. Doing so can damage the fuel system.
Do not try to pry open or push open the sealed fuel
tank with foreign objects. This can damage the fuel
system and its seal.
Make sure the fuel in the portable fuel container is
gasoline before you refuel.
3
WARNING
Gasoline is highly flammable and explosive.
You can be burned or seriously injured
when handling fuel.
•Stop the engine, and keep heat, sparks,
and flame away.
•Handle fuel only outdoors.
•Wipe up spills immediately.
Funnel Case

494

495
Information
This chapter includes your vehicle’s specifications, locations of identification numbers, and other
information required by regulation.
Specifications.................................... 496
Identification NumbersVehicle Identification Number (VIN)...... 498Engine Number and Transmission
Number...................................... 498Devices that Emit Radio Waves....... 499
Reporting Safety Defects................. 500Emissions Testing
Testing of Readiness Codes.............. 501
Warranty Coverages........................ 503
Authorized Manuals......................... 505
Client Service Information............... 506

496Information
Specifications■Vehicle SpecificationsModel
Acura RLX
No. of Passengers:
Front 2
Rear 3
Total 5
Weights:Gross Vehicle Weight
Rating
U.S.: 4,993 lbs (2,265 kg)
Canada: 2,265 kg
Gross Axle Weight
Rating (Front)
U.S.: 2,778 lbs (1,260 kg)
Canada: 1,260 kg
Gross Axle Weight
Rating (Rear)
U.S.: 2,271 lbs (1,030 kg)
Canada: 1,030 kg
Air Conditioning:
Refrigerant Type HFC-134a (R-134a)
Charge Quantity 15.8 – 17.6 oz (450 – 500 g)
Lubricant Type ND-OIL 8
■Engine Specifications
■Fuel
■Battery
■Washer FluidDisplacement
212 cu-in (3,471 cm
3)
Spark Plugs NGK DILZKR7B11G
Type
Unleaded premium gasoline, Pump octane
number of 91 or higher
Fuel Tank Capacity 18.5 US gal (70 ℓ)
Capacity/Type
55AH(5)/72AH(20)
Tank Capacity
U.S.: 2.6 US qt (2.5 ℓ)
Canada: 5.3 US qt (5.0 ℓ)
■Light Bulbs*1: Not available on all modelsHeadlights (Low Beam)
LED
Headlights (High Beam) LED
Front Turn Signal/Parking Lights
27/8W (Amber)
Front Side Marker Lights 3CP
Side Turn Signal Lights
(on Door Mirrors)
LED
Brake/Taillights/Rear Side Marker
LightsLED
Taillights
LED
Back-Up Lights 16W
Rear Turn Signal Lights
21W
High-Mount Brake Light LED
Rear License Plate Lights
LED
Door Outer Handle Ambient Lights LED
Interior Lights
Front and Rear Map Lights
LED
Front and Rear Ambient Lights
LED
Vanity Mirror Lights
2.1W
Front Door Pocket Lights
LED
Center Pocket Light
LED
Beverage Holder Light
LED
Door Courtesy Lights
3.4W
Console Compartment Light
LED
Glove Box Light
LED
Front and Rear
*1 Foot Lights
LED
Door Inner Handle Lights
LED
Trunk Lights
5W

497
uuSpecificationsu
Information
■Brake Fluid
■Automatic Transmission FluidSpecified
Acura Heavy Duty Brake Fluid DOT 3
Specified
Acura ATF DW-1
(automatic transmission fluid)
Capacity Change 3.3 US qt (3.1 ℓ)
■Engine Oil
■Engine CoolantRecommended
·Genuine Acura Motor Oil 0W-20
·API Premium-grade 0W-20 detergent oil
CapacityChange 4.2 US qt (4.0 ℓ)
Change
including
filter4.5 US qt (4.3 ℓ)
Specified
Honda Long-Life Antifreeze/Coolant Type2
Ratio 50/50 with distilled water
Capacity
2.1 US gal (8.0 ℓ)
(change including the remaining
0.225 US gal (0.85 ℓ) in the reserve tank)
■Tire*1: Except TECH, ADVANCE, and U.S. TECH-AUDIO models
*2: TECH, ADVANCE, and U.S. TECH-AUDIO models
*3: Vehicles with optional spare tire kitRegular
Size
P245/45R18 96V
*1
245/40R19 98W
*2
Pressure
psi (kPa [kgf/cm
2])
Front
32 (220 [2.2])
*1
35 (240 [2.4])
*2
Rear
32 (220 [2.2])
*1
33 (230 [2.3])
*2
Compact
Spare
*3
Size T155/70D17 110M
Pressure
psi (kPa [kgf/cm
2])60 (420 [4.2])
Wheel Size
Regular
18 x 8J
*1
19 x 8J
*2
Compact Spare
*3
17 x 4T

498Information
Identification NumbersVehicle Identification Number (VIN)Your vehicle has a 17-digit vehicle identification number (VIN) used to register your
vehicle for warranty purposes, and for licensing and insuring your vehicle. See the
image below for the VIN locations.Engine Number and Transmission NumberSee the image below for the locations of your vehicle’s engine number and
transmission number.
1Vehicle Identification Number (VIN)
The interior vehicle identification number (VIN) is
located under the cover.
Cover
Vehicle Identification Number
Engine Number
Automatic
Transmission
Number
Certification Label/
Vehicle Identification Number
Vehicle Identification Number

499Information
Devices that Emit Radio WavesThe following products and systems on your vehicle emit radio waves when in operation.Each of the above complies with the appropriate requirements or the required standards of FCC
(Federal Communications Commission) and Industry Canada Standard, described below:As required by the FCC:
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.This device complies with industry Canada Standard RSS-Gen/210/310. Operation is
subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.AcuraLinkAudio SystemBlind Spot Information SystemBluetooth® AudioBluetooth® HandsFreeLink®Collision Mitigation Braking System
TM
HomeLink® Universal TransceiverImmobilizer SystemKeyless Access SystemTire Pressure Monitoring System (TPMS)
