Insert the dipstick all the way into
the transmission securely as
shown in the illustration.
Remove the dipstick and check
the f luid level. It should be
between the upper and lower
marks.If the level is below the lower
mark, remove the f ill plug and add
f luid to bring it to the upper mark.
Insert the dipstick all the way back
into the transmission securely as
shown in the illustration.
The transmission should be drained
and ref illed with new f luid according
to the time and distance recommen-
dations in the maintenance schedule.
If youarenotsurehowtoaddfluid,
contact your Acura dealer.
Always use Honda ATF-Z1
(Automatic Transmission Fluid). If
it is not available, you may use a
DEXRON
III automatic
transmission f luid as a temporary
replacement. However, continued
use can affect shift quality. Have
the transmission f lushed and
ref illed with Honda ATF-Z1 as
soon as it is convenient.
To thoroughly f lush the
transmission, the technician
should drain and ref ill it with
Honda ATF-Z1, then drive the
vehicle a short distance. Do this
three times. Then drain and ref ill
the transmission a final time.
3. 5. 6.
4.
Maint enance
Automatic Transmission Fluid
235
U UP PP
PE
ER
R M
M A
AR
RKK
L
LO OW WE ER
R M
M A
AR
RKK
00/12/25 14:32:11 31S0K630_238

The f luid level should be between
theMINandMAXmarksontheside
of the reservoir. If the level is at or
below the MIN mark, your brake
system needs attention. Have the
brake system inspected f or leaks or
worn brake pads.
Always use Honda Heavy Duty
Brake Fluid DOT 3. If it is not
available, you should use only DOT 3
or DOT 4 f luid, f rom a sealed
container, as a temporary
replacement. However, the use of
any non-Honda brake fluid can cause
corrosion and decrease the lif e of the
system. Have the brake system
f lushed and ref illed with Honda
Heavy Duty Brake Fluid DOT 3 as
soon as possible.
Check the f luid level in the brake
f luid reservoir monthly.
The brake f luid should be replaced
according to the time recommenda-
tion in the maintenance schedule.
Brake f luid marked DOT 5 is not
compatible with your car’s braking
system and can cause extensive
damage.Brake System
Maint enance
Brake Fluid
236
M M
A
AX
X
M
M I
INN
00/12/25 14:32:20 31S0K630_239

Check the level when the engine is
cold. Look at the side of the
reservoir. The f luid should be
between the UPPER LEVEL and
LOWER LEVEL. If it is below the
LOWER LEVEL, add power steering
f luid to the UPPER LEVEL.Always use Honda Power Steering
Fluid. If it is not available, you may
use another power steering f luid as
an emergency replacement.
However, continued use can cause
increased wear and poor steering in
cold weather. Have the power
steering system f lushed and ref illed
with Honda PSF as soon as possible.
A low power steering f luid level can
indicate a leak in the system. Check
the f luid level f requently and have
the system inspected as soon as
possible. Clean the hood latch assembly with a
mild cleaner, then lubricate it with a
multipurpose grease. Lubricate all
the moving parts (as shown),
including the pivot. Follow the time
and distance recommendations in
the Maintenance Schedule. If you
are not sure how to clean and grease
the latch, contact your Acura dealer.
Maint enance
Power Steering Hood L atch
Power Steering, Hood L atch
237
M MA
AX
X
M
M I
INN L
LA
A T
TC
CH H
A
A S
SSSEEM
M B
BLLYY
T urning the steering wheel to f ull lef t
or right lock and holding it there can
damage the power steering pump.
00/12/25 14:32:31 31S0K630_240

The air cleaner element should be
cleaned or replaced according to the
time and distance recommendations
in the maintenance schedule.Loosen the two bolts with a Phillips-
head screwdriver. Remove the air
cleaner housing cover by lif ting and
pivoting it out of the loops.
Loosen the f our bolts by using a
Phillips-head screwdriver and
remove the air cleaner housing
cover.
Clean the air cleaner element by
blowing compressed air through it in
the opposite direction to normal air
f low. If you do not have access to
compressed air (such as a service
station), ask your Acura dealer to do
this service.
Follow the replacement procedure
for removal and reinstallation.
The air cleaner element is inside the
air cleaner housing on the driver’s
side of the engine compartment.
To replace it:
1.
On Premium model
On Premium model On Type S
Maint enance
A ir Cleaner Element
Cleaning (Severe Conditions)
Replacement
238
B BOOL LTT S
S
L
LOOO OPP B
BO
OL LTT S
S
00/12/25 14:32:42 31S0K630_241

Disconnect the wire connector
f rom the ignition coil by pushing
on the lock tab and pulling on the
connector. Pull on the plastic
connector, not the wires.
Loosen the two holding clips by
turning the heads one-quarter turn
counterclockwise with a f lat-tipped
screwdriver. Remove the cover on
the f ront cylinder bank by pulling
it straight up.
Clean up any dirt and oil that have
collected around the ignition coils.
The spark plugs in your car are a
special platinum-tipped design f or
longer lif e. The spark plugs should
be replaced according to the time
and distance recommendations in
the maintenance schedule.
1.
2.3.
Replacement
Spark Plugs
Maint enance240
H H
O
OL LDD I
INNG G
C
CL LIIPP L
LO
OC CKK T
TA
A B
B
00/12/25 14:33:01 31S0K630_243

µµ
The timing belt should normally be
replaced at the intervals shown in
the maintenance schedule.
Replace this belt at 60,000 miles (U.S.)
or 100,000 km (Canada) if you
regularly drive your car in one or
more of these conditions:
In very high temperatures
(over 110°F, 43°C).
In very low temperatures
(under 20°F, 29°C). To saf ely operate your car, your tires
must be the proper type and size, in
good condition with adequate tread,
and correctly inf lated. The f ollowing
pages give more detailed inf ormation
on how and when to check air
pressure, how to inspect your tires
for damage and wear, and what to do
when your tires need to be replaced.
Timing Belt Tires
Timing Belt, Tires
Maint enance250
Using tires that are excessively
worn or improperly inflated can
cause a crash in which you can
be seriously hurt or killed.
Follow all instructions in this
owner’s manual regarding tire
inflation and maintenance.
00/12/25 14:34:31 31S0K630_253

Block the rear wheels.
Fill the f uel tank.
Change the engine oil and f ilter
(see page ).
Wash and dry the exterior
completely.
Cleantheinterior.Makesurethe
carpeting, floor mats, etc. are
completely dry.
If you need to park your car f or an
extended period (more than one
month), there are several things you
should do to prepare it f or storage.
Proper preparation helps prevent
deterioration and makes it easier to
get your car back on the road. If
possible, store your car indoors.
Leave the parking brake off. Put
the transmission in Park. If the car is to be stored for a
longer period, it should be
supported on jackstands so the
tires are of f the ground.
Coverthecarwitha‘‘breathable’’
cover, one made f rom a porous
material such as cotton.
Nonporous materials, such as
plastic sheeting, trap moisture,
which can damage the paint.
If possible, run the engine f or a
while periodically (pref erably once
amonth).
Leave one window open slightly (if
the car is being stored indoors).
Disconnect the battery.
Support the f ront wiper blade
arms with a f olded towel or rag so
they do not touch the windshield.
To minimize sticking, apply a
silicone spray lubricant to all door
and trunk seals. Also, apply a
vehiclebodywaxtothepainted
surfaces that mate with the door
and trunk seals. If you store your car f or 12 months
or longer, have your Acura dealer
perf orm the inspections called f or in
the 24 months/30,000 miles (48,000
km) maintenance schedule (Normal
Conditions) as soon as you take it
out of storage (see page ). The
replacements called f or in the
maintenance schedule are not
needed unless the car has actually
reached that time or mileage.
214
225
St oring Your Car
Maint enance267
00/12/25 14:37:50 31S0K630_270

Î
ÎThe burning of gasoline in your car’s
engine produces several byproducts.
Some of these are carbon monoxide
(CO), oxides of nitrogen (NOx) and
hydrocarbons (HC). Gasoline
evaporating from the tank also
produces hydrocarbons. Controlling
the production of NOx, CO, and HC
is important to the environment.
Under certain conditions of sunlight
and climate, NOx and HC react to
f orm photochemical ‘‘smog.’’ Carbon
monoxide does not contribute to
smog creation, but it is a poisonous
gas. The United States Clean Air Act
sets standards f or automobile
emissions. It also requires that
automobile manufacturers explain to
owners how their emissions controls
workandwhattodotomaintain
them. This section summarizes how
the emissions controls work.
Scheduled maintenance is on page
.
In Canada, Acura vehicles comply
with the Canadian Motor Vehicle
Saf ety Standards (CMVSS) f or
Emissions valid at the time they are
manuf actured.
Your car has a Positive Crankcase
Ventilation System. This keeps
gasses that build up in the engine’s
crankcase from going into the
atmosphere. The Positive Crankcase
Ventilation valve routes them from the crankcase back to the intake
manif old. They are then drawn into
the engine and burned.
As gasoline evaporates in the f uel
tank, an evaporative emissions
control canister f illed with charcoal
adsorbs the vapor. It is stored in this
canister while the engine is of f . Af ter
the engine is started and warmed up,
the vapor is drawn into the engine
and burned during driving.
The Onboard Ref ueling Vapor
Recovery (ORVR) system captures
the f uel vapors during ref ueling. The
vapors are adsorbed in a canister
f illed with activated carbon. While
driving, the f uel vapors are drawn
into the engine and burned of f .
214
The Clean Air Act
Crankcase Emissions Control
System Evaporative Emissions Control
System
Onboard Ref ueling Vapor
Recovery
T echnical Inf ormation
Emissions Cont rols
314
00/12/25 14:45:26 31S0K630_317

CONT INUED
...................
Neutral Gear Position . 183
..................
New Vehicle Break-in . 164
...................
NOTICE, Explanation of . i
...............
Numbers, Identif ication . 306
..................................................
Keys . 76
.......................
Label, Certif ication . 306
.................
Lane Change, Signaling . 71
..................
Lap/Shoulder Belts . 15, 44
Lights ....................
Bulb Replacement . 259
.......................................
Indicator . 57
.........................................
Parking . 69
..................................
Turn Signal . 71
.....................................
Load Limit . 174
......
LOCK (Ignition Key Position) . 78
........................
Lockout Prevention . 80
Locks .......
Anti-thef t Steering Column . 78
............................
Fuel Fill Door . 165
....................................
Glove Box . 87
.................................
Power Door .79
...........................................
Trunk .85
........................
Low Coolant Level .169
...
Low Oil Pressure Indicator . 59, 291
...
Lubricant Specif ications Chart . 308.........................................
Luggage .173
..................................
Maintenance .209
...
Owner Maintenance Checks . 221
........................................
Record .219
......................
Required Indicator .67
..........................................
Saf ety .210
.............................
Schedule .214-218
Malf unction Indicator ....................................
Lamp .59, 293
.............
Memory, Driving Position . 96
...............................
Meters, Gauges .64
...................
Methanol in Gasoline . 312
..........................
Mirrors, Adjusting .94
.......................................
Moonroof .103
......................
Closing Manually .296
...................................
Operation .103 ...
Octane Requirement, Gasoline . 164
.........................................
Odometer .65
...............................
Odometer, Trip .65
Oil ........................
Change, How to .225
......................
Change, When to .214
......................
Checking Engine .168
..............
Pressure Indicator . 59, 291
Selecting Proper Viscosity ......................................
Chart .224
...........
ON (Ignition Key Position) . 79
Onboard Ref ueling Vapor ....................................
Recovery .314
..
Operation in Foreign Countries . 313
..............................
Outside Mirrors .94
....................
Overheating, Engine .289
.......
Owner Maintenance Checks . 221
.........................
Oxygenated Fuels .312
Index
K
L
NO
M
V
00/12/25 14:47:41 31S0K630_334

Î..................................
Saf ety Belts . 8, 44
.........
Safety Defects, Reporting . 323
.................................
Saf ety Features .7
...........................................
Airbags .9
..................................
Door Locks .10
..........................
Head Restraints .10
.......................................
Seat Belts .8
.....................
Seats & Seat-Backs .10
.............
Saf ety Labels, Location of . 54
...............................
Saf ety Messages . ii
.....................................
Seat Belts .8, 44
...............
Additional Information . 44
.....................................
Cleaning .273
................
Lap/Shoulder Belt . 15, 44
................................
Maintenance .46
Reminder Light and ................................
Beeper .44, 59
..............................
Paint Touch-up .271
..............
Panel Brightness Control . 71
........................
Park Gear Position .182
...........................................
Parking .189
...............................
Parking Brake .104
Parking Brake and Brake System ...............................
Indicator .59, 295
.................................
Parking Lights .69
..
Parking Over Things that Burn . 189
.............................
PGM-FI System .315
..................
Polishing and Waxing . 271
............
Pre-Drive Saf ety Checklist . 11
.........
Pregnancy, Using Seat Belts . 19
............................
Protecting Adults .12
...
Additional Safety Precautions . 20
.....
Advice f or Pregnant Women . 19
........................
Protecting Children .21
.......................
Protecting Inf ants .30
.......
Protecting Larger Children . 37
.........
Protecting Small Children . 34
Using Child Seats with .....................................
Tethers .41 ...................
Radiator Overheating . 289
Radio/Cassette/CD Sound ........................................
System .129
...................
Readiness Codes . 294, 317
..
Rear Lights, Bulb Replacement . 263
..........................
Rear Seat Armrest .92
............................
Rear View Mirror .94
.................
Rear Window Def ogger . 74
...............
Reclining the Seat Backs . 89
.............................
Reminder Lights .57
................
Remote Audio Controls . 150
.......................
Remote Transmitter .81
Replacement Inf ormation .................
Air Cleaner Element . 238
.............
Air Conditioning Filter . 249
..........................
Engine Coolant .230
................
Engine Oil and Filter . 225
..........................................
Fuses .298
................................
Light Bulbs .259
....................................
Schedule .214
................................
Spark Plugs .240
...........................................
Tires .254
.............................
Wiper Blades .246 Replacing Seat Belts Af ter a
............................................
Crash .46
...
Reserve Tank, Engine Coolant . 169
...............................
Restraint, Child .21
..................
Reverse Gear Position . 182
................................
Rotation, Tire .254
Index
PR
S
VI
00/12/25 14:47:47 31S0K630_335
