dashboard Acura TL 2009 User Guide

Pushing this button also turns the
power mirror heaters on and of f .This button directs the main airflow
to the windshield for faster
def rosting. It also overrides any
mode selection you may have made.
Air f lows f rom the f loor
vents.
Airf low is divided between
the vents in the dashboard and the
f loor vents.
Air flows from the center
and corner vents in the dashboard.
This button turns the rear window
def ogger on and of f (see page ).
Thedriver’ssidemodeandthe
passenger’s side mode can be
selected separately. Use the
appropriate mode control button to
select the vents the air flows from.
Some air will flow from the
dashboard vents in all modes.
Airf low is divided between
the f loor and corner vents and the
defroster vents at the base of the
windshield.
This mode can only be selected f rom
the driver’s side, however the
passenger’s side controls can still
change the temperature. When you select , the system
automatically switches to f resh air
mode and turns on the A/C. For
f aster def rosting, the f an speed
automatically increases. You can also
increase airf low to the windshield by
closing the center and corner vents
on the dashboard. To close the vents,
rotate the wheel on the side of each
center and corner vent.
When you turn of f by
pressing the button again, the
system returns to its former settings. Select to help clear the rear
window.
139
CONT INUED
Rear Window Def ogger But t on
Windshield Def rost er But t on
Mode Cont rols
Climate Control System
Features
219
——y
y
) yy
2009 TL

Theclimatecontrolsystemhastwo
sensors: a sunlight sensor on top of
the dashboard, and a temperature
and humidity sensor next to the
steering column. Do not cover the
sensors or spill any liquid on them.The humidity sensor helps reduce
window f ogging and also monitors
and adjusts cabin humidity by
automatically changing the mode to
Def rost.
The airf low f rom the rear vents can
be adjusted when either AUTO
mode (driver or passenger) is
selected or the f an mode is in the
or position.
You can adjust the direction of the
airflowbymovingthetaboneach
vent up-and-down and side-to-side.
You can also open or close the vents
with the dial between them.
Climate Control System
Climate Control Sensors
Rear Ventilation
222
SUNLIGHT SENSOR
TEMPERATURE AND HUMIDITY
SENSOR
\f—\f—y

\f\fy
) \f\fy\fy
2009 TL

You can also set the security system
by pressing the lock button on either
f ront door handle while carrying the
keyless access remote.Once the security system is set,
opening any door (without using the
key or the remote transmitter/
keyless access remote), the hood, or
the trunk will cause the system to
alarm. It also alarms if the audio unit
is removed f rom the dashboard or
the wiring is cut.
With the system set, you can still
open the trunk with the remote
transmitter/keyless access remote
without triggering the alarm. The
alarm will sound if the trunk is
opened with the trunk release button
on the driver’s door, the trunk
release handle behind the trunk
pass-through cover, or the
emergency trunk opener. Use the remote transmitter/
keyless access remote to quickly
check that the hood, the trunk, and
all doors are closed. Push the lock
button twice within 5 seconds. There
should be an audible conf irmation
beep.
The security system will not set if
the hood, trunk, or any door is not
f ully closed. If the system will not set,
check the door and trunk open
monitor on the multi-inf ormation
display (see page ) to see if the
doors and trunk are f ully closed.
Since it is not part of the monitor
display, manually check the hood.
Do not attempt to alter this system
or add other devices to it. 11
On models with keyless access system
Security System
Features
381
NOTE:
\f—
—y
\f
y
) \f\fy\fy
2009 TL

Here are some guidelines f or using
voice control:Adjust the airflow from both the
dashboard and side vents so they
do not blow against the
microphone on the ceiling.
Close the windows and the
moonroof .
To enter a command, press and
release the HFL Talk button. After
the beep, say your command in a
clear, natural tone.
When voice commands are used,
the fan speed will be automatically
adjusted to low. However, for
better voice recognition, lowering
the f an speed may be necessary. If the microphone picks up voices
other than yours, the system may
not interpret your voice
commands correctly.
If HFL does not recognize a
command, its response is ‘‘Pardon.’’
If it doesn’t recognize the
command it plays an appropriate
Help prompt. Response time may
vary depending on the voice
command.
To hear a list of available options
at any time, press the HFL Talk
button, wait f or the beep, and say
‘‘Hands f ree help’’ or ‘‘Help.’’
When you are at the main menu,
you can hear general HFL
inf ormation such as pairing or
setting up the system. Press the
HFL Talk button, wait f or the beep,
and say ‘‘Tutorial.’’Many commands can be spoken
together. For example, you can
say, ‘‘Dial 123-456-7891.’’
To enter a string of numbers in a
Call or Dial command, you can say
them all at once, or you can
separate them in blocks of 3, 4, 7,
10, and 11.
To skip a voice prompt, press the
HFL Talk button while HFL is
speaking. HFL will then begin
listening f or your next command.
BluetoothHandsFreeL ink(Models without navigation system)
Using Voice Control
396
\f—\f—y
y
) \f\fy\f\f
y
2009 TL

To operate HFL, use the Pick-Up and
Hang-Up buttons on the lef t side of
the steering wheel.Here are some guidelines f or using
voice control:
Adjust the airflow from both the
dashboard and side vents so they
do not blow against the
microphone on the ceiling.
Close the windows and the
moonroof .
HANG-UP Button: This button is
used to end a call.
PICK-UP Button: This button is used
to answer incoming calls or to make
outgoing calls. You can also go
directly to the Cellular Phone screen
by pressing this button.
BACK Button: This button has the
same function as the CANCEL
button. When you press and release
it, the current voice command is
canceled and the display returns to
the previous screen.
The HFL buttons are used as
f ollows:
TALK Button: This button activates
the voice control system and is used
f or all voice commands. Press and
release it, wait f or a beep, and give a
voice command.
If you use the voice commands to
operate HFL, also use the TALK and
BACK buttons. When voice commands are used,
the fan speed will be automatically
adjusted to low. However, for
better voice recognition, lowering
the f an speed may be necessary.
To enter a command, press and
release the Talk button. After the
beep, say your command in a clear,
natural tone.
HFL Buttons
Using Voice Control
BluetoothHandsFreeL ink(Models with navigation system)
424
BACK BUTTONHANG-UP
BUTTON
TALK
BUTTON PICK-UP BUTTON
\f—\f—y
\fy
) \f\fy\fy
2009 TL

Turn the engine of f , and conf irm the
f uel f ill cap is installed. If it is, loosen
it, then retighten it until it clicks at
least once. The message should go
off after several days of normal
driving once you tighten or replace
the f uel f ill cap. To scroll to another
message, press the INFO button.If the system still detects a leak in
your vehicle’s evaporative emissions
system, the malf unction indicator
lamp (MIL) comes on. If the f uel f ill
cap was not already tightened, turn
the engine of f , and check or
retighten the f uel f ill cap until it
clicks at least once. The MIL should
go off after several days of normal
driving once the cap is tightened or
replaced. If the MIL does not go of f ,
have your vehicle inspected by a
dealer. For more inf ormation, see
page .
Park the vehicle, and set the
parking brake. Pull the hood
release handle located under the
lower lef t corner of the dashboard.
The hood will pop up slightly.
Put your f ingers between the f ront
edge of the hood and the f ront
grille to locate the hood latch
handle. Push this handle up until it
releases the hood. Lif t the hood.
The ‘‘TIGHTEN FUEL CAP’’
message will appear each time you
restart the engine until the system
turns the message of f .
1.
2.
596
CONT INUED
Service Station Procedure
Opening and Closing the Hood
Bef ore Driving
489
HOOD RELEASE HANDLE
\f—\f—y
y
) \f\fy\fy
2009 TL

The vehicle’s f uses are contained in
threefuseboxes.
The interior f use box is located
under the dashboard on the driver’s
side. The f use label is attached
under the steering column.The passenger’s side interior f use
box is on the lower passenger’s side
panel. To remove the f use box lid,
put your f inger in the notch on the
lid, and pull it upward slightly, then
pull it toward you and take it out of
its hinges.The under-hood f use box is on the
driver’s side next to the air cleaner
housing.
To access the under-hood f use box,
remove the lef t-side engine
compartment cover (see page ).
546
Fuses
T aking Care of t he Unexpect ed
599
DRIVER’S SIDE
PASSENGER’S SIDE
NOTCH TAB
FUSE LABEL UNDER-HOOD
AIR CLEANER HOUSING
\f—\f—\fy\f
\fy
) \f\fy\f\fy
2009 TL

Your vehicle has several identif ying
numbers located in various places.
The vehicle identif ication number
(VIN) is the 17-digit number your
dealer uses to register your vehicle
f or warranty purposes. It is also
necessary f or licensing and insuring
your vehicle. The easiest place to
find the VIN is on a plate fastened to
the top of the dashboard. You can
seeitbylookingthroughthe
windshield on the driver’s side. It is
also on the certification label
attached to the driver’s doorjamb,
and is stamped on the engine
compartment bulkhead. The VIN is
also provided in bar code on the
certif ication label.
Identif ication Numbers
612
CERTIFICATION LABEL
VEHICLE IDENTIFICATION NUMBER (VIN)
\f—\f—y

y
) \f\fy\f
y
2009 TL

Î
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
Î
CONT INUED
Specif ications
Technical Inf ormation
615
Engine (2WD)
Lights
Fuses Battery
Alignment Engine (SH-AWD)3.50 x 3.66 in (89.0 x 93.0 mm)
Water cooled 4-stroke
SOHC VTEC 6-cylinder (V6), gasoline engine
12 V
1.1 W 3.4 W
5W 16 W 55 W (H11)
21 W
12 V
12 V
12 V
12 V
12 V 211.7 cu-in (3,471 cm
)
11.2 : 1
ILZKR7B11
12 V 60 W (HB3)
12 V 24/2.2 CP
12 V 3 CP 12 V 35 W (D2S)
3CP
3CP
12 V 12 V Type
BorexStroke
Displacement
Compression ratio
Spark plugs
Headlight (Low beam )
Headlight (High beam/DRL)
Front turn signal/parking
lights
Front side marker lights
Front fog lights
Rear turn signal lights
Back-up lights
Rear side marker lights
License plate light
Trunk light
Door courtesy lights
Vanity mirror lights
See page603or the fuse box
cover.
Interior
Under-hood Capacity
12 V 12 V72 AH/20 HR
60 AH/5 HR
On vehicles with high voltage discharge type low beam headlights,
replacement of a bulb should be performed by your dealer.
Toe-in
Camber
Caster 3.8°1°
0.5°
0.08 in (2.0 mm) 0.00 in (0.0 mm)
Type
BorexStroke
Displacement
Compression ratio
Spark plugs
SXU22HCR11S11.2 : 1
223.5 cu-in (3,664 cm
)
3.54 x 3.78 in (90.0 x 96.0 mm) Water cooled 4-stroke
SOHC IN/EX VTEC 6-cylinder (V6), gasoline engineSXU22HCR11
ILZKR7B-11S
See pages604and605or the fuse
label attached to the inside of the
fuse box door on each side of the
dashboard. Front
Rear
Front
Rear
FrontDENSO:
(Amber)
NGK:
(Amber)
: NGK: DENSO:
——y


y
) yy
2009 TL

ÎÎ Î
..............................
Economy, Fuel .492
............................
Carrying, Cargo .497
.............
CAUTION, Explanation of .iii
..................................
Ceiling Light .209
........................
Certif ication Label .612
...................................
Chains, tires .575
Changing Oil ........................................
How to .548
......................................
When to .535
....................
Changing a Flat Tire .583
...
Charging System Indicator .65,595
............
Checklist, Bef ore Driving .502
................
Childproof Door Locks .147
.....................................
Child Saf ety .37
..............................
Booster Seats .54
...................................
Child Seats .45
..........................................
Inf ants .42
............................
Large Children .53
.........................................
LATCH .47
......................
Risks with Airbags .38
.............................
Small Children .43
.........................................
Tethers .51
.........
Where Should a Child Sit? .38
Cleaning ...................................
Seat Belts .564
..........
Client Service Inf ormation .630
...............
Climate Control System .214 ..............................................
Clock .377
..................
CO in the Exhaust .57,624
.......................
Compact Spare tire .582
.........................................
Compass .382
.................
Console Compartment .205
...............
Consumer Inf ormation .630
.............
Controls, Instruments and .61
Coolant
........................................
Adding .550
....................................
Checking .491
.........................
Proper Solution .550
...................
Temperature Gauge .76
Crankcase Emissions Control ........................................
System .623
................
Cruise Control Indicator .72
............
Cruise Control Operation .386
...................................
Cup Holders .203
..........
Customer Relations Of f ice .630
...............
DANGER, Explanation of .iii
...................................
Dashboard .3,62
..............
Daytime Running Lights .136
.
Daytime Running Light Indicator .72
.........
Def ects, Reporting Saf ety .632 ..............
Def ogger, Rear Window .139
..............
Def rosting the Windows .219
....................................
Dimensions .614
.............
Dimming the Headlights .133
Dipstick
..........
Automatic Transmission .553
..................................
Engine Oil .490
........................
Directional Signals .133
........
Disc Brake Wear Indicators .520
.................................
Disc Changer .240
...
Disc Changer Error Messages .250
.....................
Disposal of Used Oil .550
Doors ........
Door Lock Sensor Button .170
.................
Monitor Indicator .11,88
....................
Power Door Locks .146
........
DOT Tire Quality Grading .617
...........
Driver and Passenger Safety .5
...........................................
Driving .501
....................................
Economy .492
Driving Position Memory ........................................
System .164
Index
D
E
II
——y
y
) y
y
2009 TL
