navigation system Acura TL 2009 Owner's Manual

HFL will say ‘‘Do you want to store
Voice tag Mike f or this number?’’
Rotate the dial to select ‘‘Yes’’ or
‘‘No’’ and press ENTER, or press the
Talk button and say ‘‘Yes.’’ When
you select ‘‘Yes,’’ the voice tag is
stored. You will see the voice tag
icon on the Speed Dial entry.The system will return to
step5if thevoicetagnameisnot
recognized.
If the voice tag name or similar-
sounding one is already stored, the
message ‘‘This voice tag already
exists. Please say a dif f erent name’’
will be displayed.
When the system can recognize
the voice tag, the following screen
is displayed.
Avoid using duplicate name
entries.
Avoid using ‘‘home’’ as a name
entry.
HFL will be able to better
recognize multisyllabic name
entries (‘‘Peter’’ instead of ‘‘Pete’’),
or a longer name (‘‘John Smith’’
instead of ‘‘John’’).
Use a consistent, even tone and
reduce background noise when
storing names, as the HFL voice
recognition can be sensitive.
6.
BluetoothHandsFreeL ink(Models with navigation system)
NOT E:
452
NOTE:
\f—\f—y
\fy
) \f\fy\fy
2009 TL

Using a Voice TagDeleting a Voice Tag
Press the INFO button, rotate the
dial to select ‘‘Cellular Phone,’’ and
press ENTER, or press the Talk
button and say ‘‘Cellular Phone.’’
HFL responds ‘‘Which cellular
phone item would you like to
select?’’
Press the Talk button, and say
‘‘Call’’ and the Voice Tag right
after it.
HFL starts dialing the phone
number associated with the Voice
Tag. HFL Calling screen is
displayed. Once connected, you
will hear the person you called
through the audio speakers.
To end the call, rotate the dial to
select ‘‘Hang-up’’ and press
ENTER, or press the Hang-Up
button on the steering wheel. Move the interf ace selector down
to select ‘‘Phone Setup,’’ or press
the Talk button and say ‘‘Phone
Setup.’’ Rotate the dial to select
‘‘Edit Speed Dial’’ and press
ENTER, or press the Talk button
and say ‘‘Edit Speed Dial.’’ HFL
responds ‘‘Please select a method
to edit.’’
Press the INFO button, rotate the
dial to select ‘‘Cellular Phone,’’ and
press ENTER, or press the Talk
button and say ‘‘Cellular Phone.’’
HFL responds ‘‘Which cellular
phone item would you like to
select?’’
2.
1.
3.
4. 1.
2.
CONT INUED
BluetoothHandsFreeL ink(Models with navigation system)
Features
453
\f—\f—y

\fy
) \f\fy\fy
2009 TL

Rotate the dial to select the entry
that you want to delete the voice
tag f or and press ENTER, or press
the Talk button and say the list
number of entry to delete.The selected entry will be
highlighted. Move the interf ace
selector down, or press the Talk
button and say ‘‘OK’’ to delete the
entry’s voice tag.
Rotate the dial to select ‘‘Delete
Voice Tag’’ and press ENTER, or
press the Talk button and say
‘‘Delete Voice Tag.’’ HFL responds
‘‘Please select the number of the
voice tag to delete.’’ 5.
3. 4.
BluetoothHandsFreeL ink(Models with navigation system)
454
VOICE TAG ICON
LIST NUMBER
SELECTED ENTRY
\f—
—y
\f\f\fy
) \f\fy\fy
2009 TL

HFL can store up to six phones,
with one phonebook f or each. The
Phonebook allows you to store up
to 1,000 names and 10,000 phone
numbers. The maximum names
and numbers to be stored varies
on the data size of each saved item.
Once they are stored, you can
then automatically dial any name
or number in the phonebook.Your phone may not have
this capability. Visit or call the
HandsFreeLink
consumer
support at 1-888-528-7876. In
Canada, visit , or call
1-888-9-ACURA-9. You can see
your phone’s owner’s manual f or
inf ormation. Press the INFO button, rotate the
dial to select ‘‘Cellular Phone,’’ and
press ENTER, or press the Talk
button and say ‘‘Cellular Phone.’’
HFL responds ‘‘Which cellular
phone item would you like to
select?’’
Pair your phone to HFL (see page
).Once HFL starts importing
f rom the phone, it does not accept
phone-related operations until the
process is f inished.
For saf ety purposes, only perf orm
this f unction while the vehicle is
stopped.
Hands-freecallsaremoreconvenient
if you import the phonebook f rom
your phone to HFL.
Move the interf ace selector down
to select the ‘‘Phone setup’’ screen, or press the Talk button and say
‘‘Phone setup.’’ HFL responds
‘‘Please select the phone setup
item.’’
Rotate the dial to select ‘‘Import
Cellular Phonebook’’ and press
ENTER, or press the Talk button
and say ‘‘Import Cellular
Phonebook.’’ HFL responds
‘‘Would you like to import Cellular
Phonebook?’’
2.
3.
4.
1.
426
www.acura.
com/handsf reelink
www.acura.ca To Import the Cellular Phonebook
CONT INUED
Setting Up the Cellular Phone
Book
BluetoothHandsFreeL ink(Models with navigation system)
Features
455
NOTE:
NOTE:
\f—\f—y


y
) \f\fy\f\fy
2009 TL

If you are playing Bluetooth
Audio, the above screen is displayed.
If you want to stop Bluetooth Audio
and continue to import the Cellular
Phonebook, rotate the dial to select
‘‘Yes’’ and press ENTER, or press
the Talk button and say ‘‘Yes.’’The Phonebook data is being
imported when the above screen is
displayed.
If the import is successf ul, you will
see the above screen. Press
ENTER to select ‘‘OK,’’ and the
screen will return to the ‘‘Cellular
Phone.’’
After returning to the
‘‘Cellular Phone’’ screen, rotate the
dial to select ‘‘Phonebook’’ and press
ENTER. Make sure the phonebook
was imported successf ully.
5.
BluetoothHandsFreeL ink(Models with navigation system)
456
NOTE:
NOTE:
\f—\f—y

y
) \f\fy\f
y
2009 TL

HFL stores up to 10,000 phone
numbers f or each paired phone. If
you try to import a phonebook
with more than 10,000 numbers,
or phonebook with no numbers at
all, a screen message will notif y
you that data cannot be imported.Up to three category icons are
displayed in the right side of the list.
These category icons indicate how
many numbers are stored f or the
person. If a name has more than
threecategoryicons,‘‘ ’’is
displayed.
The f ollowing category icons will
appear:
You may not be able to store the
maximum number of names and
numbers in some cases.
When you update inf ormation in
your cell phone’s phonebook, you
will need to repeat the import
process. ---
CONT INUED
BluetoothHandsFreeL ink(Models with navigation system)
Features
457
NOTE:
Home
MobileWork
Pager
Fax
Car
Preference
Other
\f—\f—y

y
) \f\fy\fy
2009 TL

To Delete the Imported Phonebook
Press the INFO button, rotate the
dial to select ‘‘Cellular Phone,’’ and
press ENTER, or press the Talk
button and say ‘‘Cellular Phone.’’
HFL responds ‘‘Which cellular
phone item would you like to
select?’’Rotate the dial to select ‘‘Delete
Cellular Phonebook’’ and press
ENTER, or press the Talk button
and say ‘‘Delete Cellular
Phonebook.’’ HFL responds ‘‘This
will delete the imported
Phonebook f or the currently
selected phone. Would you like to
continue?’’Rotate the dial to select ‘‘Yes’’ and
press ENTER, or press the Talk
button and say ‘‘Yes.’’
Move the interf ace selector down
to select the ‘‘Phone setup’’ screen,
or press the Talk button and say
‘‘Phone setup.’’ HFL responds
‘‘Please select the phone setup
item.’’
1.
2.
3. 4.
BluetoothHandsFreeL ink(Models with navigation system)
458
\f—\f—\fy

\fy
) \f\fy\fy
2009 TL

When the imported phonebook is
deleted, the above screen is
displayed.HFLcanstoreuptosixusers.Each
user has their own Phonebook,
Speed Dial, and Call history. You can
rename and delete a user name in
the ‘‘Edit User’’ screen. You can also
set a 4-digit PIN (password) to
protect user inf ormation.
Only the phonebook f or the
selected user will be deleted. Press the INFO button, rotate the
dial to select ‘‘Cellular Phone,’’ and
press ENTER, or press the Talk
button and say ‘‘Cellular Phone.’’
HFL responds ‘‘Which cellular
phone item would you like to
select?’’
Move the interf ace selector down
to select the ‘‘Phone setup’’ screen,
or press the Talk button and say
‘‘Phone setup.’’ HFL responds
‘‘Please select the phone setup
item.’’
5.
1.
2.
Store a user name
CONT INUED
Setting the User
BluetoothHandsFreeL ink(Models with navigation system)
Features
459
\f—\f—y

y
) \f\fy\fy
2009 TL

Rotate the dial to select ‘‘Edit
User’’ and press ENTER, or press
the Talk button and say ‘‘Edit User.’’
HFL responds ‘‘Please select an
edit user item.’’Rotate the dial to select ‘‘Name’’
and press ENTER, or press the
Talk button and say ‘‘Name.’’ HFL
responds ‘‘Please select the
number of user name to edit f rom
the list.’’Rotate the dial to select the phone
that you want to create a user
name f or, press ENTER, and move
the interf ace selector down f or
‘‘OK.’’ You can also press the Talk
button, say the list number of the
phone you want to create a user
name f or and say ‘‘OK.’’
5.
3. 4.
BluetoothHandsFreeL ink(Models with navigation system)
460
LIST NUMBER
\f—
—y
\fy
) \f\fy\fy
2009 TL

Rotate the dial and press ENTER
to select the letters. After the new
name is entered, move the
interf ace selector down to create
the user name.Rotate the dial to select ‘‘Edit
User’’ and press ENTER, or press
the Talk button and say ‘‘Edit User.’’
HFL responds ‘‘Please select an
edit user item.’’
Press the INFO button, rotate the
dial to select ‘‘Cellular Phone,’’ and
press ENTER, or press the Talk
button and say ‘‘Cellular Phone.’’
HFL responds ‘‘Which cellular
phone item would you like to
select?’’
Move the interf ace selector down
to select the ‘‘Phone setup’’ screen,
or press the Talk button and say
‘‘Phone setup.’’ HFL responds
‘‘Please select the phone setup
item.’’
6. 1.
2.
3.
Delete a user name
CONT INUED
BluetoothHandsFreeL ink(Models with navigation system)
Features
461
\f—\f—y
\fy
) \f\fy\fy
2009 TL
