Steps f or Determining Correct Load
Limit Locate the statement ‘‘The
combined weight of occupants and
cargo should never exceed XXX
kg or XXX lbs.’’ on your vehicle’s
placard.
Determine the combined weight
of the driver and passengers that
will be riding in your vehicle.
Subtract the combined weight of
the driver and passengers f rom
XXX kg or XXX lbs. The resulting f igure equals the
available amount of cargo and
luggage load capacity. For
example, if the ‘‘XXX’’ amount
equals 1,400 lbs. and there will be
f ive 150 lb. passengers in your
vehicle, the amount of available
cargo and luggage load capacity is
650 lbs.
(1,400 750 (5 150) = 650 lbs.)
Determine the combined weight
of luggage and cargo being loaded
on the vehicle. That weight may
not saf ely exceed the available
cargo and luggage load capacity
calculated in Step 4.
If your vehicle will be towing a
trailer, load f rom your trailer will
be transf erred to your vehicle.
Consult this manual to determine
how this reduces the available
cargo and luggage load capacity of
your vehicle.
The maximum load f or your vehicle
is 850 lbs (385 kg) f or U.S. models
and 395 kg for Canadian models.
This f igure includes the total weight
of all occupants, cargo, and
accessories, and the tongue load if
you are towing a trailer.
Label Example
See Tire And Loading Inf ormation
label attached to the driver’s
doorjamb.
(1)
(2)
(3) (4)
(5)
(6)
Load Limits
Carrying Cargo
498
Overloading or improper
loading can affect handling and
stability and cause a crash in
which you can be hurt or killed.
Follow all load limits and other
loading guidelines in this
manual.
\f—\f—y
\f\fy
) \f\fy\f\fy
2009 TL

In addition, the total weight of the
vehicle, all occupants, accessories,
cargo, and trailer tongue load must
not exceed the Gross Vehicle
Weight Rating (GVWR) or the Gross
Axle Weight Rating (GAWR). Both
areonalabelonthedriver’s
doorjamb.Store or secure all items that could
be thrown around and hurt
someone during a crash.
Do not put any items on top of the
trunk panel. They can block your
view and be thrown around the
vehicle during a crash.
Example 1
Example 2
Example 3
CONT INUED
Carrying Cargo in the Passenger
Compartment
Carrying Cargo
Bef ore Driving
499
Max Load (850 lbs)
Cargo Weight
(550 lbs)
Max Load (850 lbs)
Max Load (850 lbs) Cargo Weight
(250 lbs)
Cargo Weight
(100 lbs)
Passenger Weight
(150 lbs x 2 = 300 lbs)
Passenger Weight
(150 lbs x 4 = 600 lbs)
Passenger Weight
(150 lbs x 5 = 750 lbs)
\f—\f—y
\f
y
) \f\fy\f\fy
2009 TL

Be sure items placed on the f loor
behind the f ront seats cannot roll
underneath and interf ere with the
proper operation of the seats, the
sensors under the seats, or the
driver’s ability to operate the
pedals.
Also, keep all cargo below the
bottom of the windows. If it is
higher, it could interf ere with the
proper operation of the side
curtain airbags.
Keep the glove box closed while
driving. If it is open, a passenger
could injure their knees during a
crash or sudden stop.Cargo hook buttons in the trunk can
be used to install a net f or securing
items.
The cargo net can be used to help
hold down items stored in the trunk.
Distribute cargo evenly on the
f loor of the trunk, placing the
heaviest items on the bottom and
as far forward as possible.
If you carry large items that
prevent you f rom closing the trunk
lid, exhaust gas can enter the
passenger area. To avoid the
possibility of
, f ollow the instructions
on page . 57
If equipped
Cargo Nets
Carrying Cargo in the Trunk Cargo Hook Buttons
carbon monoxide
poisoning
Carrying Cargo
500
CARGO HOOK BUTTON
\f—\f—y
\f
y
) \f\fy\f\fy
2009 TL

This section gives you tips on
starting the engine under various
conditions, and how to operate the
automatic transmission. It also
includes important inf ormation on
parking your vehicle, the braking
system, the Super Handling-All
Wheel Drive (SH-AWD
)system,
vehicle stability assist (VSA
), aka
electronic stability control (ESC),
system and the tire pressure
monitoring system (TPMS). ........................
Preparing to Drive .502
Starting the Engine (Models without Keyless .....................
Access System) .503
Starting the Engine (Models with Keyless .....................
Access System) .505
..............
Automatic Transmission .507
Driving with the Paddle
.......................................
Shif ters .512
Super Handling-All Wheel ...
Drive (SH-AWD
) System .517
...........................................
Parking .519
.............................
Braking System .520
...............
Anti-lock Brakes (ABS) .521
Vehicle Stability Assist (VSA
),
aka Electronic Stability ........
Control (ESC), System .523
Tire Pressure Monitoring ........................
System (TPMS) .526
...........................
Towing a Trailer .531
...................
Towing Your Vehicle .531
Driving
Driving
501
TM
TM
\f—\f—y
\fy
) \f\fy\f\fy
2009 TL

Make sure all windows, mirrors,
and outside lights are clean and
unobstructed. Remove f rost, snow,
or ice.Check the seat adjustment (see
page ).
Check the adjustment of the
inside and outside mirrors (see
page ).
Check the steering wheel
adjustment (see page ).
Make sure the doors are securely
closed and locked.
Fasten your seat belt. Check that
your passengers have f astened
their seat belts (see page ).When you start the engine, check
the gauges and indicators in the
instrument panel, and the
messages on the multi-inf ormation
display (see pages , and
).
Youshoulddothesechecksand
adjustments bef ore you drive your
vehicle:
Check that the hood is f ully closed.
Check that the trunk is f ully
closed.
Visually check the tires. If a tire
looks low, use a gauge to check its
pressure.
Check that any items you may be
carrying are stored properly or
f astened down securely.
3.
2.
1.
7.
8.
9.
4.
5. 6.
155
63 75
77
16
161
140
10. 11.
Preparing to Drive
502
——y
y
) yy
2009 TL

Your vehicle’s starting system has an
auto control mode. When you turn
the ignition switch to the START
(III) position, this f eature keeps the
engine’s starter motor running until
the engine starts. Follow these
instructions to start the engine:If the engine does not start within
15 seconds, or starts but stalls
right away, repeat step 4 with the
accelerator pedal pressed halfway
down. If the engine starts, release
pressure on the accelerator pedal
so the engine does not race.
If the engine fails to start, press
the accelerator pedal all the way
down, and hold it there while
starting to clear flooding. If the
engine still does not start, return
to step 5.
Without touching the accelerator
pedal, turn the ignition switch to
the START (III) position, then
release the ignition switch. You do
not need to hold the ignition
switch in the START (III) position
to start the engine. Depending on
the outside temperature, the
starter motor runs f or about 6 to 9 seconds until the engine starts.
Make sure the shif t lever is in
Park. Press on the brake pedal.
In cold weather, turn of f all
electrical accessories to reduce
the drain on the battery.
Apply the parking brake. If the engine does not start, wait at
least 10 seconds bef ore trying
again.
If you hold the ignition switch in
the START (III) position f or more
than 7 seconds, the starter motor,
depending on the outside
temperature, runs f or about 10 to
25 seconds until the engine starts.6.
1.
2.
3.
4. 5.
Starting the Engine (Models without Keyless Access System)
Driving
503
The engine is harder to start in cold
weather. Also, the thinner air f ound at
altitudes above 8,000 f eet (2,400
meters) adds to this problem.
T he immobilizer system protects your
vehicle f rom thef t. If an improperly
coded key (or other device) is used, the
engine’s f uel system is disabled. For
more inf ormation, see page .
143
\f—\f—y
\fy
) \f\fy\f\fy
2009 TL

If there is a problem with the
starting system, you will see a
‘‘CHECK STARTING SYSTEM’’
message on the multi-inf ormation
display when the ignition switch is
turned to the ON (II) position. You
will also see this message when the
auto control mode of the starting
system has a problem.If this message is on, the ignition
switchhastobeheldintheSTART
(III) position manually until the
engine starts. The ignition switch
canbeheldinthatpositionupto15
seconds.
Even though you may be able to
start the engine manually without
the auto control mode of the starting
system, have your vehicle inspected
by a dealer.
Check Starting System Message
Starting the Engine (Models without Keyless Access System)
504
\f—\f—y
\f\f\fy
) \f\fy\f\fy
2009 TL

Your vehicle’s starting system has an
auto control mode. When you have
your keyless access remote and push
the engine start/stop button while
depressing the brake pedal, this
f eature keeps the engine’s starter
motor running until the engine starts.
Follow these instructions to start the
engine:Make sure the shif t lever is in
Park. Press on the brake pedal.
In cold weather, turn of f all
electrical accessories to reduce
the drain on the battery.
Apply the parking brake.
If the engine does not start, wait at
least 10 seconds bef ore trying
again.
If you hold the engine start/stop
button for more than 7 seconds,
the starter motor, depending on
the outside temperature, runs f or
about 10 to 25 seconds until the
engine starts.
Without touching the accelerator
pedal, push and release the engine
start/stop button. You do not need
to hold the engine start/stop
button to start the engine.
Depending on the outside
temperature, the starter motor
runs f or about 6 to 9 seconds until
the engine starts.
The keyless access remote system
main switch is of f . The keyless access remote battery
becomes weak or dead.
If the engine fails to start, press
the accelerator pedal all the way
down, and hold it there while
starting to clear flooding. If the
engine still does not start, return
to step 5.
If the engine does not start within
15 seconds, or starts but stalls
right away, repeat step 4 with the
accelerator pedal pressed halfway
down. If the engine starts, release
pressure on the accelerator pedal
so the engine does not race.
In either of the f ollowing cases, you
should insert the keyless access
remote into the keyless remote slot.
For more inf ormation, see pages and . 6.
1.
2.
3.
5.
4.
186187
CONT INUED
Starting the Engine (Models with Keyless Access System)
Driving
505
T he immobilizer system protects your
vehicle f rom thef t. If an improperly
coded keyless access remote (or other
device) is used, the engine’s f uel system
is disabled. For more inf ormation, see
page .143
\f—\f—y
\f
\fy
) \f\fy\f
\fy
2009 TL

If there is a problem with the
starting system, you will see a
‘‘CHECK STARTING SYSTEM’’
message on the multi-inf ormation
display with the power mode ON.You will also see this message when
the auto control mode of the starting
system has a problem.
If this message is on, you should
press and hold the engine start/stop
button until the engine starts. The
engine start/stop button can be
pressedupto15seconds.
Even though you may be able to
start the engine manually without
the auto control mode of the starting
system, have your vehicle inspected
by a dealer.
Your vehicle has the engine start/
stop button instead of an ignition
switch to select the power mode. For
more information, see page .
If you cannot start the engine using
the normal engine start procedure,
do the f ollowing:
Set the parking brake.
Put the shif t lever into Park.
Press the engine start/stop button
to turn on the ACCESSORY mode.
Press and hold the engine start/
stop button f or about 15 seconds
while pressing the brake pedal.
Do not f ollow this procedure unless
it is a case of emergency. Even if you
can start the engine using this
method, the system may have a
malf unction. Contact your dealer as
soon as possible.
178 1.
2.
3.
4.
Starting the Engine (Models with Keyless Access System)
Check Starting System Message
Emergency Engine Start
506
The engine is harder to start in cold
weather. Also, the thinner air f ound at
altitudes above 8,000 f eet (2,400
meters) adds to this problem.
\f—\f—y
\f
y
) \f\fy\f

y
2009 TL

Î
Î
CONT INUED
These indicators between the
tachometer and speedometer show
which position the shif t lever is in.Using a paddle shif t mode, the gear
position indicator shows you the
selected gear number (see page
).
The ‘‘D’’ indicator comes on f or a
f ew seconds when you turn the
ignition switch to the ON (II)
position. If it f lashes while driving (in
any shif t position), it indicates a
possible problem in the transmission. Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
If the malf unction indicator lamp
comes on along with the ‘‘D’’
indicator, there is a problem with the
automatic transmission control
system. Avoid rapid acceleration and
have the transmission checked by
your dealer as soon as possible.
When the ‘‘D’’ indicator warns of a
possible problem with the
transmission, you will see a ‘‘CHECK
TRANSMISSION’’ message on the
multi-inf ormation display.
512 :
180
178
Shif t L ever Position Indicators
Automatic Transmission
Driving
507
GEAR POSITION INDICATOR on
PADDLE SHIFT MODE
\f—
—y
\fy
) \f\fy\f
y
2009 TL
