To use the towing hook:Remove the cover f rom the f ront
bumper using your f ingers, or pry
it of f using a cloth and a f lat-tipped
screwdriver.
If your vehicle gets stuck in sand,
mud, or snow, call a towing service
to pull it out (see page ).
For very short distances, such as
f reeing the vehicle, you can use the
detachable towing hook that mounts
on the anchor in the f ront bumper.
When you need to release the
steering lock while your vehicle’s
battery is dead, do this:
Follow the proper jump starting
procedures, Step 1 through Step 5,
to apply the power to your vehicle
(see pages and ).
Remove the towing hook and
wheel nut wrench f rom the tool
case in the spare tire (see page).
Follow the jump starting
procedures, Step 8 and Step 9, and
the instructions to disconnect the
jumpercable(seepage ).The
steering will remain unlocked even
if the battery is dead.
Failure to comply means the steering
lockmaybedamaged. Press the ENGINE START/STOP
button to set the power mode to
ACCESSORY (see page ) and
verif y the steering lock is released.
1.
2.
606
1.
2.
3.
592
592591
179
583
On models with keyless access systemIf Your Vehicle Gets Stuck
Emergency Towing, If Your Vehicle Gets Stuck
608
—
—y


y
) y
y
2009 TL

Screw the towing hook into the
