USB port Acura TL 2010 Navigation Manual

Table of Contents
Navigation System
3
Vehicle ........................................111
Off-road Tracking ........................ 111
Correct Vehicle Position .............. 112
Color ..........................................113
Map Color .................................... 113
Menu Color .................................. 114
Switching Display Mode Manually .................................................. 114
Switching Display Mode Automatically .......................... 115
Language ..................................... 116
Wallpapers Setting ...................... 116
Importing Pictures from USB ....... 117
Selecting Wallpaper Pictures ........ 117
Delete Pictures on HDD ............... 118
Reset Factory Default Settings ....118
Clear Personal Data .................... 119
AcuraLink/Messages .................. 120
Tra f fi c & Weather Status ............ 120
Rearview Camera ........................ 121
Rearview Camera Brightness
Adjustment .............................. 121
Rearview Camera Image .............. 121
System Initialization .................122
System Initialization .................. 122Entering the Security Code .........
122
GPS Initialization ....................... 122
Map Matching ............................ 123
System Limitations ...................124
GPS Reception Issues ................. 124
Database Limitations ...............125
Client Assistance ...................... 127
Coverage Areas ......................... 129
Map Coverage ............................. 129
U.S. Detailed Coverage Areas .... 129
Canada Detailed Coverage Areas ....134
Operation in Alaska, Hawaii,
Canada, and Puerto Rico ........ 144
Alaska, Hawaii, Canada, and
Puerto Rico .............................. 144
Other Map Issues ......................... 144
INFO Screen Differences .............145 Shipping a Vehicle To or From Alaska, Hawaii, Canada, and Puerto Rico ...............................145
Frequently Asked Questions .... 146
Troubleshooting ........................ 154Glossary ....................................
155
Glossary ...................................... 155
Voice Command Index .............158
Global Commands ...................... 158
Navigation General Commands .. 158
Navigation Display Commands... 159
Find Place Commands ................ 160
Climate Control Commands ....... 161
Radio Voice Commands ............. 162
Disc Voice Commands ............... 163
HDD Voice Commands .............. 163
AUX Voice Commands .............. 163
USB Voice Commands ............... 164
iPod Voice Commands ................ 164
Bluetooth
® Audio Commands ...... 164
Cellular Phone Voice Commands ................................................ 165
SET
UP Screen (Main Set up)
Commands .............................. 165
On-Screen Commands ................ 165
On-Screen Spelling Assist ......... 166
INDEX .......................................170
Others ........................................ 174
2010 TL

System Setup
Navigation System117
Importing Pictures from USB
To use a wallpaper image other than
the factory defaults, you can import
pictures from a USB thumb drive or
similar device.
If you say or select Import pictures
from USB and a USB thumb drive
is properly connected , the following
screen will display.
Rotate the Interface Dial knob and
select the images to be uploaded to the
HDD. Move the Interface Dial down
and select OK .
NOTE:
• Depending on the USB thumb drive, pictures may not be imported. • You can import images from the root
directory. Images in folders cannot
be imported.
• The display size is 800 x 480 pixels. Smaller images are displayed with
the extra area appearing in black.
Larger images are reduced to a
displayable size without changing the
aspect ratio.
• Ten uploaded images (in BMP or JPEG format) can be saved to the
HDD for Driver 1 and Driver 2 each.
• Incompatible data formats or images greater than 6 MB cannot be saved.
• When the fi le name is longer than 221 characters, the image cannot be
uploaded.
• If you attempt to uploaded an image with the same name as an existing
image, a pop-up screen will appear,
asking if you want to overwrite the
existing image fi le.
• When music fi les that are saved within a USB thumb drive are
being played, image fi les cannot be
uploaded.
• You cannot import images while driving.
Selecting Wallpaper Pictures
If you say or select Select wallpaper
picture , a list of the images on the
HDD will appear.
NOTE:
If Wallpaper has not been set up,
“Blank” will be selected.
If you select an image, the image will
appear in a pop-up screen. Select OK to
complete the setup. The selected image
will be highlighted on the list screen.
2010 TL
