Always keep the remote and the
built-in key away from any magnetic
material.
Youshouldhavereceivedakey
number tag with your built-in key.
You will need this key number if you
ever have to get a lost key replaced.
UseonlyAcura-approvedkeyblanks.
Your vehicle has a keyless access
system. This system allows you to
operate the vehicle without an
ignition key. When you carry the
remote with you, you can lock/
unlock the door(s), unlock the trunk,
and start the engine.
When the vehicle battery is dead. When the remote battery is dead. A vehicle is being operated with a
transmitter nearby. The remote is covered by metal. You carry a cell phone, a laptop
computer, or other electrical
device near the remote. There is strong electrical current
nearby. Thebatteryof theremoteisweak.
The system may not work if: Each keyless access remote has a
built-in key. This key is used to lock/
unlock the doors when the remote
battery becomes weak and the
power door lock/unlock operation is
disabled. You cannot start the engine
with this key.
Make sure the driver always carries
the remote/built-in key set.
Protect the remote and the built-in
key f rom direct sunlight, high
temperature, and high humidity.
Do not drop the remote or the
built-in key, and do not set heavy
objects on them.
Keep the remote and the built-in key
away f rom liquids. If they get wet,
dry them immediately with a sof t
cloth.
The built-in keys do not contain
batteries.On models with navigation system
K eyless A ccess System
Inst rument s and Cont rols
167
10/07/29 12:01:27 31TK4620_172
2011 TL

The f ollowing keys come with your
vehicle. Refer to page for how to
separate the keys.
This key is used to lock/unlock the
doors, glove box, and trunk pass-
through cover.This remote is used to lock/unlock
the doors and unlock the trunk.
When you carry the remote, you can
lock/unlock the doors, unlock the
trunk, and start the engine.
Anyone can lock/unlock a door or
open the trunk if the remote is
within the operating range of the
door or the trunk. You can lock/unlock the doors
within about a 32 inch (about 80 cm)
radius f rom the outside door handle.
You can open the trunk within about
a 32 inch (about 80 cm) radius f rom
thetrunkreleaseswitch.
195
Keys
K eyless A ccess System
Built -in K ey
K eyless A ccess Remot e
168
BUILT-IN KEYS
OPERATING
RANGE
KEYLESS ACCESS
REMOTES
KEY NUMBER TAG
10/07/29 12:01:36 31TK4620_173
2011 TL

The engine may not run, and some
malf unctions may occur, if the
remote is outside the vehicle.The engine may not start if the
remote is subjected to strong radio
waves.
Also, the engine may not start if the
remote is too close to the windows.
K eyless A ccess System
Engine Start/Stop Button
Operating Range
Inst rument s and Cont rols
177
Make sure you know where the remote
is when you are inside the vehicle.
Remember that you can start the engine
when the remote is inside the vehicle.
Make sure you always carry the remote
with you.
10/07/29 12:02:57 31TK4620_182
2011 TL

The keyless access system has f our
power modes: VEHICLE OFF
(LOCK), ACCESSORY, ON, and
START.
This system uses the engine start/
stop button instead of an ignition
switch to start and stop the engine. If
you are carrying the keyless access
remote, you can start the engine by
pressing the engine start/stop
button with the brake pedal
(automatic transmission) or the
clutch pedal (manual transmission)
depressed. You can also stop the
engine by pushing this button when
the vehicle is stopped. Each time you press the engine
start/stop button without pressing
the brake pedal (automatic
transmission) or the clutch pedal
(manual transmission) while
carrying the keyless access remote,
the power mode switches between
VEHICLE OFF (LOCK),
ACCESSORY, and ON.
You can start the engine at any time
by pressing the engine start/stop
button, while pressing the brake
pedal, with the shift lever in Park or
neutral position.
You can start the engine at any time
by pressing the engine start/stopbutton, while pressing the clutch
pedal f ully, with the shif t lever in any
gear position.
To change the power mode without
turning on the engine, press the
engine start/stop button without
pressing the brake pedal (automatic
transmission) or the clutch pedal
(manual transmission). The power
mode will be changed as shown on
the next page.
Automatic transmission:
Manual transmission:
K eyless A ccess System
Engine Start/
Stop ButtonSwit ching t he Power Modes Changing t he Power Mode wit houtSt art ing t he Engine
178
10/07/29 12:03:04 31TK4620_183
Operation
2011 TL

CONT INUED
K eyless A ccess System
Inst rument s and Cont rols
Automatic TransmissionManual Transmission
179
: Press the engine start/stop button.
: Press the engine start/stop button without the shift lever in P.
: Shift to Park, then press the engine start/stop button.
Do the following without pressing the brake pedal. VEHICLE OFF (LOCK)
Indicator in the button is off.
ACCESSORY
Indicator in the button comes on green.
Some electrical components such as the
audio system and accessory power sockets
can be operated.
ON
Indicator in the button remains green when
the engine is not running.
(If the engine is running,this indicator is off.)
All electrical components can be used.
: Press the engine start/stop buttonwithout pressing the clutch pedal.
10/07/29 12:03:12 31TK4620_184
2011 TL

Automatic TransmissionManual Transmission
How the mode is switched depends
on if the shif t lever is in Park or not.Each time you press the engine
start/stop button without pressing
the clutch pedal, the power mode
switches between VEHICLE OFF
(LOCK), ACCESSORY, and ON
modes. To change the mode f rom
ON to ACCESSORY, or
ACCESSORY to VEHICLE OFF
(LOCK), press the engine start/stop
button twice. If the keyless access system
main switch in the glove box is of f ,
make sure to insert the keyless
access remote into the keyless
access slot to turn on your vehicle’s
power mode. For more inf ormation,
ref er to page .
To remove the keyless access
remote from the slot, make sure the
power mode is VEHICLE OFF
(LOCK).
With the shift lever in Park, the
power mode changes f rom ON to
VEHICLE OFF (LOCK) when you
push the engine start/stop button.
TochangethemodefromONto
ACCESSORY with the shift lever
position in Park, take your f oot of f
the brake and press the engine
start/stop button twice.
Tochangethemodefrom
ACCESSORY to VEHICLE OFF
(LOCK),shifttoPark,thenpress
the engine start/stop button twice. 189
K eyless A ccess System
180
NOTE:
10/07/29 12:03:19 31TK4620_185
2011 TL

Engine is turned of f and
power is shut down.
The steering wheel is
locked.
No electrical components
can be used.
Indicator-Of fEngine is turned of f
and power is shut
down.
The steering wheel is
locked.
No electrical
components can be
used. Use this position to start
the engine.
The ignition switch
returns to the ON (II)
position when you
release the key.
Engine is turned of f .
Some electrical components
such as the audio system
and accessory power
sockets can be operated.
Indicator-Green
Engine is turned of f .
Some electrical
components such as the
audio system and
accessory power sockets
can be operated. Indicator-
Green (engine is turned off)
Of f (engine is running)
All electrical components
can be used.
Normal key position while
driving.
All electrical components
can be used.
Indicator-Of fThe mode
automatically returns
to ON after the
engine starts.
VEHICLE OFF
(LOCK) ACCESSORY
ON ST ART
Ignition Switch
Position
Power Mode LOCK (0)
ON (II)
ACCESSORY (I)
Without Keyless
Access System
With Keyless
Access System and
Engine Start/Stop
Button ST ART (III)
OFF
Green
Ignition Switch and Power Mode Comparison
K eyless A ccess System
Inst rument s and Cont rols
181
10/07/29 12:03:31 31TK4620_186
2011 TL

You can start the engine in any
power mode.
To start the engine:Depress the brake pedal and press
the engine start/stop button. Move the shift lever to Park (P). Af ter you unlock and open the
driver’s door, you will see the ‘‘TO
START ENGINE:’’ message on the
multi-inf ormation display. The ‘‘TO
TURN ACCESSORY ON:’’ message
will be shown af ter three seconds.
The display switches between the
‘‘TO START ENGINE:’’ and ‘‘TO
TURN ACCESSORY ON:’’ messages
every three seconds.
Apply the parking brake.
Press the clutch pedal down all the
way.
The engine does not start unless
the clutch pedal is pressed.
Press the engine start/stop button.
1.
2. 1.
2.
3.
Automatic Transmission
Manual Transmission
K eyless A ccess System
Starting the EngineStarting Guidance
182
ENGINE START/STOP BUTTON
BRAKE PEDAL
AUTOMATIC TRANSMISSION ENGINE START/STOP BUTTON
MANUAL TRANSMISSION CLUTCH PEDAL
M/TTO START ENGINE:
TO TURN
ACCESSORY ON:
A/T
10/07/29 12:03:44 31TK4620_187
2011 TL

Af ter entering the vehicle, insert the
keyless access remote into the slot
to start the engine (see page ). If the keyless access remote battery
dies, you may have to use the built-in
key to unlock/lock the vehicle. The
built-in key is stored inside the
keyless access remote (see).
If the steering wheel is locked, the
engine cannot start. The multi-
inf ormation display shows you the
above message and the indicator in
the engine start/stop button blinks.
To unlock the steering wheel, apply
f orce by turning it lef t and right
while pressing the engine start/stop
button at the same time.
the multi-
inf ormation display shows the
‘‘INSERT KEYLESS REMOTE
INTO SLOT’’ message, then the ‘‘TO
START ENGINE:’’ message will be
shown af ter you insert the remote
into the slot. Each time you press the
engine start/stop button, the
‘‘INSERT KEYLESS REMOTE
INTO SLOT’’ message is shown on
the multi-information display if the
remote is not in the slot. 195
191
When the keyless access system mainswitch in the glove box is of f , T o unlock t he st eering wheel
K eyless A ccess System
Inst rument s and Cont rols
183
NOTE:
TO UNLOCK WHEEL
10/07/29 12:03:50 31TK4620_188
page
2011 TL

To turn the vehicle off, make sure
the vehicle is completely stopped and
do the f ollowing.If the shif t lever is in any gear
other than neutral, depress the
clutch pedal, then press the engine
start/stop button.
The engine stops and the power
mode switches f rom ON to
VEHICLE OFF (LOCK).
Bef ore leaving the vehicle, make
sure it is of f . You can verif y if the
power is of f by checking the engine
start/stop button LED indicator. You can only place the vehicle in the
VEHICLE OFF (LOCK) mode if the
transmission is in Park. You will see
the ‘‘SHIFT TO PARK’’ message on
the multi-information display if you
press the engine start/stop button to
turn the vehicle of f with the shif t
lever in any other position except f or
P(Park).
If the shift lever is in neutral, press
the engine start/stop button.
Press the engine start/stop button
with your f oot on the brake pedal. Shif t to park (P). Make sure to press the brake pedal
or set the parking brake before
turning off the engine. If your foot
is OFF the clutch pedal in any gear
position, pressing the engine start/
stop button turns off the engine,
and the vehicle may move forward
or backward.
1.
2.
Manual Transmission
Automatic Transmission On automatic transmission models
On manual transmission modelsStopping the Engine
K eyless A ccess System
Operat ion Guidance
184
SHIFT TO PARK
A/T model only
A/T model
10/07/29 12:04:01 31TK4620_189
2011 TL
