Turn the selector knob to select
‘‘CALIBRATION.’’Press the selector knob (ENTER)
to enter your selection. The
display shows you ‘‘PUSH CAL
START.’’
While setting the compass, press
the RETURN button to go back to
the previous display. Pressing the
SETUP button will cancel the
compass setting mode.When the calibration is successf ully
completed, the CAL indicator goes
of f and the compass display will stop
blinking and show an actual heading.
The audio system is not related to
the compass system. Even if the
compasssystemiscalibrating,the
display returns to the normal display
which you last selected.Press the selector knob (ENTER).
The compass display is blinking
and the CAL indicator is shown.
Drive the vehicle slowly in two
complete circles.
3. 4. 5.
6.
Compass
380
10/07/29 12:29:34 31TK4620_385
2011 TL

Help assure your vehicle’s f uture
reliability and perf ormance by paying
extra attention to how you drive
during the f irst 600 miles (1,000 km).
During this period:
You should also f ollow these
recommendations with an
overhauled or exchanged engine, or
when the brakes are replaced.Do not change the oil until the
multi-inf ormation display indicates
it is needed. Avoidhardbrakingforthefirst
200 miles (300 km). Avoid full-throttle starts and rapid
acceleration.
Your vehicle is designed to operate
on premium unleaded gasoline with a
pump octane of 91 or higher. If this
octane grade is unavailable, regular
unleaded gasoline with a pump
octane of 87 or higher may be used
temporarily. The use of regular
unleaded gasoline can cause metallic
knocking noises in the engine and
will result in decreased engine
perf ormance. The long-term use of
regular-grade gasoline can lead to
engine damage.
You may hear a knocking noise from
the engine if you drive the vehicle at
low engine speed (below about 1,000
rpm) in a higher gear. To stop this,
raise the engine speed by shif ting to
a lower gear.
On vehicles with manual transmission
Break-in Period
Fuel Recommendation
Break-in Period, Fuel Recommendation
444
Use of gasoline with these additives
may adversely af f ect perf ormance, and
cause the malf unction indicator lamp
on your instrument panel to come on. If
this happens, contact your dealer f or
service. Some gasoline today is blended
with oxygenates such as ethanol. Your
vehicle is designed to operate on
oxygenated gasoline containing up to
10% ethanol by volume. Do not use
gasoline containing methanol. If you
notice any undesirable operating
symptoms, try another service station
or switch to another brand of gasoline. We recommend quality gasoline
containing detergent additives that help
prevent f uel system and engine deposits.
In addition, in order to maintain good
perf ormance, f uel economy, and
emissions control, we strongly
recommend the use of gasoline that
does NOT contain harmf ul manganese-
based f uel additives such as MMT , if
such gasoline is available.
10/08/03 20:56:58 31TK4620_449
2011 TL

If you hold the engine start/stop
button for more than 7 seconds,
the starter motor, depending on
the outside temperature, runs f orabout10to25secondsuntilthe
engine starts.
Without touching the accelerator
pedal, push and release the engine
start/stop button. You do not need
to hold the engine start/stop
button to start the engine.
Depending on the outside
temperature, the starter motor
runs f or about 6 to 9 seconds until
the engine starts. The keyless access remote battery
becomes weak or dead. The keyless access remote system
main switch is of f .
In either of the f ollowing cases, you
should insert the keyless access
remote into the keyless remote slot.
For more inf ormation, see pages
and . If the engine does not start, wait at
least 10 seconds bef ore trying
again.
Your vehicle’s starting system has an
auto control mode. When you have
your keyless access remote and push
the engine start/stop button while
depressing the brake pedal (A/T) or
clutch pedal (M/T), this f eature
keeps the engine’s starter motor
running until the engine starts.
Follow these instructions to start the
engine:
Make sure the shif t lever is in
Park. Press on the brake pedal. Press the clutch pedal down all the
way. The power mode f rom ON to
START does not f unction unless
the clutch pedal is pressed. In cold weather, turn of f all
electrical accessories to reduce
the drain on the battery. Apply the parking brake.
1.
2.
3. 4.188 189Automatic transmission:
Manual transmission:
Starting the Engine (Models with Keyless Access System)
Driving
463
T he immobilizer system protects your
vehicle f rom thef t. If an improperly
coded keyless access remote (or other
device) is used, the engine’s f uel system
is disabled. For more inf ormation, see
page .
The engine is harder to start in cold
weather. Also, the thinner air f ound at
altitudes above 8,000 f eet (2,400
meters) adds to this problem. 143
10/07/29 12:41:40 31TK4620_468
2011 TL

If you cannot start the engine using
the normal engine start procedure,
do the f ollowing:Set the parking brake.
If there is a problem with the
starting system, you will see a
‘‘CHECK STARTING SYSTEM’’
message on the multi-inf ormation
display with the power mode ON.
You will also see this message when
the auto control mode of the starting
system has a problem. If this message is on, you should
press and hold the engine start/stop
button until the engine starts. The
engine start/stop button can be
pressedupto15seconds.
Even though you may be able to
start the engine manually without
the auto control mode of the starting
system, have your vehicle inspected
by a dealer.
Your vehicle has the engine start/
stop button instead of an ignition
switch to select the power mode. For
more information, see page .
Do not f ollow this procedure unless
it is a case of emergency. Even if you
can start the engine using this
method, the system may have a
malf unction. Contact your dealer as
soon as possible.Press and hold the engine start/
stop button f or about 15 seconds
while pressing the brake pedal
(automatic) or the clutch pedal
(manual). Press the engine start/stop button
to turn on the ACCESSORY mode. Put the shif t lever into Park.
178 1.
2.
3.
4.
Automatic transmission:
Starting the Engine (Models with Keyless Access System)
Emergency Engine Start
Check Starting System Message
464
10/07/29 12:41:50 31TK4620_469
2011 TL

Press the clutch pedal, and shift
to
The manual transmission has a
lockout so you cannot accidentally
shif t f rom any f orward gear to
reverse while the vehicle is moving
at a certain speed. If you cannot shif t
to reverse when the vehicle is
stopped, do the f ollowing:
With the clutch pedal pressed,
move the shift lever to the first/
second gear side of the neutral
gate, then shif t to reverse.If you are still unable to shif t to
reverse, apply the parking brake,
and select the ACCESSORY or
VEHICLE OFF (LOCK) mode
(see page ).
With the clutch pedal still pressed
f ully, press the engine start/stop
button to start the engine.
If you need to use this procedure to
shif t to reverse, your vehicle may be
developing a problem. Have it
checked by your dealer.
1. 2.
3.
4.
179
Reverse Lockout
Manual T ransmission
Driving
467
Move the shift lever in sequence.
10/07/29 12:42:10 31TK4620_472
reverse.
2011 TL

Î
Î
These indicators between the
tachometer and speedometer show
which position the shif t lever is in. Using a paddle shift mode, the
gear position indicator shows
you the selected gear number
(see page
).
The ‘‘D’’ indicator comes on f or a
f ew seconds when you turn the
ignition switch to the ON (II)
position. If it f lashes while driving (in
any shif t position), it indicates a
possible problem in the transmission. Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
If the malf unction indicator lamp
comes on along with the ‘‘D’’
indicator, there is a problem with the
automatic transmission control
system. Avoid rapid acceleration and
have the transmission checked by
your dealer as soon as possible.
When the ‘‘D’’ indicator warns of a
possible problem with the
transmission, you will see a ‘‘CHECK
TRANSMISSION’’ message on the
multi-inf ormation display. :
178 181
473
Shif t L ever Position Indicators
Automatic Transmission
468
GEAR POSITION INDICATOR on
PADDLE SHIFT MODE
10/07/29 12:42:18 31TK4620_473
2011 TL

µ
Î
Î
This position mechani-
cally locks the transmission. Use
Park whenever you are turning of f or
starting the engine. To shif t out of
Park, you must press on the brake
pedal and have your f oot of f the
accelerator pedal. Press the release
buttononthefrontof theshiftlever
to move it.
To shif t f rom Park to any position,
pressfirmlyonthebrakepedal,and
pressthereleasebuttononthefront
of the shift lever, then move the
lever. You cannot shift out of Park
when the ignition switch is in the
LOCK (0) or ACCESSORY (I)
position. Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. VEHICLE
OFF (LOCK) Mode is the
equivalent of LOCK (0) and
ACCESSORY Mode is the
equivalent of ACCESSORY (I).
For more inf ormation, see pages
and .
178
:
181
Do this:
Press the brake pedal and
press the shift lever release
button.
Press the shift lever release
button.
Move the shift lever.
To shift from:
PtoR
RtoP
NtoR DtoS
StoD
DtoN
NtoD RtoN
CONT INUED
Shif ting
Park (P)
Automatic Transmission
Driving
469
RELEASE BUTTON
10/07/29 12:42:26 31TK4620_474
2011 TL

µ
µ µ
If you have done all of the above and
still cannot move the lever out of
Park, see on
page . Press the brake
pedal and the release button on the
frontoftheshiftlevertoshiftfrom
Park to reverse. To shif t f rom
reverse to neutral, come to a
completestop,andthenshift.Press
the release button bef ore shif ting
into reverse f rom neutral.
Use neutral if you
need to restart a stalled engine, or if
it is necessary to stop brief ly with
the engine idling. Shif t to the Park
position if you need to leave your
vehicle for any reason. Press on the
brake pedal when you are moving
the shift lever from neutral to
another gear. Use this position f or
your normal driving. The
transmission automatically selects a
suitable gear (1 through 5) f or your
speed and acceleration. You may
notice the transmission shifting up at
higher engine speeds when the
engine is cold. This helps the engine
warm up f aster.
You must also press the release
button to shift into Park. To avoid
transmission damage, come to a
complete stop bef ore shif ting into
Park.
TheshiftlevermustbeinPark
bef ore you can remove the key f rom
the ignition switch.
TheshiftlevermustbeinPark
bef ore you change the power mode
f rom ON to VEHICLE OFF (LOCK). 471
On models with keyless access system
On models without keyless access
system
Shif t L ock ReleaseReverse (R)
Neutral (N) Drive (D)
Automatic Transmission
470
10/07/29 12:42:32 31TK4620_475
2011 TL

´µ
When you move the shif t lever f rom
‘‘D’’ to ‘‘S’’ and pull either paddle
shif ter, the gear position indicator
displays ‘‘M’’ along with the selected
gear number.
To upshif t, pull the (right) paddle
shif ter. To downshif t, pull the
(lef t) paddle shif ter. When you accelerate from a stop,
the transmission starts in first
gear, and you must manually
upshift between first and fifth
gears. Make sure you upshift
before the engine speed reaches
the tachometer’s red zone.
With the shift lever in the S position,
you can manually shift up or down
with the paddle shifters. The
transmission goes into the
sequential shift mode and holds the
selected gear.
To enter the sequential shif t mode,
pressthereleasebuttononthefront
of the shift lever, move the lever to
the S position, then pull either paddle
shif ter. To return to drive mode (D),
move the shif t lever to the D position.
While you are driving in the
sequential shif t mode, the
transmission will not automatically
return to drive mode (D).
CONT INUED
Using the Paddle Shif ters in the S
position (Sequential Shif t Mode)
Driving with the Paddle Shif ters (A utomatic Transmission Only)
Driving
475
‘‘M’’ INDICATOR
GEAR POSITION INDICATOR
10/07/29 12:43:09 31TK4620_480
2011 TL

´
When you are in sequential shif t
mode, and the vehicle is stopped,
pull the (right) paddle shifter to
shif t to second gear. You will see
‘‘M2’’ in the display. Starting in
second gear helps to reduce
wheelspin in deep snow or on a
slippery surf ace. Drive in the highest gear that lets
the engine run and accelerate
smoothly. This will give you good
f uel economy and ef f ective
emissions control. The f ollowing
shif t points are recommended:
Shif t up
1st to 2nd
2nd to 3rd 3rd to 4th4th to 5th Normal acceleration
15 mph (24 km/h)
25 mph (40 km/h)
40 mph (64 km/h)
45 mph (72 km/h)
Driving with the Paddle Shif ters (A utomatic Transmission Only)
St art ing in Second Gear Recommended Shif t Point s
Driving
477
10/07/29 12:43:23 31TK4620_482
2011 TL
