This switch is under the driver’s
side vent. To turn the VSA system
on and off, press and hold it
until you hear a beep.
When VSA is off, the VSA OFF
indicator comes on as a reminder.
Press and hold the switch again. It
turns the system back on.
If the low tire pressure/TPMS
indicator comes on (see page ),
or the multi-information display
shows a ‘‘CHECK TPMS SYSTEM’’
message with the indicator flashing
(see page ), the VSA system
automatically turns on even if the
VSA system is turned off with the
VSA OFF switch. In this case, you
cannot turn the VSA system of f by
pressing the VSA OFF switch again.
Without VSA, your vehicle will have
normal braking and cornering ability,
but it will not have VSA traction and
stability enhancement.
If there is a problem with the hill
start assist system, the VSA system
indicator comes on and stays on. The
multi-inf ormation display shows a
‘‘CHECK HILL START ASSIST
SYSTEM’’ message.
With the VSA system indicator on,
you may not be able to stop the
engine even if you park the vehicle
safely. To stop the engine, see
on
page .
186 487
491
CONT INUED
On models with SH-AWD
On models with keyless access systemVSA OFF Switch
Emergency Engine Stop
Vehicle Stability A ssist (VSA), aka Electronic Stability Control (ESC), System
Driving
485
VSA OFF SWITCH
10/07/29 12:44:20 31TK4620_490
2011 TL

VSA is turned on every time you
start the engine, even if
you turned it off the last time
you drove the vehicle.
In certain unusual conditions when
your vehicle gets stuck in shallow
mud or fresh snow, it may be easier
to free it with the VSA temporarily
switched off. When the VSA system
is off, the traction control system is
also off. You should only attempt to
free your vehicle with the VSA off if
you are not able to free it when the
VSA is on.
Immediately af ter f reeing your
vehicle, be sure to switch the VSA on
again. We do not recommend driving
your vehicle with the VSA and
traction control systems switched off.Driving with varying tire or wheel
sizes may cause the VSA to
malf unction. When replacing tires,
make sure they are of the same size
and type as your original tires (see
page ).
If you install winter tires, make sure
they are the same size as those that
were originally supplied with your
vehicle. Exercise the same caution
during winter driving as you would
Your vehicle is equipped with a hill
start assist f eature to help prevent
the vehicle f rom rolling on inclines
as you move your f oot f rom the
brake pedal to the accelerator.
To activate hill start assist, you must
come to a complete stop and make
sure the shif t lever is either in D or S
when f acing uphill, or reverse when
f acing downhill. This f eature begins
working a few seconds after you are
in the correct gear position. Release
thebrakepedal.Thebrakesremain
engaged brief ly to keep the vehicle
f rom rolling f orward or backward.
Gently apply the accelerator pedal as
in normal driving. Hill start assist will
release brake pressure gradually as
you accelerate.
540
On models with SH-AWD
Vehicle Stability A ssist (VSA), aka Electronic Stability Control (ESC), System
VSA and Tire Sizes
Hill Start Assist
486
10/07/29 12:44:28 31TK4620_491
if your vehicle was not equipped
with VSA.
2011 TL

Hillstartassistmaynotpreventyour
vehicle f rom rolling downhill on a
very steep or slippery slope, and will
not operate on small inclines.
Hill start assist is not a replacement
f or the parking brake. If parking
your vehicle, ensure that the
transmission is in park, and/or the
parking brake is f ully applied bef ore
exiting the vehicle. For vehicles with
manual transmission, it is
recommended that you turn of f the
engine bef ore exiting the vehicle.If the VSA system indicator comes
on with a ‘‘CHECK HILL START
ASSIST SYSTEM’’ message on the
multi-inf ormation display, there may
be a problem with the hill start assist.
The VSA also may not f unction.
Have your vehicle inspected by your
dealer.
Hill start assist will still operate even
when VSA is switched off.
On manual transmission models:
You must come to a complete stop,
press the clutch pedal, and shif t to
f irst gear when f acing uphill, or
reverse when f acing downhill.
Release the brake pedal. The brakes
remain engaged brief ly to keep the
vehicle f rom rolling f orward or
backward while you move your f oot
f rom the brake pedal to the
accelerator pedal. Gently apply the
accelerator pedal while
simultaneously releasing the clutch
pedal, as in normal driving. Hill start
assist will release brake pressure
gradually as you accelerate.
Hill start assist will also hold braking
brief ly if you select the neutral gear
position with the clutch pedal
depressed when f acing uphill.
Vehicle Stability A ssist (VSA), aka Electronic Stability Control (ESC), System
Driving
487
10/07/29 12:44:33 31TK4620_492
2011 TL

Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.If you think you can saf ely drive a
short distance to a service station,
proceed slowly to the station, then
inflate the tire to the recommended
pressure shown on the driver’s
doorjamb.
If the tire is f lat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire (see page ).
Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Becausetirepressurevariesby
temperature and other conditions,
the low tire pressure/TPMS
indicator may come on unexpectedly.
When the low tire pressure/TPMS
indicator is on, one or more of your
tires is signif icantly underinf lated.
Youshouldstopandcheckyourtires
as soon as possible, and inflate them
to the proper pressure as indicated
on the vehicle’s tire inf ormation
placard.
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes signif icantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure/TPMS indicator in the
instrument panel to come on. If this
happens, you will see which tire is
losing pressure on the multi-
inf ormation display along with a
‘‘CHECK TIRE PRESSURE’’
message. It is possible that the pressures
shown on the multi-inf ormation
display and the pressures you
manually measure are slightly
dif f erent.
If the dif f erence is signif icant or you
cannot make the low tire pressure/
TPMS indicator and message on the
multi-inf ormation display go out af ter
inf lating the tires to the specif ied
values, have your dealer check the
system as soon as possible. 549
Low Tire Pressure/
TPMS Indicator
Tire Pressure Monitoring System (TPMS)
488
10/07/29 12:44:41 31TK4620_493
2011 TL

Î Each tire pressure is shown in
PSI (U.S. models) or in kPa
(Canadian models).If any of the tires has low pressure,
thetirepressuremonitoralsoshows
the above message and each tire
pressure to warn you about the low
tire pressure when you select the
displaybypressingtheINFObutton
several times.
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes significantly low, the
sensor in that tire immediately
sends a signal that causes the low
tire pressure/TPMS indicator
in the instrument panel to come on.
If this happens, you will see
which tire is losing pressure on the
multi- information display
along with a ‘‘CHECK
TIRE PRESSURE’’ message.
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
:
178 181
Tire Pressure Monitoring System (TPMS)
490
Canadian model U.S. model Canadian model
10/07/29 12:44:56 31TK4620_495
2011 TL

Î
Î
CONT INUED
Your vehicle displays engine oil lif e
and maintenance service items on
the multi-information display to show
youwhenyoushouldhaveyour
dealer perf orm engine oil
replacement and indicated
maintenance service.To see the current engine oil lif e
displayed on the multi-inf ormation
display, turn the ignition switch to
the ON (II) position, and press the
SEL/RESET button on the steering
wheel repeatedly until the engine oil
lif e is displayed. Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
Based on the engine operating
conditions, the onboard computer in
your vehicle calculates the remaining
engine oil lif e and displays it as a
percentage. :
178 181
Maintenance Minder
Engine Oil L if e Indicator
Maint enance
497
REMAINING ENGINE OIL LIFE
U.S. model is shown.
TM
10/07/29 12:45:43 31TK4620_502
2011 TL

ÛÝ
Î
Î
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ µ
µ
Pressing either INFO button ( / )
switches the display f rom the
message to another display. Once
you switch the display, this message
will go of f .
Along with the message, the system
message indicator comes on (see
page ).
When the remaining engine oil lif e is
15 to 6 percent, the multi-inf ormation
display shows a ‘‘SERVICE DUE
SOON’’ message along with the
maintenance item code(s) indicating
themainandsubitemsrequiredat
thetimeof theoilchange.Referto
page f or a complete list of the
maintenance main items and sub
items.
The remaining engine oil lif e is
shown on the multi-inf ormation
display according to this table:
The message appears on the multi-
inf ormation display each time you
turn the ignition switch to the ON
(II) position.Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pagesand .
72
: 178 181
506
Calculated Engine
Oil Lif e (%)
100% 91% 90% 81%
80% 71%
70% 61%
60% 51%
50% 41%
40% 31%
30% 21%
20% 16%
15% 11%10% 6% 5% 1% 0% Displayed
Engine Oil Lif e (%) 100%90%
80%
70%
60%
50%
40%
30%
20%
15%
10%5%
0%
Maintenance Minder
498
MAINTENANCE MAIN ITEM CODE
MAINTENANCE SUB ITEM CODE(S)
TM
10/07/29 12:45:50 31TK4620_503
2011 TL

Î
ÛÝ
Î
CONT INUED
Press the SEL/RESET button on the
steering wheel repeatedly to select
the engine oil lif e. The message
‘‘SERVICE,’’ along with ‘‘0%,’’ and the
maintenance item code are displayed
on the multi-information display
when the calculated engine oil lif e is
0to1percent.
These messages will come on every
time you turn the ignition switch to
the ON (II) position.
If the indicated required service is
not done and the remaining engine
oil lif e becomes 0%, the multi-
inf ormation display will show a
‘‘SERVICE PAST DUE’’ message,
the total distance traveled after the
remaining oil lif e became 0%, and the
maintenance item code(s).
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
Pressing either INFO button ( / )
switches the display f rom the
message to another display. To see
the message again, press either
INFO button repeatedly. Immediately have the service
perf ormed, and make sure to reset
the display as described on page . :
178 181 503
Maintenance Minder
Maint enance
501
U.S.TOTAL PAST DUE DISTANCE
TRAVELED
MAINTENANCE CODES
Canada
TM
10/07/29 12:46:09 31TK4620_506
2011 TL

ÛÝ
Î
Î Î
Select ‘‘RESET’’ by pressing the
INFO ( / ) button, then press
the SEL/RESET button to reset
the engine oil lif e display. The
maintenance item code(s) will
disappear, and the engine oil lif e
will reset to ‘‘100.’’ If you want to
cancel the oil lif e reset mode,
select ‘‘CANCEL.’’
Your dealer will reset the display
af ter completing the required
maintenance service. You will see
‘‘OIL LIFE 100%’’ on the display the
next time you turn the ignition
switch to the ON (II) position.
Turn the ignition switch to the
ON (II) position.
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages and .
If maintenance service is done by
someone other than your dealer,
reset the Maintenance Minder as
f ollows: If the engine oil lif e is not
displayed, press the SEL/RESET
buttononthesteeringwheel
repeatedly.
Press and hold the SEL/RESET
button on the steering wheel f or
more than 10 seconds. The
remaining engine oil lif e reset
mode will be shown on the multi-
inf ormation display.
3. 1.
2.
4.
:
178 181
Maintenance Minder
Resetting the Engine
Oil Lif e Display
Maint enance
503
TM
10/07/29 12:46:26 31TK4620_508
2011 TL

Remove the check bolt and look for
transmission f luid coming out of the
bolt hole. If a small amount of f luid
drips out of the bolt hole, reinstall
the check bolt.
Check the f luid level with the
transmission at normal operating
temperature and the vehicle sitting
on level ground.
To check the transmission f luid level,
remove the mounting bolt and the
under cover holding clips, then pull
out the driver’s side under cover
caref ully. If no f luid comes out, remove the
f iller bolt. Slowly add Acura Manual
Transmission Fluid (MTF) untilPour the f luid into the f iller hole
slowly and caref ully so you do not
spill any. Clean up any spills
immediately; it could damage
components in the engine
compartment.
Let the f luid run out until it stops,
then reinstall the check bolt and the
f iller bolt.
CONT INUED
T ransmission Fluid
Manual Transmission
Maint enance
517
WASHER
CHECK BOLT
FILLER BOLT
10/07/29 12:48:12 31TK4620_522
it starts to run out of the check
bolt hole.
2011 TL
