To listen to XM Radio, set the power
mode to ACCESSORY or ON. Push
the button to select the XM
Radio. The last channel you listened
to will show in the audio screen (if
selected) and the center display.
Adjust the volume by turning the
VOL/ knob.Yourvehiclehastheenginestart/
stop button instead of an ignition
switch. For more inf ormation on how
to select the power mode, see
.
Each time you push the interface
selector up, the band will change to
XM1 or XM2. Push the AUDIO
button to display XM inf ormation on
the screen. You can operate the XM
radio system with the interf ace dial.
Your vehicle is capable of receiving
XM
Radio anywhere in the United
States and Canada, except Hawaii,
Alaska,andPuertoRico.XMisa
registered trademark of Sirius XM
Radio
,Inc.andXMCANADAis a
registered business name of
Canadian Satellite Radio Inc.
XM Radio receives signals from two
satellites to produce clear, high-
quality digital reception. It offers
many channels in several
categories. Along with a large
selection of different types of
music, XM Radio also allows you to
view channel and category
selections in the audio display. Operating the XM Radio
Playing the XMRadio (Models with navigation system)
288
10/07/29 12:17:18 31TK4620_293
page 178
2011 TL

µµ µ
µ´µ
Each time you press and release the
TITLE button, the center display
changes in the f ollowing sequence:
NAME (artist name), TITLE (music
title), and CHANNEL NAME
(channel name).
Onthescreen,youwillseethe
selected CHANNEL (number),
CATEGORY, NAME (artist name),
and TITLE (music title).
You may experience periods when
XM Radio does not transmit the
artist’s name and song title
inf ormation. If this happens, there is
nothing wrong with your system.
To switch between the
category mode and channel mode,
push the interface selector down
to display AUDIO MENU, then
turn the interface dial to select
Mode, and press ENTER on the
interface selector.
Turn the interf ace dial to select CH
or CAT, then press ENTER on the
interface selector. Move the
interfaceselectoruptogoback.
You can also switch the mode by
pressing the TITLE button for
In the category mode, such as Jazz,
Rock, Classical, etc., you can
navigate through all of the channels
within that category. In the channel
mode, you can select all of the
available channels. Press either side of the
TUNE bar to change channel
selections. Press the side of the
bar f or higher numbered channels
and the side for lower
numbered channels. You can also
change channels with the interf ace
selector. Push down the interf ace selector to select AUDIO MENU,
then turn the interface dial to choose
TuneandpressENTERonthe
interf ace selector. Turn the interf ace
dial to the appropriate direction. In
the category mode, you can only
select channels within that category.
Push down the
interf ace selector to select AUDIO
MENU,thenturntheinterfacedial
to select Channel List and press
ENTERontheselector.Turnthe
interf ace dial to select a channel,
then press ENTER to set your
selection.
Press
either side of the bar to select
another category.
CONT INUED
MODE
TUNECHA NNEL L IST
CATEGORY ( or )
Playing the XMRadio (Models with navigation system)
Features
289
10/07/29 12:17:26 31TK4620_294
3 seconds.
2011 TL

µµ µ
µ
The scan f unction gives
you a sampling of all channels while
in the channel mode. In the category
mode, only the channels within
The system plays each channel in
numerical order f or a f ew seconds,
then selects the next channel. When
you hear a channel you want to
continue listening to, press the
SCAN side of the bar to cancel.
This f unction
samples all channels. Push down the
interf ace selector to select AUDIO
MENU,thenturntheinterfacedial
to select Channel Scan and press
ENTER on the interf ace selector. Press the button. Either
XM1 or XM2 will be shown on the
display.
To store a channel: Youcanstoreupto12
preset channels using the six preset
buttons. Each button stores one
channel f rom the XM1 band and one
channel f rom the XM2 band.
This
f unction samples the stations in the
selected category. Push down the
interf ace selector to select AUDIO
MENU,thenturntheinterfacedial
to select Category Scan and press
ENTER on the interf ace selector. 1.
SCAN
CHA NNEL SCA N
Preset
CAT EGORY SCAN
Playing the XMRadio (Models with navigation system)
290
XM BAND
10/07/29 12:17:34 31TK4620_295
that category are scanned. To
activate SCAN, press the SCAN
center display. side of the SCAN/A.SEL bar. You
will see SCAN on the screen and
2011 TL

µ
µ
µ
µ µ
µ
µ
The encryption
code is being updated. Wait until the
encryption code is f ully updated.
Channels 0 and 1 should still work
normally. XM is loading the
audio or program inf ormation. The channel
currently selected is no longer
broadcasting. Once a channel is stored, press
and release the proper preset
button to tune to it.
Press the button or scroll
up again. The other XM band will
be shown. Store the next six
channels using steps 2 and 3. Repeat steps 2 and 3 to store the
f irst six channels. Pick the preset button you want
f or that channel. Press and hold
the preset button until you hear a
beep. You can also pick the
number with the interf ace dial.
Select your desired number and
press and hold ENTER on the
interf ace selector. In category mode, only channels
within that category can be
selected. In channel mode, all
channels can be selected. Use the tune, list, or scan f unction
to tune to a desired channel. The signal is
currently too weak. Move the vehicle
to an area away from tall buildings,
and with an unobstructed view of the
southern horizon. The selected channel
number does not exist, or is not part
of your subscription, or this channel
has no artist or title inf ormation at
this time.
There is
a problem with the XM antenna.
Please consult your dealer. The selected
channel has no artist or title
inf ormation at this time.
5. 3.
4. 2.
CONT INUED
‘‘UPDA T ING’’ ‘‘L OA DING’’ ‘‘OFF A IR’’ XM Radio Display Messages
‘‘NO SIGNA L ’’ ‘‘----’’
‘‘CHECK A NT ENNA ’’ ‘‘NO INFO’’
Playing the XMRadio (Models with navigation system)
Features
291
10/07/29 12:17:44 31TK4620_296
2011 TL

The XM satellites are in orbit over
the equator; therefore, objects south
of the vehicle may cause satellite
reception interruptions. To help
compensate f or this, ground-based
repeaters are placed in major
metropolitan areas. Satellite signals
aremorelikelytobeblockedbytall
buildings and mountains the f arther
north you travel f rom the equator.
Depending on where you drive, you
may experience reception problems.
Interf erence can be caused by any of
these conditions:Driving on the north side of an
east/west mountain road.
Driving on the north side of a
large commercial truck on an
east/west road.
Driving in tunnels. Driving on a single lane road
alongside dense trees taller than
50 ft. (15 m) to the south of you. Driving on the lower level of a
multi-tiered road. Driving on a road beside a vertical
wall, steep clif f , or hill to the south
of you.When DPLII is turned on (see page
), sound coming f rom the rear
speakers may be distorted due
to the compression of the music
being broadcast. Turn DPLII off if
this happens. 286
Playing the XMRadio (Models with navigation system)
292
GROUND REPEATER
Signal may be blocked by
mountains or large obstacles
to the south.
Signal weaker in
these areas.
SATELLITE
10/07/29 12:17:52 31TK4620_297
2011 TL

CONT INUED
To replay and see the stored file,
press the AUDIO button to select
the audio display on the
navigation screen.
Push down the interf ace selector
to display the audio menu. Turn
the interface dial to select Note,
then press ENTER.
This f unction stores the sound
content played on the selected XM
Radio station with the channel,
category, name, and title inf ormation.
To activate this function, press and
hold the button for about 2
seconds while a song or passage
which you want to store is playing.
You can record f or up to 10 seconds.
To stop recording, press the AM/
FM button or button.
Once you store the recorded sound
f ile, you can replay it and conf irm the
inf ormation. The system can store
up to 30 sound f iles. If you continue
tostoremorefiles,theoldestone
will be deleted each time you add a
new f ile.
There may be other geographic
situations that could af f ect XM Radio
reception.
As required by the FCC:
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment. U.S. models only
Playing the XMRadio (Models with navigation system)
Note Function
Features
293
NOTE ICON
10/07/29 12:18:02 31TK4620_298
2011 TL

Turn the selector dial to select a
sound file, then press ENTER. The
display shows the category, name
and title information of the
selected file.
To delete all f iles, push the interf ace
selector to the lef t to select
‘‘DELETE ALL,’’ then press ENTER.
To delete one f ile, select the f ile you
want to delete and push the interf ace
selector to the right, then press
ENTER.If your XM Radio service has expired
or you purchased your vehicle f rom
a previous owner, you can listen to a
sampling of the broadcasts available
on XM Radio. With the power mode
in ACCESSORY or ON, press the
button. A variety of music
types and styles will play.
Your vehicle has the engine start/
stop button instead of an ignition
switch. For more inf ormation on how
to select the power mode, see
.
If you decide to purchase XM radio
service, contact XM Radio at ,orat
1-800-852-9696. In Canada, contact
XM CANADA
at , or
at 1-877-209-0079. You will need to
give them your radio I.D. number
and your credit card number. To get
your radio I.D. number, press the side of the TUNE bar until ‘‘0’’ appears in the display. Your I.D. will
appear in the display.
Af ter you have registered with XM
Radio, keep your audio system in the
XM Radio mode while you wait f or
activation. This should take about 30
minutes.
While waiting f or activation, make
sure your vehicle remains in an open
area with good reception. Once your
audio system is activated, CAT
(category) or CH (channel) will
appear in the center display, and
you’ll be able to listen to XM Radio
broadcasts. XM Radio will continue
to send an activation signal to your
vehicle for at least 12 hours from the
activation request. If the service has
not been activated after 36 hours,
contact XM
Radio. In Canada,
contact XM CANADA
.
www.xmradio.com
www.xmradio.ca
Playing the XMRadio (Models with navigation system)
Receiving XM Radio Service
294
SOUND FILE RECORDED DATE
10/07/29 12:18:10 31TK4620_299
page 178
2011 TL

CONT INUED
Playing a Disc (Models with navigation system)
Features
295
CATEGORY BARSKIP BAR
AUDIO BUTTON PRESET BUTTONS EJECT BUTTON
INTERFACE DIALCENTER DISPLAY NAVIGATION SCREEN
DISC BUTTON
DISC SLOT
TITLE BUTTON VOL/
(VOLUME/POWER)KNOB
SCAN/A.SEL
(SCAN/AUTO SELECT) BAR
10/07/29 12:18:17 31TK4620_300
2011 TL

The disc packages or jackets should
have one of these marks.The disc player can also play MP3,
WMA, or AAC format that saved
on CD-R/RW or DVD-R/RW (see
page ).
If a f ile on WMA or AAC disc is
protected by digital rights
management (DRM), the audio
system skips to the next f ile.
DVD-A discs not meeting DVD
verification standards may not be
playable.
Video CDs and DVD-V format discs
will not work in this unit.
Some CD-DA and CD-ROM mixed
discs are not playable.
Your vehicle’s audio system has an
in-dash disc player. To operate the
disc player, the power mode must be
in the ACCESSORY or ON.
Your vehicle has the engine start/
stop button instead of an ignition
switch. For more inf ormation on how
to select the power mode, see
.
CD (CD-DA, CD-TEXT)
CD-R/CD-RW(MP3,WMA,AAC)
DVD-A
DVD-R/DVD-RW (MP3, WMA,
AAC)
The disc player can play these disc
formats: 301
Playing a Disc (Models with navigation system)
296
NOTE:
10/07/29 12:18:27 31TK4620_301
page
178
2011 TL

Ì
You cannot load and play 3-inch
(8-cm)discsinthissystem.
It is possible to select up to 999 f iles
f or inclusion in CD-Rs and CD-RWs,
and up to 3,500 f iles f or inclusion in
DVD-Rs and DVD-RWs.Insert a disc about half way into the
disc slot. The drive will pull the disc
intherestof thewaytoplayit.You
operate the disc player with the
same controls used f or the radio.
The number of the current track is
showninthedisplay.Whenplayinga
disc in MP3, WMA or AAC, the
numbers of the current f older and
f ile are shown. The system will
continuously play a disc until you
change modes.
For information on how to handle
and protect compact discs, see
.
Manuf actured under license under
U.S. Patent ’s: 5,451,942; 5,956,674;
5,974,380; 5,978,762; 6,487,535 &
other U.S. and worldwide patents
issued & pending. DTS and DTS
Digital Surround are registered
trademarks and the DTS logos and
Symbol are trademarks of DTS, Inc.
1996-2008 DTS, Inc. All Rights
Reserved.
Depending on the sof tware the f iles
were made with, it may not be
possible to play some f iles, or display
some text data. To Load a Disc
Playing a Disc (Models with navigation system)
Features
297
Do not use discs with adhesive labels.
The label can curl up and cause the
disc to jam in the unit.
10/07/29 12:18:34 31TK4620_302
page
364
2011 TL
