Î
ÎThis indicator comes on brief ly when
you turn the ignition switch to the
ON (II) position. If it comes on at
any other time, it indicates that the
passenger’s side airbag has
automatically shut off. For more
inf ormation, see page .
You will also see a ‘‘PASSENGER
SIDE AIRBAG OFF’’ message on the
multi-inf ormation display.
This indicator comes on brief ly when
you turn the ignition switch to the
ON (II) position. If it comes on at
any other time, it indicates a
potential problem with your f ront
airbags. This indicator will also alert
you to a potential problem with your
airbag system components. You will
also see a ‘‘CHECK AIRBAG
SYSTEM’’ message on the multi-
inf ormation display. For more
inf ormation, see page .
33
32
Supplemental Restraint
System Indicator
Side A irbag Of f
Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
67
U.S. Canada
12/07/20 10:38:21 31TK4640_072
Î Models equipped with the keyless
access system have an engine start/
stop button instead of an ignition
switch. ON Mode is the equivalent of
ON (II). For more information, see
pages
and .
:
184 187
Î
Models equipped with the keyless
access system have an engine start/
stop button instead of an ignition
switch. ON Mode is the equivalent of
ON (II). For more information, see
pages
and .
:
184 187
2013 TL

Î
This indicator comes on as a
reminder that you have turned of f
the vehicle stability assist (VSA)
system.
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. For more inf ormation, see
page .
This indicator has two f unctions:
It flashes when VSA is active (see
page ).
If itcomesonandstaysonatany
other time, there is a problem with
the VSA or Hill Start Assist (on
SH-AWD models only) system.
You will also see a ‘‘CHECK VSA
SYSTEM’’ or ‘‘CHECK HILL
START ASSIST SYSTEM’’
message on the multi-inf ormation
display. Take your vehicle to a
dealer to have it checked. Without
VSA, your vehicle still has normal
driving ability, but will not have
VSA traction and stability
enhancement. For moreinf ormation, see page . If the VSA indicator illuminates,
hill start assist will not be working.
Without hill start assist, the
vehicle will roll downhill
immediately when you release the
brakeonanincline.
1.
2. 510
510
510
Vehicle Stability Assist
(VSA ) System Indicator
VSA OFF Indicator
Instrument Panel Indicators
68
12/07/20 10:38:30 31TK4640_073
Î
Î
Models equipped with the keyless
access system have an engine start/
stop button instead of an ignition
switch. ON Mode is the equivalent of
ON (II). For more information, see
pages
and .
:
184 187 ÎModels equipped with the keyless
access system have an engine start/
stop button instead of an ignition
switch. ON Mode is the equivalent of
ON (II). For more information, see
pages
and .
:
184 187
Inst rument s and Cont rols
2013 TL

Î
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
This indicator has two f unctions:If it comes on while driving, it
indicates that one or more of your
vehicle’s tires are signif icantly low
on pressure. You will also see a ‘‘CHECK TIRE
PRESSURE’’ message on the multi-
inf ormation display (see page ).
Check the tire pressure monitor on
the multi-inf ormation display and
determinethecause(seepage ).
If this indicator begins to flash,
there is a problem with the tire
pressure monitoring system
(TPMS). You will also see a
‘‘CHECK TPMS SYSTEM’’
message on the multi-
information display. The
indicator continues to flash for a
while (approximately 1 minute),
then stays on. If this happens,
have your dealer check the
system as soon as possible. For
more information, see page
.
If this happens, pull to the side of the
road when it is saf e, check which tire
has lost pressure on the multi-
inf ormation display, and determine
the cause. If it is because of a flat tire,
replace the flat tire with the compact
spare (see page ), and have the
f lat tire repaired as soon as possible.
If two or more tires are underinf lated,
call a prof essional towing service.
For more inf ormation, see page .
1.
2.
516
515
514
583
607
Instrument Panel Indicators
Low Tire Pressure/
TPMS Indicator
Inst rument s and Cont rols
69
12/07/20 10:38:38 31TK4640_074
ÎModels equipped with the keyless
access system have an engine start/
stop button instead of an ignition
switch. ON Mode is the equivalent of
ON (II). For more information, see
pages
and .
:
184 187
2013 TL

ÎThe lef t or right turn signal indicator
blinks when you signal a lane change
or turn. If an indicator does not blink
or blinks rapidly, it usually means
one of the turn signal bulbs is
burned out (see pages and ).
Replace the bulb as soon as possible,
since other drivers cannot see that
you are signaling.
When you press the hazard warning
button, both turn signal indicators
and all turn signals on the outside of
the vehicle f lash.This indicator normally comes on
when you turn the ignition switch to
the ON (II) position and goes of f
af ter the engine starts. If it comes on
at any other time, there is a problem
in the electric power steering system.
If this happens, stop the vehicle in a
saf e place and turn of f the engine.
Reset the system by restarting the
engine. The indicator will stay on,
but should go of f af ter driving a
short distance. If it does not go of f ,
or comes back on again while driving,
take the vehicle to your dealer to
have it checked. With the indicator
on, the EPS may be turned of f ,
making the vehicle harder to steer.
If you turn the steering wheel to the
f ull lef t or right position repeatedly
while stopping or driving at very low
speed, you may f eel slightly harder
steering in order to prevent damage
to the steering system caused by
overheating. This may also happen if
you hold the steering wheel on the
f ull lef t or right position f or a while.
You will also see a ‘‘CHECK POWER
STEERING SYSTEM’’ message on
the multi-information display.
558 562
Instrument Panel Indicators
Turn Signal and
Hazard Warning
Indicators
Electric Power Steering
(EPS) Indicator
70
12/07/20 10:38:46 31TK4640_075
Inst rument s and Cont rols
Î
Mod els eq uip ped wit h th e keyless
a cce ss sy ste m have an en gin e sta rt/
s to p butto n in ste ad of an ignition
s w it c h .O N Mod e is th e eq uiv ale n t of
O N (II) . F or m ore in fo rm atio n ,se e
p ag es
and .
:
184 187
2013 TL

Î
This indicator comes on with the
high beam headlights. For more
inf ormation, see page .
This indicator also comes on with
reduced brightness when the
daytime running lights (DRL) are on
(see page ).
This indicator comes on when you
turn on the f og lights. For more
inf ormation, see page .
This indicator reminds you that the
exterior lights are on. It comes on
when the light switch is in either the
or position. This indicator
will also come on when the light
switch is in AUTO and the lights
turn on automatically. If you turn the
ignition switch to the ACCESSORY
(I) or the LOCK (0) position, without
turning of f the light switch, this
indicator will remain on. Reminder
beeps will also sound when you open
the driver’s door. This indicator comes on red if any
door or the trunk lid is not closed
tightly.
You will also see a corresponding
indicator(s) on the multi-information
display to indicate which door and/
or the trunk is not closed tightly (see
page ).
12
140
142
143
Instrument Panel Indicators
High Beam Indicator
Fog L ight Indicator
Lights On Indicator
Door/Trunk
Inst rument s and Cont rols
71
12/07/20 10:38:56 31TK4640_076
Î
Models equipped with the
keyless access system have an engine
start/stop button instead of
an ignition switch. VEHICLE OFF
(LOCK) Mode is the equivalent of
LOCK (0) and ACCESSORY Mode
is the equivalent of ACCESSORY (I).
For more information, see pages
and .
:
184 187
Open Indicator
2013 TL

This in dica to r co m es on when you
tu rn on th ecru is e co n tr olsy ste m by
p re ssin g th eCRU IS E butto non th e
st eeri ng wheel (s ee pag e ).
T his in dica to r co m es on when you
se tthe cruise co nt ro l. Se epag e
f o r inf orma tion onope ra ting th e
cr uise contr o l. T
his in dica to r co m es on when th ere
i s a sy ste m messa g e on th em ulti -
inf ormation dis pla y.P re ss th e IN FO
b utto n on th e st eeri ng wheel (s ee
p ag e )to see th e m essa ge (s ee
pa ge ).
M ost of th etim e,th is in dic a to r
c o me son along wit h ot he rindic ato rs
i n th ein str um en t pan elsu ch as th e
se at be ltre minde rindic ato r, SR S
indic ato r, V SA sy ste m indic ato r, e tc .
This in dica to r co m es on when th e
secur it y syst emis set .F or m ore
inf orm ation, se e pag e .
401
79
401 395
90
Inst
ru ment Panel Indica tor s
Cr uis eMa inIndica to r
Cr uise Cont rol Indica tor Sy
stem Messag e
Indica to r Secur
it y Sy stem In di ca to r
72
SE CURIT YSYST EM IND ICATOR
12/07/20 10:39:04 31TK4640_077
Inst rument s and Cont rols
2013 TL

Î
This indicator is in the f uel gauge. It
comesonasareminderthatyou
must ref uel soon. You will also see a
‘‘LOW FUEL’’ message on the multi-
inf ormation display.This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. If this indicator comes on at
any other time, there is a problem in
the SH-AWD system. You will also
see a ‘‘CHECK SH-AWD SYSTEM’’
message on the multi-information
display (see page ). Take your
vehicle to a dealer to have it checked.
For more inf ormation, see page .
When the indicator comes on, there
are about 2.5 U.S. gal (9.6
)on
SH-AWD models, and 2.8 U.S. gal
(10.5
)on2WDmodelsof fuel
remaining in the tank.
When the needle reaches E, there is
a very small amount of f uel in the
tank.
505504
CONT INUED
On SH-AWD models
L ow Fuel Indicator Super Handling-A ll
Wheel Drive (SH-AWD)
Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
73
LOW FUEL INDICATOR
U.S. model is shown.
12/07/20 10:39:12 31TK4640_078
Î Models equipped with the keyless
access system have an engine start/
stop button instead of an ignition
switch. ON Mode is the equivalent of
ON (II). For more information, see
pages
and .
:
184 187
2013 TL

If the indicator blinks while driving,
the dif f erential temperature is too
high.You will also see an ‘‘SH-AWD
DIFF TEMP. HIGH’’ message
on the multi-information display
(see page ).
Pull to the side of the road when it is
saf e, shif t to Park, and let the engine
idle until the indicator goes out. This indicator normally comes on f or
a f ew seconds when you select the
ON mode with the engine start/stop
button (see page ). If it comes on
at any other time, it indicates that
there is a problem with the system. If this indicator comes on along
with a ‘‘CHECK KEYLESS
STARTING SYSTEM’’ message
on the multi-information display,
there is a problem with the keyless
starting system. In this case, your
vehicle may not restart. If you can
continue to drive saf ely, take the
vehicle to your dealer and have it
checked as soon as possible. For
more information, see page .
This indicator has two f unctions:
If this indicator comes on along
with a ‘‘CHECK KEYLESS
ACCESS SYSTEM’’ message on
the multi-information display,
there is a problem with the keyless
access system. Have the vehicle
checked by your dealer as soon as
possible. For more inf ormation,
see page .
1. 2.
505 195
196 196
On models with keyless access system
Instrument Panel Indicators
K eyless Access System
Indicator
74
Continuing to drive with the SH-AWD
indicator blinking may cause serious
damage to the system.
12/07/20 10:39:20 31TK4640_079
Inst rument s and Cont rols
2013 TL

If the indicator comes on at any
other time, there is a problem with
BSI. You will also see a ‘‘CHECK
BLIND SPOT SYSTEM’’ message on
the multi-information display. If this
happens, take your vehicle to a
dealer, and have it checked. For
more information, see page .
When this indicator is on, BSI is not
working.
This indicator normally comes on f or
a f ew seconds when you select the
ON mode by operating the engine
start/stop button (see page ).
This indicator comes on as a
reminder that you have turned of f
the blind spot inf ormation system
(BSI).
When you turn the system on, the
indicator will turn of f .
The BSI indicator also comes on if
the rear bumper becomes dirty while
driving. You will see a ‘‘BLIND
SPOT NOT AVAILABLE’’ message
on the multi-information display.
When you clean the rear bumper,
the indicator should go off after you
begin driving again. 519
185
On models with blind spot
information system (BSI)
Blind Spot Inf ormation
System (BSI) Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
75
12/07/20 10:39:25 31TK4640_080
2013 TL

This shows how much f uel you
have. It may show slightly more
or less than the actual amount.
The needle returns to the
bottom after you turn off the
ignition/power mode. Fuel Gauge
Gauges
76
SPEEDOMETER
TEMPERATURE
GAUGE TACHOMETER
FUEL GAUGE
U.S. model with automatic transmission is shown. MULTI-INFORMATION DISPLAY
Avoid driving with an extremely low
f uel level. Running out of f uel could
cause the engine to misf ire, damaging
the catalytic converter.
12/07/20 10:39:30 31TK4640_081
Inst rument s and Cont rols
2013 TL
