window Acura TSX 2005 User Guide

µ
Turn the ignition switch to ON (II)
toraiseorloweranywindow,push
the switch down and hold it. Release
the switch when you want the
window to stop. Close the window by
pulling the switch up and holding it. To open the driver’s
window, push the window switch
f irmly down, then release it. To stop
the window f rom going all the way
down, pull back on the window
switch brief ly.
To close the driver’s window f ully,
pull back the window switch f irmly,
then release it. To stop the window
f rom going all the way up, push
down on the window switch brief ly.
CONT INUED
AUTO
Power Windows
Inst rument s and Cont rols
89
DRIVER’S WINDOW SWITCH MAIN SWITCH
Closing a power window on
someone’s hands or fingers can
cause serious injury.
Make sure your passengers are
away from the windows before
closing them.

µIf the driver’s
window senses any obstacle while it
is closing automatically, it will
reverse direction and then stop. To
close the window, remove the
obstacle, then use the window switch
again.
Auto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it. If your vehicle’s battery is
disconnected or goes dead, or the
driver’s window f use is removed, the
AUTO f unction will be disabled. The
power window system needs to be
reset af ter reconnecting the battery
or installing the f use.
Start the engine. Push down and
hold the driver’s window switch
until the window is f ully open.
Pull and hold the driver’s window
switch to close the window
completely, then hold the switch
f or a second or two more.
If the power windows do not operate
properly af ter resetting, have your
vehicle checked by your dealer.
To open or close the driver’s window
partially, push down or pull back on
the window switch lightly and hold it.
The window will stop when you
release the switch.
The passenger windows cannot be
raised or lowered if the MAIN switch
is OFF. Keep the MAIN switch off
whenyouhavechildreninthe
vehicle so they do not injure
themselves by operating the
windows unintentionally.
1.
2.
AUTO REVERSE
Power Windows
90

You can open all of the windows
from the outside with the remote
transmitter.Press the UNLOCK button once
to unlock the driver’s door.
Press the UNLOCK button a
second time, and hold it. The
passenger’s doors unlock, and all
f our windows start to open. To
stop the windows, release the
button.
To open the windows f urther,
press the button again.
You cannot close the windows with
the remote transmitter.
The power window system has a key-
of f delay f unction. The windows will
stilloperateforupto10minutes
after you turn off the ignition switch.
Opening either f ront door cancels
the delay function. You must turn
the ignition switch to ON (II) again
bef ore you can raise or lower the
windows.
You can open and close the windows
with the key in the driver’s door lock.
To open:Insert the key in the driver’s door
lock.
Turn the key clockwise, then
release it.
1.
2.
3.
1.
2.
CONT INUED
Power Window Control
Operations
Opening t he Windows wit h t he
Remote Transmitter
Opening/Closing t he Windows wit hthe Key
Power Windows
Inst rument s and Cont rols
91
Open
Close UNLOCK BUTTON

Turnthekeyclockwiseagain,and
hold it. All f our windows start to
open. To stop the windows,
release the key.
To open the windows f urther, turn
andholdthekeyagain.
To close: Insert the key in the driver’s door
lock.
Turn the key counterclockwise,
then release it.
Turn the key counterclockwise
again, and hold it. All four
windowsstarttoclose.Tostopthe
windows, release the key.
To close the windows f urther, turn
andholdthekeyagain. To tilt up the back of the moonroof ,
press and hold the center button
( ). To close the moonroof ,
press and hold the upper button
( ). To open the moonroof ,
press and hold the lower button
( ). Release the button when
the moonroof gets to the desired
position. Make sure everyone’s
hands are away f rom the moonroof
bef ore opening or closing it.
The moonroof has two positions: it
can be tilted up in the back f or
ventilation, or it can be slid back into
the roof . Use the switch under the
lef t dashboard vent to operate the
moonroof . The ignition switch must
be in the ON (II) position.
1.
2.
3.
4. 3.
4.
Moonroof
Power Windows, Moonroof
92
MOONROOF SWITCH
Opening or closing the
moonroof on someone’s hands
or fingers can cause serious
injury.
Make sure all hands and fingers
are clear of the moonroof
before opening or closing it.

To use the sun visor, pull it down.
You can also use the sun visor at the
side window. Remove the support
rod f rom the clip and swing the sun
visor toward the side window.Touseavanitymirroronthebackof
the sun visor, pull up the cover.The lights come on when you pull up
the cover.
Sun Visor
Vanity Mirror
Sun Visor, Vanit y Mirror
94

Vents, Heating, and A/C
100
Without Navigation SystemFAN CONTROL BARTEMPERATURE DISPLAY
MODE BUTTON
DUAL BUTTON
OFF BUTTON
AUTO BUTTON TEMPERATURE
CONTROL BAR
(DRIVER’S SIDE)
FAN SPEED
INDICATOR
TEMPERATURE
CONTROL BAR
(PASSENGER’S SIDE)
REAR WINDOW
DEFOGGER BUTTON
WINDSHIELD
DEFROST BUTTON
RECIRCULATION BUTTON A/C BUTTON

Vents, Heating, and A/C
Features
101
AUTO BUTTONMODE ICONS A/C BUTTON
FAN CONTROL ICONS
DUAL BUTTON
OFF BUTTON
With Navigation System
TEMPERATURE
CONTROL BAR
(DRIVER’S SIDE) TEMPERATURE
CONTROL BAR
(PASSENGER’S SIDE)
REAR WINDOW
DEFOGGER BUTTON WINDSHIELD
DEFROST BUTTON RECIRCULATION BUTTON
AIR CONDITIONING ICONS
TEMPERATURE DISPLAY

On vehicles without the navigation
system, press the A/C button to turn
on the A/C. You will see A/C ON or
A/C OFF in the display.
On vehicles with the navigation
system, press the A/C button to view
the display. Touching ‘‘ON’’ or
‘‘OFF’’ in the display turns the air
conditioningonandoff.Youwillsee
A/C ON or A/C OFF in the display.
When you turn the A/C of f , the
system cannot regulate the inside
temperature if you set the
temperature control buttons below
the outside temperature.When the recirculation indicator is
on, air f rom the vehicle’s interior is
sent throughout the system again.
When the indicator is off, air is
brought in f rom the outside of the
vehicle (Fresh Air mode).
The outside air intakes f or the
heating and cooling system are at
the base of the windshield. Keep this
area clear of leaves and other debris.
Thesystemshouldbeleftinfresh
air mode under almost all conditions.
Keeping the system in recirculation
mode, particularly with the A/C of f ,
can cause the windows to fog up.
Switch to recirculation mode when
driving through dusty or smoky
conditions, then return to fresh air
mode.This button turns the rear window
def ogger of f and on (see page ).
69
Air Conditioning (A/C) Button Recirculation Button
Rear Window Def ogger Button
Vents, Heating, and A/C
Features
103

Use the mode control buttons or
icons to select the vents the air f lows
f rom. Some air will f low f rom the
dashboard corner vents in all modes.Airflows from the center and
corner vents in the dashboard.
Airf lows f rom the f loor vents.
Air f lows f rom the def roster
vents at the base of the windshield. When you select or ,
the system automatically switches to
Fresh Air mode and turns on the
A/C. In these modes, the A/C stays
on with the indicator off.
When you select , the system
automatically switches to Fresh Air
mode.
Airf low is divided between
the vents in the dashboard and the
f loor vents.
Airf low is divided between
the f loor vents and the def roster
vents at the base of the windshield. The f low-through ventilation system
draws in outside air, circulates it
through the interior, then exhausts it
through vents near the rear window.
Set the temperature to the lower
limit.
Make sure the A/C is of f .
Select and Fresh Air mode.
Set the f an to the desired speed.
Each time you press the MODE
button, the display shows the mode
selected.
Press the A/C button to view the
display, then touch any of the mode
icons on the display. 1.
2.
3.
4.
For Vehicles without Navigation System
For Vehicles with Navigation System
Mode Control Ventilation
Vents, Heating, and A/C
104

Û
Ý
ÛÝ
The heater uses engine coolant to
warm the air. If the engine is cold, it
will be several minutes bef ore you
f eel warm air coming f rom the
system.
Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page
). If it moves near the red zone,
turn of f the A/C until the gauge
reads normally. Press the A/C button, the Manual
Operation A/C screen will appear.
Select the ON icon on the display.
Select the desired temperature
and MODE selections. If the
outside air is humid, select the
Recirculation mode. If the outside
air is dry, select Fresh Air mode.
you can
cool it down more rapidly by partially
opening the windows, turning on the
A/C, and setting the fan to
maximum speed in Fresh Air mode.
Select .
When you select , the system
automatically switches to the
Fresh Air mode.
Set the f an to the desired speed.
Adjust the warmth of the air with
the temperature control bars (
or side).
Press the A/C button, the manual
operation of A/C screen will
appear.
Select the desired mode and f an
speed icons on the display.
Adjustforwarmthwiththe
temperature control bars ( or
side). Turn on the A/C by pressing the
A/C button.
Make sure the temperature
control is set to maximum cool.
Select .
If the outside air is humid, select
Recirculation mode. If the outside
air is dry, select Fresh Air mode.
Set the f an to the desired speed.
1.
2.
3. 1.
2.
3.
1.
2.
3. 61
1.
2.
3.
4.
5.
If the interior is very warm,
Without Navigation System
With Navigation System Without navigation system
With Navigation System
Using the Heater
Using the A /C
Vents, Heating, and A/C
Features
105
