µIf the driver’s
window senses any obstacle while it
is closing automatically, it will
reverse direction, and then stop. To
close the window, remove the
obstacle, then use the window switch
again.
Auto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it. If your vehicle’s battery is
disconnected or goes dead, or the
driver’s window f use is removed, the
AUTO f unction may be disabled. If
the AUTO f unction is disabled, the
power window system will need to be
reset af ter reconnecting the battery
or installing the f use.
The power window system has a key-
of f delay f unction. The windows will
still operate f or up to 10 minutes
after you turn off the ignition switch.
Opening either f ront door cancels
the delay function. You must turn
the ignition switch to the ON (II)
position again bef ore you can raise
or lower the windows.
If the power windows do not operate
properly af ter resetting, have your
vehicle checked by your dealer. Pull and hold the driver’s window
switch to close the window
completely, then hold the switch
f or about 2 seconds. Start the engine. Push down and
hold the driver’s window switch
until the window is f ully open.
1.
2.
AUTO REVERSE
Power Windows
148

Bef ore you begin driving your
vehicle, you should know what
gasoline to use and how to check the
levels of important f luids. You also
need to know how to properly store
luggage or packages. The
inf ormation in this section will help
you. If you plan to add any
accessories to your vehicle, please
read the information in this section
first..............................
Break-in Period .230
.................
Fuel Recommendation . 230
.........
Service Station Procedures . 231
....................................
Ref ueling .231
OpeningandClosingthe .......................................
Hood .232
...................................
Oil Check .234
.............
Engine Coolant Check . 234
...............................
Fuel Economy .235
...
Accessories and Modif ications . 236
.............................
Carrying Cargo .238
Bef ore Driving
Bef ore Driving
229

Remove the dipstick again, and
check the level. It should be
between the upper and lower
marks. Look
at the coolant level in the
radiator reserve tank. Make sure it is
between the MAX and MIN lines. If
it is below the MIN line, see
on page for
informationonaddingtheproper
coolant.
Refer to
on page for information
about checking other items on your
vehicle.
If
it is near or below the lower mark,
see on page .
Insert the dipstick all the way back
into its hole. Wipe the dipstick with a clean
cloth or paper towel. Remove the dipstick (orange
handle).
Wait a f ew minutes af ter turning the
engine of f bef ore you check the oil. Park the vehicle on a level surf ace.
1.
2.
3. 4.
291
282
287
Oil Check
Engine Coolant Check
A dding
Engine Coolant
Owner’s Maintenance
Checks
A dding Engine Oil
Service Station Procedure
234
UPPER MARK
DIPSTICK (orange handle) LOWER MARKRESERVE TANK
MAX
MIN

Always drive in the highest gear
possible.
Try to maintain a constant speed.
Everytimeyouslowdownand
speed up, your vehic le uses extra
fuel. Use cruise control when
appropriate.
Combine several short trips into
one.
The air conditioning puts an extra
load on the engine which makes it
usemorefuel.Usethefresh-air
ventilation when possible.
Always
maintain your vehicle
according to the maintenance
messages given by the multi-
inf ormation display. See on page
.
an underinf lated tire
causes more ‘‘rolling resistance,’’
which uses more f uel.
The build-up of snow or mud on
your vehicle’s underside adds
weight and rolling resistance.
Frequent cleaning helps your f uel
mileage and reduces the chance of
corrosion.
Drive moderately. Rapid
acceleration, abrupt cornering,
and hard braking use more f uel. 282
For example,
Improving Fuel Economy
Owner’s
Maintenance Checks
Fuel Economy
Bef ore Driving
235

Make sure all windows, mirrors,
and outside lights are clean and
unobstructed. Remove frost, snow,
or ice.
Make sure the doors are securely
closed and locked.
Fasten your seat belt. Check that
your passengers have fastened
their seat belts (see page ).
Check
the steering wheel
adjustment (see page ).
Check that the hood is fully closed.
Check that the trunk is fully
closed.
Check that any items you may be
carrying are stored properly or
fastened down securely. Check
the adjustment of the
inside and outside mirrors (see
pages and ).
Youshoulddothesechecksand
adjustments
before you drive your
vehicle:
Visually check the tires. If a tire
looks low, use a gauge to check its
pressure (see page ). Check
the seat adjustment (see
page ). When
you start the engine, check
the gauges and indicato rs in the
instrument panel, and the
messages on the multi-inform ation
display (see pages , and ).
11.
61
76
3. 2. 1.
4.
5. 6.
7.
8.
9.
10. 145
15
146
138
125
310 68
Preparing to Drive
242

If you exceed the maximum speed
f or the gear you are in, the engine
speed will enter into the tachometer’s
red zone. If this occurs, you may f eel
the engine cut in and out. This is
caused by a limiter in the engine’s
computer controls. The engine will
run normally when you reduce the
rpm below the red zone.The 6-speed manual transmission
has an electric lockout so you cannot
accidentally shif t f rom f if th to
reverse instead of sixth while the
vehicle is moving. If you cannot shif t
to reverse when the vehicle is
stopped:
Apply the parking brake, and turn
the ignition key to the
ACCESSORY (I) or the LOCK (0)
position.
Press the clutch pedal, and shif t to
reverse.
With the clutch pedal still pressed,
start the engine.
If you need to use this procedure to
shif t to reverse, your vehicle may be
developing a problem. Have the
vehicle checked by your dealer.
The engine speed limiter only works
when you upshif t; engine speed is
not limited during downshif ts.
Bef ore downshif ting, make sure the
engine will not go into the
tachometer’s red zone. 1.
2.
3.
Manual T ransmission
Engine Speed L imiter
Reverse L ockout
Driving
245

Insert the key in the shift lock
release slot.
Push down on the key while you
move the shift lever out of Park to
neutral.
To release the reverse lockout, move
the shift lever from neutral to
reverse, then to Park. Remove the key from the shift
lock release slot, then reinstall the
cover. Make sure the notch on the
cover is on the driver’s side. Press
the brake pedal, and restart the
engine.
If you need to use the shif t lock
release, it means your vehicle is
developing a problem. Have it
checked by your dealer. 6.
5. 4.
Automatic Transmission
252
SHIFT LOCK RELEASE SLOT

Your vehicle is equipped with disc
brakes at all f our wheels. A power
assist helps reduce the ef f ort needed
on the brake pedal. The anti-lock
brake system (ABS) helps you retain
steering control when braking very
hard.The hydraulic system that operates
the brakes has two separate circuits.
Each circuit works diagonally across
the vehicle (the lef t-f ront brake is
connected with the right-rear brake,
etc.). If one circuit should develop a
problem, you will still have braking
at two wheels.All f our brakes have audible brake
wear indicators.
If the brake pads need replacing, you
will hear a distinctive, metallic
screeching sound when you apply
the brake pedal. If you do not have
the brake pads replaced, they will
screech all the time. It is normal f or
the brakes to occasionally squeal or
squeak when you apply them.
Resting your f oot on the pedal keeps
the brakes applied lightly, builds up
heat, increases wear, and reduces
their ef f ectiveness. It also keeps
your brake lights on all the time,
conf using drivers behind you.
Constant application of the brakes
when going down a long hill builds
up heat and reduces their ef f ective-
ness. Use the engine to assist the
brakes by taking your f oot of f the
accelerator and downshif ting to a
lower gear. Check the brakes after driving
through deep water. Apply the
brakes moderately to see if they f eel
normal. If not, apply them gently and
f requently until they do. Be extra
cautious and alert in your driving.
Braking System
Braking System Design
Brake Wear Indicators
254

Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes significantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure indicator to come on. Although
your tire pressure is
monitored, you must manually check
thetirepressuresmonthly.
Each tire, including the spare, should
be checked monthly when the
vehicle is cold, and set to the
recommended inflation pressure as
sp ecified on the vehicle placard and
intheowner’smanual(seepage ).
Driving on a significantly under-
inflated tire causes the tire to
ov erheat and can lead to tire failure.
Under-infl ation also reduces fuel
efficiency and tire tread life, and may
affect the vehicle’s handling and
stopping ability. When
the low tire pressure indicator
is on, one or more of your tires is
signifi cantly underinflated. You
should stop and check your tires as
soon as possible, and inflate them to
the proper pressure as indicated on
the vehicle’s tire information placard.
With this indicator on, you will see
which tire is losing the pressure on
the multi-inf ormation display along
with a ‘‘CHECK TIRE PRESSURE’’
message (see page ).
311
259
CONT INUED
Low Tire Pressure
Indicator
Tire Pressure Monitoring System (TPMS)
Driving
257

If the indicator does not come on
when the ignition switch is turned to
the ON (II) position, there may be a
problem with the VSA system. Have
your dealer inspect your vehic le as
soon as possible.
Wh en the VSA system indicator
comes on, you will also see a
‘‘CHECK VSA SYSTEM’’ message
on the multi-information display.
Without VSA, your vehicle will have
normal braking and cornering ability,
but it will not have VSA traction and
stability enhancement.
When
VSA activates, you will see the
VSA activation indicator blink (see
page ).
If this indicator comes on while
driving, pull to the side of the road
when it is saf e, and turn of f the
engine. Reset the system by
restarting the engine. If the VSA
system indicator stays on, or comes
back on while driving, have the VSA
system inspected by your dealer.
The vehicle stability assist (VSA)
system helps to stabilize the vehicle
during cornering if the vehicle turns
more or less than desired. It also
assists you in maintaining traction
while accelerating on loose or
slippery road surf aces. It does this
by regulating the engine’s output and
by selectively applying the brakes.
When VSA activates, you may notice
that the engine does not respond to
the accelerator in the same way it
does at other times. You will also see
the VSA activation indicator blink.
The VSA system cannot enhance the
vehicle’s driving stability in all
situations and does not control your
vehicle’s entire braking system. It is
still your responsibility to drive and
corner at reasonable speeds and to
leave a sufficient margin of safety. 65
VSA A ctivation Indicator
Vehicle Stability Assist
(VSA ) System Indicator
Vehicle Stability Assist (VSA) System
262
