Acura TSX 2012 Owner's Manual

uuReplacing Light BulbsuHeadlight Bulbs
250Maintenance
High voltage can remain in the circuit for a long period of time after the light is
switched off. Do not attempt to inspect or replace the high voltage discharge type
bulbs yourself. Ask a dealer to inspect and replace low beam headlights.
1.Turn the steering wheel all the way to the
opposite side from the headlight being
replaced.
Passenger side: Turn the steering wheel to
the left.
Driver side: Turn the steering wheel to the
right.
2.Remove the holding clips and screws, and
pull the inner fender back.
3.Rotate the cover to the left, and remove.■
Low Beam Headlights
■
Low Beam Headlights
High Voltage Discharge TypesHalogen Types
1Low Beam Headlights
Insert a flat-tip screwdriver, lift and remove the
central pin to remove the clip.
Inner Fender
Cover Screw
Clip

Continued
251
uuReplacing Light BulbsuFog Light Bulbs
Maintenance
4.Unhook the hook, and pull out the
connector.
5.Remove the old bulb and insert the new
bulb.
6.Put the connector back into the headlight
assembly.
Fog Light BulbsWhen replacing, use the following bulbs.
1.Remove the clip using a flat-tip screwdriver,
and lower the under cover.
1Low Beam Headlights
Insert the clip with the central pin raised, and push
until it is flat.
Push until the
pin is flat
HookBulb
Connector
Fog Light: 55 W
1Fog Light Bulbs
NOTICEHalogen bulbs get very hot when lit. Oil, perspiration,
or a scratch on the glass can cause the bulb to
overheat and shatter.
The fog lights are halogen bulbs.
When replacing a bulb, handle it by its plastic case,
and protect the glass from contact with your skin or
hard objects. If you touch the glass, clean it with
denatured alcohol and a clean cloth.
Clip
Under Cover

252
uuReplacing Light BulbsuFront Turn Signal/Parking/Side Marker Light Bulbs
Maintenance
2.Remove the coupler.
uIt can be removed by pushing the tab.
3.Rotate the old bulb to the left to remove.
4.Insert a new bulb into the fog light
assembly and turn it to the right.
5.Insert the coupler into the connector of the
bulb.
Front Turn Signal/Parking/Side Marker Light BulbsWhen replacing, use the following bulbs.
Turn the steering wheel and pull the inner fender back in the same way as when
replacing the low beam headlights.
2Changing the Low Beam Headlight P. 250
1.Turn the socket to the left and remove it.
2.Push in the old bulb, rotate to the left until
it unlocks, and remove.
3.Insert a new bulb.
Bulb
Coupler
TabFront Turn Signal/Parking/Side Marker: 21/5W
Socket
Bulb

253
uuReplacing Light BulbsuSide Turn Signal/Emergency Indicator Light Bulbs
Continued
Maintenance
Side Turn Signal/Emergency Indicator Light BulbsDoor mirrors have the side turn lights. Have an authorized Acura dealer inspect and
replace the light bulbs.Brake Light, Taillight, Rear Turn Signal Light and Rear Side Marker Light BulbsWhen replacing, use the following bulbs.
1.Pull out and remove the cover.Brake/Taillight: 21/5 W
Rear Turn Signal Light: 21 W
Rear Side Marker Light: 3 CPCover

254
uuReplacing Light BulbsuBack-Up Light Bulbs
Maintenance
2.Turn the socket to the left and remove it.
Remove the old bulb.
3.Remove the old bulb and insert a new bulb.
Back-Up Light BulbsWhen replacing, use the following bulbs.
1.Remove the clip in the trunk using a flat-tip
screwdriver.
2.Pull out the lining.Back-Up Light: 21 W Lining
Clip

255
uuReplacing Light BulbsuRear License Plate Light Bulbs
Maintenance
3.Turn the socket to the left and remove.
4.Remove the old bulb and insert the new
bulb.
Rear License Plate Light BulbsHave an authorized Acura dealer inspect and replace the light bulbs.
Lining
Clip
Socket
Bulb

256
uuReplacing Light BulbsuHigh-Mount Brake Light Bulbs
Maintenance
High-Mount Brake Light BulbsWhen replacing, use the following bulbs.
1.Open the trunk.
2.Turn the socket to the left and remove it.
3.Remove the old bulb and insert a new bulb.High-Mount Brake Light: 21 W
BulbSocket

257
Continued
Maintenance
Checking and Maintaining Wiper BladesChecking Wiper BladesIf the wiper blade rubber has deteriorated, it will leave streaks and the metal wiper
arm may scratch the window glass.Changing the Wiper Blade Rubber
1.Lift the driver side wiper arm first, then the
passenger side.
2.Place a cloth on the edge of the lock tab.
Push the lock tab up with a flat-tip screw
driver.
3.Slide the blade from the wiper arm.
1Changing the Wiper Blade Rubber
NOTICEAvoid dropping the wiper arm; it may damage the
windshield.
Lock Tab

258
uuChecking and Maintaining Wiper BladesuChanging the Wiper Blade Rubber
Maintenance
4.Slide the wiper blade out from its holder by
pulling the tabbed end out.
5.Remove the retainers from the rubber blade
that has been removed, and mount to a
new rubber blade.
uCorrectly align the rubber protrusion and
the retainer grooves.
6.Slide the new wiper blade onto the holder
from the bottom end.
uThe tab on the blade should fit in the
indent of the wiper blade.
7.Slide the wiper blade onto the wiper arm,
then push down the lock tab.
8.Lower the passenger side wiper arm first,
then the driver side.
Blade
TopRetainer
Blade
TabIndent

259
Maintenance
Checking and Maintaining TiresChecking TiresTo safely operate your vehicle, your tires must be of the proper type and size, in
good condition with adequate tread, and properly inflated.■
Inflation guidelines
Properly inflated tires provide the best combination of handling, tread life, and comfort.
Refer to the driver’s doorjamb label or specification’s page for the specified pressure.
Underinflated tires wear unevenly, adversely affect handling and fuel economy, and
are more likely to fail from overheating.
Overinflated tires make your vehicle ride harshly, are more prone to road hazards,
and wear unevenly.
Every day before you drive, look at each of the tires. If one looks lower than the
others, check the pressure with a tire gauge.
At least once a month or before long trips, use a gauge to measure the pressure in
all tires, including the spare. Even tires in good condition can lose 1 to 2 psi (10 to
20 kPa, 0.1 to 0.2 kgf/cm
2) per month.
■
Inspection guidelines
Every time you check inflation, also examine the tires and valve stems.
Look for:
•Bumps or bulges on the side or in the tread. Replace the tire if you find any cuts,
splits, or cracks in the side of the tire. Replace it if you see fabric or cord.
•Remove any foreign objects and inspect for air leaks.
•Uneven tread wear. Have a dealer check the wheel alignment.
•Excessive tread wear.
2Wear Indicators P. 264
•Cracks or other damage around valve stem.
1Checking Tires
Measure the air pressure when tires are cold. This
means the vehicle has been parked for at least three
hours, or driven less than 1 mile (1.6 km). If
necessary, add or release air until the specified
pressure is reached.
If checked when hot, tire pressure can be as much as
4–6 psi (30–40 kPa, 0.3–0.4 kgf/cm
2) higher than if
checked when cold.
Have a dealer check the tires if you feel a consistent
vibration while driving. New tires and any that have
been removed and reinstalled should be properly
balanced.
3
WARNING
Using tires that are excessively worn or
improperly inflated can cause a crash in
which you can be seriously hurt or killed.
Follow all instructions in this owner’s
manual regarding tire inflation and
maintenance.
