20
A Few Words About Safety
Your safety, and the safety of others, is very important. And
operating this vehicle safely is an important responsibility.
To help you make informed decisions about safety, we have
provided operating procedures and other information on labels and
in this manual. This information alerts you to potential hazards that
could hurt you or others.
Of course, it is not practical or possible to warn you about all the
hazards associated with operating or maintaining your vehicle. You
must use your own good judgement. You will find this important safety information in a variety of forms,
including:
●
Safety Labels - on the vehicle.
● Safety Messages - preceded by a safety alert symbol
3 and
one of three signal words: DANGER, WARNING , or CAUTION .
These signal words mean:
● Safety Headings - such as Important Safety Precautions.
● Safety Section - such as Safe Driving.
● Instructions - how to use this vehi cle correctly and safely.
This entire book is fi lled with important safety information - please
read it carefully.
3 DANGERYou WILL be KILLED or SERIOUSLY HURT if
you don't follow instructions.
3 WARNINGYou CAN be KILLED or SERIOUSLY HURT if
you don't follow instructions.
3 CAUTIONYou CAN be HURT if you don't follow
instructions.
14 ACURA TSX 5D-31TL76300.book 20 ページ 2013年6月17日 月曜日 午後3時21分
Index
Quick Reference Guid e - 2014 TSX Sport WagonQRG
Page 22 of 331
21
Safe Driving
You can find many safety recommendations throughout this chapter, and throughout this manual.
For Safe Driving
Important Safety Precautions ............ . 22
Your Vehicle’s Safety Features............ 24
Seat Belts About Your Seat Belts ........................ 26
Fastening a Seat Belt .......................... 29
Seat Belt Inspection............................ 33
Airbags
Airbag System Components ............... 34
Types of Airbags ................................ 37
Front Airbags (SRS) ............................ 37
Side Airbags....................................... 41 Side Curtain Airbags ..........................
44
Airbag System Indicators.................... 45
Airbag Care ....................................... 48
Child Safety Protecting Child Passengers ............... 49
Safety of Infants and Small Children ..
51
Safety of Larger Children ................... 59
Exhaust Gas Hazard
Carbon Monoxide Gas ....................... 61
Safety Labels Label Locations .................................. 62
14 ACURA TSX 5D-31TL76300.book 21 ページ 2013年6月17日 月曜日 午後3時21分
QRG
Index
2014 TSX Sport Wagon
Page 23 of 331
22
Safe Driving
For Safe Driving
The following pages explain your vehicle’s safety features and how to use them
properly. The safety precautions below are ones that we consider to be among the
most important.
Important Safety Precautions
■Always wear your seat belt
A seat belt is your best protection in all types of collisions. Ai rbags are designed to
supplement seat belts, not replace them. So even though your vehicle is equipped
with airbags, make sure you and your passengers always wear your seat belts, and
wear them properly.
■Restrain all children
Children ages 12 and under should ride properly restrained in a back seat, not the
front seat. Infants and small children should be restrained in a child seat. Larger
children should use a booster seat and a lap/shoulder seat belt until they can use the
belt properly without a booster seat.
■Be aware of airbag hazards
While airbags can save lives, they can caus e serious or fatal injuries to occupants
who sit too close to them, or are not pr operly restrained. Infants, young children,
and short adults are at the greatest risk. Be sure to follow all instructions and
warnings in this manual.
■Don’t drink and drive
Alcohol and driving don’t mix. Even one dr ink can reduce your ability to respond to
changing conditions, and your reaction time gets worse with every additional drink.
So don’t drink and drive, and don’t let your friends drink and drive, either.
1 Important Safety Precautions
Some states, provinces and territories prohibit the use
of cell phones other than hands-free devices by the
driver while driving.
14 ACURA TSX 5D-31TL76300.book 22 ページ 2013年6月17日 月曜日 午後3時21分
QRG
Index
TOC
2014 TSX Sport Wagon
Page 24 of 331
23
uu For Safe Driving u Important Safety Precautions
■Pay appropriate attention to the task of driving safely
Engaging in cell phone conversation or ot her activities that keep you from paying
close attention to the road, other vehicles, and pedestrian s could lead to a crash.
Remember, situations can change quickly, an d only you can decide when it is safe to
divert some attention away from driving.
■Control your speed
Excessive speed is a major factor in crash injuries and deaths. Generally, the higher
the speed, the greater the risk, but serious injuries can also occur at lower speeds.
Never drive faster than is safe for curre nt conditions, regardless of the maximum
speed posted.
■Keep your vehicle in safe condition
Having a tire blowout or a mechanical failure can be extremely hazardous.
To reduce the possibility of such problems, check your tire pressures and condition
frequently, and perform all regularly scheduled maintenance.
14 ACURA TSX 5D-31TL76300.book 23 ページ 2013年6月17日 月曜日 午後3時21分
QRG
Index
Safe DrivingTOC
2014 TSX Sport Wagon
Page 25 of 331
24
uu For Safe Driving u Your Vehicle’s Safety Features
Your Vehicle’s Safety Features
The following checklist will help you take an active role in protecting yourself and
your passengers.
1 Your Vehicle’s Safety Features
Your vehicle is equipped with many features that
work together to help protect you and your
passengers during a crash.
Some features do not require any action on your part.
These include a strong steel framework that forms a
safety cage around the passenger compartment,
front and rear crush zone s, a collapsible steering
column, and tensioners that tighten the front seat
belts in a sufficient crash.
However, you and your passengers cannot take full
advantage of these features unless you remain seated
in the correct position and always wear your seat
belts. In fact, some safety features can contribute to
injuries if they are not used properly.
67891011
Safety Cage
Crush Zones
Seats and Seat-Backs
Head Restraints
Collapsible Steering Column
Seat Belts
Front Airbags
Side Curtain Airbags
Seat Belt Tensioners
Occupant Position Detection
System (OPDS) Sensor Side Airbags
Door Locks
6
7
8
9
10
11
8912
10
7
12
14 ACURA TSX 5D-31TL76300.book 24 ページ 2013年6月17日 月曜日 午後3時21分
QRG
Index
Safe DrivingTOC
2014 TSX Sport Wagon
Page 26 of 331
25
uu For Safe Driving u Your Vehicle’s Safety Features
For the safety of you and your passenger s, make a habit of checking these items
each time before you drive.
• After everyone has entered the vehicle, be sure all doors and the tailgate are
closed and locked. Locking the doors and the tailgate helps prevent an
occupant from being ejected and an outsider from unexpectedly opening a
door or the tailgate.
2 Locking/Unlocking the Doors from the Inside P. 91
•Adjust your seat to a position suitable for driving. Be sure the front seats
are adjusted as far to the rear as possible while allowing the driver to control
the vehicle. Sitting too close to a front airbag can result in serious or fatal
injury in a crash.
2 Adjusting the Seats P. 119
• Adjust head restraints to the proper position. Head res traints are most effective
when the center of the head restraint ali gns with the center of your head. Taller
persons should adjust their head restraint to the highest position.
2 Adjusting the Head Restraints P. 121
•Always wear your seat belt, and make sure you wear it properly. Confirm that any
passengers are properly belted as well.
2 Fastening a Seat Belt P. 29
• Protect children by using seat belts or child seats according to a child’s age, height
and weight.
2 Child Safety P. 49
■Safety Checklist1Safety Checklist
If the door and tailgate open indicator is on, a door
and/or the tailgate is not co mpletely closed. Close all
doors and the tailgate tightly until the indicator goes
off. 2 Door and Tailgate Open Indicator P. 68
14 ACURA TSX 5D-31TL76300.book 25 ページ 2013年6月17日 月曜日 午後3時21分
QRG
Index
Safe DrivingTOC
2014 TSX Sport Wagon
Page 27 of 331
26
Seat Belts
About Your Seat Belts
Seat belts are the single most effective safety device because they keep you
connected to the vehicle so that you ca n take advantage of many built-in safety
features. They also help keep you from being thrown against the inside of the
vehicle, against other passengers, or out of the vehicle. When worn properly, seat
belts also keep your body properly position ed in a crash so that you can take full
advantage of the additional prot ection provided by the airbags.
In addition, seat belts help protect you in almost every type of crash, including:
- fro
ntal impacts
- side impacts
- rear impacts
- rollovers
■Lap/shoulder seat belts
All five seating positions are equipped with lap/shoulder seat belts with emergency
locking retractors. In normal driving the retractor lets you move freely while keeping
some tension on the belt. During a collision or sudden stop the retractor locks to
restrain your body. The rear seat belts also have a lockable retractor for use with
child seats.
2 Installing a Ch ild Seat with a Lap/Shoulder Seat Belt P. 56
1About Your Seat Belts
Seat belts cannot completely protect you in every
crash. But in most cases, seat belts can reduce your
risk of serious injury.
Most states and all Canadian provinces and territories
require you to wear seat belts.
3 WARNING
Not wearing a seat belt properly increases
the chance of serious injury or death in a
crash, even though your vehicle has
airbags.
Be sure you and your passengers always
wear seat belts and wear them properly.
14 ACURA TSX 5D-31TL76300.book 26 ページ 2013年6月17日 月曜日 午後3時21分
QRG
Index
Safe DrivingTOC
2014 TSX Sport Wagon
Page 28 of 331
Continued27
uu Seat Belts u About Your Seat Belts
■Proper use of seat belts
Follow these guidelines for proper use:
• All occupants should sit upright, well back in the seat, and remain in that position
for the duration of the trip . Slouching and leaning reduc e the effectiveness of the
belt and can increase the chance of serious injury in a crash.
• Never place the shoulder part of a lap/shoulder seat belt under your arm or
behind your back. This could cause very serious injuries in a crash.
• Two people should never use the same seat belt. If they do, they could be very
seriously injured in a crash.
• Do not put any accessories on the seat belts. Devices intended to improve comfort
or reposition the shoulder part of a seat belt can reduce the protective capability
and increase the chance of serious injury in a crash.
Your vehicle monitors front seat belt use. If
the ignition switch is turned to ON
(w
before
the driver’s seat belt is fastened, the beeper
will sound and the indicator will blink. If the
driver does not fasten the belt before the
beeper stops, the indicator will remain on.
The beeper will also periodically sound and
the indicator will blink while driving until
the driver’s and front passenger’s seat belts
are fastened.
■Seat Belt Reminder
1About Your Seat Belts
If a rear seat passenge r moves around and extends
the seat belt, the lockable retractor may activate. If
this happens, release the re tractor by unfastening the
seat belt and allow the belt to retract completely.
Then refasten the belt.
1 Seat Belt Reminder
The indicator will also come on if a front passenger
does not fasten their seat be lt within six seconds after
the ignition switch is turned to ON
(w
.
When no one is sitting in the front passenger’s seat,
or a child or small adult is riding there, the indicator
will not come on.
This is because the weight sensors in the seat cannot
detect their presence.
14 ACURA TSX 5D-31TL76300.book 27 ページ 2013年6月17日 月曜日 午後3時21分
QRG
Index
Safe DrivingTOC
2014 TSX Sport Wagon
Page 29 of 331
uu Seat Belts u About Your Seat Belts
28
The front seats are equipped with automatic seat belt tensioners to enhance safety.
The tensioners automatically tighten the front seat belts during a moderate-to-
severe frontal collision, so metimes even if the collisio n is not severe enough to
inflate the front airbags.
■Automatic Seat Belt Tensioners1Automatic Seat Belt Tensioners
The seat belt tensioners can only operate once.
If a tensioner is activated, the SRS indicator will come
on. Have a dealer replace the tensioner and
thoroughly inspect the seat belt system as it may not
offer protection in a subsequent crash.
During a moderate-to-severe side impact, the
tensioner on that side of the vehicle also activates.
14 ACURA TSX 5D-31TL76300.book 28 ページ 2013年6月17日 月曜日 午後3時21分
QRG
Index
Safe DrivingTOC
2014 TSX Sport Wagon
Page 30 of 331
29
uu Seat Belts u Fastening a Seat Belt
Continued
Fastening a Seat Belt
After adjusting a front seat to the proper position, and while sitting upright and well
back in the seat:
2 Adjusting the Seats P. 119
1. Pull the seat belt out slowly.
2. Insert the latch plate into the buckle,
then tug on the belt to make sure the
buckle is secure.
u Make sure that the belt is not twisted or
caught on anything.
1Fastening a Seat Belt
No one should sit in a seat with an inoperative seat
belt or one that does not appear to be working
correctly. Using a seat belt that is not working
properly may not protect the occupant in a crash.
Have a dealer check the belt as soon as possible.
Never insert any foreign objects into the buckle or
retractor mechanism.
Pull out slowly.
Correct
Seated
Posture.
Latch
Plate
Buckle
14 ACURA TSX 5D-31TL76300.book 29 ページ 2013年6月17日 月曜日 午後3時21分
QRG
Index
Safe DrivingTOC
2014 TSX Sport Wagon
