Quick Reference Guide15
Handling the Unexpected
(P275)
Flat Tire
(P277)
●Park in a safe location and replace the
flat tire with the compact spare tire
located under the cargo area.
Indicators Come On
(P292)
●Identify the indicator and consult the
owner’s manual.
Engine Won’t Start
(P284)
●If the battery is dead, jump start using a
booster battery.
Blown Fuse
(P300)
●Check for a blown fuse if an electrical
device does not operate.
Overheating
(P290)
●Park in a safe location. If you do not see
steam under the hood, open the hood,
and let the engine cool down.
Emergency Towing
(P301)
●Call a professional towing service if you
need to tow your vehicle.

80
uuIndicatorsuMulti-Information Display Warning and Information Messages
Instrument Panel
Message
Condition
Explanation
●Appears when the scheduled maintenance is due soon.●Consequently, SERVICE DUE NOW and SERVICE
PAST DUE follow.
2Maintenance Minder Messages on the Multi-
Information Display P. 232
●Appears when the engine coolant temperature gets
abnormally high.
2Overheating P. 290
●Appears when the starting system has a problem.
●As a temporary measure, press and hold the ENGINE
START/STOP button for 15 seconds while depressing
the brake pedal and manually start the engine.
Have the vehicle checked by a dealer.

221
Continued
Driving
RefuelingFuel Information■Fuel recommendation
Your vehicle is designed to operate on premium unleaded gasoline with pump
octane of 91 or higher. If this octane grade is unavailable, regular unleaded gasoline
with a pump octane of 87 or higher may be used temporally.
The use of regular unleaded gasoline can cause metallic knocking noises in the
engine and will result in decreased engine performance. The long-term use of
regular-grade gasoline can lead to engine damage.■Top tier detergent gasoline
Because the level of detergency and additives in gasoline vary in the market, Honda
endorses the use of “TOP TIER Detergent Gasoline” where available to help
maintain the performance and reliability of your vehicle. TOP TIER Detergent
Gasoline meets a new gasoline standard jointly established by leading automotive
manufacturers to meet the needs of today’s advanced engines.■Gasoline containing ethanol
Some gasoline today is blended with oxygenates such as ethanol. Your vehicle is
designed to operate on oxygenated gasoline containing up to 10% ethanol by
volume. Do not use gasoline containing methanol. If you notice any undesirable
operating symptoms, try another service station or switch to another brand of
gasoline.Premium Unleaded premium gasoline, pump octane number 91 or higher
1Fuel InformationNOTICEWe recommend quality gasoline containing
detergent additives that help prevent fuel system and
engine deposits. In addition, in order to maintain
good performance, fuel economy, and emissions
control, we strongly recommend the use of gasoline
that does NOT contain harmful manganese-based
fuel additives such as MMT, if such gasoline is
available.
Use of gasoline with these additives may adversely
affect performance, and cause the malfunction
indicator lamp on your instrument panel to come on.
If this happens, contact a dealer for service.

227
Maintenance
This chapter discusses basic maintenance.
Before Performing Maintenance
Inspection and Maintenance ............ 228Safety When Performing Maintenance..... 229Parts and Fluids Used in Maintenance
Service ........................................... 230
Maintenance Minder
TM..................... 231
Maintenance Under the Hood
Maintenance Items Under the Hood ..... 235Opening the Hood ........................... 236
Engine Compartment Covers ........... 237
Recommended Engine Oil ................ 238
Oil Check ......................................... 239
Adding Engine Oil ............................ 240
Changing the Engine Oil and Oil Filter ..... 241Engine Coolant ................................ 243
Transmission Fluid ............................ 245
Brake Fluid ....................................... 246
Power Steering Fluid Check.............. 247
Refilling Window Washer Fluid......... 248
Replacing Light Bulbs....................... 249Checking and Maintaining Wiper
Blades.......................................... 256Checking and Maintaining Tires
Checking Tires ................................. 258Tire and Loading Information Label ...... 259Tire Labeling .................................... 259
DOT Tire Quality Grading (U.S. Vehicles) ...... 261Wear Indicators ............................... 263
Tire Service Life ................................ 263
Tire and Wheel Replacement ........... 264
Tire Rotation .................................... 265
Winter Tires ..................................... 266
Battery............................................... 267
Remote Transmitter Care................. 268Climate Control System Maintenance
..... 269
Cleaning
Interior Care .................................... 270
Exterior Care.................................... 272

232
uuMaintenance Minder
TMuTo Use Maintenance Minder
TM
Maintenance
The system message indicator ( ) comes on along with the Maintenance Minder message.■Maintenance Minder Messages on the Multi-Information
DisplayMaintenance Message
Oil Life Display
Explanation
Information
SERVICE DUE SOON
15%
The remaining engine oil life is 15 to
6 percent. Once you switch the
display by pressing the
(information) button, this message
will go off.
The engine oil is approaching the end
of its service life, and the maintenance
items should be inspected and serviced
soon.
SERVICE DUE NOW
5%
The remaining engine oil life is 5 to 1
percent. Press the button
to switch to another display.
The engine oil has almost reached the
end of its service life, and the
maintenance items should be inspected
and serviced as soon as possible.
SERVICE PAST DUE
Negative Distance
The remaining engine oil life has
passed its service life, and a negative
distance appears after driving over
10 miles (U.S. models) or 10 km
(Canadian models). Press the
button to switch to
another display.
The engine oil life has passed.
The maintenance items must be
inspected and serviced immediately.

233
uuMaintenance Minder
TMuTo Use Maintenance Minder
TM
Continued
Maintenance
■Maintenance Service Items
1Maintenance Service Items•Independent of the Maintenance Minder
information, replace the brake fluid every 3 years.•Inspect idle speed every 160,000 miles (256,000
km).•Adjust the valves during services A, B, 1, 2, or 3 if
they are noisy.
Maintenance Minder
Message System Message
Indicator
Sub Items Main
Item
*1: If the message SERVICE DUE NOW does not appear more than 12 months after the display is
reset, change the engine oil every year.
# : See information on maintenance and emissions warranty.
*2: If you drive in dusty conditions, replace the air cleaner element every 15,000 miles (24,000 km).
*3: If you drive primarily in urban areas that have high concentrations of soot in the air from industry and
from diesel-powered vehicles, replace the dust and pollen filter every 15,000 miles (24,000 km).CODE
Maintenance Main Items
A
●Replace engine oil
*1
B
●Replace engine oil
*1 and oil filter
●Inspect front and rear brakes●Check parking brake adjustment●Inspect these items:
•Tie rod ends, steering gear box, and boots
•Suspension components
•Driveshaft boots
•Brake hoses and lines (Including ABS/VSA)
•All fluid levels and condition of fluids
•Exhaust system
#
•Fuel lines and connections
#
*4: If you regularly drive in very high (over 110 °F, 43 °C) or very low (-20 °F, -29 °C) temperatures, or
regularly tow a trailer, replace every 60,000 miles/100,000 km.
*5: Driving in mountainous areas at very low vehicle speeds or trailer towing results in higher level of
mechanical (shear) stress to fluid. This requires differential fluid changes more frequently than
recommended by the Maintenance Minder. If you regularly drive your vehicle under these conditions,
have the differential fluid changed at 7,500 miles/12,000 km, then every 15,000 miles/24,000 km.CODE
Maintenance Sub Items
1
●Rotate tires
2
●Replace air cleaner element
*2
●Replace dust and pollen filter
*3
●Inspect drive belt
3●Replace transmission and transfer fluid
4
●Replace spark plugs●Replace timing belt and inspect water pump
*4
●Inspect valve clearance
5●Replace engine coolant
6
●Replace rear differential fluid
*5

263
uuChecking and Maintaining TiresuWear Indicators
Maintenance
Wear Indicators
The groove where the wear indicator is
located is 1/16 inch (1.6 mm) shallower than
elsewhere on the tire. If the tread has worn so
that the indicator is exposed, replace the tire.
Worn out tires have poor traction on wet
roads.
Tire Service LifeThe life of your tires is dependent on many factors, including driving habits, road
conditions, vehicle loading, inflation pressure, maintenance history, speed, and
environmental conditions (even when the tires are not in use).
In addition to regular inspections and inflation pressure maintenance, it is
recommended that you have annual inspections performed once the tires reach five
years old. All tires, including the spare, should be removed from service after 10
years from the date of manufacture, regardless of their condition or state of wear.
Example of a Wear
Indicator mark

317Index
Bulb Specifications................................... 306CCarbon Monoxide Gas............................... 63
Cargo Hooks............................................. 159
Carrying Cargo................................. 173, 175
Certification Label................................... 307
Changing Bulbs........................................ 249
Charging System Indicator................ 67, 292
Child Safety................................................ 49
Childproof Door Locks ............................ 114
Child Seat................................................... 49
Booster Seats ............................................ 62
Child Seat for Infants ................................ 51
Child Seat for Small Children .................... 52
Installing a Child Seat with a Lap/
Shoulder Seat Belt ................................... 57
Larger Children ......................................... 61
Rear-facing Child Seat............................... 51
Selecting a Child Seat ............................... 53
Using a Tether .......................................... 59
Childproof Door Locks............................. 114
Cleaning the Exterior............................... 272
Cleaning the Interior............................... 270
Client Service Information....................... 315
Climate Control System........................... 163
Changing the Mode................................ 163
Defrosting the Windshield and
Windows .............................................. 164
Dust and Pollen Filter .............................. 269Recirculation/Fresh Air Mode ................... 163
Sensor ..................................................... 166
Synchronized Mode ................................. 165
Using Automatic Climate Control ............ 163
Clock.............................................................. 9
Coat Hook................................................. 159
Compact Spare Tire.......................... 277, 306
Console Compartment............................. 155
Controls..................................................... 105
Coolant (Engine)....................................... 243
Adding to the Radiator ............................ 244
Adding to the Reserve Tank ..................... 243
Overheating ............................................ 290
Temperature Gauge .................................. 86
Creeping.................................................... 188
Cruise Control........................................... 193
Indicator .................................................... 75
Cup Holders.............................................. 157
Customized Features.................................. 92
DDaytime Running Lights........................... 134
Dead Battery............................................. 287
Devices that Emit Radio Waves............... 308
Dimming
Headlights ............................................... 132
Rearview Mirror ....................................... 142
Dipstick (Engine Oil)................................. 239
Directional Signals (Turn Signal)............. 132
Door Mirrors............................................. 143Doors......................................................... 106
Auto Door Locking .................................. 115
Auto Door Unlocking .............................. 115
Door and Tailgate Open Indicator ........ 26, 71
Keys ........................................................ 106
Locking/Unlocking the Doors
from the Inside ...................................... 113
Locking/Unlocking the Doors
from the Outside ................................... 108
Lockout Prevention System ...................... 111
DOT Tire Quality Grading........................ 261
Driving...................................................... 171
Automatic Transmission .......................... 188
Braking ................................................... 212
Cruise Control ......................................... 193
Shifting Gear ........................................... 189
Starting the Engine.................................. 185
Driving Position Memory System............ 139
Dust and Pollen Filter............................... 269
EElapsed Time............................................... 90
Electronic Stability Control (ESC)............. 202
Emergency................................................ 301
Emissions Testing (Readiness Codes)....... 310
Engine....................................................... 307
Coolant ................................................... 243
Jump Starting .......................................... 287
Oil ........................................................... 238
Starting ................................................... 185

320Index
MMaintenance............................................. 227
Battery..................................................... 267
Brake ....................................................... 246
Cleaning .................................................. 270
Climate Control ....................................... 269
Coolant ................................................... 243
Maintenance Minder
TM............................ 231
Oil ........................................................... 239
Precautions .............................................. 228
Radiator................................................... 244
Remote Transmitter ................................. 268
Replacing Light Bulbs ............................... 249
Safety ...................................................... 229
Service Items............................................ 233
Tires ........................................................ 258
Transmission Fluid.................................... 245
Under the Hood....................................... 235
Malfunction Indicator Lamp.............. 67, 293
Map Lights................................................ 153
Maximum Load Limit................................ 175
Meters, Gauges........................................... 86
Mirrors....................................................... 142
Adjusting ................................................. 142
Door ........................................................ 143
Exterior .................................................... 143
Interior Rearview...................................... 142
Modifications (and Accessories)............... 225
Multi-Information Display.......................... 87
NNumbers (Identification).......................... 307OOdometer................................................... 88
Oil (Engine)............................................... 238
Adding .................................................... 240
Checking................................................. 239
Displaying Oil Life .................................... 231
Low Oil Pressure Indicator ................. 66, 292
Recommended Engine Oil ....................... 238
Viscosity .................................................. 238
Opening/Closing
Hood....................................................... 236
Panoramic Glass Roof .............................. 128
Power Windows ...................................... 125
Tailgate ........................................... 116, 303
Outside Temperature Display.................... 89
Overheating.............................................. 290PPaddle Shifters (Sequential Shift
Mode)...................................................... 191
Panic Mode............................................... 124
Panoramic Glass Roof............................... 128
Parking...................................................... 216
Parking Brake........................................... 212
Parking Brake and Brake System
Indicator............................................ 66, 294Parking Sensor System............................. 217
Passenger Airbag Off Indicator................. 46
Passing Indicators..................................... 132
Power Windows....................................... 125
Precautions While Driving....................... 187
Rain ........................................................ 187
Pregnant Women....................................... 32
Puncture (Tire)......................................... 277
RRadiator.................................................... 244
Range.......................................................... 90
Readiness Codes (Emissions Testing)...... 310
Rear Defogger/Heated Door Mirror
Button..................................................... 138
Rear Seat Heaters..................................... 162
Rear Seats (Folding Down)...................... 150
Rearview Mirror....................................... 142
Rearview Mirror with Rearview Camera
Display.................................................... 220
Refueling.................................................. 221
Fuel Gauge ............................................... 86
Gasoline ......................................... 221, 306
Low Fuel Indicator..................................... 69
Regulations.............................. 210, 261, 308
Remote Transmitter................................. 108
