Page 234 of 324
233
uuMaintenance Minder
TMuTo Use Maintenance Minder
TM
Continued
Maintenance
■Maintenance Service Items
1Maintenance Service Items•Independent of the Maintenance Minder
information, replace the brake fluid every 3 years.•Inspect idle speed every 160,000 miles (256,000
km).•Adjust the valves during services A, B, 1, 2, or 3 if
they are noisy.
Maintenance Minder
Message System Message
Indicator
Sub Items Main
Item
*1: If the message SERVICE DUE NOW does not appear more than 12 months after the display is
reset, change the engine oil every year.
# : See information on maintenance and emissions warranty.
*2: If you drive in dusty conditions, replace the air cleaner element every 15,000 miles (24,000 km).
*3: If you drive primarily in urban areas that have high concentrations of soot in the air from industry and
from diesel-powered vehicles, replace the dust and pollen filter every 15,000 miles (24,000 km).CODE
Maintenance Main Items
A
●Replace engine oil
*1
B
●Replace engine oil
*1 and oil filter
●Inspect front and rear brakes●Check parking brake adjustment●Inspect these items:
•Tie rod ends, steering gear box, and boots
•Suspension components
•Driveshaft boots
•Brake hoses and lines (Including ABS/VSA)
•All fluid levels and condition of fluids
•Exhaust system
#
•Fuel lines and connections
#
*4: If you regularly drive in very high (over 110 °F, 43 °C) or very low (-20 °F, -29 °C) temperatures, or
regularly tow a trailer, replace every 60,000 miles/100,000 km.
*5: Driving in mountainous areas at very low vehicle speeds or trailer towing results in higher level of
mechanical (shear) stress to fluid. This requires differential fluid changes more frequently than
recommended by the Maintenance Minder. If you regularly drive your vehicle under these conditions,
have the differential fluid changed at 7,500 miles/12,000 km, then every 15,000 miles/24,000 km.CODE
Maintenance Sub Items
1
●Rotate tires
2
●Replace air cleaner element
*2
●Replace dust and pollen filter
*3
●Inspect drive belt
3●Replace transmission and transfer fluid
4
●Replace spark plugs●Replace timing belt and inspect water pump
*4
●Inspect valve clearance
5●Replace engine coolant
6
●Replace rear differential fluid
*5
Page 322 of 324
321Index
Replacement
Battery .................................................... 268
Bulbs ...................................................... 249
Fuses ...................................................... 295
Tires........................................................ 264
Wiper Blade Rubber ................................ 256
Reporting Safety Defects......................... 309
Resetting a Trip Meter............................... 89
Reverse Tilt Door Mirror.......................... 143SSafe Driving................................................ 21
Safety Check............................................... 26
Safety Labels.............................................. 64
Safety Message.......................................... 19
Seat Belts.................................................... 27
Adjusting the Shoulder Anchor ................. 31
Automatic Seat Belt Tensioners ................. 29
Checking .................................................. 33
Fastening .................................................. 30
Installing a Child Seat with a Lap/
Shoulder Seat Belt ................................... 57
Pregnant Women...................................... 32
Reminder .................................................. 28
Warning Indicator ............................... 28, 69
Seat Heaters..................................... 161, 162
Seats.......................................................... 144
Adjusting ................................................ 144
Front Seats.............................................. 144
Rear Seats ............................................... 150Seat Heaters .................................... 161, 162
Security System......................................... 122
Immobilizer System Indicator ..................... 74
Security System Alarm Indicator ................. 75
SEL/RESET Button........................................ 87
Select Lever......................................... 12, 189
Operation .......................... 12, 190, 191, 192
Releasing ................................................. 289
Won’t Move ............................................ 289
Selecting a Child Seat................................. 53
Sequential Shift Mode............................. 191
Setting the Clock.......................................... 9
SH-AWD®................................................... 204
Indicator .................................................... 76
Shift Lever........................................... 12, 189
Shift Position Indicator....................... 68, 190
Shifting...................................................... 189
Shoulder Anchor......................................... 31
Side Airbags................................................ 41
Cutoff System ........................................... 43
Off Indicator .............................................. 43
Side Curtain Airbags................................... 44
Side Storage Compartment..................... 156
Snow Tires................................................. 266
Spare Tire.......................................... 277, 306
Spark Plugs................................................ 306
Specifications............................................ 306
Specified Fuel.................................... 221, 306
Speedometer.............................................. 86
SRS Airbags (Airbags)................................. 37Starting the Engine.................................. 185
Does Not Start......................................... 284
Jump Starting .......................................... 287
Steering Wheel......................................... 141
Adjusting ................................................ 141
Stopping................................................... 216
Super Handling-All Wheel Drive
TM (SH-AWD®)
System..................................................... 204
Supplemental Restraint System (SRS)........ 37
Switches (Around the Steering
Wheel)............................................. 2, 3, 129
SYNC Mode............................................... 165
System Message Indicator.......................... 72
TTachometer................................................. 86
Tailgate..................................................... 116
Unable to Open....................................... 303
Temperature
Outside Temperature Display ..................... 89
Temperature Sensor................................. 166
Time (Setting)............................................... 9
Tire Pressure Monitoring System
(TPMS)..................................................... 208
Indicator............................................ 72, 294
