IN AN EMERGENCY
219
IN THE EVENT
OF AN ACCIDENT
– It is important to keep calm.
– If you are not directly involved, stop at
least a few dozen metres away from the ac-
cident.
– On motorways, stop without blocking
the emergency lane.
– Turn the engine off and the hazard warn-
ing lights on.
– At night, illuminate the place of the ac-
cident with the headlights.
– Take care, do not risk being run over.– Signal the accident placing the triangle
at regulation distance in a clearly visible
place.
– Call the emergency organisation, giving
the most accurate information possible. On
motorways use the special phones provid-
ed.
– In motorway pileups, especially with
poor visibility, the risk of being involved in
other crashes is high. Leave the car imme-
diately and go beyond the guard-rail.
– If the doors are blocked, do not try to
get out of the car breaking the windscreen
which is stratified. The windows and rear
screen are easier to break.
– Remove the ignition key of the vehi-
cles involved.– If you note a smell of fuel or other chem-
ical products, do not smoke and have ciga-
rettes stubbed out.
– To put out fires, even small ones, use
the extinguisher, blankets, sand, or earth.
Never use water.
– If use of the lighting system is not nec-
essary, disconnect the battery negative ter-
minal (–).

IN AN EMERGENCY
220
IF PEOPLE ARE INJURED
– An injured person must never be aban-
doned. Helping is compulsory also for per-
sons not directly involved in the accident.
– Do not crowd around injured people.
– Reassure the injured person that help
is on the way, and stay near to overcome
any panic.
– Release or cut the seat belt restraining
injured persons.
– Do not give injured persons anything
to drink.
– An injured person should never be
moved except in the following circum-
stances.
– Remove an injured person from the car
only in danger of fire, sinking or falling.
When removing an injured person: do not
pull the limbs or bend the head and keep
the body as horizontal as possible.
FIRST AID KIT
It is advisable to have also a fire extin-
guisher and a blanket besides the first-aid
kit.

VEHICLE MAINTENANCE
221
It is however wise to remember that Pro-
grammed Maintenance does not complete-
ly cover all the car’s requirements: also in
the initial period before the 20,000 km ser-
vice coupon and later, between one coupon
and another, ordinary care is still necessary
such as for example routinely checking and
topping up the level of fluids, checking the
tyre pressure, etc...
IMPORTANTThe Programmed Mainte-
nance coupons are specified by the Manu-
facturer. The failure to have them carried out
may invalidate the warranty.
The Programmed Maintenance service is
carried out by all Alfa Romeo Authorised Ser-
vices, at pre-established times.If during each operation, in addition to the
ones programmed, the need arises for fur-
ther replacements or repairs, these may be
carried out only with the explicit agreement
of the customer.
IMPORTANTYou are advised to contact
Alfa Romeo Authorised Services in the event
of any minor operating faults, without wait-
ing for the next service coupon. SCHEDULED
SERVICING
Correct maintenance is determinate in en-
suring long vehicle life under the best con-
ditions.
This is why Alfa Romeo has programmed
a series of checks and maintenance opera-
tions every 20,000 km.
IMPORTANTOn versions fitted with re-
configurable multifunction display, at 2000
km from the maintenance deadline, the dis-
play will show “REFER TO SERVICE MANU-
AL” which is shown again turning the igni-
tion key to MAR, every 200 km. For fur-
ther details, see “Service” in the “Recon-
figurable multifunction display” paragraph.
V V
E E
H H
I I
C C
L L
E E
M M
A A
I I
N N
T T
E E
N N
A A
N N
C C
E E

●●●●●●●●●
●●●●●●●●●
●●●●●●●●●
●●●●●●●●●
●●●●●●●●●
●●●●
●●●●●●●●●
●●●●●●●●●
●●
●●●●
●●
●●●●
●●●●●●●●●
●●●●●●●●●
●●
VEHICLE MAINTENANCE
222
SCHEDULED MAINTENANCE PROGRAMME
20 40 60 80 100 120 140 160 180Thousands of km
Check tyre conditions/wear and adjust pressure if necessary
Check operation of lighting system (headlights, direction indicators, hazard
warning lights, boot, passenger compartment, glovebox lights, warning lights, etc..)
Check operation of windscreen washer system, adjust spray jets
Check position/wear of windscreen/rearscreen wiper blades
Check operation of front disk brake pad wear indicator
Check wear conditions of rear disk brake pads
Sight check the conditions of: body exterior, underbody protection, stiff pipes and
hoses (exhaust - fuel supply - brakes), rubber parts (boots - sleeves - bushes etc..)
Check for bonnet and boot lock cleanness, lever cleanness and lubrication
Sight check for accessory poly-V drive belt
Check handbrake lever stroke adjustment
Check antievaporation system
Change air cleaner cartridge
Top up fluid levels (engine coolant, brakes, windscreen washer, battery, etc..)
Check and if necessary top up the Selespeed automatic transmission oil level
Sight check for conditions of timing gear drive toothed belt

VEHICLE MAINTENANCE
223
20 40 60 80 100 120 140 160 180Thousands of km
Change timing gear drive belt (*)
Change accessory Poly-V drive belt
Change spark plugs
Check operation of engine control system (through diagnosis socket)
Check mechanical transmission and differential oil level
Change engine oil
Change engine oil filter
Change brake fluid (or every 2 years)
Change pollen filer (or once a year)
Check emissions/smoke at the exhaust
●
●
●●●
●●●●
●●
●●●●●●●●●
●●●●●●●●●
●●●
●●●●●●●●●
●●●●
(*) Or every 3 years for harsh conditions (cold climates, city driving or prolonged lengths of time at idle speed, dusty areas)
Or every 5 years, regardless of mileage.

VEHICLE MAINTENANCE
224
ADDITIONAL
OPERATIONS
Every 1000 kmor before long journeys,
check and if necessary top up:
– engine coolant fluid level
– brake/hydraulic clutch control fluid level
– power steering fluid level
– windscreen/rearscreen and headlamp
washer fluid level
– tyre pressure and conditions.
Every 3000 kmcheck and if necessary
top up the engine oil level.
The use of products of the FL Seleniais
recommended which have been designed
and made expressly for Alfa Romeo cars
(see “Refuelling” in the “Technical Specifi-
cations” chapter).
ANNUAL INSPECTION
PROGRAMME
For cars with an annual mileage
of below 20,000 km (for example
about 10,000 km) the following
yearly inspection programme is ad-
vised:
– Check tyre conditions/wear and if nec-
essary adjust the pressure
– Check operation of lighting system
(headlights, direction indicators, hazard
warning lights, boot, passenger compart-
ment, glovebox lights, warning lights )
– Check operation of windscreen wiper
system, spray jet adjustment
– Check position/wear of windscreen/
rearscreen wiper blades
– Check front disk brake pad conditions
and wear
– Check for bonnet and boot lock clean-
ness, lever cleanness and lubrication– Sight check for conditions of: engine,
gearbox, transmission, pipes (exhaust - fu-
el supply - brakes) rubber parts (boots -
sleeves - bushes etc..), brake and fuel sup-
ply system hoses
– Check battery charge
– Sight check for conditions of various dri-
ve belts
– Check and if necessary top up fluid lev-
els (engine coolant, brakes, windscreen
washer, battery, etc...)
– Change engine oil
– Change engine oil filter
– Change pollen filter.

VEHICLE MAINTENANCE
225
IMPORTANT
Engine oil
Should prevailing use of the car be under
one of the following specially heavy condi-
tions:
– trailer or caravan towing
– dusty roads
– frequently idling engines or long distance
low speed driving or in case of a long term
inactivity
– short distances (less than 7-8 km) re-
peated and with external temperatures be-
low zero replace engine oil more frequent-
ly than required on Service Schedule.
IMPORTANT
Air cleaner
Using the car on dusty roads change the
air cleaner more frequently than specified in
the Scheduled Maintenance Programme.
For any doubts concerning the intervals be-
tween engine oil and air cleaner replacement
in relation to how the vehicle is used, con-
tact Alfa Romeo Authorised Services.IMPORTANT
Battery
It is advisable to check the battery charge,
preferably at the onset of winter, to prevent
the possibility of the electrolyte freezing.
This check should be carried out more fre-
quently if the car is used mainly for short
trips, or if it is fitted with accessories that
permanently absorb electricity even with the
ignition key removed, especially in the case
of after market accessories.
If the vehicle is used in hot climates or par-
ticularly harsh conditions it is wise to check
the level of the battery fluid (electrolyte)
more frequently than specified in the Sched-
uled Maintenance Programme.Vehicle maintenance should
be entrusted to Alfa Romeo
Authorised Services. For
routine and minor maintenance op-
erations you wish to carry out your-
self, always make sure you have the
proper equipment, genuine Alfa
Romeo spares and the necessary flu-
ids;do not however carry out these
operations if you have no experi-
ence.IMPORTANT
Pollen filter
If the vehicle is used frequently in dusty or
heavily polluted environments it is advisable
to replace the filtering element more fre-
quently; in particular it should be replaced
if a reduction of the amount of air admitted
to the passenger compartment is noted.

VEHICLE MAINTENANCE
226
A0A0405m
fig. 1
CHECKING LEVELS
1Engine oil - 2Battery - 3Brake fluid - 4Power steering fluid - 5Windscreen/rearscreen/head-
lamp washer fluid - 6Engine coolant fluid When topping up take
care not to confuse the var-
ious types of fluids: they
are all incompatible with one an-
other and could seriously damage
the vehicle.
Never smoke while work-
ing in the engine compart-
ment; gas and inflammable vapours
may be present, with the risk of
fire.
WARNING

VEHICLE MAINTENANCE
227
Used engine oil and filter
contain harmful substances
for the environment. Con-
tact Alfa Romeo Authorised Ser-
vices, to have the oil and filter
changed as they are equipped to
dispose of the waste oil and filters
respecting nature and the law.
ENGINE OIL (fig. 3)
The engine oil should be checked with the
vehicle on a level surface a few minutes
(about 5) after the engine has been
switched off.
Remove the dipstick (A) clean it, put it
back in completely, remove it and check that
the level is within the MINandMAX
marks on the dipstick. The interval between
theMINandMAXmarks corresponds to
about one litre of oil.If the oil level is near or even below the
MINmark, add oil through the filler neck
(B), until reaching the MAXmark.
IMPORTANTIf a routine check reveals
that the level is above the MAXmark, con-
tact Alfa Romeo Authorised Services to have
the correct level restored.
IMPORTANTAfter topping up the oil,
before checking the level again, run the en-
gine a few seconds and wait for a few min-
utes after stopping it.Engine oil consumption
Max engine oil consumption is usually 400
grams every 1000 km.
During the initial period of use the engine
settles, therefore engine oil consumption
may be considered stabilised only after the
first 5000 ÷ 6000 km.
IMPORTANTEngine oil consumption de-
pends on the way of driving and the condi-
tions of use of the vehicle.
fig. 3
A0A0406m
Do not add oil with spec-
ifications (classification,
viscosity) other than those
of the oil already in the engine.
When the engine is hot,
take care when working
inside the engine compartment to
avoid burns. Remember that when
the engine is hot, the fan may cut
in: danger of injury.
WARNING

VEHICLE MAINTENANCE
228
SELESPEED TRANSMISSION
OIL
(fig. 4)
The Selespeed transmission oil should be
checked with the vehicle on a level surface
and with the engine stopped and cold.
To check the level, proceed as follows:
– turn the ignition key to MAR;
– disconnect the breather tube and re-
move the cap (A) checking that the level
corresponds with the MAXmark on the dip-
stick integrated with the cap;– if the oil is below the MAXmark, top
up to reach the correct level;
– after refitting the cap, insert the breather
tube firmly on the housing on the cap and
turn the ignition key to STOP.
Used gearbox oil contains
dangerous substances for
the environment. For chang-
ing the oil we advise contacting Al-
fa Romeo Authorised Services who
are equipped for disposing of used
oil respecting nature and the law.Do not add oil with spec-
ifications other than that
already in the gearbox.
fig. 4
A0A00197m
Be very careful working in-
side the engine compart-
ment if the engine is hot: danger of
burns. Remember that the fan may
cut in if the engine is very hot: dan-
ger of injury.
WARNING
