Alfa Romeo 159 2005 Owner handbook (in English)

N N
O O
T T
E E
S S

Always ask your mechanic for
®
®

The engine of your car is factory filled with Selenia,
This is an engine oil range which satisfies the most advanced
international specifications. Its superior technical characteristics
allowSeleniato guarantee the highest performanceand
protectionof your engine.
For further information on Selenia products visit the web site www.flselenia.com. The range also includes Selenia 20K, Selenia Performer 5W-30 e 5W-40, Selenia Digitech.
Your car is factory filled with Selenia
SELENIA 20K ALFA ROMEO
API SL Lubricant which guarantees maximum
wear protection and performance of
aspirated, turbocharged and multivalve engines.
Specific Selenia formulation for Alfa Romeo.
SELENIA RACING
This lubricant has been developed as a result of
Selenia's extensive experience in track and rally
competitions,it maximises engine performance
in all kinds of competition use.SELENIA TD
Oil for aspirated and turbocharged and multivalve
diesel engines, guarantees excellent engine cleanliness
and stability even at very high temperatures.
SELENIA WR
Oil spccifically designed for common rail Multijet engines.
Particularly effective during cold starts, it guaranteed
maximum wear protection and hydraulc tappets control,
reduction in consumption and stabitlity at high temperatures.
The Selenia range includes a number of technologically advanced products:

ENGINE OIL REPLEACEMENT (litres)
REFUELLING (litres)
AFTER SALESASSISTENZA TECNICA - INGEGNERIA ASSISTENZIALE
Viale Alfa Romeo 20020 Arese (MI) - Italia
Fiat Auto S.p.A.
Publication no. 60431392 - 1
stEdition - 05/2005All rights reserved. Reproduction, even in part is prohibited without written permission
from Fiat Auto S.p.A.
SERVICE
1.9 JTS - 2.2 JTS - 3.2 JTS 1.9 JTDM8v 2.4 JTDM1.9 JTDM16v
Lubrication system
engine5.4 4.6 6.4
Do not discard used oil in the environment.
COLD TYRE INFLATION PRESSURE
Tyres
205/55 R16 91V
front rear
2.3 2.3
2.6 2.6Tyres
215/55 R16 93V
front rear
2.3 2.3
2.6 2.6Tyres
225/50 R17 98W
front rear
2.5 2.5
2.7 2.7Tyres
235/45 R18 98W
front rear
2.7 2.5
2.8 2.6
Add +0.3 bar to the prescribed inflation pressure when the tyres are warm. Recheck pressure value with cold tyres.
With snow tyres, add +0.2 bar to the inflation pressure value prescribed for standard tyres.
Inflate tyres to full load pressures if driving at continuous speed exceeding 160 km/h.Space-saver
spare wheel
T125/80 R17
4.2
average load bar
full load bar
1.9 JTS - 2.2 JTS - 1.9 JTDM8v - 1.9 JTDM16v - 2.4 JTDM3.2 JTS
Fuel tank capacity 70 69
Reserve 10 10
For cars with petrol engine, only use unleaded petrol with over 95 R.O.N. (Specification EN228).
For cars with diesel engine only use Diesel fuel for motor vehicles (Specification EN590).

OWNER HANDBOOK
ENGLISH
Alfa Services
Cop Alfa Giulietta GB:Alfa 159 cop. LUM GB 21-01-2010 9:07 Pagina 1
