USERS FUSE AMPERE FIGURE
Climate control system fan (1.8 140 HP versions) F02 (MAXI-FUSE) 40 60
Climate control system fan (2.2 JTS Selespeed versions) F02 (MAXI-FUSE) 50 60
Electric steering lock F03 (MAXI-FUSE) 20 60
Brake branch point (pump) F04 (MAXI-FUSE) 40 60
Brake branch point (solenoid valve) (ABS version) F05 (MAXI-FUSE) 40 60
Brake branch point (solenoid valve) (VDC version) F05 (MAXI-FUSE) 20 60
Radiator fan (low speed) (1.8 140 HP, 2.2 JTS Selespeed versions)F06 (MAXI-FUSE) 40 60
Radiator fan (high speed) F07 (MAXI-FUSE) 50 60
Additional heater supply (passenger compartment water heating 300W)
(diesel versions) F08 30 60
Headlight washer F09 20 60
Horns F10 15 60
Climate control system compressor F19 7.5 60
Rear window heating F20 20 60
