Alfa Romeo Giulietta 2014 Owners Manual

PROTECTING THE
ENVIRONMENTThe following devices are used for
reducing petrol fuel engine emissions:
catalytic converter, oxygen sensors and
evaporation control system
The following devices are used for
reducing diesel fuel engine emissions:
oxidising catalytic converter, exhaust
gas recirculation system (EGR) and
particulate filter (DPF).
62)
DIESEL PARTICULATE
FILTER (DPF)
(Diesel Particulate Filter)
(for versions/markets, where provided)
The Diesel Particulate Filter is a
mechanical filter, integral to the exhaust
system, that physically traps carbon
particles present in the exhaust gases
of diesel engines.
The diesel particulate filter is needed to
eliminate almost all carbon particle
emissions in compliance with
current/future regulations and
standards.During standard use of the vehicle, the
engine control unit records a set of data
(e.g.: travel time, type of route,
temperatures, etc.) and it will then
calculate how much particulate has
been trapped by the filter.
Since this filter physically traps
particulate, it should be periodically
regenerated (cleaned) at regular
intervals by burning carbon particles.
The regeneration procedure is
controlled automatically by the engine
management control unit according
to the filter conditions and vehicle use
conditions.
During the regeneration there may be a
limited increase in the engine idle
speed, fan activation, a limited increase
in fumes and high temperatures at the
exhaust.
These are not faults; they do not impair
normal car performance or damage
the environment. If the dedicated
message is displayed, see contents of
"Warning lights and messages"
paragraph, in chapter "Knowing the
instrument panel".
WARNING
62) The catalytic converter and
particulate filter (DPF) reach very
high temperatures during
operation. Therefore do not park
the car on flammable materials
(e.g. grass, dry leaves, pine
needles, etc.): fire hazard.
87

88
This page is intentionally left blank

KNOWING THE INSTRUMENT PANEL
This section of the booklet gives you all
the information you need to
understand, interpret and use the
instrument panel correctly.DISPLAY ......................................... 90
MENU ITEMS .................................. 93
CONTROL PANEL AND
INSTRUMENTS ...............................100
TRIP COMPUTER ...........................102
WARNING LIGHTS AND
MESSAGES ...................................10
- LOW BRAKE FLUID/HANDBRAKE
ENGAGED .......................................... 106
- EBD FAILURE .................................. 107
- AIRBAG FAILURE ............................. 107
- SEAT BELTS NOT FASTENED .......... 107
- ALTERNATOR FAILURE ................... 108
- LOW ENGINE OIL PRESSURE ......... 1
-ENGINE OIL DETERIORATED ........... 110
- ENGINE COOLANT TEMPERATURE
TOO HIGH .......................................... 112
- ALFA TCT FAILURE .......................... 113
-INCOMPLETE DOOR LOCKING ........ 113
-SPEED LIMIT EXCEEDED ................. 113
- DUAL PINION ACTIVE STEERING
FAILURE ............................................. 114
- ALFA ROMEO CODE SYSTEM
FAILURE/ALARM FAILURE ................. 114
- FUEL RESERVE/LIMITED RANGE .... 115
- GENERAL FAILURE ......................... 116
- GENERAL FAILURE ......................... 117
-REAR FOG LIGHTS ........................... 11
- ABS FAILURE ................................... 119
-BRAKE PAD WEAR ........................... 119
- PASSENGER SIDE AIRBAG
DEACTIVATED .................................... 119
- INJECTION/EOBD SYSTEM
FAILURE ............................................. 120
- GLOW PLUG HEATING/GLOW
PLUG HEATING FAILURE (diesel
versions) ............................................. 121-WATER IN DIESEL FILTER (diesel
versions) ............................................. 121
- DPF CLEANING (particulate trap) in
progress (diesel versions with DPF
only) ................................................... 123
- iTPMS SYSTEM ............................... 125
- ELECTRONIC STABILITY CONTROL
(ESC) SYSTEM ................................... 126
- CRUISE CONTROL .......................... 127
- SIDE LIGHTS ................................... 127
- FOLLOW ME HOME ........................ 12
- DIPPED BEAM HEADLIGHTS .......... 127
- FOG LIGHTS .................................... 128
- LEFT-HAND DIRECTION
......................................... 128
- RIGHT-HAND DIRECTION
INDICATOR ........................................ 128
- MAIN BEAM HEADLIGHTS .............. 128
- FUEL CUT-OFF ................................ 12
- POSSIBLE ICE ON ROAD ................ 129
- BRAKE LIGHT FAILURE ................... 129
- DUSK SENSOR FAILURE ................. 129
- RAIN SENSOR FAILURE .................. 130
- PARKING SENSOR FAILURE ........... 130
-START&STOP SYSTEM
ACTIVATION/DEACTIVATION .............. 131
-START&STOP FAILURE .................... 131
- DISPLAY OF SELECTED DRIVING
MODE (“Alfa DNA” system) ................. 13
89
INDICATOR
687
2 9 09

DISPLAYThe car may be provided with a
multifunction or reconfigurable
multifunction display that shows useful
information to the driver, according
to the previous settings, when driving.
With the ignition key removed, the
display lights up and shows the time
and total odometer reading (in km
or miles) for a few seconds when a
door is opened/closed.
MULTIFUNCTION
DISPLAY "STANDARD"
SCREEN
The following information appears on
the display fig. 96:ADateBMilometer (distance covered in km or
miles)
CDriving mode selected via "Alfa DNA"
(dynamic car control system) (for
versions/markets, where provided): d
= Dynamic; n = Natural;a=All
WeatherDTime (always displayed, even with
key removed and doors closed)EStart&Stop function indicator (for
versions/markets where provided)FOutside temperatureGGear Shift Indicator (for versions/
markets, where provided)HHeadlamp alignment position (only
with dipped headlamps on)
RECONFIGURABLE
MULTIFUNCTION
DISPLAY “STANDARD”
SCREEN
The following information appears on
the display fig. 97:
ATimeBTrip mileage (in km or miles)CMilometer (distance covered in km or
miles)DCar status indications (e.g. doors
open, possible ice on road,
etc.)/Start&Stop function indication
(for versions/markets, where
provided)/Gear Shift Indicator (for
versions/markets, where provided)EHeadlamp alignment position (only
with dipped headlamps on)FOutside temperature
On some versions, selecting
“DYNAMIC” driving mode (see “Alfa
DNA system” paragraph in this section)
causes the display to show the turbine
pressure fig. 98.
96
A0K2010
97
A0K0600
98
A0K0539
90
KNOWING THE INSTRUMENT PANEL

GEAR SHIFT INDICATOR
The “GSI” (Gear Shift Indicator) system
advises the driver to change gear
through a special indication on the
display fig. 99.
Through the GSI, the driver is notified
that changing gear will allow a
reduction in fuel consumption.
Therefore, for driving oriented towards
reducing fuel consumption, it is
recommended to stick to "Natural" or
"All Weather" mode and to follow the
suggestions of the Gear Shift Indicator,
where the traffic conditions allow it.
When the SHIFT UP icon (
SHIFT) is
shown on the display, the GSI is
advising the driver to engage a higher
gear, when the SHIFT DOWN (
SHIFT) icon is displayed, it advises
the driver to engage a lower gear.NoteThe indication in the instrument
panel remains on until the driver shifts
gear or the driving conditions go back
to a situation where gearshifting is
not required to improve consumption.
WELCOME MOVEMENT
On some versions, when the key is
turned to MAR-ON, the following
occurs:
❒quick movement (up and down) of
the speedometer and rpm gauge;
❒lighting of graphic symbols/display;
❒displaying of an animated graphic
representation of the vehicle profile.
Gauge movement
❒If the key is removed from the ignition
switch whilst the gauges are moving,
they immediately go back to their
initial position.
❒Once they have reached the full scale
values, the gauges rest on the value
indicated by the vehicle.
❒The movement of the gauges stops
when the engine is started.Lighting of graphic
symbols/display
A few seconds after the key is inserted,
the gauges, graphic symbols and
display light up in sequence.
Display of graphic
animation
When the key is removed from the
ignition switch (with the doors closed),
the display remains lit up and shows
a graphic animation.
The display lighting is then dimmed
gradually until it goes out completely.
CONTROL BUTTONS
fig. 100: to scroll up through the
displayed screen and the related
options or to increase the displayed
value.
99
A0K0540
100
A0K0541
91

SET/
: press briefly to access the
menu and/or go to next screen or
confirm the selection. Hold down to go
back to the standard screen.
: to scroll down through the
displayed menu and the related options
or to decrease the value displayed.
IMPORTANT The
and
buttons activate different
functions according to the following
situations:
❒within the menu, they allow you to
scroll up and down through the
options;
❒during settings operations, they
increase or decrease values.
SETUP MENU
The menu comprises a series of
options which can be selected using
buttons "
" and "
" to access
the different selection and setting
operations (Setup) indicated below.
Some options have a submenu. The
menu can be activated by briefly
pressing the SET/
button.
The menu comprises the following
options:
❒MENU
❒LIGHTING❒SPEED BEEP
❒LIGHT SENSOR (for versions/
markets where provided)
❒RAIN SENSOR (for versions/markets,
where provided)
❒TRIP B ACTIVATION/DATA
❒SET TIME
❒SET DATE
❒FIRST PAGE (for versions/markets
where provided)
❒AUTOCLOSE
❒MEASUREMENT UNIT
❒LANGUAGE
❒BUZZER VOLUME
❒SEAT BELT BEEP/BUZZ
❒SERVICE
❒AIRBAG/PASSENGER BAG
❒DAYTIME RUNNING LIGHTS
❒ADAPTIVE LIGHTS (for versions/
markets, where provided)
❒COURTESY LIGHTS
❒MENU EXIT
NoteOn cars equipped with radio
navigator systems (for versions/
markets, where provided), some menu
items are shown on the navigator
display.Selecting an option from
the main menu without a
submenu:
❒press the SET/
button briefly to
select the main menu setting you
wish to change;
❒press buttons ""or"
" (by
single presses) to select the new
setting;
❒press the SET/
button briefly to
save the new setting and go back to
the previous main menu option.
Selecting an option from
the main menu with a
submenu:
❒briefly press the SET/
button to
display the first submenu option;
❒press buttons "
"or"
"
(with single presses) to scroll through
all the submenu options;
❒briefly press the SET/
button to
select the displayed submenu option
and to open the relevant settings
menu;
❒press buttons "
"or"
" (by
single presses) to select the new
setting for this submenu option;
❒press the SET/
button briefly to
save the new setting and go back to
the previous submenu option.
92
KNOWING THE INSTRUMENT PANEL

MENU ITEMSIMPORTANT WithUconnect™5"radio
system (for versions/markets where
provided), orUconnect™ 6.5" Radio
Nav system (for versions/markets, where
provided), some Menu items are displayed
and managed by the latter and not by
the instrument panel (refer to the
dedicated supplement).
Menu
This item allows you to access the
Setup Menu.
Press the "
"or"
" button to
select the various Menu items. Hold
down the SET/
button to return to
the standard screen.Lighting (Car interior
lighting adjustment)
(only with side lights on)
This function is used to set the
brightness of the instrument panel,
UConnect™ system controls (for
versions/markets where provided) and
automatic climate control system controls
(for versions/markets where provided)
to 8 levels.
Proceed as follows to adjust the light
intensity:
❒press button SET/
briefly. The
level set previously flashes on the
display;
❒press button "
"or"
"to
set the required brightness level;
❒briefly press the SET/
button to
go back to the menu screen or hold
the button down to go back to the
standard screen without saving.
NoteOn versions with reconfigurable
multifunction display, adjustment can
be made both with lights off ("Daytime"
mode brightness level) and with lights
on ("Nighttime" mode brightness level).Speed Beep
(Speed limit)
With this function it is possible to set
the car speed limit (km/h or mph); when
this limit is exceeded the driver is
alerted.
To set the desired speed limit, proceed
as follows:
❒briefly press the SET/
button: the
display will show the wording "Speed
Beep";
❒press button "
"or"
"to
select speed limit activation ("On")
or deactivation ("Off");
❒if the function is On, press ""or
"
" to select the required speed
limit and then press the
SET/button to confirm.
IMPORTANT Setting is possible
between 30 and 200 km/h, or 20 and
125 mph, according to the previously
set unit. See the "Unit of Measurement"
paragraph described below. The
setting will increase/decrease by five
units each time button
/
is
pressed. Hold down the
/
button to automatically
increase/decrease the setting rapidly.
Complete the setting by single pressing
the button when you approach the
required value.
93

Briefly press the SET/
button to go
back to the menu screen or hold the
button down to go back to the
standard screen without saving.
To cancel the setting, proceed as
follows:
❒briefly press the SET/
button,
"On" will flash in the display;
❒press button
, "Off" will flash on
the display;
❒briefly press the SET/
button to
go back to the menu screen or hold
the button down to go back to the
standard screen without saving.
Headlight sensor
(Automatic
headlight/dusk sensor
sensitivity adjustment)
(for versions/markets, where provided)
This function enables the headlights
to come on or go off depending on
external lighting conditions.
The dusk sensor sensitivity can be
adjusted according to 3 levels (level 1=
minimum sensitivity, level 2= average
sensitivity, level 3= maximum
sensitivity).The higher the sensitivity set, the lesser
is the external light variation needed
to switch the lights on (e.g. with a
setting on level 3 at sunset the
headlights come on in advance in
relation to levels 1 and 2).
Proceed as follows to set the desired
adjustment:
❒press the SET/
button briefly to
make the display flash the previously
set level;
❒press the "
"or"
" button
to select;
❒briefly press the SET/button to
go back to the menu screen or hold
the button down to go back to the
standard screen without saving.Rain sensor (Rain
sensor sensitivity
adjustment)
(for versions/markets, where provided)
This function allows you to adjust the
rain sensor sensitivity to 4 levels.
To set the required sensitivity level
proceed as follows:
❒briefly press the SET/
button, the
previously set sensitivity level will
flash on the display;
❒press the "
"or"
" button
to make the adjustment;
❒briefly press the SET/button to
go back to the menu screen or hold
the button down to go back to the
standard screen without saving.
94
KNOWING THE INSTRUMENT PANEL

Activation/Trip B data
(Trip B enablement)
This function may be used to activate
(On) or deactivate (Off) the Trip B (partial
trip). For further information see “Trip
computer”.
Proceed as follows to switch the
function on and off:
❒press the SET/
button briefly to
make the display flash "On" or "Off"
according to what was previously set;
❒press the "
"or"
" button
to select;
❒briefly press the SET/button to
go back to the menu screen or hold
the button down to go back to the
standard screen without saving.Time adjustment
(Clock adjustment)
This function enables to set the clock
through two submenus: "Time" and
"Format".
To carry out the adjustment, proceed as
follows:
❒briefly press the SET/
button and
two submenus ("Time" and "Format")
will be displayed;
❒press button "
"or"
"to
switch between the two submenus;
❒once you have selected a sub-menu
to be modified, press
SET/
briefly;
❒when the “Time” submenu is entered,
by briefly pressing SET/
the
hours flash on the display;
❒press the "
"or"
" button
to make the adjustment;
❒briefly press the SET/button,
which makes the display flash the
"minutes";
❒press the "
"or"
" button
to make the adjustment.IMPORTANT The setting will increase or
decrease by one unit each time the
"
"or"
" button is pressed.
Hold down the button to increase/
decrease the setting rapidly and
automatically. Complete the setting by
single pressing the button when you
approach the required value.
❒When you select "Format": briefly
pressing the SET/
button makes
the display mode flash on the display;
❒press button ""or"
"
to select “24h” or “12h”.
When you have made the required
settings, briefly press the
SET/
button to go back to the
submenu screen or hold the button
down to go back to the main menu
screen without saving the new settings.
Hold the SET/
button down again
to return to the standard screen or
to the main menu according to where
you are in the menu.
95

Set date (Setting the
date)
Using this function it is possible to
change the date (day – month – year).
Proceed as follows to start the update:
❒briefly press the SET/
button:
the "year" starts flashing on the
display;
❒press the "
"or"
" button
to make the adjustment;
❒briefly press the SET/button: the
"month" will flash on the display;
❒press the "
"or"
" button
to make the adjustment;
❒briefly press the SET/button: the
“day” will flash on the display;
❒press the "
"or"
" button
to make the adjustment.
IMPORTANT The setting will increase or
decrease by one unit each time the
"
"or"
" button is pressed.
Hold the button down to increase/
decrease the setting rapidly. Complete
the setting by single pressing the
button when you approach the required
value.
Briefly press the SET/
button to go
back to the menu screen or hold the
button down to go back to the
standard screen without saving.First page (Display of
information on the main
screen)
(for versions/markets, where provided)
This function allows you to choose
the information you would like to see on
the main screen. You can view the
date or the trip distance.
To make your choice, proceed as
follows:
❒briefly press the SET/
button:
"Initial page" will be displayed;
❒press the SET/
button again
briefly to display the "date" and
"engine info" options;
❒press "
"or"
" to select
the information you wish to see on
the main page of the display;
❒briefly press the SET/button to
go back to the menu screen or hold
the button down to go back to the
standard screen without saving.
When the key is turned to MAR-ON
and the initial check stage is over, the
display will show the information
selected via the "First page" menu
function.Autoclose (Automatic
door lock operation with
car running)
When activated (On), this function locks
the doors automatically when the
vehicle speed exceeds 20 km/h.
Proceed as follows to activate or
deactivate this function:
❒press the SET/
button briefly to
display a submenu;
❒press the SET/button briefly to
make the display flash "On" or "Off"
according to what was previously set;
❒press the "
"or"
" button
to select;
❒press the SET/
button briefly to
return to the submenu screen or
hold the button down to return to the
main menu screen without saving;
❒hold the SET/button down
again to return to the standard
screen or to the main menu
according to where you are in the
menu.
96
KNOWING THE INSTRUMENT PANEL
