Warning lights on
panelWhat it means What to do
amberGENERAL FAILURE
(for versions/markets, where provided)
The warning light switches on in the
circumstances indicated below.In these cases contact an Alfa Romeo Dealership
to have the fault fixed as soon as possible.
Dusk sensor failure
(for versions/markets, where provided)
This warning light comes on when a dusk sensor
fault is detected.
Engine oil pressure sensor failure
The warning light comes on when the engine oil
pressure sensor is faulty. The display shows the
dedicated message.
AFS adaptive lights failure
(for versions/markets, where provided)
The warning light switches on when a fault is
detected with the AFS adaptive lights (see “AFS
adaptive lights” paragraph in this section). The
display shows the dedicated message.
Anti-pinch system failure
The warning light comes on when a fault is
detected in the electric window anti-pinch
system. The display shows the dedicated
message.
117

Warning lights on
panelWhat it means What to do
amberExterior lights failure
The warning light switches on when a fault is
detected on one of the following lights:
❒daytime running lights (DRL)
❒side lights
❒direction indicators
❒rear fog lights
❒number plate lights
The fault relating to these lights may be caused
by: one or more blown fuses, one or more blown
bulbs or a broken electrical connection.Check, and if necessary replace the fuses
involved, in accordance with the "Fuse
replacement" paragraph, in chapter "In an
emergency". If this does not resolve the fault,
check, and if necessary replace, the bulbs
involved, in accordance with the "External bulb
replacement" paragraph, in chapter "In an
emergency".
Should this operation also fail to resolve the fault,
contact an Alfa Romeo Dealership, for a
comprehensive check of the electrical system.amberREAR FOG LIGHTS
This warning light comes on when the rear fog
lights are switched on.
118
KNOWING THE INSTRUMENT PANEL

Warning lights on
panelWhat it means What to do
amberABS FAILURE
When the key is turned to MAR-ON, the warning
light switches on but should switch off after a few
seconds.
The warning light (or symbol on the display)
switches on when the system is inefficient. In this
case the braking system will work as normal, but
without the extra performance offered by the
ABS.
The display shows the dedicated message.Drive carefully and contact an Alfa Romeo
Dealership as soon as possible.amberBRAKE PAD WEAR
(for versions/markets, where provided)
The warning light (or symbol on the display)
switches on when the front and rear brake pads
are worn.
The display shows the dedicated message.Have them replaced as soon as possible.amberPASSENGER SIDE AIRBAG DEACTIVATED
The
warning light (located in the trim above the
internal rear view mirror) switches on deactivating
the passenger side front airbag.
With front passenger airbag on, when the ignition
key is turned to MAR-ON, the
warning light
switches on constantly for several seconds and
then it should switch off.
If the warning light flashes, this indicates an
airbag warning light fault.
68)
119

Warning lights on
panelWhat it means What to do
amberINJECTION/EOBD SYSTEM FAILURE
In normal conditions, when the ignition key is turned to
MAR-ON the warning light switches on, but should
switch off as soon as the engine is started.
The operation of
warning light may be checked by
the traffic police using specific devices. Comply with the
laws and regulations of the country where you are
driving.
13)
If the warning light remains on or switches on whilst
driving, it means that the injection system is not working
properly. In particular, the warning light on constantly
signals a malfunction in the injection/ignition system
which could cause high exhaust emissions, a possible
loss of performance, poor driveability and high
consumption.
On some versions, the display shows the dedicated
message.
The warning light goes out after the fault disappears: the
indication is stored in the system.Under these conditions, you may continue
travelling at a moderate speed without
demanding excessive effort from the
engine. Prolonged use of the car with the
warning light on constantly may cause
damage.
Contact an Alfa Romeo Dealership as
soon as possible.
Petrol engines only
If the warning light flashes, it means that the catalytic
converter may be damaged.In this case, it is necessary to release the
accelerator pedal to lower the speed of
the engine until the warning light stops
flashing. Continue the journey at moderate
speed, trying to avoid driving conditions
that may cause further flashing and
contact an Alfa Romeo Dealership as
soon as possible.
120
KNOWING THE INSTRUMENT PANEL

Warning lights on
panelWhat it means What to do
amberGLOW PLUG HEATING/GLOW PLUG
HEATING FAILURE (diesel versions)
This warning light switches on when the key is
turned to MAR-ON. It will switch off as soon as
the heater plugs have reached a preset
temperature. The engine can be started as soon
as the warning light switches off.
IMPORTANT In mild or high temperature
conditions, the warning light comes on for a very
short time only.
Glow plug preheating failure
The warning light will flash (a message will appear
on the display, on some versions) to indicate a
fault in the glow plugs preheating system.Contact an Alfa Romeo Dealership as soon as
possible.amberWATER IN DIESEL FILTER (diesel versions)
The warning light remains on constantly when
driving (together with a message in the display),
to indicate the presence of water in the diesel
filter.
14)
121

WARNING
68) Failure of the
warning light is indicated by the
warning light switching on. In addition, the airbag system
automatically disables the passenger side airbag. Before proceeding, contact an Alfa Romeo Dealership to have the
system checked immediately.
IMPORTANT
13) If, turning the ignition key to MAR-ON, the
warning light does not turn on or if it turns on steadily or flashing
when travelling (on certain versions together with the message on the display), contact an Alfa Romeo Dealership
as soon as possible.
IMPORTANT
14) The presence of water in the fuel supply system circuit may cause severe damage to the injection system and
irregular engine operation. If the
warning light comes on in the instrument panel (together with a message in the
display) contact an Alfa Romeo Dealership as soon as possible to bleed the system. If the above indications come
on immediately after refuelling, water has probably been poured into the tank: turn the engine off immediately and
contact an Alfa Romeo Dealership.
122
KNOWING THE INSTRUMENT PANEL

Warning lights on
panelWhat it means What to do
amberDPF CLEANING (particulate trap) in progress
(diesel versions with DPF only)
When the key is turned to MAR-ON, the warning
light switches on but should switch off after a few
seconds.
The warning light switches on constantly to
indicate that the DPF system needs to eliminate
the trapped pollutants (particulate) through the
regeneration process.
The warning light does not come on during every
DPF regeneration, but only when driving
conditions require that the driver is notified. To
switch the warning light off, the car must be kept
moving until the regeneration process is
completed.
On average, the process lasts 15 minutes.
Optimal conditions for completing the process are
achieved by travelling at 60 km/h with engine
speed above 2000 rpm.
When this warning light switches on, it does not
indicate a car failure and thus it should not be
taken to a workshop.
On some versions, together with the warning light
switching on, the display shows a dedicated
message.
69)
123

WARNING
69) Always drive at a speed appropriate to the traffic conditions, the weather and traffic regulations. The engine can be
stopped even if the DPF warning light is on: however, repeated interruptions of the regeneration process could cause
premature deterioration of the engine oil. For this reason, always wait until the warning light switches off before
stopping the engine as described above. It is not advisable to complete DPF regeneration with the car stationary.
124
KNOWING THE INSTRUMENT PANEL

Warning lights on
panelWhat it means What to do
amberiTPMS SYSTEMIMPORTANT Do not continue driving with one or
more flat tyres as handling may be
compromised. Stop the car, avoiding sharp
braking and steering. Repair immediately using
the dedicated kit (see the "Repairing a wheel"
paragraph in the "In an emergency" chapter)
and contact an Alfa Romeo Dealership as soon
as possible.
iTPMS failure
The warning light switches on when a fault is
detected in the iTPMS.
Should one or more wheels be fitted without
sensors, the display will show a warning message
until initial conditions are restored.In this case, contact an Alfa Romeo Dealership
as soon as possible.
Low tyre pressure - See manual
The warning light switches on, together with a
dedicated message on the display, to indicate that
the tyre pressure is lower than the recommended
value and/or that slow pressure loss is occurring. In
these circumstances, optimal tyre duration and fuel
consumption may not be guaranteed.
Should two or more tyres be in the condition
mentioned above, the display will show the
indications corresponding to each tyre in
sequence.In any situation in which the message on the
display is "See manual", it is ESSENTIAL to refer
to the contents of the "Wheels" paragraph in the
"Technical data" chapter, strictly complying with
the indications that you find there.
125

Warning lights on
panelWhat it means What to do
amberELECTRONIC STABILITY CONTROL (ESC)
SYSTEM
When the ignition key is turned to MAR-ON, the
warning light switches on, but should switch off
as soon as the engine is started.
Intervention by the system is indicated by the
flashing of the warning light: it indicates that the
car is in critical stability and grip conditions.
If the warning light (or symbol on the display)
does not switch off, or if it stays on with the
engine running, this means that an ESC system
malfunction has been detected.
On some versions, the display shows the
dedicated message.Contact an Alfa Romeo Dealership as soon as
possible to have the problem diagnosed and
resolved.
ASR system failure
When the ignition key is turned to MAR-ON, the
warning light switches on, but should switch off
as soon as the engine is started.
The warning light will flash while driving to indicate
that the ASR system is intervening.
If the warning light (or symbol on the display)
does not switch off, or if it stays on with the
engine running, this means that an ASR system
malfunction has been detected.
On some versions, the display shows the
dedicated message.In this case, contact an Alfa Romeo Dealership as
soon as possible.
Hill Holder system failure
The warning light switches on together with the
symbol and corresponding message on the
display to indicate Hill Holder system failure.In this case, contact an Alfa Romeo Dealership as
soon as possible.
126
