AIR VENTS
❒Climate control system ....................... 22
LEFT STALK
❒External lights
INSTRUMENT PANEL
❒Control panel and on-board
instruments .........................................100
❒Warning lights .....................................105
RIGHT STALK
❒Window cleaning ................................ 39
UConnect Radio/UConnect Radio
Nav (for versions/markets, where
provided)PASSENGER SIDE AIRBAG
❒Operation ...........................................144
GLOVE COMPARTMENT
❒Opening .............................................. 47
HEATER/CLIMATE CONTROL
SYSTEM
❒Climate comfort .................................. 23
❒Manual climate control system ............ 24
❒Automatic dual-zone climate control
system................................................ 28
CONTROL BUTTONS
❒Door locking ....................................... 45
❒Fog lights ............................................ 45
❒Rear fog lights .................................... 45
❒iTPMS system (for versions/markets
whereprovided).................................. 77STEERING WHEEL❒Adjustment ......................................... 19
❒Driver side front airbag ........................144
1
2
67
1110
8
9
3
A0K0661
7
CRUISE CONTROL LEVER (for
versions/markets, where provided)❒Operation ........................................... 41 .................. .............. 35.....
Page 55 of 280
SUN VISORS
These are located at the sides of the
interior rear view mirror. They can be
adjusted forwards and sideways.
A courtesy mirror with light is fitted
behind the visors. The light allows to
use the mirror in poor visibility
conditions.
Lift cover A fig. 54 to access the mirror.
IMPORTANT On both sides of the
passenger side sun visor there is a label
remembering that it is compulsory to
deactivate the airbags if a rearward
facing child restraint system is fitted.
Always comply with the instructions on
the sun visor (see the "Front airbag"
paragraph in chapter "Safety").EXTINGUISHER
(for versions/markets, where provided)
This is located under the front
passenger seat fig. 55.
NOTE On some versions, the
extinguisher is located on the right side
of the luggage compartment inside a
suitable container.
WARNING
19) Do not travel with the storage
compartments open: they may
injure the front seat occupants in
the event of an accident.
20) The cigar lighter reaches high
temperatures Handle it carefully
and make sure that children do
not use it: risk of fire and/or
burns.
21) Do not use the ashtray as a
waste paper basket: it may catch
fire in contact with cigarette
stubs.
54
A0K0574
55
A0K0575
51
Page 93 of 280
KNOWING THE INSTRUMENT PANEL
This section of the booklet gives you all
the information you need to
understand, interpret and use the
instrument panel correctly.DISPLAY ......................................... 90
MENU ITEMS .................................. 93
CONTROL PANEL AND
INSTRUMENTS ...............................100
TRIP COMPUTER ...........................102
WARNING LIGHTS AND
MESSAGES ...................................10
- LOW BRAKE FLUID/HANDBRAKE
ENGAGED .......................................... 106
- EBD FAILURE .................................. 107
- AIRBAG FAILURE ............................. 107
- SEAT BELTS NOT FASTENED .......... 107
- ALTERNATOR FAILURE ................... 108
- LOW ENGINE OIL PRESSURE ......... 1
-ENGINE OIL DETERIORATED ........... 110
- ENGINE COOLANT TEMPERATURE
TOO HIGH .......................................... 112
- ALFA TCT FAILURE .......................... 113
-INCOMPLETE DOOR LOCKING ........ 113
-SPEED LIMIT EXCEEDED ................. 113
- DUAL PINION ACTIVE STEERING
FAILURE ............................................. 114
- ALFA ROMEO CODE SYSTEM
FAILURE/ALARM FAILURE ................. 114
- FUEL RESERVE/LIMITED RANGE .... 115
- GENERAL FAILURE ......................... 116
- GENERAL FAILURE ......................... 117
-REAR FOG LIGHTS ........................... 11
- ABS FAILURE ................................... 119
-BRAKE PAD WEAR ........................... 119
- PASSENGER SIDE AIRBAG
DEACTIVATED .................................... 119
- INJECTION/EOBD SYSTEM
FAILURE ............................................. 120
- GLOW PLUG HEATING/GLOW
PLUG HEATING FAILURE (diesel
versions) ............................................. 121-WATER IN DIESEL FILTER (diesel
versions) ............................................. 121
- DPF CLEANING (particulate trap) in
progress (diesel versions with DPF
only) ................................................... 123
- iTPMS SYSTEM ............................... 125
- ELECTRONIC STABILITY CONTROL
(ESC) SYSTEM ................................... 126
- CRUISE CONTROL .......................... 127
- SIDE LIGHTS ................................... 127
- FOLLOW ME HOME ........................ 12
- DIPPED BEAM HEADLIGHTS .......... 127
- FOG LIGHTS .................................... 128
- LEFT-HAND DIRECTION
......................................... 128
- RIGHT-HAND DIRECTION
INDICATOR ........................................ 128
- MAIN BEAM HEADLIGHTS .............. 128
- FUEL CUT-OFF ................................ 12
- POSSIBLE ICE ON ROAD ................ 129
- BRAKE LIGHT FAILURE ................... 129
- DUSK SENSOR FAILURE ................. 129
- RAIN SENSOR FAILURE .................. 130
- PARKING SENSOR FAILURE ........... 130
-START&STOP SYSTEM
ACTIVATION/DEACTIVATION .............. 131
-START&STOP FAILURE .................... 131
- DISPLAY OF SELECTED DRIVING
MODE (“Alfa DNA” system) ................. 13
89
INDICATOR
687
2 9 09
Page 96 of 280
SET/
: press briefly to access the
menu and/or go to next screen or
confirm the selection. Hold down to go
back to the standard screen.
: to scroll down through the
displayed menu and the related options
or to decrease the value displayed.
IMPORTANT The
and
buttons activate different
functions according to the following
situations:
❒within the menu, they allow you to
scroll up and down through the
options;
❒during settings operations, they
increase or decrease values.
SETUP MENU
The menu comprises a series of
options which can be selected using
buttons "
" and "
" to access
the different selection and setting
operations (Setup) indicated below.
Some options have a submenu. The
menu can be activated by briefly
pressing the SET/
button.
The menu comprises the following
options:
❒MENU
❒LIGHTING❒SPEED BEEP
❒LIGHT SENSOR (for versions/
markets where provided)
❒RAIN SENSOR (for versions/markets,
where provided)
❒TRIP B ACTIVATION/DATA
❒SET TIME
❒SET DATE
❒FIRST PAGE (for versions/markets
where provided)
❒AUTOCLOSE
❒MEASUREMENT UNIT
❒LANGUAGE
❒BUZZER VOLUME
❒SEAT BELT BEEP/BUZZ
❒SERVICE
❒AIRBAG/PASSENGER BAG
❒DAYTIME RUNNING LIGHTS
❒ADAPTIVE LIGHTS (for versions/
markets, where provided)
❒COURTESY LIGHTS
❒MENU EXIT
NoteOn cars equipped with radio
navigator systems (for versions/
markets, where provided), some menu
items are shown on the navigator
display.Selecting an option from
the main menu without a
submenu:
❒press the SET/
button briefly to
select the main menu setting you
wish to change;
❒press buttons ""or"
" (by
single presses) to select the new
setting;
❒press the SET/
button briefly to
save the new setting and go back to
the previous main menu option.
Selecting an option from
the main menu with a
submenu:
❒briefly press the SET/
button to
display the first submenu option;
❒press buttons "
"or"
"
(with single presses) to scroll through
all the submenu options;
❒briefly press the SET/
button to
select the displayed submenu option
and to open the relevant settings
menu;
❒press buttons "
"or"
" (by
single presses) to select the new
setting for this submenu option;
❒press the SET/
button briefly to
save the new setting and go back to
the previous submenu option.
92
KNOWING THE INSTRUMENT PANEL
Page 102 of 280
Belt reminder
(Reactivation of SBR
buzzer)
(for versions/markets, where provided)
This function can be displayed only
after an Alfa Romeo Dealership has
deactivated the SBR system (see
paragraph “SBR system” in the “Safety”
chapter).
To reactivate this function, proceed as
follows:
❒briefly press the SET/
button, the
display shows "OFF" flashing. Press
the "
"or"
" button and
"On" will be displayed;
❒briefly press the SET/
button to
go back to the previous screen or
hold the button down to go back to
the standard screen without saving.
Service (Scheduled
servicing)
With this function it is possible to view
information on servicing deadlines
depending on kilometres travelled or
daily intervals.
To consult this information, proceed as
follows:❒briefly press the SET/
button: the
display shows when servicing is due
in km or mi according to the previous
setting (see paragraph "Units of
measurement");
❒briefly press the SET/button to
go back to the menu screen or hold
the button down to go back to the
standard screen.
IMPORTANT The “Scheduled Servicing
Plan” includes car maintenance at
fixed intervals, refer to the
"Maintenance and care" chapter. This
message is displayed automatically
when the key is turned to MAR-ON,
starting at 2,000 km (or equivalent
value in miles) from when the
next service is due and reappearing
every 200 km (or equivalent value
in miles). Below 200 km servicing
indications are more frequent. The
display will be in km or mi depending
on the measurement unit settings.
When the next scheduled service is
approaching and the key is turned to
MAR-ON, the word "Service" will
appear on the display, followed by the
number of kilometres or miles left.
Go to an Alfa Romeo Dealership, where
the “Scheduled Servicing Plan”
operations will be performed and the
message will be reset.Passenger airbag/side
bag (front passenger
side airbag and side
bag for pelvis, chest
and shoulder protection
- Side bag -
activation/deactivation)
This function is used to activate/
deactivate the passenger side air bag.
Proceed as follows:
❒press the SET/
button and, after
the message (Bag pass: Off) (to
deactivate) or (Bag pass: On) (to
activate) is displayed by pressing
buttons "
" and "
", press
the SET/
button again;
❒a confirmation request message will
appear on the display;
❒by pressing the "
"or"
"
buttons select "Yes" (to confirm
activation/deactivation) or "No" (to
cancel);
❒press the SET/
button briefly, a
message confirming the selection
will be displayed and you will return
to the menu screen or, pressing
the button for longer, you will return
to the standard screen without
memorising.
98
KNOWING THE INSTRUMENT PANEL
Page 111 of 280
Warning lights on
panelWhat it means What to do
redamberEBD FAILURE
The simultaneous switching on of the
(red)
and
(amber) warning lights with the engine
on, indicates either a fault of the EBD system or
that the system is not available. In this case, the
rear wheels may suddenly lock and the vehicle
may swerve when braking sharply.
The display shows the dedicated message.Drive very carefully to the nearest Alfa Romeo
Dealership to have the system inspected
immediately.
redAIRBAG FAILURE
When the key is turned to MAR-ON, the warning
light switches on but should switch off after a few
seconds.
If the warning light switches on constantly, this
indicates a fault in the airbag system.
The display shows the dedicated message.
63) 64)
redSEAT BELTS NOT FASTENED
(for versions/markets, where provided)
The warning light switches on constantly with the
car stationary and the driver’s seat belt not
fastened.
The warning light flashes and a buzzer sounds if
the car is in motion and the front seat belts are
not correctly fastened.For permanent deactivation of the SBR (Seat Belt
Reminder) system buzzer, contact an Alfa Romeo
Dealership. The system can be reactivated using
the Setup Menu.
107
Page 112 of 280
Warning lights on
panelWhat it means What to do
redALTERNATOR FAILURE
The warning light switches on when the ignition
key is turned to MAR-ON, but it should switch off
as soon as the engine has started (with the
engine idling a brief delay before switching off is
acceptable).If the warning light (or symbol on the display)
stays on constantly or flashing, contact an Alfa
Romeo Dealership as soon as possible.
WARNING
63) If the
warning light does not switch on when the key is turned to MAR-ON or if it stays on when driving (together
with the message on the display), there may be a fault in the restraint systems; in this case, the airbags or
pretensioners may not deploy in the event of an accident or, in a lower number of cases, they could deploy
erroneously. Before proceeding, contact an Alfa Romeo Dealership to have the system checked immediately.
64) Failure of the
warning light is signalled by the flashing for longer than the usual 4 seconds of the
warning light
(located in the trim above the internal rear view mirror). In addition, the airbag system automatically disables the
passenger side airbag. In this case, the
warning light may not indicate a fault in the restraint systems. Before
proceeding, contact an Alfa Romeo Dealership to have the system checked immediately.
108
KNOWING THE INSTRUMENT PANEL
Page 123 of 280
Warning lights on
panelWhat it means What to do
amberABS FAILURE
When the key is turned to MAR-ON, the warning
light switches on but should switch off after a few
seconds.
The warning light (or symbol on the display)
switches on when the system is inefficient. In this
case the braking system will work as normal, but
without the extra performance offered by the
ABS.
The display shows the dedicated message.Drive carefully and contact an Alfa Romeo
Dealership as soon as possible.amberBRAKE PAD WEAR
(for versions/markets, where provided)
The warning light (or symbol on the display)
switches on when the front and rear brake pads
are worn.
The display shows the dedicated message.Have them replaced as soon as possible.amberPASSENGER SIDE AIRBAG DEACTIVATED
The
warning light (located in the trim above the
internal rear view mirror) switches on deactivating
the passenger side front airbag.
With front passenger airbag on, when the ignition
key is turned to MAR-ON, the
warning light
switches on constantly for several seconds and
then it should switch off.
If the warning light flashes, this indicates an
airbag warning light fault.
68)
119
Page 126 of 280
WARNING
68) Failure of the
warning light is indicated by the
warning light switching on. In addition, the airbag system
automatically disables the passenger side airbag. Before proceeding, contact an Alfa Romeo Dealership to have the
system checked immediately.
IMPORTANT
13) If, turning the ignition key to MAR-ON, the
warning light does not turn on or if it turns on steadily or flashing
when travelling (on certain versions together with the message on the display), contact an Alfa Romeo Dealership
as soon as possible.
IMPORTANT
14) The presence of water in the fuel supply system circuit may cause severe damage to the injection system and
irregular engine operation. If the
warning light comes on in the instrument panel (together with a message in the
display) contact an Alfa Romeo Dealership as soon as possible to bleed the system. If the above indications come
on immediately after refuelling, water has probably been poured into the tank: turn the engine off immediately and
contact an Alfa Romeo Dealership.
122
KNOWING THE INSTRUMENT PANEL
Page 137 of 280
SAFETY
The chapter that you are about to read
is very important: it describes the
safety systems with which the car is
equipped and provides instructions on
how to use them correctly.SEAT BELTS ..................................133
SBR SYSTEM (SEAT BELT
REMINDER) ....................................134
PRETENSIONERS...........................136
CARRYING CHILDREN SAFELY ......139
FITTING “UNIVERSAL” CHILD
SEAT (WITH SEAT BELTS)...............140
PREPARATION FOR “ISOFIX”
CHILD SEAT ...................................143
FRONT AIRBAGS............................146
SIDE AIRBAGS (SIDE BAGS -
WINDOW BAGS) .............................1
133
50
