Page 9 of 280
GRAPHICAL INDEX
.
HEADLIGHTS
❒Bulb types ..........................................180
❒External lights ..................................... 35
❒Bulb replacement ................................177
WHEELS
❒Rims and tyres ....................................234
❒Tyre pressure ......................................236❒Wheel repair .......................................169
DOOR MIRRORS
❒Adjustment ......................................... 20
❒Folding ............................................... 21
DOORS
❒Central opening/closing ...................... 54
BONNET
❒Opening/closing .................................. 62
WINDSCREEN WIPERS
❒Blade replacement ..............................214
1
A0K0620
5
Page 18 of 280
ALARM(for versions/markets, where provided)
ALARM ACTIVATION
The alarm activates in the following
cases:
❒wrongful opening of a door/bonnet/
luggage compartment (perimeter
protection);
❒wrongful operation of the ignition
switch (ignition key turned to
MAR-ON);
❒cutting of the battery cables;
❒movement inside the passenger
compartment (volumetric protection);
❒anomalous lifting/tilting of the car (for
versions/markets, where provided).
Operation of the alarm is indicated by
an acoustic and visual signal (flashing of
the direction indicators for several
seconds). The alarm activation modes
may vary according to the market.
There is a maximum number of
acoustic/visual cycles. When this is
reached the system returns to normal
operation.IMPORTANT The engine locking
function is guaranteed by the Alfa
Romeo CODE, which is automatically
activated when the ignition key is
extracted from the ignition switch.
IMPORTANT The alarm is adapted to
meet requirements in various countries.
SWITCHING ON THE
ALARM
With the doors, bonnet and tailgate
closed and the ignition key either
turned to STOP or removed, point the
key with remote control towards the car
and press and release the
button.
Except for specific markets, the system
emits a visual and acoustic signal and
enables door locking.
A self-diagnosis stage precedes the
switching on of the alarm: in the event
of faults, the system will generate a
further acoustic and/or visual signal
through the LED on the dashboard.
If after the alarm is switched on, a
second acoustic signal is emitted
and/or a visual signal via the LED on
the dashboard, wait about 4 seconds
and switch off the alarm by pressing the
button, check that the doors,
bonnet and luggage compartment are
closed correctly and then reactivate the
system by pressing the
button.If the alarm emits an acoustic signal
even when the doors, bonnet and
luggage compartment are correctly
closed, a fault has occurred in system
operation: in this case, contact an
Alfa Romeo Dealership.
ALARM SELF-ACTIVATION
(for versions/markets, where provided)
If the alarm has not been activated
using the remote control, once about
30 seconds have elapsed from when
the ignition key was turned to STOP
and a door or the tailgate was last
opened and then closed, the alarm
activates automatically.
This is indicated by the LED on the
button A fig. 10 lighting up intermittently
and the indications of activation
described previously.
To deactivate the alarm, press the
button on the remote control.
The alarm also activates when the
doors are closed by turning the metal
insert of the key in the driver side door
latch. If the system self-activates, the
doors are not locked.
14
GETTING TO KNOW YOUR CAR
Page 66 of 280
BAG HOOKS
There are also bag hooks inside the
luggage compartment.
LUGGAGE RETAINING
NET
(for versions/markets, where provided)
This is useful for correctly arranging
the load and/or for transporting light
materials. The luggage retaining net is
available from Lineaccessori Alfa
Romeo.
WARNING
24) A heavy load that has not been
secured may cause serious
injuries to passengers in the event
of an accident.
25) If you are travelling in an area
with limited opportunities for
refuelling and you wish to bring
petrol with you in a petrol can, you
must do so in compliance with
current regulations and using an
approved can, appropriately
secured to the load securing
attachments. However, the risks
of fire in case of collision increase
anyway.
BONNETOPENING
Proceed as follows:
❒pull lever A fig. 71 in the direction
indicated by the arrow;
❒operate lever B, in the direction
indicated by the arrow, and raise the
bonnet.
IMPORTANT Two side gas shock
absorbers are provided to assist in
opening the bonnet. Do not tamper
with the shock absorber and
accompany the bonnet while lifting it.
IMPORTANT Before raising the bonnet,
make sure that the arms of the wipers
are not raised from the windscreen and
that the wiper is not operational.CLOSING
Lower the bonnet to approximately 20
centimetres from the engine
compartment then let it drop. Make
sure that the bonnet is completely
closed and not only fastened by the
locking device by trying to open it. If it is
not perfectly closed, do not try to
press the bonnet down but open it and
repeat the procedure.
26) 27)
IMPORTANT Always check that the
bonnet is closed correctly to prevent it
from opening while the car is travelling.
The following plate is applied inside
the engine compartment fig. 72:
71
A0K0607
72
A0K2012
62
GETTING TO KNOW YOUR CAR
Page 67 of 280
WARNING
26) For safety reasons, the bonnet
must always be properly closed
while driving. Therefore, make
sure that the bonnet is properly
closed and that the lock is
engaged. If you discover that the
bonnet is not perfectly closed
during travel, stop immediately
and close the bonnet in the
correct manner.
27) Perform these operations only
when the car is stationary.
ROOF RACK/SKI
RACKThe attachments A are located in the
areas illustrated in the figure and can
only be accessed with the doors open.
28) 29)8) 9)
Lineaccessori Alfa Romeo includes a
dedicated roof rack/ski rack for this car.
WARNING
28) After travelling for a few
kilometres, check to ensure that
the fixing screws for the
attachments are well tightened.
29) Evenly distribute the load and
take into account, when driving,
the increased responsiveness
of the car to side wind.
IMPORTANT
8) Never exceed the maximum
permitted loads (see “Technical
specifications” section).
9) The size of the loads you
transport must strictly comply
with currently applicable
regulations.
73
A0K0590
63
Page 80 of 280
JUMP STARTING
When jump starting, never connect the
negative lead (–) of the auxiliary battery
to the negative pole A fig. 84 of the
car battery, but rather to an
engine/gearbox earth point.
49)
IMPORTANT
10) If you wish to run the air
conditioning system, you may
deactivate the Start&Stop system
to allow continuous operation of
the air conditioning system.
WARNING
48) When replacing the battery,
always contact an Alfa Romeo
Dealership. The replacement
battery should be of the same
type (HEAVY DUTY) and should
have the same characteristics.49) Before opening the bonnet,
make sure that the engine is off
and that the ignition key is in
the STOP position. Follow the
instructions on the dedicated
label on the front crossmember
(fig. 85). We recommend that you
remove the key from the ignition if
other people remain in the car.
The car should always be left after
the key has been removed or
turned to the STOP position.
During refuelling, make sure that
the engine is off (and that the
ignition key is in the STOP
position).
84
A0K0594
85
A0K0614
76
GETTING TO KNOW YOUR CAR
Page 117 of 280
Warning lights on
panelWhat it means What to do
redALFA TCT FAILURE
(for versions/markets, where provided)
When the key is turned to MAR-ON, the warning
light switches on but should switch off after a few
seconds.
The warning light flashes (together with a
message in the display and an acoustic signal) to
indicate that the transmission is faulty.
The warning light can switch on even in case of
transmission overheating, after a particularly
demanding use. In this case an engine
performance limitation is carried out.Contact an Alfa Romeo Dealership as soon as
possible.
If it is necessary to start the engine with a
transmission failure, follow the procedure
described in the "Alfa TCT" paragraph, in chapter
"Starting and driving".redINCOMPLETE DOOR LOCKING
(for versions/markets, where provided)
The warning light (or symbol on the display) lights
up when one or more doors or the tailgate are not
closed correctly. An acoustic signal is activated
with the doors open and the car moving.
On some versions the warning light (or symbol on
the display) also lights up when the bonnet is not
closed correctly.redSPEED LIMIT EXCEEDED
(for versions/markets, where provided)
The warning light switches on when the car
exceeds the speed limit value set in the Setup
Menu (e.g. 120 km/h).
On some versions a message is shown along
with a symbol on the display, and an acoustic
signal is emitted.
113
Page 274 of 280
INDEX
ABS .............................................. 65
Additional heater ............................ 35
AFS adaptive lights (Adaptive
Frontlight System) ........................ 38
Air cleaner ...................................... 213
Alarm ............................................. 14“Alfa DNA” system ........................ 69
– Driving modes ........................... 70
– Engagement/disengagement
of "All Weather" mode ............... 72
– Engagement/disengagement
of "Dynamic" mode ................... 71
– "Natural" Mode.......................... 70Alfa Romeo Code system ............. 10
ALFA TCT ...................................... 157
Ashtray .......................................... 50
ASR system (Anti-Slip
Regulation) ................................... 66
Automatic dual zone climate
control ......................................... 28Battery .......................................... 214
– advice for extending lifetime ...... 214
– replacement .............................. 214
Battery (recharging) ........................ 196
Bodywork
– maintenance ............................. 218
– protection against
atmospheric agents................... 218
– warranty .................................... 218Bonnet ........................................... 62
– Closing ...................................... 62
– Opening .................................... 62
Brakes ........................................... 233
– brake fluid level.......................... 212
bulb replacement ........................... 184
Bulb replacement
– exterior lights ............................. 183
– interior lights .............................. 186
Bulbs
– types of bulbs ........................... 181
Carrying children safely ................. 139
CBC (Cornering Brake Control)
system ......................................... 66
Central locking ............................... 46
Changing a bulb............................. 179
– General instructions................... 179
Changing a wheel .......................... 171
Checking levels .............................. 208
Cigar lighter.................................... 50
Cleaning and maintenance
– bodywork .................................. 218
– car interior ................................. 220
– front headlights ......................... 219
– leather parts .............................. 221
– leather seats.............................. 220
– plastic and coated parts ............ 221
– seats and fabric parts ................ 220
Climate control ............................... 22– Central air diffusers.................... 22
– Rear air diffuser ......................... 22
– Side air diffusers ........................ 22
– Upper air diffusers ..................... 22
Climatic comfort ............................. 23
– Diffusers .................................... 23
Clutch ............................................ 232
CO2 emissions............................... 252
CODE Card .................................... 11
Control buttons .............................. 91
Control panel and instruments ....... 100
– Multifunction display .................. 100
– Reconfigurable multifunction
display....................................... 101
Controls ......................................... 45
Courtesy light
– bulb replacement ...................... 187
Cruise Control ................................ 41
Daytime running lights (DRL) ......... 36
Diesel filter ..................................... 213
Dimensions .................................... 240
Dipped beam headlights
– bulb replacement ...................... 183
Direction indicators ................... 37-184
– bulb replacement ...................... 184
– “Lane change” function ............. 37
Display ........................................... 90
Doors ............................................. 54
– Child safety device .................... 55
