VERY IMPORTANTREFUELLING
Petrol engines: only refuel with unleaded petrol with octane rating (RON) not less than 95 in compliance with the European specification EN228.Diesel
engines: refuel only with diesel fuel conforming to the European specification EN590. The use of other products or mixtures may damage the engine beyond
repair and consequently invalidate the warranty, due to the damage caused.
STARTING THE ENGINE
Petrol engines: make sure that the handbrake is engaged; set the gear lever to neutral; fully depress the clutch pedal without pressing the accelerator, then
turn the ignition key to AVV and release it as soon as the engine has started.Diesel engines: turn the ignition key to MAR-ON and wait for the
and
warning lights to switch off. Then turn the ignition key to AVV and release it as soon as the engine has started.
PARKING ON FLAMMABLE MATERIAL
The catalytic converter develops high temperatures during operation. Do not park the car on grass, dry leaves, pine needles or other flammable material: fire
hazard.
RESPECTING THE ENVIRONMENT
The car is fitted with a system that carries out a continuous diagnosis of the emission-related components in order to help protect the environment.
ELECTRICAL ACCESSORIES
If, after buying the car, you decide to add electrical accessories (with the risk of gradually draining the battery), contact an Alfa Romeo Dealership. They will
calculate the overall electrical requirement and check that the car’s electrical system can support the required load.
CODE card(for versions/markets, where provided)
Keep it in a safe place, not in the car. We recommend that you always carry the electronic code provided on the CODE card with you, in case you need to
perform an emergency start.
SCHEDULED SERVICING
Correct maintenance of the car is essential for ensuring that it maintains its performance and its safety features, its environmental friendliness and low running
costs for a long time to come.
THE OWNER MANUAL CONTAINS…
… important information, advice and warnings for correct use, driving safety and maintenance of your car over time. Particular attention should be paid to
information marked with the following symbols: (personal safety) (environmental protection) (car integrity).
Page 13 of 280
GETTING TO KNOW YOUR CAR
In-depth knowledge of your new car
starts here.
The booklet that you are reading simply
and directly explains how it is made
and how it works.
That’s why we advise you to read it
seated comfortably on board, so that
you can see what is described here for
yourself.SYMBOLS ...................................... 10
ALFA ROMEO CODE SYSTEM ....... 10
THE KEYS....................................... 11
ALARM ........................................... 14
IGNITION DEVICE ........................... 15
SEATS ............................................ 17
HEAD RESTRAINTS ........................ 18
STEERING WHEEL ......................... 19
REAR VIEW MIRRORS .................... 20
CLIMATE CONTROL ....................... 22
CLIMATIC COMFORT ..................... 23
MANUAL CLIMATE CONTROL........ 24
AUTOMATIC DUAL ZONE
CLIMATE CONTROL ....................... 28
EXTERNAL LIGHTS......................... 35
WINDOW CLEANING ...................... 39
CRUISE CONTROL ......................... 41
ROOF LIGHTS ................................ 42
CONTROLS .................................... 45
INTERIOR FITTINGS ....................... 47
ELECTRIC SUN ROOF .................... 52
DOORS ........................................... 54
ELECTRIC WINDOWS .................... 56
LUGGAGE COMPARTMENT ........... 59
BONNET ......................................... 62
ROOF RACK/SKI RACK .................. 63
HEADLIGHTS.................................. 64ESC SYSTEM ................................. 65
“ALFA DNA” SYSTEM (CAR
DYNAMIC CONTROL SYSTEM) ...... 69
START&STOP SYSTEM .................. 73
ITPMS (INDIRECT TYRE
PRESSURE MONITORING
SYSTEM) ........................................ 77
EOBD SYSTEM (EUROPEAN ON
BOARD DIAGNOSIS) ...................... 79
DUAL PINION ACTIVE STEERING... 79
WIRING FOR RADIO SYSTEM ........ 80
ACCESSORIES PURCHASED BY
THE OWNER .................................. 81
PARKING SENSORS....................... 82
REFUELLING THE CAR .................. 85
PROTECTING THE
ENVIRONMENT .............................. 87
9
Page 66 of 280
BAG HOOKS
There are also bag hooks inside the
luggage compartment.
LUGGAGE RETAINING
NET
(for versions/markets, where provided)
This is useful for correctly arranging
the load and/or for transporting light
materials. The luggage retaining net is
available from Lineaccessori Alfa
Romeo.
WARNING
24) A heavy load that has not been
secured may cause serious
injuries to passengers in the event
of an accident.
25) If you are travelling in an area
with limited opportunities for
refuelling and you wish to bring
petrol with you in a petrol can, you
must do so in compliance with
current regulations and using an
approved can, appropriately
secured to the load securing
attachments. However, the risks
of fire in case of collision increase
anyway.
BONNETOPENING
Proceed as follows:
❒pull lever A fig. 71 in the direction
indicated by the arrow;
❒operate lever B, in the direction
indicated by the arrow, and raise the
bonnet.
IMPORTANT Two side gas shock
absorbers are provided to assist in
opening the bonnet. Do not tamper
with the shock absorber and
accompany the bonnet while lifting it.
IMPORTANT Before raising the bonnet,
make sure that the arms of the wipers
are not raised from the windscreen and
that the wiper is not operational.CLOSING
Lower the bonnet to approximately 20
centimetres from the engine
compartment then let it drop. Make
sure that the bonnet is completely
closed and not only fastened by the
locking device by trying to open it. If it is
not perfectly closed, do not try to
press the bonnet down but open it and
repeat the procedure.
26) 27)
IMPORTANT Always check that the
bonnet is closed correctly to prevent it
from opening while the car is travelling.
The following plate is applied inside
the engine compartment fig. 72:
71
A0K0607
72
A0K2012
62
GETTING TO KNOW YOUR CAR
Page 80 of 280
JUMP STARTING
When jump starting, never connect the
negative lead (–) of the auxiliary battery
to the negative pole A fig. 84 of the
car battery, but rather to an
engine/gearbox earth point.
49)
IMPORTANT
10) If you wish to run the air
conditioning system, you may
deactivate the Start&Stop system
to allow continuous operation of
the air conditioning system.
WARNING
48) When replacing the battery,
always contact an Alfa Romeo
Dealership. The replacement
battery should be of the same
type (HEAVY DUTY) and should
have the same characteristics.49) Before opening the bonnet,
make sure that the engine is off
and that the ignition key is in
the STOP position. Follow the
instructions on the dedicated
label on the front crossmember
(fig. 85). We recommend that you
remove the key from the ignition if
other people remain in the car.
The car should always be left after
the key has been removed or
turned to the STOP position.
During refuelling, make sure that
the engine is off (and that the
ignition key is in the STOP
position).
84
A0K0594
85
A0K0614
76
GETTING TO KNOW YOUR CAR
Page 89 of 280
60) Parking and other dangerous
manoeuvres are, however, always
the driver’s responsibility. While
carrying out these manoeuvres,
always make sure that no people
(especially children) or animals are
in the area concerned. The
parking sensors are an aid for the
driver, but the driver must never
allow their attention to lapse
during potentially dangerous
manoeuvres, even those executed
at low speeds.
REFUELLING THE
CARStop the engine before refuelling.
PETROL ENGINES
Only use unleaded petrol 95 R.O.N.
compliant with the European
specification EN228. The petrol octane
rating (R.O.N.) must not be lower than
95. In order to prevent damage to
the catalytic converter never introduce
even the smallest amount of leaded
petrol, even in the event of an
emergency.
DIESEL ENGINES
Use only diesel fuel compliant with
European specification EN590. The use
of other products or mixtures may
damage the engine beyond repair and
consequently invalidate the warranty,
due to the damage caused.Operation at low
temperatures
If the outside temperature is very low,
the diesel thickens due to the formation
of paraffin clots with consequent
defective operation of the fuel supply
system.
In order to avoid these problems,
different types of diesel are distributed
according to the season: summer type,
winter type and arctic type (cold,
mountain areas).
If refuelling with diesel whose
specifications are not suitable for the
usage temperature, it is advisable
to mix TUTELA DIESEL ART additive in
the proportions shown on the container
with the fuel. Pour the additive into
the tank before the fuel.
When using or parking the car for a
long time in the mountains or cold
areas, it is advisable to refuel using
locally available fuel. In this case, it is
also advisable to keep the tank over
50% full.
85
Page 90 of 280
FILLING THE TANK
To fill the tank completely, top-up twice
after the first click of the fuel supply
gun. Further top-ups could cause faults
in the fuel feeding system.
FUEL TANK CAP
The fuel flap is unlocked when the
central locking system is released and
automatically locked when the central
locking system is applied.
Opening
Press flap A fig. 94 to release it and
access fuel tank cap B. Then press cap
B and turn it anticlockwise.
61)
The cap is provided with a loss
prevention device C which attaches it
to the flap and prevents it from being
lost. Attach the cap to device D during
refuelling.Emergency flap opening
In case of emergency, pull the cord A
fig. 95 on the right-hand side of the
boot to open the fuel flap.
Pulling the cord will unlock the flap: it
will then be necessary to press on
the flap to open it.
Closure
Release cap B from device D and insert
it in its housing. Then tighten the cap
clockwise until one or more clicks
are heard. Finally, close flap A checking
that it is correctly locked.
The sealing may cause a slight pressure
increase in the tank. A little breathing
off, while slackening the cap is
absolutely normal.
WARNING
61) Keep naked flames or lit
cigarettes away from the fuel tank
filler: fire risk. Avoid bringing
your face close to the filler, in
order not to breathe in harmful
vapours.
94
A0K0598
95
A0K0599
86
GETTING TO KNOW YOUR CAR
Page 126 of 280
WARNING
68) Failure of the
warning light is indicated by the
warning light switching on. In addition, the airbag system
automatically disables the passenger side airbag. Before proceeding, contact an Alfa Romeo Dealership to have the
system checked immediately.
IMPORTANT
13) If, turning the ignition key to MAR-ON, the
warning light does not turn on or if it turns on steadily or flashing
when travelling (on certain versions together with the message on the display), contact an Alfa Romeo Dealership
as soon as possible.
IMPORTANT
14) The presence of water in the fuel supply system circuit may cause severe damage to the injection system and
irregular engine operation. If the
warning light comes on in the instrument panel (together with a message in the
display) contact an Alfa Romeo Dealership as soon as possible to bleed the system. If the above indications come
on immediately after refuelling, water has probably been poured into the tank: turn the engine off immediately and
contact an Alfa Romeo Dealership.
122
KNOWING THE INSTRUMENT PANEL
Page 227 of 280
TECHNICAL SPECIFICATIONS
Everything you may find useful for
understanding how your car is made
and works is contained in this chapter
and illustrated with data, tables and
graphics. For the enthusiasts and the
technician, but also just for those who
want to know every detail of their
car.IDENTIFICATION DATA....................224
ENGINE CODES - BODYWORK
VERSIONS ......................................22
ENGINE ..........................................227
FUEL SUPPLY .................................231
TRANSMISSION .............................232
BRAKES .........................................233
SUSPENSION .................................23
STEERING SYSTEM .......................235
WHEELS .........................................236
DIMENSIONS ..................................240
PERFORMANCE .............................241
WEIGHTS .......................................242
REFUELLING ..................................244
FLUIDS AND LUBRICANTS ............247
FUEL CONSUMPTION ....................25
CO2 EMISSIONS ............................252
PRESCRIPTIONS FOR HANDLING
THE VEHICLE AT THE END OF ITS
LIFE ................................................253
223
5
4
1
Page 248 of 280
REFUELLING
1.4 Turbo Petrol 1.4 Turbo MultiAir
Recommended fuels
and original lubricants
litres kg litres kg
Fuel tank 60 – 60 –Unleaded petrol not less
than 95 RON (EN 228
specification) including a reserve of 8 - 10 – 8 - 10 –
Engine cooling system (with
climate control)5,7 5,0 5,7 5,050-50 mixture of
demineralised water and
PARAFLU
UP
(*)
Engine sump 2,75 2,3 3,1 2,6SELENIA K P.E. (1.4 Turbo
Petrol versions)
SELENIA DIGITECH P.E.
(1.4 Turbo MultiAir
versions) Engine sump and filter 3,1 2,6 3,5 2,9
Gearbox casing/differential 1,87 1,6 1,87 1,6TUTELA TRANSMISSION
GEARFORCE
Hydraulic brake circuit with
ABS antilock brakes0,83 0,78 0,83 0,78 TUTELA TOP 4
Windscreen/rear window/
headlight washer fluid
reservoir (**)2,8 (4,6) 2,5 (4,1) 2,8 (4,6) 2,5 (4,1)Mixture of water and
TUTELA PROFESSIONAL
SC 35
(*) For particularly harsh climate conditions, a mixture of 60%
UPand 40% demineralised water is recommended.
(**) Values in brackets refer to versions with headlight washers
244
TECHNICAL SPECIFICATIONS
Page 276 of 280
– rear light clusters (changing a
bulb).......................................... 184
Luggage compartment courtesy
light
– bulb replacement ...................... 186
Luggage compartment................... 59
– Bag hooks................................. 62
– Closing the luggage
compartment ............................ 60
– Emergency luggage
compartment opening ............... 59
– Extending the luggage
compartment ............................ 60
– Luggage compartment
initialisation ................................ 60
– Luggage retaining net ................ 62
– Opening the luggage
compartment ............................ 59
– Securing your load .................... 61M
ain beam headlights .................. 37
– bulb replacement ...................... 183
Maintenance and care
– heavy-duty use of the car .......... 207
– periodic checks ......................... 207
– scheduled servicing ................... 200
– scheduled servicing plan ........... 201
Manual climate control ................... 24
Menu options ................................. 93
Money holder ................................. 50
MSR system .................................. 67
Multifunction display....................... 90
Number plate lights
– bulb replacement ...................... 185Parking ......................................... 155
– Handbrake ................................ 156
Parking lights ................................. 36
Parking sensors ............................. 82
Performance .................................. 241
Pollen filter ..................................... 213
Power sockets ............................... 49
Pre-Fill system (RAB - Ready
Alert Brake) .................................. 68
Preparation for "Isofix" child seat .... 143
Pretensioners ................................. 137
– Load limiters.............................. 137
Protecting the environment ............ 87Radio transmitters and mobile
phones ........................................ 81
Rain sensor .................................... 39
Raising the car ............................... 197
Rear armrest .................................. 48
Rear fog lights ................................ 45
Rear fog lights/reversing lights........ 184
Rear roof light
– bulb replacement ...................... 186
Rear view mirrors ........................... 20
– Door mirrors .............................. 21
– Internal mirror ............................ 20
Rear window washer jets ............... 217
Rear window washer– rear window washer fluid level ... 212
Rear window washer/wiper ............ 40
Rear window wiper
– blade replacement..................... 217
Reconfigurable multifunction
display ......................................... 90
Refuelling ....................................... 244
Refuelling the car ........................ 85-86
Rev counter ................................... 102
Rim Protector (tyres)....................... 237
Roof lights...................................... 42
– Courtesy lights .......................... 44
– Front roof light ........................... 42
– Glove compartment light ........... 44
– Luggage compartment roof
light ........................................... 44
– Rear roof light............................ 43
Roof rack/ski rack .......................... 63
Saving fuel .................................... 164
SBR system (Seat Belt
Reminder) .................................... 135
Scheduled Servicing Plan ............... 201
Seat belts....................................... 134
– Use ........................................... 134
Seats ............................................. 16
– Front seats ................................ 16
Setup menu ................................... 92
Side airbags (Side Bags -
Window Bags).............................. 150
Side bags (front side airbags) ......... 150
