Ariel Atom Owner ________________________________________

Contact Information ______________________________ ________

Date of Purchase ________________________________ ________

Vehicle PIN _____________________________________ ________

Immobilizer Serial No. ___________________________ _________

5

DASH LAYOUT



The LCD panel includes readings for the total mileage , the trip odometer, the water temperature and the fuel
gauge. The fuel gauge will flash when the tank is app roaching empty. The panel settings are pre-programmed.
If you wish to modify the default settings, please con tact Brammo Motorsports for programming instructions.

NOTE: If your vehicle is equipped with non-canceling tur n signals, they must be cancelled manually.
1. Tachometer
2. Immobilizer
3. Charge System Warning
4. Parking Brake Indicator
5. Left Turn Signal
6. High Beam Indicator Light
7. Right Turn Signal
8. Lighting Indicator
9. Oil Pressure W arning
10. Speedometer
11. Turn Signal Switch
12. Horn
13. Engine Start Button
14. Ignition Power Switch
15. Emergency Flashers Button
16. Fog/Rain/Light
17. Marker/Lighting Selector/High
Beams
18. LCD Panel
19. Dash Programming Button

9

START SEQUENCE




The
Remote Keyless Immobilizer
When the immobilzer
indicator light is flashing
moderately, the anti-theft
system is armed. The
flashing light will blink rapidly
when the ignition is on (the
system will still be armed).
To unarm the system, wave
the key fob in range of the
transponder antennae (#2 in
diagram). The light will go
off, and the car is then able
to start.
After you kill the ignition
switch the light will stay on
solid for 20 seconds.
If the starter switch is not
pushed within 20 seconds,
the system will re-arm, and
the sequence will need to be
repeated.
