Page 3 of 64
3
Contents
Principles
Vehicle suspension.................................................................. 4
The suspension system .......................................................... 6
Vibration ................................................................................... 8
Characteristic values of springs .......................................... 12
Conventional running gear without self-levelling ............ 14
The self-study programme is not intended as a workshop manual.
The self-study programme will provide you with
information on design and functions.
New
NoteImportant:
Note
Page
For maintenance and repairs please refer to the current
technical literature.
Principles of air suspension
Self-levelling air suspension ............................................... 16
Characteristic values of air spring ...................................... 21
Vibration damping................................................................. 23
Shock absorbers (vibration dampers) ................................ 25
PDC shock absorbers ........................................................... 33
System overview ................................................................... 38
Air springs .............................................................................. 40
Air supply unit ........................................................................ 42
Diagram of pneumatic system ............................................. 43
Compressor ........................................................................... 44
Air dryer ................................................................................. 47
Discharge valve N111 ........................................................... 48
Valve for suspension struts N150 and N151....................... 51
Self-levelling suspension sender G84 ................................ 52
Self-levelling suspension control unit J197 ....................... 54
Self-levelling suspension warning lamps K134 ................ 55
Function diagram ................................................................... 56
Interfaces................................................................................ 57
The control concept .............................................................. 58
Other features of the control concept ................................ 60
Self-levelling suspension, A6
Page 55 of 64
55
Self-levelling suspension
warning lamp K134
The warning lamp É
... is constantly illuminated in the case of
corresponding system errors or when the
system is switched off.
... ...ßashes in the case of extremely low or
high levels. <Ð55 mm/>+30 mm.
... ... ßashes during Þnal control diagnosis.
... ßashes when the control system is
switched off (only possible with diagnostic
tester).
After switching off the ignition, K134
illuminates for a function check and
extinguishes after the control system has
performed internal control unit test sequence
(unless an error is present).
Warning lamp K134
242_050
The vehicle should not be driven as
long as the warning lamp is ßashing, as
low vehicle parts may be damaged due
to inadequate ground clearance.
If the warning lamp remains on
continuously to indicate a system error,
the system is switched off.
The driver is requested to contact the
nearest Audi service centre.
Page 56 of 64
56
Self-levelling suspension, A6
M
+ -+ -+ -
31
1234
Functional diagram
C11 Condenser
G84 Self-levelling suspension sender
J197 Self-levelling suspension control unit
J403 Relay for self-levelling suspension
compressor
K134 Self-levelling suspension warning
lamp
N11 Discharge valve
N150 Rear left strut valve
N151 Rear right strut valve
S Fuse
V66 Compressor motor
T. 30T. 15T. 30
242_001 S SJ403
V66
N111 N150 N151 K134
J197
G84
= Input signal
= Output signal
= Positive
= Earth
= bi-directional
1 Diagnostic interface
2 Driving speed signal
3 Door contact signal
4 Terminal 50 signal
C11
Page 61 of 64
61
Overheating protection
In order to protect the compressor from
overheating, it switches off at excess
temperatures.
A temperature module is integrated into the
control unit. This monitors the temperature
and is used to calculate the compressor
temperature.
The calculations are based on the running
and cooling times of the compressor.
The max. running time is limited to 120 sec.
(an fault entry is made in the control unit
whenever the maximum running time is
exceeded).
15 seconds running time are allowed
following every 6 minutes of cooling time.
After 48 minutes of cooling time the
maximum running time of 120 seconds is
available.
242_011
Battery protection
In order to protect the battery, the maximum
running time of the compressor is limited to
60 seconds after the ignition has been
switched ÒOFFÓ. The system switches off and
only reactivates after the ignition has been
switched ÒONÓ again.
Switching self-levelling on/off.
The system can be switched off using the
diagnostic tester, e.g. during repair work.
When the ignition is switched ÒONÓ, the
systemÕs off status is indicated by a ßashing
warning lamp (T34).
At a driving speed of >20 km/h the system is
activated automatically.
198_039242_085
