0100.0 INDEX











ABS HYDRAULIC UNIT, Y1 3450.1-01. . . . . . . . . . . . . . . . . . . . . . . . .
ABS PUMP MOTOR RELAY, TIMED, K125 3450.1-00. . . . . . . . . . . .
AIR BAG GAS GENERATOR, DRIVER’S, G5 3234.0-00. . . . . . . . . .
AIR BAG GAS GENERATOR, LEFT SIDE, G14 3234.0-01. . . . . . . .
AIR BAG GAS GENERATOR, PASSENGER’S, G6 3234.0-00. . . . .
AIR BAG GAS GENERATOR, RIGHT SIDE, G15 3234.0-01. . . . . .
AIR CONDITIONING COMPRESSOR, Y2 6450.6-02. . . . . . . . . . . . .
AIR PUMP, Y6133 1210.20-08. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ANTENNA AMPLIFIER AM/FM, N8 6424.0-01. . . . . . . . . . . . . . . . . . .
ANTI–THEFT CONTROL MODULE (ALPINE), N12w 6575.2. . . . . .
ANTI–THEFT HORN (ALPINE), H1w 6575.2-01. . . . . . . . . . . . . . . . .
ANTI–THEFT SYSTEM (ALPINE) 6575.2. . . . . . . . . . . . . . . . . . . . . . .
ASC SWITCH, S6 3450.1-02. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AUTOMATIC TRANSMISSION RANGE SWITCH, S3 2460.2-01. . .
AUXILIARY FAN MOTOR, M9 6450.6-03. . . . . . . . . . . . . . . . . . . . . . .
AUXILIARY FUSE BOX, P95 0670.2-02. . . . . . . . . . . . . . . . . . . . . . . .
AUXILIARY FUSE BOX, P97 0670.2-01. . . . . . . . . . . . . . . . . . . . . . . .
AUXILIARY THROTTLE POSITION MOTOR (ADS), M93 3450.1-02
AUXILIARY TURN LIGHT, LEFT FRONT, H9 6313.0-02. . . . . . . . . .
AUXILIARY TURN LIGHT, RIGHT FRONT, H8 6313.0-02. . . . . . . . .
BACK UP LIGHT, LEFT, H27 6322.0-00. . . . . . . . . . . . . . . . . . . . . . . .
BACK UP LIGHT, RIGHT, H28 6322.0-00. . . . . . . . . . . . . . . . . . . . . . .
BACK UP LIGHTS 6322.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BATTERY, G1 0670.2-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BLOWER MOTOR, M30 6410.7-01. . . . . . . . . . . . . . . . . . . . . . . . . . . .
BLOWER MOTOR, M30 6450.6-00. . . . . . . . . . . . . . . . . . . . . . . . . . . .
BLOWER RELAY, K4 6410.7-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BLOWER RELAY, K4 6450.6-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BLOWER RESISTORS, R11 6410.7-01. . . . . . . . . . . . . . . . . . . . . . . .
BLOWER RESISTORS, R11 6450.6-00. . . . . . . . . . . . . . . . . . . . . . . .
BLOWER SWITCH, S75 6410.7-01. . . . . . . . . . . . . . . . . . . . . . . . . . . .
BLOWER SWITCH, S75 6450.6-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . BOARD COMPUTER (BC – LOW) 6581.3. . . . . . . . . . . . . . . . . . . . . .
BOARD COMPUTER (BC – LOW), A35y 6581.3-00. . . . . . . . . . . . . .
BODY ELECTRONICS CONTROL MODULE (ZKE IV),
A104 6100.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BRAKE FLUID LEVEL SWITCH, B18 6211.0-00. . . . . . . . . . . . . . . . .
BRAKE LIGHT SWITCH, S29 6325.0-00. . . . . . . . . . . . . . . . . . . . . . . .
BRAKE LIGHT SWITCH, S30 2460.2-04. . . . . . . . . . . . . . . . . . . . . . . .
BRAKE LIGHT SWITCH, S30 6325.0-00. . . . . . . . . . . . . . . . . . . . . . . .
BRAKE LIGHT, LEFT, H24 6325.0-00. . . . . . . . . . . . . . . . . . . . . . . . . .
BRAKE LIGHT, RIGHT, H31 6325.0-00. . . . . . . . . . . . . . . . . . . . . . . . .
BRAKE LIGHTS 6325.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BRAKE PAD SENSOR, LEFT FRONT, B16 6211.0-01. . . . . . . . . . . .
BRAKE PAD SENSOR, RIGHT REAR, B17 6211.0-01. . . . . . . . . . .
CARBON CANISTER VALVE, Y199 1210.20-08. . . . . . . . . . . . . . . . .
CD CHANGER, N22 6510.0-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CD CHANGER, N22 6510.1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CELLULAR TELEPHONE (PROVISIONS) 6561.0. . . . . . . . . . . . . . .
CENTER INTERIOR LIGHT, REAR, E32z 6330.3-00. . . . . . . . . . . . .
CENTRAL BODY ELECTRONICS (ZKE IV) 6100.0. . . . . . . . . . . . . .
CENTRAL LOCKING SWITCH, S302 5126.0-00. . . . . . . . . . . . . . . . .
CHARGING SYSTEM 1230.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CHIME MODULE, H10 6211.0-05. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CIGAR LIGHTER LIGHT, FRONT, E29 6332.0-00. . . . . . . . . . . . . . . .
CIGAR LIGHTER, FRONT, E28 6332.0-00. . . . . . . . . . . . . . . . . . . . . .
CLIMATE CONTROL SWITCH ILLUMINATION, E103 6424.0-00. .
CLIMATE CONTROL SWITCH ILLUMINATION, E103 6450.6-00. .
CLOCK 6213.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CLUTCH SWITCH, S32 6571.0-01. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
COMBINATION SWITCH, S7 6312.0. . . . . . . . . . . . . . . . . . . . . . . . . . .
COMBINATION SWITCH, S7 6313.0-00. . . . . . . . . . . . . . . . . . . . . . . .
COMBINATION SWITCH, S7 6581.3-00. . . . . . . . . . . . . . . . . . . . . . . .
COMPONENT LOCATION CHART 7000.0. . . . . . . . . . . . . . . . . . . . . .




INDEX










LICENSE PLATE LIGHT, RIGHT, E44 6320.0-00. . . . . . . . . . . . . . . .
LICENSE PLATE/LUGGAGE COMPARTMENT LIGHTS 6320.0. . .
LIGHT SWITCH DETAILS 6300.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LIGHT SWITCH ILLUMINATION, E97 6300.0-00. . . . . . . . . . . . . . . .
LIGHT SWITCH, S8 6300.0-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LOW BEAM LIGHT RELAY, K48 6312.0. . . . . . . . . . . . . . . . . . . . . . . .
LOW BEAM LIGHT, LEFT, E13 6312.0. . . . . . . . . . . . . . . . . . . . . . . . .
LOW BEAM LIGHT, RIGHT, E14 6312.0. . . . . . . . . . . . . . . . . . . . . . . .
LOW RANGE SPEAKER, LEFT FRONT, H58 6510.0-00. . . . . . . . . .
LOW RANGE SPEAKER, LEFT FRONT, H58 6510.1-01. . . . . . . . . .
LOW RANGE SPEAKER, LEFT REAR, H57 6510.1-01. . . . . . . . . . .
LOW RANGE SPEAKER, RIGHT FRONT, H51 6510.0-00. . . . . . . .
LOW RANGE SPEAKER, RIGHT FRONT, H51 6510.1-02. . . . . . . .
LOW RANGE SPEAKER, RIGHT REAR, H52 6510.1-02. . . . . . . . .
LUGGAGE COMPARTMENT LIGHT ASSEMBLY, LEFT,
E46 0670.4-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LUGGAGE COMPARTMENT LIGHT ASSEMBLY, RIGHT,
E47 0670.4-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LUGGAGE COMPARTMENT LIGHT SWITCH, S61y 6320.0-01. . .
LUGGAGE COMPARTMENT LIGHT, RIGHT, H91 6320.0-01. . . . . .
LUGGAGE COMPARTMENT LOCK MOTOR, M17 5126.0-03. . . . .
MAKE–UP MIRROR LIGHT, DRIVER’S, E35 6330.3-00. . . . . . . . . .
MAKE–UP MIRROR LIGHT, PASSENGER’S, E36 6330.3-00. . . . .
MAKE–UP MIRROR SWITCH, DRIVER’S, S77 6330.3-00. . . . . . . .
MAKE–UP MIRROR SWITCH, PASSENGER’S, S78 6330.3-00. . .
MID–HIGH RANGE SPEAKER, LEFT, H42 6510.1-03. . . . . . . . . . . .
MID–HIGH RANGE SPEAKER, RIGHT, H43 6510.1-03. . . . . . . . . .
MIDRANGE SPEAKER, LEFT FRONT, H55 6510.1-03. . . . . . . . . . .
MIDRANGE SPEAKER, RIGHT FRONT, H54 6510.1-03. . . . . . . . . .
MIRROR CONTROL SWITCH, S17 5116.0-00. . . . . . . . . . . . . . . . . .
MIRROR, DRIVER’S SIDE, Y5 5116.0-01. . . . . . . . . . . . . . . . . . . . . . .
MIRROR, PASSENGER’S SIDE, Y6 5116.0-01. . . . . . . . . . . . . . . . . . NORMAL SPEED RELAY, K21 6450.6-03. . . . . . . . . . . . . . . . . . . . . . .
OBD II CONNECTOR, D110 0670.5-09. . . . . . . . . . . . . . . . . . . . . . . . .
OIL PRESSURE SWITCH, B6231 6211.0-02. . . . . . . . . . . . . . . . . . . .
ON–BOARD COMPUTER TEMPERATURE SENSOR,
B21 6581.3-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OXYGEN SENSOR
(BEHIND CATALYTIC CONVERTER), B62002 1210.20-03. . . . . .
OXYGEN SENSOR
(IN FRONT OF CATALYTIC CONVERTER), B62001 1210.20-03.
PARK BRAKE SWITCH, S31 6211.0-00. . . . . . . . . . . . . . . . . . . . . . . .
PARK LIGHT, LEFT, E15 6314.0-00. . . . . . . . . . . . . . . . . . . . . . . . . . . .
PARK LIGHT, RIGHT, E19 6314.0-00. . . . . . . . . . . . . . . . . . . . . . . . . . .
PARK/TAIL/UNDERHOOD LIGHTS 6314.0. . . . . . . . . . . . . . . . . . . . .
POWER DISTRIBUTION 0670.2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
POWER DISTRIBUTION BOX, FRONT, P90 0670.2. . . . . . . . . . . . .
POWER DISTRIBUTION CHART 0670.0. . . . . . . . . . . . . . . . . . . . . . .
POWER MIRRORS 5116.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
POWER SEATS 5200.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
POWER TILT/SLIDE SUNROOF (SHD) 5410.1. . . . . . . . . . . . . . . . . .
POWER WINDOW SWITCH, DRIVER’S, S126y 5133.0-01. . . . . . .
POWER WINDOW SWITCH, PASSENGER’S, S127y 5133.0-01. . .
PRESSURE SWITCH, B8y 1210.20-07. . . . . . . . . . . . . . . . . . . . . . . . .
PRESSURE SWITCH, B8y 6450.6-03. . . . . . . . . . . . . . . . . . . . . . . . . .
PRESSURE SWITCH, B9508 6450.6-03. . . . . . . . . . . . . . . . . . . . . . . .
PROGRAM SWITCH, S8503 2460.2-00. . . . . . . . . . . . . . . . . . . . . . . .
PYROTECHNICAL BELT TENSIONER,
PASSENGER’S SIDE, G13 3234.0-02. . . . . . . . . . . . . . . . . . . . . . . .
PYROTECHNICAL BELT TENSIONER, DRIVER’S SIDE,
G12 3234.0-02. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RADIO, N9 6510.0-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RADIO, N9 6510.1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RADIO/HIFI 6510.1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

GROUND DISTRIBUTION
X7091 X710
1
.75 BR .75 BR
X6381
GROUND X13006







X7131B17
RIGHT REAR
BRAKE PAD
SENSOR
2.5 BRM2
FUEL PUMP
X3521S14
DRIVER’S DOOR
JAMB SWITCH
.5 BRX733
1E57
DRIVER’S SEAT
HEATER
.5 BRX732
1
4 BR E56
DRIVER’S SEAT-
BACK HEATERE44
RIGHT LICENSE
PLATE LIGHT
E43
LEFT LICENSE
PLATE LIGHT
X13007
.5 BR





0670.4-17
1 BR
X4002
1.5 BR 1.5 BR .5 BR
X18441N8
ANTENNA
AMPLIFIER AM/FM
2.5 BR
X13006


X7112S61y
LUGGAGE
COMPARTMENT
LIGHT SWITCH
.75 BR
X12923S302
CENTRAL LOCKING
SWITCH
.35 BR
.5 BRX1892
1N22
CD CHANGER
X3801E9
REAR DEFOGGER I
2.5 BR
X102711E32z
REAR CENTER
INTERIOR LIGHT
.5 BR LUGGAGE
COMPARTMENT
TELEPHONE
CONNECTOR
X4131H34
HIGH LEVEL STOP
LIGHT
.5 BR
X6036S51
DRIVER’S SEAT,
SEAT CONTROL
SWITCH
2.5 BR
2.5 BRX840
X2751
2.5 BR







Pin Assignments


E = Input, A = Output, M = Ground
X8500
Pin Type Description/Function Connection
89
Not used
90AShift-lock solenoid controlShift-lock
91Not used
92ASolenoid valve band control (–)Transmission valve unit
93AHydraulic pressure regulator control (–)Transmission valve unit
94MGroundGround point
95Not used
96EGear range signal L2Automatic transmission range switch
97EGear range signal L4Automatic transmission range switch
98EBrake pedal positionBrake light switch
99Not used
100ESport mode signalNot used
101EManual mode signalProgram switch
102EOutput speed (–)Transmission valve unit
103MGround for shieldShield for speed sensor
104Not used
105ES-program indicationNot used
106EKick-down signalKick-down switch
107Not used
108EAutomatic mode signalProgram switch
109EOil temperature signal (–)Transmission valve unit
11 0EOil temperature signal (+)Transmission valve unit
111Not used
11 2Not used
11 3AFault indicator signalInstrument cluster
11 4EBattery voltageB+ junction point
11 5EM-program indicationProgram switch
11 6MGroundGround point
11 7Not used
11 8ASolenoid valve 1 control (–)Transmission valve unit




F215A
3450.1-01
3450.1-00
Y1
ABS HYDRAULIC
UNITP90
FRONT POWER
DISTRIBUTION BOX
K125
ABS PUMP MOTOR
RELAY, TIMED
A52
SLIP CONTROL
MODULE
(ABS/ASC)
17 X1170
41 X11395
TXD 36


F1030AF275A
A2w
INSTRUMENT
CLUSTER
42528311
S30
BRAKE LIGHT
SWITCH F38
30AF4615A
3
3450.1-00
3450.1-00
32 11
B2
LEFT FRONT
SPEED SENSOR –
ABS 3450.1-0313 34
B4
LEFT REAR SPEED
SENSOR – ABS 3450.1-0312 33
B1
RIGHT FRONT
SPEED SENSOR –
ABS 3450.1-0314 35
B3
RIGHT REAR
SPEED SENSOR –
ABS 3450.1-033776
A6000
ENGINE CONTROL
MODULE (DME) 3450.1-02A8500
TRANSMISSION
CONTROL MODULE
(EGS) 3450.1-02
2232425262227294
F215A
S6
ASC SWITCH 3450.1-02
39
LIGHT SWITCH
DETAILS
6300.0
404
58g
X1170
15
2
S29
BRAKE LIGHT
SWITCH
X11395
M93
AUXILIARY
THROTTLE
POSITION MOTOR
(ADS)R6255z
THROTTLE
POSITION SENSOR
(ASC)
1930831
X1170X11395X1170
X1170X11395
3450.1-02
3450.1-00X1170
9
3450.1 SLIP CONTROL (ABS/ASC)







Pin Assignments


E = Input, A = Output, M = Ground
X1170
Pin Type Description/Function Connection
1
ALeft front outlet valveABS hydraulic unit
2ALeft front inlet valveABS hydraulic unit
3MGroundGround point
4EVoltage supplyFuse 21
5Not used
6E/ACAN-LOWDME/EGS module
7E/ACAN-HIGHDME/EGS module
8AAccelerator pedal position, voltageAccelerator pedal position sensor (ASC)
9MAccelerator pedal position, groundAccelerator pedal position sensor (ASC)
10Not used
11ESpeed signalLeft front speed sensor ABS
12ESpeed signalRight front speed sensor ABS
13ESpeed signalLeft rear speed sensor ABS
14ESpeed signalRight rear speed sensor ABS
15ESignal pump motorABS pump motor relay, timed
16Not used
17EBrake pedal positionBrake light switch
18Not used
19MGroundGround point
20Not used
21Not used
22ARight rear outlet valveABS hydraulic unit
23ARight front inlet valveABS hydraulic unit
24ARight front outlet valveABS hydraulic unit
25ALeft rear outlet valveABS hydraulic unit
26ALeft rear inlet valveABS hydraulic unit
27ARight rear inlet valveABS hydraulic unit
28AActivate relayABS pump motor relay, timed
29ASeperator valveABS hydraulic unit
30EAccelerator pedal position, signalAccelerator pedal position sensor (ASC)







X11395
X11393
SLIP CONTROL (ABS/ASC)







K125
ABS PUMP MOTOR
RELAY, TIMED


32X10018
1 X78
.5 GR/SW/GEX181
1.5 BL/RT
216X1001814X1001720X10015
212 X78
692
48 X11393
23 X16
17
BRAKE LIGHTS
6325.0
440
.75 BL/RT
A52
SLIP CONTROL
MODULE
(ABS/ASC) S30
BRAKE LIGHT
SWITCH
1) BRAKE PEDAL
RELEASED
2) BRAKE PEDAL
DEPRESSED
.5 BR/SW 2.5 RT/GN/GE
A2w
INSTRUMENT
CLUSTERP90
FRONT POWER
DISTRIBUTION BOX
FUSE DETAILS
0670.3FUSE DETAILS
0670.3
GROUND
DISTRIBUTION
0670.4
F4615AF215AF3830A F275AF1030A
.5 BL/BR12 X17
FUSE DETAILS
0670.3 FUSE DETAILS
0670.3
42
FUSE DETAILS
0670.3
3450.1-01
.35 RT/BL
21

X116
X116
S29
BRAKE LIGHT
SWITCH
1) NORMAL
STATE
2) BRAKE PEDAL
DEPRESSED
30X1170
32 X6255
8
11X603112 .5 WS/RT .5 BL/GN
.5 GR/SW .5 GR/BL
R6255z
THROTTLE
POSITION SENSOR
(ASC)
.5 GR/WS
X11704
1 X6255
WITH EGS
 !



6211.0-04
A
F4615A
16K16
HAZARD FLASHER
RELAY S7
COMBINATION
SWITCH
F275A
P90
FRONT POWER
DISTRIBUTION BOX
A2w
INSTRUMENT
CLUSTER F31
5A
A6000
ENGINE CONTROL
MODULE (DME)
18
B6232
ENGINE COOLANT
TEMPERATURE
SENSOR1
B10
VEHICLE SPEED
SENSOR 6211.0-04G6509
GENERATOR
5B
D+ C
S2
IGNITION SWITCH 6211.0-00
F235AF1515A NSW
232248B
6312.0
16312.036313.04A
6313.0
1B
6313.0
2A
LIGHT SWITCH
DETAILS
6300.0 /
12
A64
WIPER/WASHER
MODULE (LOW II) 6211.0-03A8
CRUISE CONTROL
MODULE
(TEMPOMAT) 6211.0-03N9
RADIO 6211.0-03A35y
BOARD
COMPUTER
(BC – LOW) 6211.0-03
2
A51
WIPER/WASHER
MODULE 6211.0-03
2017
B6
FUEL LEVEL
SENSOR 6211.0-04B25y
FUEL TANK
SENSOR II
34A617
S31
PARK BRAKE
SWITCH14
A12
SUPPLEMENTAL
RESTRAINT
SYSTEM CONTROL
MODULE 6211.0-00
6211.0-0018
B18
BRAKE FLUID
LEVEL SWITCH 6211.0-0019
B6231
OIL PRESSURE
SWITCH5
A8500
TRANSMISSION
CONTROL MODULE
(EGS) 6211.0-0119
B17
RIGHT REAR
BRAKE PAD
SENSOR B16
LEFT FRONT
BRAKE PAD
SENSOR
A52
SLIP CONTROL
MODULE
(ABS/ASC)
243
1230.0A
B
6211.0-01 6211.0-01
6211.0-00A
B
A= X16B= X17C= X271
BAB
6211.0-02
6211.0-02 6211.0-05
9
B
2316
6300.0
S14
DRIVER’S DOOR
JAMB SWITCH6211.0-04
D100
DATA LINK
CONNECTOR
13
S2
IGNITION SWITCH 6211.0-05
22 B
H10
CHIME MODULE 6211.0-05
S58
DRIVER’S SEAT
BELT SWITCH 6211.0-00 14
1221
6211.0-02
15
6211.0 INSTRUMENT CLUSTER





Pin Assignments




E = Input, A = Output, M = Ground
X16
Pin Type Description/Function Connection
1
EHigh beam indicator controlCombination switch
2ETerminal 58g, instrument illumination powerDimmer
3ERight turn signal indicator controlHazard flasher relay
4ELeft turn signal indicator controlHazard flasher relay
5EWarning lamp for EGS fault (information
signal transmission oil temperature)Transmission control module (EGS)
6Not used
7Not used
8Not used
9Not used
10Not used
11Not used
12E/ATxD diagnostic data linkData link connector
13Not used
14EAirbag warning lamp (SRS) controlSupplemental restraint system control
module
15Not used
16E“Check engine” indicator controlEngine control module (DME)
17EPark brake warning lamp controlPark brake switch
18EBrake fluid warning lamp controlBrake fluid level switch
19EBrake pad wear warning lamp controlBrake pad sensors
20ECrankshaft RPM speed signal TDEngine control module (DME)
21Not used
22EVoltage supply, terminal 30Front power distribution box, fuse 31
23EVoltage supply, terminal 15 for indicator and
warning lampsFront power distribution box, fuse 27
24MGround supply, terminal 31 for instrument
cluster electronicsGround point
25Not used
26Not used

INSTRUMENT CLUSTER
INDICATORS
GROUND
DISTRIBUTION
0670.4






3
GROUND
DISTRIBUTION
0670.4A2w
INSTRUMENT
CLUSTER
HEADLIGHTS/FOG
LIGHTS
6312.0TURN/HAZARD
LIGHTS
6313.0LIGHT SWITCH
DETAILS
6300.0
X178.35 WS1
.5 BL/GN
4
.5 BL/BR
X163
.5 WS/RT
X171
.5 GR/RT
X162
519 X16
.5 GR/BR
A8500
TRANSMISSION
CONTROL MODULE
(EGS)2 X713
X1322 .5 GE
X850025
2X118
1X118
1 X713
X13006
.5 GE
B16
LEFT FRONT
BRAKE PAD
SENSOR
.5 GE
B17
RIGHT REAR
BRAKE PAD
SENSOR
.5 GR/BR31
!
X173
14 X10017
23
F275AP90
FRONT POWER
DISTRIBUTION BOX
FUSE DETAILS
0670.3
X69


X17
25
10 X10016
F1515AP90
FRONT POWER
DISTRIBUTION BOX
NSW
FUSE DETAILS
0670.3
